Digital Projection E-Vision 7500 Series User manual

Rev D July 2014
USER MANUAL
INSTALLATION AND QUICK-START GUIDE
CONNECTION GUIDE
OPERATING GUIDE
REMOTE COMMUNICATIONS GUIDE
114-738D
E-Vision 7500 Series
High Brightness Digital Video Projector

Digital Projection E-Vision 7500 Series
i
Rev D July 2014
About This Document
Please follow the instructions in this manual carefully to ensure safe and long-lasting use of the projector.
Keep this manual handy for future reference.
Symbols used in this manual
Many pages in this document have a dedicated area for notes. The information in that area is accompanied by the following symbols:
ELECTRICAL WARNING: this symbol indicates that there is a danger of electrical shock unless the instructions are closely
followed.
WARNING: this symbol indicates that there is a danger of physical injury to yourself and/or damage to the equipment unless
the instructions are closely followed.
NOTE: this symbol indicates that there is some important information that you should read.
Product revision
Because we at Digital Projection continually strive to improve our products, we may change specications and designs, and add new features
without prior notice.
Legal notice
Trademarks and trade names mentioned in this document remain the property of their respective owners.
Digital Projection disclaims any proprietary interest in trademarks and trade names other than its own.
Copyright © 2014 Digital Projection Ltd. All rights reserved.
Notes

Digital Projection E-Vision 7500 Series
ii
Rev D July 2014
Introduction
Congratulations on your purchase of this Digital Projection product.
Your projector has the following key features:
• Swappable color wheels for high brightness and color critical applications.
• HDMI 1.4 for Side by Side, Frame Packing & Top Bottom 3D formats.
• HDBaseT® enables transmission of uncompressed High Denition Video over standard CAT5e/6 LAN cable.
• Motorized and programmable shift, zoom and focus. Intelligent Lens Memory with 10 user-denable preset positions.
• Control via LAN and RS232.
A serial number is located on the back of the projector. Please record it here:
Notes

Digital Projection E-Vision 7500 Series
iii
Rev D July 2014
CONTENTS
INSTALLATION AND QUICK-START GUIDE..............................1
WHAT’S IN THE BOX? ................................................................... 3
PROJECTOR OVERVIEW ............................................................... 4
Front view.............................................................................................. 4
Rear view .............................................................................................. 4
Remote control...................................................................................... 5
Control panel......................................................................................... 7
Indicators............................................................................................... 7
CHANGING THE LENS, LAMPS, FILTERS AND COLOR WHEEL .... 8
Fitting the lens....................................................................................... 8
Removing the lens ................................................................................ 8
Changing a lamp................................................................................... 9
Changing the lters ............................................................................. 10
Changing the color wheel.................................................................... 11
POSITIONING THE SCREEN AND PROJECTOR........................... 12
OPERATING THE PROJECTOR.................................................... 13
Switching the projector on................................................................... 13
Selecting an input signal or test pattern.............................................. 13
Input signal ........................................................................................ 13
Test pattern ........................................................................................ 13
Adjusting the lens................................................................................ 14
Zoom................................................................................................ 14
Focus ............................................................................................... 14
Shift ................................................................................................. 14
Adjusting the image............................................................................. 14
Orientation ......................................................................................... 14
Aspect Ratio....................................................................................... 14
Picture .............................................................................................. 14
Switching the projector off................................................................... 15
CONNECTION GUIDE ............................................................................17
SIGNAL INPUTS AND OUTPUTS.................................................. 19
SUPPORTED SIGNAL INPUT MODES .......................................... 20
CONTROL CONNECTIONS........................................................... 23
WIRING DETAILS......................................................................... 24
Signal inputs and outputs.................................................................... 24
HDBaseT input.................................................................................... 24
3D sync connection .............................................................................. 24
HDMI input......................................................................................... 25
DVI-D ............................................................................................... 26
DisplayPort ........................................................................................ 27
VGA ................................................................................................. 28
COMPONENT .................................................................................... 28
Control connections ............................................................................ 29
LAN connection................................................................................... 29
RS232 Serial control input...................................................................... 29
Wired Remote control connection ............................................................ 29
Screen Trigger output ........................................................................... 29

