1. INTRODUCTION
This manual was created to help you install and learn all about the functional possibilities of the purchased indicator.
The instrument is suitable for use in various weighing environments.
Not only does it have all the normal features of high-precision scales, but it also gives you the possibility to work in specific
environments due to the functioning modes contained in the software implemented in the FLASH MEMORY on the internal
board; This makes the instrument extremely flexible and it can be used in many different industrial applications linked to
weighing. The double numerical and interactive alphanumerical display, the alphanumerical and function keyboard, allow
the operator an easy and immediate use and provide the microcontroller with DATA ENTRY functions in addition to the
normal weighing functions. The input/output allows the instrument to control various external devices, to receive external
commands, control a printer and communicate with a personal computer or to be inserted in a network of weight indicators
controlled by a PC.
WARNING
Please note that this instrument is covered by a warranty and MUST NOT BE OPENED BY THE USER for any reason
whatsoever. Any attempt to repair or modify the unit exposes the user to the risk of electric shock and will invalidate the
entire warranty.
If any problems are found in the unit or with the system in which it is used, the fact must be communicated to the
manufacturer or the dealer from whom it was purchased.
In any case, DISCONNECT THE POWER SUPPLY before taking any action.
The version with the 6V rechargeable battery has to be completely recharged (12 hours) in the first installation of
the instrument; we RECOMMEND disconnecting the battery if the instrument is not going to be used for more than
30 days. In order to avoid the deterioration of the rechargeable battery:
- In standard conditions, never leave the battery partially or completely uncharged; at least once a week recharge
it completely.
- In case the instrument is not used for a long period, one needs to:
1. completely recharge the battery before the system is switched off for the last time;
2. recharge completely every 3 months.
Do not pour liquids on the weight indicator.
Do not use solvents to clean the weight indicator.
Do not expose the instrument to direct sunlight nor place it near heat sources.
Place or anchor the weight indicator and platform on a non-vibrating base.
All the connections of the indicator have to be made respecting
the rules applicable in the zone and in the installing environment.
Everything not expressly described in this manual has to be
considered as improper use of the equipment.
Read carefully and apply what is described in section 3.
Do not install in any area where there is a risk of explosion.
The crossed-out wheeled bin on the product means that at the product end of life, it must be taken to
separate collection or to the reseller when a new equivalent type of equipment is purchased. The adequate
differentiated refuse collection in having the product recycled, helps to avoid possible negative effects on
the environment and health and supports the recycling of the materials of which the equipment is made. The
unlawful disposal of the product by the user will entail fines foreseen by the current regulations.

