Dino lift DINO 105TL User manual

OPERATING
INSTRUCTIONS
Manufacturer:
Dinolift Oy
Raikkolantie 145 | FI-32210 LOIMAA
Tel. + 358 20 1772 400 | [email protected] | www.dinolift.com
DINO
105TL

3
TRANSLATION OF THE ORIGINAL INSTRUCTIONS
Valid from serial number
105TL 10196 -

4
Operating instructions • DINO 105TL
CONTENTS
1. TO THE OPERATOR................................................................................................... 7
1.1. OVERVIEW OF THE UNIT.................................................................................. 8
1.2. INTENDED USE OF THE WORK PLATFORM ................................................... 8
2. TECHNICAL SPECIFICATIONS ................................................................................. 9
2.1. DIMENSION DRAWING.................................................................................... 10
2.2. REACH DIAGRAM ............................................................................................ 11
2.3. EXAMPLE OF THE MACHINE’S NAMEPLATE ................................................ 12
2.4. EXAMPLE OF EU DECLARATION OF CONFORMITY .................................... 13
2.5. SAMPLE OF INSPECTION PROTOCOL FOR THE ACCESS PLATFORM ..... 14
3. SAFETY..................................................................................................................... 16
3.1. SAFETY INSTRUCTIONS................................................................................. 16
3.2. SAFETY-RELATED NOTIFICATIONS............................................................... 20
3.3. SAFETY DEVICES............................................................................................ 22
4. STRUCTURE AND FUNCTIONS OF THE LIFT ....................................................... 24
4.1. STRUCTURE OF THE LIFT.............................................................................. 24
4.2. FUNCTIONS OF THE WORK PLATFORM....................................................... 25
4.3. OPERATING CONTROLS FOR THE FUNCTIONS.......................................... 26
4.3.1. Operating controls in the chassis control centre..........................................................26
4.3.2. Operating controls for the outriggers ........................................................................... 27
4.3.3. Operating controls in the platform control centre.........................................................28
5. OPERATING INSTRUCTIONS .................................................................................. 29
5.1. START-UP ......................................................................................................... 29
5.1.1. Worksite inspection...................................................................................................... 29
5.1.2. Positioning the lift......................................................................................................... 30
5.1.3. Starting up ................................................................................................................... 31
5.1.4. Supporting the lift......................................................................................................... 31
5.2. OPERATION...................................................................................................... 32
5.2.1. Operating the lift from the chassis control centre ........................................................32
5.2.2. Operating the lift from the platform control centre ....................................................... 33
5.2.3. Special instructions for winter use ............................................................................... 35
5.2.4. Ending the work ........................................................................................................... 35
5.3. TRANSFERRING THE LIFT.............................................................................. 36
5.3.1. Preparing the lift for transport ...................................................................................... 36
5.3.2. Using the driving device............................................................................................... 37
5.3.3. Towing the lift ............................................................................................................... 39
5.3.4. Lifting the device.......................................................................................................... 40
5.4. LONG-TERM STORAGE .................................................................................. 41

5
5.3. IN CASE OF EMERGENCY.............................................................................. 42
5.3.1. When at risk of losing the stability ...............................................................................42
5.3.2. In case of overloading.................................................................................................. 42
5.3.3. In case the power supply is interrupted ....................................................................... 42
5.3.4. In case of malfunction, when even the emergency descent system is not operational43
6. INSTRUCTIONS FOR FAULT-FINDING ................................................................... 44
7. MAINTENANCE SCHEDULE.................................................................................... 48
7.1. SCHEDULE FOR INSPECTIONS REQUIRED BY THE AUTHORITIES .......... 50
7.2. LUBRICATION PLAN ........................................................................................ 51
8. ROUTINE MAINTENANCE DURING OPERATION .................................................. 52
8.1. INSTRUCTIONS FOR DAILY MAINTENANCE AND INSPECTIONS .............. 53
8.1.1. Check the condition of chassis, the boom and the work platform................................ 53
8.1.2. Check the tyres and tyre pressure...............................................................................53
8.1.3. Check the lights ........................................................................................................... 53
8.1.4. Check the hydraulic oil level ........................................................................................ 53
8.1.5. Check the hydraulic hoses, pipes and connectors ...................................................... 53
8.1.6. Check the operation of the safety limit switches..........................................................54
8.1.7. Check the operation of the emergency descent, the emergency stop and the sound
signal 54
8.1.8. Stickers, plates and instructions .................................................................................. 54
9. CHANGE OF OWNER............................................................................................... 57