Digital Projection E-Vision 7500 Series
iv
Rev D July 2014
OPERATING GUIDE ................................................................................31
USING THE MENUS ..................................................................... 34
Navigating the menus ......................................................................... 34
Submenus........................................................................................... 35
Selecting parameters .......................................................................... 36
Sliders ................................................................................................. 37
Commands.......................................................................................... 37
A TOUR OF THE MENUS.............................................................. 38
INPUT menu ....................................................................................... 38
Input Selection .................................................................................... 38
Test Pattern........................................................................................ 39
Color Space ....................................................................................... 39
Input Lock.......................................................................................... 39
Background........................................................................................ 39
Auto Sync Adjust ................................................................................. 39
PICTURE menu .................................................................................. 40
Picture Mode ...................................................................................... 40
Contrast, Brightness, Saturation, Hue ....................................................... 40
Gamma............................................................................................. 40
Color submenu.................................................................................... 41
Sharpness, Noise Reduction................................................................... 41
Aspect Ratio....................................................................................... 42
PICTURE menu continued ................................................................... 43
Overscan........................................................................................... 43
VGA Setup submenu ............................................................................ 43
Auto Sync .......................................................................................... 43
LAMPS menu...................................................................................... 44
Mode................................................................................................ 44
Power............................................................................................... 44
High Altitude Mode ............................................................................... 44
Custom Power Level ............................................................................ 44
Lamp Status....................................................................................... 44
ALIGNMENT menu ............................................................................. 45
Projection Mode .................................................................................. 45
Fan Mode .......................................................................................... 45
Lens Control....................................................................................... 45
Lens Memory submenu ......................................................................... 46
Center Lens ....................................................................................... 46
Keystone ........................................................................................... 46
Digital Alignment submenu ..................................................................... 47
H/V Alignment submenu ........................................................................ 47
CONTROL menu................................................................................. 48
Eco Network Power.............................................................................. 48
Auto Power Off.................................................................................... 48
Auto Power On.................................................................................... 48
Projector Control ................................................................................. 48
Network submenu................................................................................ 49
Startup Logo....................................................................................... 49
Trigger .............................................................................................. 49
Auto Search ....................................................................................... 49
Dynamic Black .................................................................................... 49
3D submenu....................................................................................... 50
Language submenu.............................................................................. 51
SERVICE menu .................................................................................. 52
Information......................................................................................... 52
Blue Only........................................................................................... 52
Factory Reset ..................................................................................... 52
MENU MAP .................................................................................. 53

Digital Projection E-Vision 7500 Series
v
Rev D July 2014
REMOTE COMMUNICATIONS GUIDE ..........................................57
INTRODUCTION........................................................................... 59
Operation commands.......................................................................... 59
Key commands ................................................................................... 59
THE OPERATION COMMANDS..................................................... 60
INPUT menu ....................................................................................... 60
PICTURE menu .................................................................................. 61
LAMPS menu...................................................................................... 64
ALIGNMENT menu ............................................................................. 65
CONTROL menu................................................................................. 65
SERVICE menu .................................................................................. 67
Miscellaneous commands................................................................... 67
ERROR CODES ........................................................................... 68
THE KEY COMMANDS ................................................................. 72
WEB CONFIGURATION UTILITY .................................................. 73
Email settings...................................................................................... 74
Projector controls ................................................................................ 75

Rev D July 2014
E-Vision 7500 Series
High Brightness Digital Video Projector
INSTALLATION AND QUICK-START GUIDE

Digital Projection E-Vision 7500 Series IN THIS GUIDE Installation and Quick-Start Guide
Rev D July 2014
IN THIS GUIDE
What’s In The Box?............................................................................................. 3
Projector Overview............................................................................................. 4
Front view ....................................................................................................................4
Rear view .....................................................................................................................4
Remote control............................................................................................................5
Control panel ...............................................................................................................7
Indicators .....................................................................................................................7
Changing The Lens, Lamps, Filters And Color Wheel............................. 8
Fitting the lens.............................................................................................................8
Removing the lens ......................................................................................................8
Changing a lamp .........................................................................................................9
Changing the lters ..................................................................................................10
Changing the color wheel ........................................................................................11
Positioning The Screen And Projector....................................................... 12
Operating The Projector ................................................................................. 13
Switching the projector on.......................................................................................13
Selecting an input signal or test pattern.................................................................13
Input signal......................................................................................................................13
Test pattern .....................................................................................................................13
Adjusting the lens .....................................................................................................14
Zoom...............................................................................................................................14
Focus ..............................................................................................................................14
Shift.................................................................................................................................14
Adjusting the image..................................................................................................14
Orientation ......................................................................................................................14
Aspect Ratio....................................................................................................................14
Picture.............................................................................................................................14
Switching the projector off.......................................................................................15