3590EKR, 3590EXP, 3590EXT, CPWE, CPWET series indicator E-AF04_03_16.05_EN_U
5
2. MAIN TECHNICAL SPECIFICATIONS
POWER SUPPLY
3590E:
- 12 ÷ 24Vdc ( 12 Vdc with internal supply adapter)
- 6 Vdc from internal rechargeable battery, available in according to the model.
CPWE - CPWET:
- 12 ÷ 24Vdc
MAXIMUM POWER
16 VA.
OPERATING TEMPERATURE
From -15 to +40 °C (from 5 to 104 °F).
CONVERTER
24 bit Sigma Delta.
CONVERSION SPEED
200 conv./sec with automatic selection.
RANGE OF INPUT SIGNAL
0,6 mV/V - 3,2 mV/V.
MINIMUM VOLTAGE PER DIVISION
0.3 V (approved instrument); 0.03 V (non-approved instrument).
AUTOMATIC ZERO DETECTION
Only in gross mode, programmable at +/- ¼, ½, 1, 2 divisions.
ZERO RANGE
Configurable up to +/- 50% of max load capacity.
AUTO ZERO AT START-UP
Configurable up to +/- 50% of max load capacity.
LOAD CELL POWER SUPPLY
5Vdc ± 5%, 120mA (max 8 350-Ohm cells).
LOAD CELL CONNECTIONS
6 wires with Remote Sense.
DISPLAY DIVISIONS
10000e, 3 x 3000e for legal for trade weighing, expandable up to 800.000 for
internal use (with minimum signal coming from the 1,6 mV/V cell).
DISPLAYS
3590E:
- Red, high-luminosity LED indicators, with six digits (h 13 mm).
- Back lit graphic 160x32 dot LCD.
CPWE: Back lit graphic 160x32 dot LCD.
DATABASE/MEMORY
Database of 1000 articles (3 lines of description of 20 characters).
Database of 300 preset tares.
SIGNALS
3590E: 16 status LEDs. Graphic icons on LCD display.
CPWE: Graphic icons on LCD display.
CPWET: 3-way control light. Graphic icons on LCD display
KEYBOARD
Impermeable polycarbonate keyboard (IP65 protection degree), with membrane
keys with audible and tactile feedback.
PARAMETER SETUP
Calibration and linearity (up to 8 points), fully digital and programmable from the
keyboard or from PC with Dinitools ™.
CLOCK/DATE
Fitted, with buffer RAM.
SERIAL OUTPUTS
- 2 input/output RS232 ports on terminal board/ amp connector.
- 1 input/output RS485 port on terminal board or RS232 on amp connector.
INPUTS AND OUTPUTS
- Management of PC keyboard or barcode reader
3590EXP, 3590EXT and CPWET:
- 2 optoisolated inputs (optoisolated photo couplers), 12Vdc –24Vdc, 20mA max
- 4 outputs (optoisolated photomosfets), 48Vac / 0.15A, 60Vdc / 0.15A, 10 Ω
max.
3590EXT in IO version and CPWE:
- 8 inputs (optoisolated photo couplers), 12Vdc –24Vdc, 20mA max.
- 16 outputs (optoisolated photomosfets), 48Vac / 0.15A, 60Vdc / 0.15A.
ANALOGUE OUTPUT (Option
available on the 3590EXT “IO” version
and CPWE version)
- 16-bit analogue output configurable from keyboard (full-scale value; zero scale
value and minimum value) from 0 to 10 Vdc or from 0 to 20mA; the maximum
resistance applicable on the output current is 350 Ohm and the minimum
resistance applicable on the output voltage is 10 kohm.

3590EKR, 3590EXP, 3590EXT, CPWE, CPWET series indicator E-AF04_03_16.05_EN_U
6
2.1 ACCESSORIES AVAILABLE
On the indicator it is possible to implement internal and external modules used to increase interfacing possibilities. (For
example, the number of usable outputs various types of printers, in order to have a report of the weighs made, or giant
display in order to better see the weigh operations. Also, one can connect a PC in order to simply program the instrument
through Dinitools™, or in order to have a complete management of the weighs.
Contact the reseller for the list of the available hardware and software accessories.
2.2 SYMBOLS USED
Below are the symbols or texts used in the manual to recall the reader’s attention and on the instrument to recall
the user’s attention
ATTENTION!
Only qualified personnel must perform this operation
ATTENTION!
This is referred to working with live wires: only qualified personnel must perform this operation.
CE CONFORMITY
IDENTIFIES THE CLASS OF PRECISION.
“TECH.MAN.REF.”
It means that an advanced function is being described (therefore for the technical personnel)
which will be further explained in the corresponding technical manual.
THE INSTRUMENT’S DANGEROUS VOLTAGE PARTS AND THE PARTS THE USER CAN ACCESS HAVE BEEN
ELECTRICALLY INSULATED.

