Directed 403.CHRYSLER6 User manual

DB3 403.CHRYSLER6
v2.14
2014 Dodge/Ram 3500
THCHD3, THCHD3-REV2 Compatible
(Sold Separately)

Introduction 3
Vehicle function compatibilities 4
Pre-installation and application warnings 5
Installation 6
Wiring diagram with T-Harness (THCHD3 Rev. 1 to 2) 6
Wiring diagram 7
Locating components in the vehicle 8
Vehicle connections 9
Module programming 11
Key2GO 12
Connecting the module 12
LED diagnostics and troubleshooting 13
Soft reset 15
Hard reset 15
Feature programming 16
Feature and option list 17
Limited one year consumer warranty 18
Quick reference guide (customer copy) 19
Contents

3403.CHRYSLER6 2.14 2014 Dodge/Ram 3500
©2022 VOXX•DEI LLC. All rights reserved.
Introduction
DB3 is an all-in-one door lock and override module.
Warning!
This module can only be flashed and configured using DirectLink at www.directechs.com or using the Directechs
Mobile application for smartphones. Refer to “Connecting the module” for more information.

4403.CHRYSLER6 2.14 2014 Dodge/Ram 3500
©2022 VOXX•DEI LLC. All rights reserved.
Vehicle function compatibilities
This section lists all the functions compatible with this vehicle for the installation illustrated in this guide.
Note: The telematics features listed below (with an asterisk) ONLY apply when using SmartStart.
Panic Mode Activation
Parking Lights Control
Arm Factory Security
Disarm Factory Security
Door Lock Control
Door Unlock
Driver Priority Unlock
Control of aftermarket alarm with OEM remote
Fuel level/EV battery level
Key2GO
Immobilizer Bypass-Data No Key Req'd
OEM Remote Start Activation using XL-202 or RF kit
RAP Shut Down (Retained ACC Power)
Remote Start Ready
Remote Start Takeover
SmartStart
Tach / RPM Output
Entry Monitoring ALL Door Pins
Entry Monitoring Hood Pin
Factory Alarm Trigger Monitoring
Brake Status (foot brake)
Door Locks Status
E-Brake Status
Ignition Status

5403.CHRYSLER6 2.14 2014 Dodge/Ram 3500
©2022 VOXX•DEI LLC. All rights reserved.
Pre-installation and application warnings
Firmware notes: This section highlights important information for this specific firmware and will assist in
pricing accordingly, as well as bringing awareness to any operational or vehicle limitations.
T-Harness
compatible THCHD3 (Rev. 1 to 2) Keys required for programming 1Keys required for operation 0
The optional Plug & Play THCHD3 (Rev. 1 to 2) T-Harnesses are sold sparately.
The OBDII Diagnostic Connector features will remain the same even when the T-Harness is installed.
The keyless entry control on the OEM Key FOB used during Key2Go programming will not work while the vehicle is remote
started.
Unless specified otherwise, all connectors are displayed from the wire side, with the exception of the OBDII diagnostic
connector.
Refer to the "Vehicle connections" section following the wiring diagram.
General notes: This section highlights important information for this specific firmware.
[1] The Tach wire is an optional connection required on some remote starters, which do not support a tach signal in D2D.
[2] The RAP Off connection is ONLY required if NOT supported in data.