6
Operating instructions • DINO 105TL
BLANK

7
1. TO THE OPERATOR
Keep this manual on the work platform of the lift in the box reserved for it. If the instruction
manual gets lost, damaged, or for some other reason becomes unreadable, order a new
manual from the manufacturer.
This manual is intended to familiarise the user with the structure and functions of the work
platform, as well as with its appropriate use. The manual provides guidance on the service
measures that are the responsibility of the user of the work platform.
Other maintenance procedures on the work platform require special skills, special tools or
accurate knowledge about measurements or adjusted values. Guidance for these measures
is provided in a separate service manual. For situations that require service or repair
measures, contact the authorised service provider, importer or manufacturer.
DANGER
WARNING
CAUTION
NOTICE
Read all the instructions in this manual before using the aerial work platform. Make sure that
you have understood all the instructions. The instructions must absolutely be followed during
operation and maintenance of the aerial work platform.
When handling the unit, in addition to the instructions in this manual, the user must also
observe the local legislation, the guidelines stipulated by the employer, and regulations valid
at the work site.
Dinolift Oy is constantly developing its products. For this reason, the contents of this manual
might not always be in full compliance with the most recent version of the product. Dinolift Oy
reserves the right to modify the product without prior notice. Dinolift Oy assumes no liability
for any problems caused by changed or missing data or mistakes in this manual.
Please consult your dealer or the manufacturer for more information and detailed
instructions.

8
Operating instructions • DINO 105TL
1.1. OVERVIEW OF THE UNIT
This unit is a trailer mounted, towable aerial work platform.
This aerial work platform complies with the standard EN280 type 1. Moving the lift by means
of the driving device or by towing is possible only when the lift is in the transport position.
For the operation, the tyres of the lift shall be raised off the ground by means of the hydraulic
outriggers.
1.2. INTENDED USE OF THE WORK PLATFORM
The aerial work platform is exclusively intended for transferring people and tools to the work
position and acting as a work platform within its permissible load-bearing capacity and reach
(refer to the “Technical Specications” table and the “Reach Diagram”).
The intended use also covers:
• Following all the instructions in the Operating Instructions
• Performance of the inspections and maintenance operations.
• Observation of the occupational safety regulations and road trafc regulations.
This aerial work platform is NOT insulated, and does not offer protection against contact with
electric current. The aerial work platform must not be used for work on electric systems.
Observe the safety instructions concerning the operating environment, and the restrictions
given in them,
DANGER
WARNING
CAUTION
NOTICE
The operator must receive instructions and consent from the manufacturer for all
such specic work methods or conditions that the manufacturer has not explicitly
dened in the unit's operation and maintenance instructions.
The primary power source of the lift is the electric motor. The outriggers and the boom
system are hydraulically powered.
As an option, the lifts can be equipped with a hydraulic driving device.
Consult the chapters “Technical data" and “Structure and functions of the work platform" in
this manual for more detailed information about the lift.

9
2. TECHNICAL SPECIFICATIONS
105TL
Max. working height 10.5 m
Max. platform height 8.5 m
Max. outreach to the side 6.5 m
Boom rotation ± 355°
Platform rotation -
Turn area refer to the reach diagram
Support width 3.57 m
Transport width 1.49 m
Transport length 5.45 m
Transport height 1.98 m
Weight 955 kg
Max. allowed load on platform 130 kg
Max. number of persons + additional load 1 person + 50 kg
Max. allowed sideways load (caused by persons) 200 N
Max. lateral inclination (chassis) ±0,3°
Maximum allowed gradient of ground to the side
Maximum allowed gradient of ground lengthwise
Max. wind speed during operation 12,5 m/s
Min. ambient temperature when working -20 °C
Max. support force on the outriggers 7500 N
Platform size 0,7 x 0,85 m
Gradeability using the driving device (optional) 15%
Socket outlets on the platform 2 x 230V/50Hz/10A
Power supply Mains current
230V/50Hz/10A
Sound pressure level < 70 dB
Whole-body vibration Not detectable

10
Operating instructions • DINO 105TL
2.1. DIMENSION DRAWING

11
2.2. REACH DIAGRAM
4CB6974
ULOTTUMAKAAVIO
DINO 105 TL
SFS-EN 22768-1
08.01.2013
_
Nro Piirr.nro Nimitys Muoto / Malli Materiaali Kpl
0
1
2
3
4
5
6
7
8
9
10
11
0123456712
0
5
10
15
20
25
30
35
05 5 10 15 20
m
ft
130 kg
286 lbs
08.01.2013 Ent.
Piirt.
Suunn.
Massa
Kg
Hyv.
Yleistoleranssit Mittakaava Tuote Liittyy
Uusi
Rev.