3590EKR, 3590EXP, 3590EXT, CPWE, CPWET series indicator E-AF04_03_16.05_EN_U
7
3. INSTALLATION
3.1 POWER SUPPLY
The 3590E indicator is powered with 12Vdc voltage, through an internal adapter which converts the 100 ÷240Vac,
50÷60Hz mains voltage and 6 Vdc, from internal battery (fitted depending on the model).
TO POWER the instrument through the 240 Vac mains, or TO RECHARGE the battery, insert the plug and the adapter to
the 240 Vac mains socket.
- The CPWE indicator is powered with 8÷24 Vdc voltage.
- The CPWET indicator is powered with 8÷ 24Vdc voltage.
To connect the indicator to the power mains, the safety regulations must be observed, including the use of a "clean" line
without disturbances or interference caused by other electronic equipment.
Version with rechargeable battery: The battery inside the indicator lasts about 25 hours (without the expansion board,
with 1-cell platform) and it needs a recharging time of about 12 hours.
BATTERY FEATURES
Material LEAD
Power 4,5 Ah
Voltage 6 V
THE BATTERY MUST BE SUPPLIED DIRECTLY FROM THE MANUFACTURER.
NOTE: it is advisable to completely recharge it (12 hours) in the first installation of the instrument; we
RECOMMEND disconnecting the battery if the instrument is not going to be used for more than 30 days.
Do not connect other equipment to the same socket as the one that the adapter is in. !!
Do not step on or crush the power supply cable. !!
3.2 START UP
TO TURN ON the 3590E/CPWET press the C key until the 6 status indicator LEDS turn on; then release.
The CPWE instead is automatically turned on as soon as it is powered.
The LCD display shows:
-Initially a welcome message (settable in the TECHNICAL SET-UP, << LoGo >> StEP, TECH.MAN.REF)while the
instrument carries out a series of checking and preheating self tests.
-E-AF04 - XX” name of the installed software, in which XX identifies the software language.
-XX.YY is the software version installed.
-“EXECUTION AUTOZERO”
The instrument carries out the "autozero at start-up” function: if a weight is detected within the percentile set in the << Auto-
0 >> step (TECH.MAN.REF.), it is cleared; if the weight is not within this tolerance:
-with a non approved instrument, the display shows the weight after a few instants,
-with an approved instrument, the message “EXECUTION AUTOZERO” appears continuously on the display, until the
weight is within tolerance.
The auto zero function at start-up may be disabled in the set-up environment (only with non approved instrument); see
SEtuP >> ConFiG >> PArAm. >> Auto-0 (TECH.MAN.REF.)
By pressing the 2ndF key for an instant while the version is shown in the display, the indicator will show in this order:
01.01 in which 01 indicates the instrument type, 01 indicates the metrological software version.
XX.YY.ZZ is the installed software version.
HH is the installed hardware version (08).
LEGAL FOR TRADE or
HIGH RESOLUTION if the instrument is APPROVED or UNAPPROVED, respectively.
9.XXXXX is the g gravity value (only with APPROVED instrument).

3590EKR, 3590EXP, 3590EXT, CPWE, CPWET series indicator E-AF04_03_16.05_EN_U
8
3.3 TURNING OFF THE INSTRUMENT
TO TURN OFF the 3590E/CPWET or TO RESTART the CPWE keep the C key pressed until the “- OFF -“ message
appears on the display and “ *** POWER OFF *** ” on the display.
TO TURN OFF the CPWE remove the instrument’s power supply
3.4 TURNING ON PRINTER IN ENERGY SAVING MODE
In a system where the indicator is connected to a printer, both are battery powered, the printer is normally maintained in
STAND-BY and powered only when a printout is needed. This function reduces the energy absorbed by the battery when
the printer is not being used.
If, in this configuration, one should power the printer to change the paper and other maintenance jobs, one needs to press
in sequence the ENTER and 0 keys during the weighing: the display shows Prn –on (Blinking), and the printer is kept on.
Press any key to exit from this condition.
4. FRONT PANEL KEYS AND DISPLAYS
3590E

3590EKR, 3590EXP, 3590EXT, CPWE, CPWET series indicator E-AF04_03_16.05_EN_U
9
CPWE
CPWET