Digital Projection E-Vision 7500 Series WHAT’S IN THE BOX? Installation and Quick-Start Guide
3
Rev D July 2014
What’s In The Box? Notes
Make sure your box contains
everything listed. If any pieces are
missing, contact your dealer.
You should save the original box
and packing materials, in case you
ever need to ship your projector.
An RYGCWB color wheel, optimized
for brightness, is tted as standard.
Use the RGBCMY color wheel for
optimized color.
Only one power cable - dependent
on the destination territory - will be
supplied with the projector.
Remote control
(114-230)
User Manual on disc
(115-759)
Important Information
(114-739)
Projector
Lens cap
Power cable,
China
(112-817)
Power cable,
United Kingdom
(112-814)
Power cable,
Europe
(112-816)
Power cable,
North America
(112-815)
RGBCMY color wheel

Digital Projection E-Vision 7500 Series PROJECTOR OVERVIEW Installation and Quick-Start Guide
4
Rev D July 2014
Projector Overview
Front view
1Front infra-red window
2Lens
3Color wheel cover
4Indicator panel
5Control panel
6Adjustable feet
7Air inlet
8 Air lter cover
9Mains input
10 Connection panel
Rear view
1Rear infra-red window
2Lamp covers
3 Air lter cover
4Air outlet
5Air inlet
Notes
The air lters should be cleaned or
changed regularly, depending on the
installation environment.
The lters should be changed at the
same time as the lamp is changed.
The projector lens is shipped
separately.
123 5
7
4
10
8 9
6
4
1
5
2 3

Digital Projection E-Vision 7500 Series PROJECTOR OVERVIEW Installation and Quick-Start Guide
5
Rev D July 2014
Remote control
1Power ON/OFF
2Lens controls
3Menu controls
Press MENU to open the OSD, then use the buttons to
navigate.
When the OSD is closed, ENTER opens lens controls.
4INPUT
Select input source.
5AUTO SYNC
Re-synchronise with the current input signal.
6OVERSCAN
Select from Off, Crop and Zoom.
73D MODE
Access 3D settings.
8CLEAR
Use only with ID SET.
9PICTURE
Open the Picture menu.
10 FREEZE
Freeze the current frame.
11 SHUTTER
Notes
The projector can use an infra-red or
a wired remote control.
Some of the controls are duplicated
on the projector control panel, as
shown in the next section.
For full details of how to use the
controls and the menu system, see
the Operating Guide.
Infra-red
reception
40°
40°

2 31
5 64
8 97
0
ENTER
FOCUS
TEST
PATTERN
+
EXIT
MENU
ON POWER OFF

ZOOM
+
LENS SHIFT
INPUT PICTURE NETWORK
AUTO SYNC ASPECT BLANK
OVERSCAN FREEZE
INFO.3D MODE
LAMP MODE
LIGHT
CLEAR SHUTTER ID SET
1
2
3
4
9
5
6
10
7
8
11

Digital Projection E-Vision 7500 Series PROJECTOR OVERVIEW Installation and Quick-Start Guide
6
Rev D July 2014
12 TEST PATTERN
Open the list of available test patterns.
13 NETWORK
Access network settings.
14 ASPECT
Change the aspect ratio.
15 BLANK
Image mute.
16 LAMP MODE
Open the Lamps menu.
17 INFO
Open the Service menu.
18 LIGHT
Illuminate the buttons on the remote control for 10 seconds.
19 ID SET
Hold for 5 seconds to view ID status.
COMBINATION: ID SET + number
Set the ID (Hold for 5 seconds)
COMBINATION: ID SET + CLEAR
Clear the ID (Hold for 5 seconds)

2 31
5 64
8 97
0
ENTER
FOCUS
TEST
PATTERN
+
EXIT
MENU
ON POWER OFF

ZOOM
+
LENS SHIFT
INPUT PICTURE NETWORK
AUTO SYNC ASPECT BLANK
OVERSCAN FREEZE
INFO.3D MODE
LAMP MODE
LIGHT
CLEAR SHUTTER ID SET
12
14
17
13
15
16
18
19
Infra-red
reception
40°
40°
Notes
To protect the lamps from thermal
shock, it will not be possible to
change the Lamp Mode more than
once within ve minutes.
Use the ID SET feature to assign
discrete ID addresses for up to nine
projectors. This will enable you to
operate each projector separately
with a dedicated remote control.