12
Operating instructions • DINO 105TL
2.3. EXAMPLE OF THE MACHINE’S NAMEPLATE
The name of the manufacturer, and the production number and serial number of the machine
have been marked on the nameplate as shown in the picture below.
The nameplate of the lift is located on the
right-hand side of the chassis, as shown in
the picture.
The serial number is also engraved in the
lift's chassis, on the upper surface of the
right-hand tow-bar.
The nameplate of the trailer is located on the chassis, on the right-hand side of the
nameplate of the lift.
Following data is written on the plate:
EU Type Approval Number (if available)
Serial number
Total weight kg
0Maximum allowed weight on the towing
hitch kg
1 Maximum allowed axle weight kg
2 kg
Raikkolantie 145
32210 Loimaa
FINLAND
400 N
230 V
-20 C
o
12,5 m/s
50 Hz
o
kg
kg
DINO
54.1329
Serial number
Type Manufacturer
Year of manufacture Manufacturer's address
Voltage Frequency
Min. ambient temperature
when working
Maximum allowed wind speed
Weight kg Max. allowed load on platform 130
Maximum allowed sideways
load
Max. lateral inclination (chassis) 0.3
Maximum allowed number of
persons
Maximum allowed additional
load
1 50
200

13
2.4. EXAMPLE OF EU DECLARATION OF CONFORMITY
EU declaration of conformity for machine
Manufacturer:
Dinolift Oy
Raikkolantie 145
FI-32210 Loimaa,
which has authorised the Chief Engineer Mr. Santtu Siivola, Dinolift Oy, Raikkolantie 145,
32210 Loimaa, FINLAND, to draw up the Technical Construction File,
declares that
DINO 105TL Aerial Work Platform no YGCD105TLH0010277
complies with the provisions of the Machine Directive 2006/42/EC and its amendments as
well as the national decree (VNA 400/2008), through which they have been brought into effect
as well as the regulations of the Low Voltage Directive 2000/14/EC and the EMC Directive
2014/30/EC.
Notied body no. 0537,
VTT
P.O.Box 1300
FI-33101 Tampere
FINLAND
has granted the certicate no. VTT 182 / 524 / 13
In designing the machine, the following harmonised standards have been applied:
SFS-EN 280/A1+A2; SFS-EN 60204-1/A1
Loimaa 08.06.2017
-----------------------------------------
Santtu Siivola
Chief Engineer

14
Operating instructions • DINO 105TL
2.5. SAMPLE OF INSPECTION PROTOCOL FOR THE ACCESS PLATFORM
TEST CERTIFICATE
DATE: I
START-UP TESTS:
Inspection place: Dinolift Oy Inspector's signature: I
I
BASIC INFORMATION
Manufacturer: Dinolift OY Place of manufacture: Finland
Address: Raikkolantie 145
32210 LOIMA
A
Importer:
Type of lift:
Chassis:
Boom:
Load control:
Outriggers:
TECHNICAL SPECIFICATIONS
Machine and type: DINO 105TL Max. platform height 8,50 m
Number of manufacture IMax. outreach: 6,50 m
Year of manufacture I
Max. lifting capacity: 130 kg Boom rotation: +/- 355°
Max. person number: 1Support width: 3,25 x 3,3 m
Max. additional load: 50 kg Transport width: 1,50 m
Power supply: 230 VAC Transport length: 5,44 m
Lowest temperature: -20 °C Transport height: 1,99 m
Weight: 955 kg Platform size: 0,85 x 0,7 m
Boom platform Scissor platform Mast platform
Car Self propelled Trailer mounted
Articulated boom Telescopic boom Articulated telescopic boom
Position control Moment sensing Load sensing
Hydraulic turning Hydraulic pushing Mechanical
Limited size of work
platform
Scissor
Stabilized with wheels
Vehicle mounted
(quick coupler)
Fixed mast Telescopic mast