3590EKR, 3590EXP, 3590EXT, CPWE, CPWET series indicator E-AF04_03_16.05_EN_U
10
4.1 FUNCTION OF THE KEYS
In the following section, and later on in the manual, the keys’ functioning is described in accordance to how these are
configured by factory.
It is possible to customise the functionality of the keys through the << F.KEYS >> step (TECH.MAN.REF).
C/DEL
- Turns the instrument on/off
- If pressed for an instant, it clears the tare value.
- Exits the parameter without confirming and saving the modifications.
- In the numeric input phase, it quickly clears the present value
TARE/ZERO
- If pressed for an instant it carries out the semiautomatic tare, or cancels the tare value if the gross
weight is 0.
- If pressed at length, it clears the displayed gross weight, if it’s within the percentage configured in the
<< 0.PErC >> step.
Fn/ENTER
- In the alphanumeric input phase, it confirms the entry made.
- In the menu it allows to enter a step or to confirm a parameter inside a step.
2nd F
-If pressed together with the other keys, it allows carrying out a specific function. (see section”"2ndF"
KEY: SECOND FUNCTION OF THE KEYS”)
./HELP
- In the numeric or alphanumeric input phase, it enters, in this order, the following characters: . , ; : # <
> \ | ” % & / ( ) = ? ^ ’ [ ] { };
-HELP function, see section 4.1.4.
- If pressed in some steps or functions of the weight indicator, the display shows the keys and their
functions specific to that state of the instrument.
F1
- If pressed for an instant, it enters into the article database.
- If pressed at length, it locks and unlocks the instrument’s keyboard (except the Ckey).
- In the numeric or alphanumeric input phase, it allows to copy entered characters.
F2
- If pressed at length, the weight visualisation function with sensitivity x 10 is enabled.
- In the numeric or alphanumeric input phase, it allows to stick with copied characters.
F3
- If pressed for an instant, it allows one to select the line (when minimum 2 lines are enabled in
SETUP, see section 13.4).
- If pressed at length, one can adjust the date and time of the instrument.
F4
-If pressed for an instant, it allows to fill in the free texts, if configured
-If pressed at length, it enters the instrument’s diagnostics menu.
F5
-If pressed at length, it locks/unlocks the tare.
- Commands the data transmission to the printer serial port.
F6
-After the sample has been started, it executes the totalization.
- In the numeric or alphanumeric phase, it decreases the blinking digit.
- It allows scrolling ahead inside the menu steps or in the parameters within a step.
F7
-It allows to start a new sample.
- In the numeric or alphanumeric input phase, it increases the blinking digit.
-It allows scrolling backwards in the menu steps or in the parameters within a step.
F8
-If pressed for an instant, it executes the printing and the zeroing of the partial total.
- In the numeric or alphanumeric input phase, it selects the digit to be modified from right to left.
F9
-If pressed for an instant, it executes the printing and the zeroing of the general total.
- In the numeric or alphanumeric input phase, it selects the digit to be modified from left to right.
F10
-If pressed for an instant, it executes the printing and the zeroing of the large total.
- In the numeric or alphanumeric input phase, it enters a space between two characters.
NUMERIC
KEYBOARD
-Entry of digits or characters.
- While weighing, these enter a numeric value with which it’s possible to:
1) set the tare value, by pressing subsequently TARE key (see section 7.2)
2) execute calculations (see section ”CALCULATOR”).

3590EKR, 3590EXP, 3590EXT, CPWE, CPWET series indicator E-AF04_03_16.05_EN_U
11
4.2 "2ndF" KEY: SECOND FUNCTION OF THE KEYS
In the weighing phase, by pressing the 2ndF key together with another key, it’s possible to execute various functions
(continue reading the manual for the details of the functions):
2ndF
TARE/ZERO
Cyclical scale zero on the connected scales
2ndF
F1
Print/Clearing of Total of each handled Article
2ndF
F3
Prints weighs’report
2ndF
F5
Repetition of the last printout made.
2ndF
F7
Prints article report
2ndF
F8
Net/Gross Conversion 1
2ndF
F9
Modification of what is viewed on the display
2ndF
F10
Sets the lower totalisation threshold
2ndF
0
Selection of remote scale
2ndF
1
Selection of scale 1
2ndF
2
Selection of scale 2
2ndF
3
Selection of scale 3
2ndF
4
Selection of scale 4
4.3 ENTERING ALPHANUMERIC TEXT
It might be necessary, while the weighing system is working, to enter some alphanumerical texts such as descriptions,
alphanumerical messages (operator, lot number, customer, etc.).
To enter the characters one uses the 0 to 9 keys.
By pressing one of these keys a few times, the characters shown on the key (and other special characters) will be shown
on the display: initially the first letter in the bottom left will appear, and then the other characters towards the right.
After digiting a character, the blinking cursor, after a few instants, advances automatically of a position.
Function of the keys
F5
switches the writing mode from “numeric” (nuM) to “characters” (ChAr).
In the nuM mode one enters just the numbers, while in the ChAr mode one can enter all the characters of
a key.
C
If pressed for an instant, it cancels the written characters: first the characters that follow the cursor are
cancelled; than those that precede it, one at a time.
If pressed at length, it deletes all entered characters.
With empty text, it exits the entry phase without confirming.
SHIFT
It enters a space in the middle of a text.
./HELP
If pressed a few times it allows entering the following characters: . , ; : # < > \ | ” % & / ( ) = ? ^ ’ [ ] { }.
0
In “characters” mode (ChAr), by pressing once a space is entered; by pressing twice it enters the “0”
character.
1
In “characters” mode (ChAr), pressed repeatedly, it allows to enter the following symbols:
? ! 1 @ ’ + – * / = ~ € „ … † ‡ ˆ ‰ š < OE ž ı ’ “ ” • – –˜ ™ Š > oe ž ¢ £ ¤ ¥ ¦ § ¨ © ª « ¬ - ® ¯ ° ± ² ³ ´ μ ¶ · ¸
¹ º » ¼ ½ ¾ ¿ ã.