Digital Projection E-Vision 7500 Series PROJECTOR OVERVIEW Installation and Quick-Start Guide
7
Rev D July 2014
Control panel
1POWER
Off or Standby.
2INPUT
Select input source.
3AUTO SYNC
Re-synchronise with the current input signal.
4ASPECT
Change the aspect ratio.
5SHUTTER
6Menu controls
7Lens controls
Indicators
POWER off = NO POWER
green = normal RUNNING mode red = STANDBY mode
 ashinggreen = PROJECTOR WARM UP
ashingamber = PROJECTOR COOL DOWN
STATUS off = NO ERROR
ashingred(1ash) = COVER OPEN ashingred(4ashes) = FAN ERROR
red = SYSTEM ERROR
LAMPS 1,2 off = OFF
ashingred = LAMP ERROR red = END OF LIFE
ashinggreen = LAMP WARM-UP green = ON
TEMP off = NO ERROR ashing red = ERROR (temperature)
SHUTTER off = OPEN green = CLOSED
ENTER
1
6
2 3 4 5
7
Notes
For full details of how to use the
controls and the menu system, see
the Operating Guide.
POWER STATUS LAMP1 LAMP2 TEMP. SHUTTER

Digital Projection E-Vision 7500 Series CHANGING THE LENS, LAMPS, FILTERS AND COLOR WHEEL Installation and Quick-Start Guide
8
Rev D July 2014
Changing The Lens, Lamps, Filters And Color Wheel
Fitting the lens
1. Remove the lens cap.
2. Position the lens so that the labels are at the top, and gently insert it all
the way into the lens mount.
3. Push the lens in rmly, and turn it clockwise until it clicks into place.
Removing the lens
1. Push in the lens release lever, and turn the lens anti-clockwise.
2. Remove the lens.
Notes
The projector lens is shipped
separately.
The Center Lens command must
be used after a new lens is inserted.
See the Operating Guide for more
details.

Digital Projection E-Vision 7500 Series CHANGING THE LENS, LAMPS, FILTERS AND COLOR WHEEL Installation and Quick-Start Guide
9
Rev D July 2014
Changing a lamp
1. Unscrew the two captive screws securing the cover for the lamp that needs changing.
2. Open the lamp compartment.
3. Unscrew the three captive screws securing the lamp module.
4. Pull rmly on the handle to remove the lamp module.
5. Insert a new lamp module and fasten the screws.
6. Replace the lamp compartment cover and fasten the screws.
Notes
Always allow the lamp to cool for
5 minutes before:
- disconnecting the power
- moving the projector
- changing the lamp
The lamp and color wheel must
be changed only by suitably
qualied personnel.
The projector will shut down if any
of the covers are opened whilst in
operation.
The lters should be changed at the
same time as the lamp is changed.

Digital Projection E-Vision 7500 Series CHANGING THE LENS, LAMPS, FILTERS AND COLOR WHEEL Installation and Quick-Start Guide
10
Rev D July 2014
Changing the lters
1. Press the air lter covers, then pull them out as shown in Fig. 1.
2. Pull out the old lters as shown in Fig. 2.
3. Insert the new lters and close the lter covers as shown in Fig. 3.
Notes
The projector will shut down if any
of the covers are opened whilst in
operation.
The lters should be changed at the
same time as the lamp is changed.
Fig. 1
Fig. 2
Fig. 3

Digital Projection E-Vision 7500 Series CHANGING THE LENS, LAMPS, FILTERS AND COLOR WHEEL Installation and Quick-Start Guide
11
Rev D July 2014
Changing the color wheel
1. Unscrew the captive screw securing the color wheel compartment cover (Fig. 1) and open the compartment.
2. Unscrew the four captive screws securing the color wheel (Fig. 2).
3. Remove the color wheel (Fig. 3).
4. Insert a new color wheel (Fig. 4) and fasten the screws (Fig. 5).
5. Replace the cover and fasten the screw (Fig. 6).
Notes
The lamp and color wheel must
be changed only by suitably
qualied personnel.
Allow the projector to cool for
5 minutes before changing the
color wheel.
The projector will shut down if any
of the covers are opened whilst in
operation.
Fig. 1 Fig. 2 Fig. 3
Fig. 6Fig. 5
Fig. 4

