Dimplex RITZ User manual

08/53445/0 Issue 2
OCN 11689
RITZ
RITZ WHITE

1
4
2
1
2
3
I
I
II
II
3
min max
OFF
ON
T
econ
510 340
597

General
Unpack the heater carefully and retain the packaging for possible future
use, in the event of moving or returning the re to your supplier.
These models are designed to be free standing and are normally
positioned against a wall.
The re incorporates a ame e󰀨ect, which can be used with or without
heating, so that the comforting e󰀨ect may be enjoyed at any time of
the year. Using the ame e󰀨ect on its own only requires little electricity.
A choice of 1kW or 2kW heat output is provided by the fan heater, which
is located at the bottom of the unit.
Before connecting the heater check that the supply voltage is the same
as that stated on the heater.
Please note: Used in an environment where background noise is very
low, it may be possible to hear a sound which is related to the operation
of the ame e󰀨ect. This is normal and should not be a cause for concern.
Electrical connection
WARNING – THIS APPLIANCE MUST BE EARTHED.
This heater must be used on an AC ~ supply only and the voltage marked
on the heater must correspond to the supply voltage. Before switching
on, please read the safety warnings and operating instructions.
Controls - see Fig. 2
The switches provide a choice of heat settings, The appliance is in standby
mode when the mainslead is plugged in. This is indicated by the red neon
behind the ame e󰀨ect screen. The two
selector switches are in the ON position when the side with the markings
on (i.e. I, or II) is pushed in.
Selector switch 1 (0) Controls the electricity supply to the
appliance and ame e󰀨ect. Press for ‘ON’
and ‘Standby’. If both selector switches 2 and
3 are in the OFF position, the product works
on ame e󰀨ect only.
Selector Switch 2 (I) Provides 1kW heat output
Selector Switch 3 (II) Provides 2kW output with switch 2
Thermostat (T) - see Fig. 4
In order to maintain a certain room temperature, set the controller to
‘max.’. Operate the appliance at full power until the required room
temperature is reached. Set back the thermostatic controller until the
appliance switches o󰀨 with an audible “click”. This temperature will be
kept almost constant by the thermostatic control switching on and o󰀨
automatically.Please note that the appliance can only be switched on
when the thermostat setting is higher then the room temperature.
IMPORTANT: THESE INSTRUCTIONS SHOULD BE READ CAREFULLY AND RETAINED FOR FUTURE REFERENCE
- Ritz - RIT20
- Ritz White - RIT20W
Important Safety Advice
When using electrical appliances, basic
precautions should be followed to reduce
the risk of re, electric shock, and injury to
persons, including the following:
Do not use it there are visible signs of dam-
age, check immediately with the supplier
before installation and operation.
Do not use this appliance in the immediate
surroundings of a bath, shower or swimming
pool.
Do not use outdoors.
Do not use this heater if it has been dropped.
This appliance must not be located imme-
diately above or below a xed socket outlet
or connection box.
WARNING : The appliance carries
the Warning Symbol indicating that it
must not be covered or has a Do not
cover label. Do not cover or obstruct in
any way the heat outlet grille located under-
neath the appliance, overheating will result
if the appliance is accidentally covered. Do
not place material or garments on the appli-
ance, or obstruct the air circulation around
the appliance, for instance by curtains or
furniture, as this could cause overheating
and a re risk.
In the event of a fault unplug the heater.
Unplug the appliance when not required
for long periods.The supply cord must be
placed on the right hand side of the heater
away from the heat outlet underneath the
appliance.
This appliance is not intended for use by
persons (including children) with reduced
physical, sensory or mental capabilities, or
lack of experience and knowledge, unless
they have been given supervision or instruc-
tion concerning use of the appliance by a
person responsible for their safety.
Children should be supervised to ensure that
they do not play with the appliance.
Cleaning and user maintenance shall not be
made by Children.
The appliance must be positioned so that
the plug is accessible.
If the supply cord is damaged it must be
replaced by the manufacturer or service
agent or similarly qualied person in order
to avoid a hazard.
Use this applaince on a horizontal and stable
surface, or x to the wall, as applicable.
Although this heater complies with safety
standards, we do not recommend its use on
deep pile carpets or on long hair type of rugs.
Warning: Do not use the heater in small
rooms when they are occupied by persons
not capable of leaving the room on their own,
unless constant supervision is provided.
CAUTION: In order to avoid a hazard due to
inadvertent resetting of the thermal cut-out,
this appliance must not be supplied through
an external switching device, such as a tim-
er, or connected to a circuit that is regularly
switched on and o󰀨 by the utility.
Warning: To reduce the risk of re, keep
textiles,curtains, or other ammable material
a minimum distance of 1m from the air outlet.
CAUTION - Some parts of this product can
become very hot and cause burns. Particular
attention has to be given where children and
vulnerable people are present.
This instruction can be found at
www.dimplex.com.au &
www.dimplex.co.nz