Moves the blinking cursor to the left or to the right.

Scrolls in one sense or the other the list of all the enterable characters (0, 1…9, A, B…Y, Z)
1
In case of APPROVED instrument and active tare, the gross weight will show for about 5 seconds, then return to the net weight visualization.

3590EKR, 3590EXP, 3590EXT, CPWE, CPWET series indicator E-AF04_03_16.05_EN_U
12
Examples:
-To enter the letter “B” one should press the “2” key twice in the ChAr mode.
-To enter the number “3” one should press the “3” key four times (in the ChAr mode) or press the F5 key (one passes to
the nuM mode) and press the “3” key once.
4.4 DISABLING THE KEYBOARD
It is possible to disable the all keyboard functions (except the Ckey for turning on and off), in order to avoid undesired
pressings of the scale keys:
-To lock the keyboard, press at length the F1 key: the display shows the “LoCK” message for a few instants. Now the
keyboard is LOCKED: if one presses a key, the display shows for a few instants the “HOLD F1 TO UNLOCK” message.
-To unlock the keyboard, press again at length, the F1 key: the display shows the “unLoCk” message for a few instants.
NOTE: It’s possible to lock all keys individually in a permanent way through the TECHNICAL SET-UP, TECH.MAN.REF.
4.5 HELP MENU
By pressing at length the HELP key it is possible to access a menu containing the list of keys with the relative function, and
status (locked or unlocked) indication.
The display shows:
- in the upper part: the key, followed by the code of the linked function in the << F.Keys >> step, and a symbol
indicating whether the key is unlocked ( ) or locked ( ) in the << EN.KEYS >> step.
- in the lower part: the description of the linked function.
NOTE: If the remote control has been configured on "IR 4", "RD 6" or "RD.BR 6", by pressing at length the HELP key, it's
also possible to visualise the function of the keys of the remote control.
Scroll the list with the arrow keys , press the Ckey to exit.
F1:306  C
DATABASE
ARTICLES

3590EKR, 3590EXP, 3590EXT, CPWE, CPWET series indicator E-AF04_03_16.05_EN_U
13
4.6 INDICATOR CONNECTED TO PC KEYBOARD
It’s possible to connect a PC keyboard (optional), used to emulate the functions of the indicator keys.
The keys are managed in the following way:
KEYBOARD
KEY OR FUNCTION EMULATED
Esc
- C key.
- If pressed at start-up, it allows entering in the technical set-up.
- In the alphanumeric input, it deletes all entered characters.
e Canc
- C key.
- If pressed at start-up, it allows entering in the technical set-up.
- In the alphanumeric input, it cancels first the characters which follow the cursor, then the ones
which precede it, one at a time.
Enter