15
The initial inspection and test loading of the Dino aerial work platforms is performed by the
manufacturer. A protocol, drawn up during the inspection, will accompany the lift.
The protocols of the start-up and periodic inspections must be kept with the lift or its
immediate proximity for at least ve years.
INSPECTION POINTS (Y = meet standards N = do not meet standards not applicable)
Y
N
Y
N
A. GENERAL REQUIREMENTS
1. Suitability for use D. ELECTRIC SYSTEM
2. Certificate of conformity 1. Electric system
3. User manual and storage 2. Electric appliances
4. Machine plate - inspection plate 3. Lights
5. Instructional and safety plates
6. Safety colours E. SAFETY AND CONTROL DEVICES
1. Safety sensors and limit switches
2. Sound signal
3. Emergency descent system
B. STABILITY 4. Protection of controls
1. Load plate and reach diagram 5. Symbols / control directions
2. Supports / outriggers 6. Placement of controls
3. Indicator for horizontal position 7. Emergency stop
C. STRUCTURES F. SAFETY FEATURES
1. Transport position / transp. equipment 1. Prevention of unauthorized use
2. Driving/towing equipment 2. Locking device, covers and guards
3. Chassis 3. Prevention of lifting
4. Turning device 4. Prevention of opening of support
5. Boom system 5. Safety distances
6. Structure and position of work platform 6. Control of loading
7. Hydraulic system 7. Limiting devices
G. TEST LOADING
1. Overload test (150%) 195 kg
2. Functional test (110%) 145 kg
COMMENTS
DEFICIENCIES
Deficiencies have been repaired
Date: Signature:

16
Operating instructions • DINO 105TL
3. SAFETY
All the essential safety instructions and warnings, relevant to transport, use and maintenance
of the lift, are described in this chapter.
DANGER
WARNING
CAUTION
NOTICE
Failure to observe these instructions and safety regulations may cause a severe injury or
even death. Familiarise yourself with all the safety regulations, operating instructions and
signs afxed to the machine, and follow them.
Make sure that you understand all the safety instructions and regulations. Also make sure
that others operating the machine or working on the work platform are familiar with these
instructions.
3.1. SAFETY INSTRUCTIONS
Only specially trained personnel with authorisation in writing, who are well familiarised with
the device, and at least 18-years old, are allowed to operate the unit.
Keep the lift free of any dirt, which may impair safe operation, and impede the inspection of
the structures.
The device must be serviced and inspected regularly.
Only skilled persons, familiar with the service and repair instructions for the lift, are allowed
to carry out servicing and repair work.
It is strictly prohibited to use a lift which is out of order.
Never remove or disable any safety devices of the machine.
DANGER
WARNING
CAUTION
NOTICE
The device must neither be altered without the manufacturer’s consent nor be used under
conditions, which do not meet the manufacturer's requirements.
The operator must be given instructions and consent from the manufacturer for all such
specic work methods or conditions that the manufacturer has not explicitly dened.

17
TRANSFERS
Observe the maximum allowed gradient when transferring the lift. During transfer in rough
terrain, always try to position yourself higher than the machine.
Beware of xed or moving obstacles in the terrain or near the lift while driving. Make sure
that you have a clear view of the driving path.
Do not use the machine for towing.
WORK AREA AND PREPARATIONS BEFORE LIFTING WORK
When working in busy areas, the operating range of the lift must be clearly marked by using
either warning lights or fencing.
Also observe the road trafc regulations.
Ensure the unobstructed range of movement before operating the stabilisers.
The load-bearing capacity and the gradient of the base must be taken into account when
supporting the chassis. Do not operate the machine while it is placed on a truck, railway car,
oating vessel or other possibly unstable structures.
Ensure that the stabilisers cannot slide while on a gradient.
Additional support plates of adequate size must be used under the stabilisers, when working
on soft ground. Only use such additional support plates, on which the metallic stabilisers will
not slide.
While in the support position, ensure that the wheels are off the ground.
Always verify the horizontal position of the machine before operation.
Always ensure that the work area is clear of outsiders. Danger of getting crushed between
rotating and xed structures.
While operating the boom from the control centre on the turning device, beware of
getting pressed against the stabilisers or other structures that do not turn with the
boom.