Light Emitting Diode
This re is tted with LED (Light Emitting Diode) lamps. These LED
lamps are maintenance-free and should not require replacing during
the life of the product.
Thermal Safety Cut-out
The built-in overheat cut-out switches o󰀨 the appliance automatically in
the event of a fault. If this occurs switch o󰀨 the appliance or disconnect
the mains plug from the socket. After a short cooling down phase, the
appliance is ready for use again. If the fault should occur again, see
your local dealer.
Cleaning
WARNING – ALWAYS DISCONNECT FROM THE POWER SUPPLY
BEFORE CLEANING THE HEATER.
For general cleaning use a soft clean duster – never use abrasive
cleaners. The glass viewing screen should be cleaned carefully with a
soft cloth. DO NOT use proprietary glass cleaners.
To remove any accumulation of dust or u󰀨 the soft brush attachment of
a vacuum cleaner should occasionally be used to clean the outlet grille
of the fan heater.
Recycling
At the end of the electrical products useful life it should not
be disposed of with household waste. Please recycle where
facilities exist. Check with your Local Authority or retailer for
recycling advice in your country.
After Sales Service
Please see the separate Warranty leaet for details of your
Warranty & After Sales Service including contact details.
Should you require after sales information or assistance with this
product, please contact Glen Dimplex Australia on 1300 556 816
(AUS) / 09 274 8265 (NZ) or visit our website at www.dimplex.
com.au (AUS) / www.dimplex.co.nz (NZ).
Remote control - see Fig. 3
The maximum range of use is ~ 5 metres.
Warning: It takes time for the receiver to respond to the transmitter.
Do not press the buttons more than once within two seconds for
correct operation.
Battery information - see Fig. 3
1. To activate the remote control remove the battery isolation strip,
which is used to ensure your remote control reaches you fully charged.
2. To replace the remote control battery, turn over the remote control,
and follow the diagram embossed on the remote control
3. Only use CR2025 size of batteries.
Discard leaking batteries
Dispose of batteries in the proper manner according to provincial
and local regulations.
Any battery may leak electrolyte if mixed with a di󰀨erent battery
type, if inserted incorrectly, if all the batteries are not replaced at the
same time, if disposed of in a re, or if an attempt is made to charge
a battery not intended to be recharged.
WARNING - KEEP BATTERIES OUT OF REACH OF CHILDREN
1. Swallowing may lead to serious injury in as little as 2 hours or death,
due to the chemical burns and potential perforation of the oesophagus.
2. If you suspect your child has swallowed or inserted a button battery
immediately call the 24-hour Poisons Inforation Centre on 13 11 26 (in
Australia) or 0800 764 766 (in New Zealand) for fast, expert advice.
3. Examine devices and make sure the battery compartment is
correctly secured, e.g. that the screw or other mechanical fastener
is tightened. Do not use if the compartment is not secure.
4. Dispose of used button batteries immediately and safely. at
batteries can still be dangerous.
Maintenance
WARNING: ALWAYS DISCONNECT FROM THE POWER SUPPLY
BEFORE ATTEMPTING ANY MAINTENANCE.