-Fn key.
- Confirms the entered value.
- Enters the displayed step
Numeric and
alphanumeric
keys, SHIFT and
CAPS LOCK
- Quick entry of a numeric and alphanumeric string: through the CAPS/LOCK or SHIFT key it is
possible to switch from the capital letters to the lower case letters, and vice versa, or enter the
second character corresponding to the key (for example ", %, &, /, ? )
Cursor keys

- Scroll the parameters
- Increase or decrease the blinking digit while entering a value.
Cursor keys

- When entering a value or an alphanumeric string, it scrolls the digits to the right or to the left.
F1, F2….F10
F1,F2….F10 keys.
F11
2ndF key
F12
TARE key.
NOTE: through the remote keyboard, it’s not possible to carry out the functions made by pressing the keys at length.
4.6.1 DIRECT COMPILATION OF INPUT TEXT
By entering an alphanumeric text through an external keyboard the instrument goes in alphanumeric clipboard mode; by
pressing a function key from F1 to F9 programmed with a direct function to compile an input text (121 up to 130) the edited
alphanumeric text is assigned to the corresponding input text.
Alphanumeric clipboard contains up to 32 characters.
4.7 REMOTE CONTROL
Depending on the model of indicator, it is possible to remotely control the instrument through one of the following types of
remote controls: 18-key infrared (ir) or 6-key radio (rd).
The type of remote control to be used must be selected in the Setup environment, in the << inF.Red >> step
(TECH.MAN.REF).
NOTE: The infrared remote controls are for indoor use only.

3590EKR, 3590EXP, 3590EXT, CPWE, CPWET series indicator E-AF04_03_16.05_EN_U
14
4.7.1 “19-KEY” INFRARED REMOTE CONTROL
With this type of remote control, the functioning of the keys will be as described in the following table.
FUNCTION OF THE KEYS
4.7.2 TELECOMANDO RADIO A 6 TASTI
With this type of remote control, the functioning of each key can be programmed so that it is matched to one of the available
keys of the indicator.
This configuration must be carried out in the Setup environment, in the << inF.Red >>, after the selection of this type of
remote control.
By pressing the ./HELP key of the indicator, it’s possible to see, while weighing, the list of the functions matched to the keys
of the indicator and also to the keys of the remote control (see section 4.1.4).
EXAMPLE OF CONFIGURATION
USE OF VARIOUS REMOTE CONTROLS WITH ONLY ONE INDICATOR
If one works with only an indicator, it is possible to use any 6-key remote control, without combining it to the indicator,
therefore without limiting the number of usable remote controls.
To enable this mode one has to first select “RD 6 BR” in the << inF.Red >>.
KEYBOARD
KEY OR FUNCTION EMULATED
F1…F3
F1…F3 keys
C
C key
NUMERIC KEYS
Entry of digits
TARE / 
Tare/zero function or increase of a digit while entering a
value
.
./HELP key
ZERO / 
Decrease of a digit while entering a value
MODE / 
Scrolls the digits to the right while entering a value
PRINT / 
Confirms the entered value or enters the displayed step

3590EKR, 3590EXP, 3590EXT, CPWE, CPWET series indicator E-AF04_03_16.05_EN_U
15
USE OF VARIOUS REMOTE CONTROLS WITH SEVERAL INDICATORS IN THE SAME AREA
If one needs to use several indicators in the same area, it is possible to combine each remote control to the desired
indicator, in order to execute the function only on it and therefore avoid emulating the function on all indicators in use.
By enabling this mode it will be possible to combine up to 3 different remote controls (e.i. for 3 different operators) for each
indicator.
To enable this mode one has to first select “RD 6” in the << inF.Red >> (TECH.MAN.REF).
To link a new remote control to the indicator one has to:
- press at length 1and 2keys together (3 seconds).
- the instrument displays "aut.rd?"
- press the ENTER key of the indicator
- the new remote control is linked
To remove the linking of a remote control one has to:
- press at length 1and 2keys together (3 seconds).
- the instrument displays "aut.rd?"
- press the Ckey of the indicator; if the remote control was previously linked, it will be removed.