Digital Projection E-Vision 7500 Series POSITIONING THE SCREEN AND PROJECTOR Installation and Quick-Start Guide
12
Rev D July 2014
Notes
Always allow the lamp to cool for
5 minutes before:
- disconnecting the power
- moving the projector
Ensure that there is at least 70
cm (28 in) of space between the
ventilation outlets and any wall,
and 50 cm (20 in) on all other
sides.
If ceiling mounting, ensure there
is 30 cm (12 in) of space between
the projector and ceiling.
Backup safety chains or wires
should always be used with
ceiling mount installations.
Do not stack the projectors.
Do not tilt the projector more than
±10° from side to side when in
use, as this may cause serious
lamp failure, damage the lamp
module and cause extra cost on
replacement.
±10°
±360°
±10°
Desktop
Ceiling
Positioning The Screen And Projector
1. Install the screen, ensuring that it is in the best
position for viewing by your audience.
2. Mount the projector, ensuring that it is at a suitable
distance from the screen for the image to ll the
screen. Set the adjustable feet so that the projector
is level, and perpendicular to the screen.
The drawing shows the positions of the feet for table
mounting, and the xing holes for ceiling mounting.
1Three adjustable feet
2Six M4 holes for ceiling mount
The screws should not penetrate more than 15
mm into the body of the projector.
150 mm150 mm
1 2 1
1 2

Digital Projection E-Vision 7500 Series OPERATING THE PROJECTOR Installation and Quick-Start Guide
13
Rev D July 2014
Operating The Projector
Switching the projector on
1. Connect the power cable between the mains supply and the projector. Switch on at the switch next to the power connector.
2. Wait until the self-test has completed and the Power indicator on the projector control panel shows red. The lamp will be off and the
projector will be in STANDBY mode.
3. Press POWER on the control panel or POWER ON on the remote control.
The Power indicator on the control panel will ash green for a few seconds whilst the lamp comes up to full brightness. When the
projector is ready for use, the Power indicator will show steady green.
Selecting an input signal or test pattern
Input signal
1. Connect an image source to the projector. The signal should be automatically detected by the projector, and should be displayed within
two or three seconds.
2. If more than one signal is connected, select the input you want to display:
• Press INPUT repeatedly on the control panel or remote control to cycle through the inputs.
• or use Input Selection in the INPUT menu.
Test pattern
If you do not have an image source connected to the projector, you can display a test pattern instead:
• Press TEST PATTERN repeatedly on the remote control to cycle through the test patterns,
• or select a Test Pattern from the INPUT menu.
Notes
For full details of how to connect an
image source to the projector, see
the Connection Guide.
For full details of how to use the
controls and the menu system, see
the Operating Guide.
To return to viewing the image from
your image source, scroll through
the test pattern list to Off.

Digital Projection E-Vision 7500 Series OPERATING THE PROJECTOR Installation and Quick-Start Guide
14
Rev D July 2014
Adjusting the lens
Zoom
• Use the ZOOM +/− buttons on the control panel or on the remote control to adjust the
lens so that the image lls the screen.
or use Lens Control in the ALIGNMENT menu.
Focus
• Use the FOCUS +/− buttons on the control panel or on the remote control to adjust the
lens until the image is sharp.
or use Lens Control in the ALIGNMENT menu.
Shift
• Use the LENS SHIFT buttons , , and on the control panel to adjust the
position of the image,
or press the LENS SHIFT button on the remote control then use , , and
to adjust the position of the image.
or use Lens Control in the ALIGNMENT menu.
Adjusting the image
Orientation
• This can be set from the ALIGNMENT menu.
Select the orientation which suits the positioning of the projector.
Aspect Ratio
• This can be set from the PICTURE menu, or from the ASPECT button on the remote
control or control panel.
Settings such as Brightness and Contrast can be set from the PICTURE menu.
Notes
For full details of how to use the
controls and the menu system, see
the Operating Guide.