18
Operating instructions • DINO 105TL
LIFTING AND WORKING ON THE PLATFORM
Never exceed the maximum number of persons, maximal loading or manual force, allowed
for the lift. Never add load onto the platform while in the upper position.
Before operating, always ensure that the safety devices and the emergency descent system
are in working order.
Use the safety harness! Fix the safety harness
to the xing points, intended for the purpose.
Note! The platform is tted with a xing point for the
safety harness of each user. Only one harness per
xing point.
Do not use ladders, steps or other similar equipment
on the platform.
Before operating the machine, make sure all gates are properly closed.
If the platform is tted with a ladder, the ladder must be locked in the upper position.
Never throw or drop any objects from the platform. All tools must be carried inside the work
platform. Never leave power tools hanging by the cord outside the work platform.
Do not carry tools, equipment or materials on or attached to the platform railing.
The lift must not be used as a crane.
The lift must not be used for transferring goods or persons between different oors or
working levels. Stepping on or off the platform in motion is prohibited.
When the boom is in its lowest positions, make sure it cannot clash during rotation with
structures that do not turn with the boom.
Always make sure, before lowering the platform, that the area under it is clear.
Avoid damaging the platform by lowering it on the ground, or bringing it in contact with any
structures.
Never use a lift alone. Make sure that there is always someone on the ground, who can call
for help in case of an emergency.

19
OPERATING CONDITIONS
The weather conditions, such as wind, visibility and rain, must always be taken into account
so that these will not adversely affect the safe performance of the lifting operations.
The use of the lift is prohibited, if
the temperature drops under -20 °C or
the wind speed exceeds 12.5 m/s
Wind speed ( m/s) Conditions on land
0 Calm Smoke rises vertically
1-3 Light breeze Smoke moves with the wind and the wind feels on exposed
skin. Leaves rustle.
4-7 Moderate
breeze
Leaves and small branches of trees are moving. Flag is
ying. Wind lifts dust and loose pieces of paper from the
ground.
8-13 Strong breeze
Small broad-leaved trees and large branches sway. Wind
whistles as it hits houses or other xed objects. Umbrella is
difcult to use.
14-17 Moderate gale All the trees are swaying. It is difcult to walk against the
wind.
NOTICE! Wind speed can be signicantly greater at height than at ground level.
Do not take tools/material of large surface area onto the platform. The increase in wind load
may jeopardize the stability of the device.
Beware of the live aerial power lines in the area – observe the minimum
safety distances:
Voltage area (from phase to
phase)
Minimum distance
Metres Feet
0–300 V Avoid contact
300 V–50 kV 3 10
50 kV–200 kV 4.5 15
200 kV–350 kV 6 20
350 kV–500 kV 8 25
500 kV–750 kV 11 35
750 kV–1000 kV 14 45
Observe these distances, if the worksite-specic instructions or the local or national
regulations do not require even longer safety distances.
This aerial work platform is NOT insulated, and does not offer protection against contact with
electric current. The aerial work platform must not be used for work on electric systems.

20
Operating instructions • DINO 105TL
3.2. SAFETY-RELATED NOTIFICATIONS
The following safety alert symbols and safety signal words are used in this manual.
Observe all the safety instructions that follow these symbols, in order to avoid dangerous
situations and personal injuries.
This is a general safety alert symbol and it is used to alert you about a potential
hazard. Observe the additional instructions given in form of text or symbols that
follow this symbol.
DANGER
WARNING
CAUTION
NOTICE
Red DANGER-message warns for an imminent or potential hazardous situation which, if not
avoided, may result in death or serious injury.
DANGER
WARNING
CAUTION
NOTICE
Orange WARNING -message is used in connection with potential risk factors, which if not
avoided, under certain conditions, may result in death or serious injury.
DANGER
WARNING
CAUTION
NOTICE
Yellow CAUTION -message is used to warn about a hazardous situation which, if not
avoided, could result in minor or moderate injury.
DANGER
WARNING
CAUTION
NOTICE
Blue notice-message is used to draw your attention to special notications or instructions
that are related to the operation or maintenance. Such messages include, for example,
instructions that are related to reliability of the machine or aim to avoid material losses.