3590EKR, 3590EXP, 3590EXT, CPWE, CPWET series indicator E-AF04_03_16.05_EN_U
16
5. FUNCTION DISPLAY
During the weighing the displays are subdivided mainly in 3 sections, shown in the figure below:
-WEIGHT
-STATUS INDICATORS (led pilot lights / or graphic symbols)
-DATA (two lines in the 3590E; one or two lines in the CPWE/CPWET, depending on the weight zoom function, see
following section).
Figure 1: 3590E displays
Figure 2: CPWE/CPWET display
NOTE: If the EEEEE message appears, this means that the value exceeds the maximum number of digits shown by the
instrument.
5.1 WEIGHT ZOOM
The zoom function allows to increase the size of the weight digits, in order to ease the reading from a distance; with the
active zoom, the data is shown on a single line.
Through the << ZOOM.W >> step, one can disable/enable the function and set a delay which determines the activation
mode:
- always active function (with delay equal to 0), or
- disabled function at the pressing of a key and reenabled automatically when the keyboard inactivity time reaches the
configured delay period (with delay greater than 0).
NET 1.000kg
B1 TARE 0.000kg
GROSS 1.450kg
ARTICOLO 1
B1 TARA 1.250kg

3590EKR, 3590EXP, 3590EXT, CPWE, CPWET series indicator E-AF04_03_16.05_EN_U
17
5.2 STATUS INDICATORS
LED
FUNCTION
POWER
Indicates the type of indicator power supply:
-red pilot light: through built-in power adapter;
-green pilot light: through battery (charged battery);
-pilot light off: through battery (discharged battery).
0
Indicates that the weight detected by the weighing system is near zero, including the interval of 1/4 +1/4 of
the scale’s division.
~
Indicates that the weight is unstable.
NET
Indicates that the weight shown by the display is a NET WEIGHT.
T
Indicates that a tare value has been acquired or entered.
g
Indicates that the unit of measure in use is the gram.
kg
Indicates that the unit of measure in use is the kilogram.
t
Indicates that the unit of measure in use is the ton.
PCS
Not used in this application
F
Not used in this application
START
Not used in this application
STOP
Not used in this application
W1 W2 W3
See section MULTIRANGE AND MULTIDIVISION FUNCTION
SP1
Not used in this application
SP2
Not used in this application

3590EKR, 3590EXP, 3590EXT, CPWE, CPWET series indicator E-AF04_03_16.05_EN_U
18
SYMBOLS SHOWN ON THE LCD DISPLAY
SYMBOL
FUNCTION
The weight detected by the weighing system is near the zero, included within the interval
of –1/4 and +1/4 of the scale division.
The weight is unstable.
The displayed weight is a GROSS WEIGHT (depending on the software language).
The displayed weight is a NET WEIGHT.
A tare value has been acquired.
A manual tare value has been entered.
Unit of measure in use: ton, kilogram, gram, pounds, millilitres, or millivolts.
Active weighing range, see section 8.
Active scale (see section 5).
Indicates that a specific function of the instrument is active.
Battery charge level: see section 4.2.3.
Status output, respectively non active and active. Icon viewable only with active
DIAGNOSTICS PERIPHERAL UNITS function, see section 15.5.
Status input, respectively non active and active. Icon viewable only with active
DIAGNOSTICS PERIPHERAL UNITS function, see section 15.5.
Serial communication status with external device. Icon viewable only with active
DIAGNOSTICS PERIPHERAL UNITS function, see section 15.5.
Active during the configuration of the date and time.
Locked keyboard, see section 4.1.3
In the HELP menu these respectively indicate whether a key is unlocked or locked in the
SETUP level (<< En.KEYS >> step, see section 4.1.4.
The Fn key has been pressed.
The 2nd Fkey has been pressed.
Transmission of the data to the printer serial port under way.
Inside the step, these respectively indicate an unselected or selected parameter.
Active calculator function, see section 15.1 CALCULATOR.

3590EKR, 3590EXP, 3590EXT, CPWE, CPWET series indicator E-AF04_03_16.05_EN_U
19
5.3 BATTERY LEVEL INDICATION
The indicator is able to recognise whether it is powered by mains or by battery, and indicate its charge level; to enable the
battery level indication, one should configure the << bt.LEVEL >> step.
The charge level is shown during weighing by the battery symbol.
- : charged battery.
- : partially charged battery.
- : discharged battery: connect the indicator to the mains for recharging the battery (if provided for by that model) or
replacing the battery. Furthermore, the "Low.bat " message will appear for a few seconds on the display (voltage at
minimum level).
The indicator shows also when the battery is being recharged (if provided for the model):
RECHARGE PHASE: …
COMPLETED RECHARGE:
NOTES:
- During the recharge the instrument can be normally used.
- The instrument automatically turns off when the voltage goes below the minimum level.
5.4 "TILT" DEVICE
The TILT is a device which inhibits the indicator’s weighing system and starts working when the instrument’s inclination is
greater than 2% for the pallet truck application or 5% for application on lift trucks.
The “tilt” message is shown on the display, alternately with the weight value.
The activation of the tilt alarm has a delay of about three seconds from the detection of the exceeding inclination.
See the electrical connection scheme (TECH.MAN.REF.) for the connection of the device.
5.5 MODIFICATION OF THE DISPLAYED DATA
3590E
The data is displayed on two lines; by pressing in sequence the 2nd F and F9 keys, one scrolls in order the following
visualisations:
NUM.
VISUALISATION
0
First article description or net/gross weight.
Active scale and active semiautomatic tare (PT if manual tare).
1
Lot Description.
Active scale, number of lines and number of weighs.
NOTE: this visualisation is available with an active sample.
2
Tolerance signalling (see section 13.5).
NOTE: this visualisation is available with an active sample.
3
Target.
Weight/Volume average (shows in reverse if the average is under the
target).
NOTE: this visualisation is available with an active sample.
ARTICLE DESCRIPTION
B1 TARE 0.00 kg
DESCRIPTION
B1 –L0 NP.000/030
TARGET 100 g
AVG. 100.00 g
3 2 1 Ta 1 2 3


3590EKR, 3590EXP, 3590EXT, CPWE, CPWET series indicator E-AF04_03_16.05_EN_U
20
By linking the function to a direct key, see the << F.KEYS >> step, it is possible to quickly recall a visualisation by digiting,
with the numeric keyboard, the relative number and pressing the key linked to the function.
Furthermore, by linking the number of a specific visualization to the function (preamble function in the << F.KEYS >> step),
it is possible to select it directly with a direct key, for example F1 key to select the visualization n.1, and F2 key to select the
visualization n. 2.
Notes:
- Default Visualisation: 0.
- If the EEEEE message appears, this means that the value exceeds the maximum number of digits shown by the
instrument.
CPWE/CPWET
VISUALISATION WITH NON ACTIVE WEIGHT ZOOM
The data is shown on two lines under the “weight” section; by pressing in sequence the 2nd F and F9 keys, one scrolls in
order the following visualisations:
NUM.
VISUALISATION
0
First article description or net/gross weight.
Active scale and active semiautomatic tare (PT if manual tare).
1
Lot Description.
Active scale, number of lines and number of weighs.
NOTE: this visualisation is available with an active sample.
2
Tolerance signalling (see section “TOLERANCE LEVEL
INDICATION AND MANAGEMENT OF THE LINKED OUTPUTS”).
NOTE: this visualisation is available with an active sample.
3
Target.
Weight/Volume average (shows in reverse if the average is under
the target).
NOTE: this visualisation is available with an active sample.
By linking the function to a direct key, see the << F.KEYS >> step, it is possible to quickly recall a visualisation by digiting,
with the numeric keyboard, the relative number and pressing the key linked to the function.
Furthermore, by linking the number of a specific visualization to the function (preamble function in the << F.KEYS >> step),
it is possible to select it directly with a direct key, for example F1 key to select the visualization n.1, and F2 key to select the
visualization n. 2.
Notes:
-Default Visualisation: 0.
-If the ZOOM function is always active, these visualizations are not be displayed.
-If the EEEEE message appears, this means that the value exceeds the maximum number of digits shown by the
instrument.
ARTICLE DESCRIPTION
B1 TARE 1.000kg
DESCRIPTION
B1 –L0 NP.000/030
3 2 1 Ta 1 2 3

TARGET 100 g
AVG. 100.00 g
