DMP Electronics 9000 Series Installation guide

FRI 2:52 PM
A
C
B
D
F
E
G
I
H
J
L
K
V
X
W
S
U
T
P
R
Q
M
O
N
Y
Z
E
N
T
E
R
B
A
C
K
ALL RESET HOME
CHIME PERIM SLEEP
1 2 3 4
5 6 7 8
9 0 CMD
A
POWE
R
R
M
E
D
INSTALLATION AND PROGRAMMING GUIDE
9000 Series
Wireless Keypad

TABLE OF CONTENTS
About the Keypad ...................................... 1
Features.............................................................................. 1
What’s Included............................................................... 1
Keypad Layout ............................................2
Enter Characters .........................................3
Number Pad ..................................................................... 3
Card Reader ..................................................................... 4
Two-Button Panic Keys................................................ 4
Backlit Logo..................................................................... 5
User Options Menu........................................................ 6
Backlighting Brightness .................................................. 6
Internal Speaker Tone....................................................... 6
Internal Volume Level....................................................... 6
Model Number .................................................................... 6
Serial Number...................................................................... 6
Select a Location........................................7
Install the Keypad.......................................8
Remove the Cover ......................................................... 8
Mount the Keypad ......................................................... 9
Power the Keypad ........................................................10
Primary DC Power Supply ............................................ 10
Standby Battery ............................................................... 10
Pair the Keypad ......................................... 11
Step 1: Enable Pairing at the Keypad.........................12
Step 2: Initiate Pairing at the Panel............................12
Program the Panel.................................... 13
Device Setup.......................................................................13
Program Keypad Options........................ 15
Keypad Options.................................................................15
Card Formats......................................................................17
No Communication with Panel ................................... 23
Keypad Language............................................................24
Additional Programming (9063 only) .................25
Proximity Credential Compatibility ..........................25
Program a Credential .....................................................25

Test the Keypad ....................................... 26
Keypad Diagnostics ........................................................26
Exit Installer Options ...................................................... 27
End User Training .....................................28
Keypad Arming and Disarming ..............................29
Area System Type ............................................................29
All/Perimeter System Type.......................................... 30
Home/Away System Type............................................ 30
Keypad Entry Delay ..................................................... 31
All Systems ..........................................................................31
Compatibility ............................................35
Panel Models..................................................................35
Public Card Formats...................................................35
Credentials......................................................................36
Product Specifications ............................37
Patents .............................................................................37
Compliance Listing Specifications ........38
Commercial Burglary..................................................38
Certifications.............................................38
Underwriters Laboratory (UL) Listed ..................38
FCC Information .......................................39
Industry Canada Information................. 40

9000 Series Installation and Programming Guide | Digital Monitoring Products, Inc. 1
ABOUT THE KEYPAD
The 9060 and 9063 are supervised keypads that provide installation flexibility. The backlit
keys are easy to read and when the system is in alarm, both the keyboard and logo turn
red.
Features
• Custom 32-character full LCD
display
• Three 2-button panic keys
• Backlit keys
• Internal sounder
• Wall tamper protection
• Keypad turns red in alarm
• Wireless Encryption (requires a
keypad with firmware Version 300
or higher and a panel with firmware
Version 183 or higher)
• Built-in proximity card reader
(Model 9063)
What’s Included
• One wireless keypad mounted in a
Thinline™ housing
• One internal rechargeable 3.7V
lithium battery
• One 12VDC Plug-in Power Supply
• Mounting hardware

Digital Monitoring Products, Inc | 9000 Series Installation and Programming Guide2
KEYPAD LAYOUT
FRI 2:52 PM
A
C
B
D
F
E
G
I
H
J
L
K
V
X
W
S
U
T
P
R
Q
M
O
N
Y
Z
E
N
T
E
R
B
A
C
K
ALL RESET HOME
CHIME PERIM SLEEP
1 2 3 4
5 6 7 8
9 0 CMD
A
POWE
R
R
M
E
D
Armed/Power
LEDs
Proximity
Credential Reader
and Backlit Logo
Keypad Display/
Status List
Select Keys
Panic Keys
Command
(CMD) Key
Back Arrow Key
1 43
2
Figure 1: 9000 Series LCD Keypad

9000 Series Installation and Programming Guide | Digital Monitoring Products, Inc. 3
ENTER CHARACTERS
Number Pad
1. Choose a character from the appropriate table.
2. Identify the Number that the character correlates with and press that key.
3. Identify the Select Key for the character and press that key. For lowercase Latin
characters, press the select key again.
4. If you want to enter another character, repeat steps 1 - 4.
5. When you’re finished, press CMD.
Table 1: Latin Characters
NUMBER
SELECT KEY
1 2 3 4
1 A B C ( [ {
2 D E F ) ] }
3 G H I ! ^ ~
4 J K L ? “ |
5 M N O / \ `
6 P Q R & $
7 S T U @ %
8 V W X , =
9 Y Z Space : _ ;
0 - + . ‘ * < # >
Table 2: Greek Characters
NUMBER
SELECT KEY
1 2 3 4
1 Α Β Γ ( [ {
2 Δ Ε Ζ ) ] }
3 Η Θ Ι ! ^ ~
4 Κ Λ Μ ? “ |
5 Ν Ξ Ο / \ `
6 Π Ρ Σ & $
7 Τ Υ Φ @ %
8 Χ Ψ Ω , =
9 Space Space Space : _ ;
0 - + . ‘ * < # >

Digital Monitoring Products, Inc | 9000 Series Installation and Programming Guide4
Card Reader
When a proximity credential is presented to the 9063 internal reader, located behind
the backlit logo, a beep tone is emitted to provide an audible acknowledgment of the
credential read.
Two-Button Panic Keys
All keypads oer a panic key function that allows users to send panic, emergency, or fire
reports to the central station in an emergency. Enable the panic key function in the keypad
user menu. Place the supplied icon stickers below the top row select keys. The user must
press and hold the two select keys for two seconds until a beep is heard.
Panic (left two select keys)—Zone 19 + Device Address
Emergency Non-Medical (center two select keys)—Zone 29 + Device Address
Fire (right two select keys)—Zone 39 + Device Address

9000 Series Installation and Programming Guide | Digital Monitoring Products, Inc. 5
Backlit Logo
The backlit logo indicates the armed status of the panel and the power and battery status
of the keypad.
COLOR AND ACTIVITY ARMED STATUS DC POWER STATUS BATTERY STATUS PAIRED
Green Steady Disarmed OK OK Yes
Green Blinking Disarmed OK Fault Yes
Red Steady Armed OK OK No
Red Blinking Armed Fault OK No
Red/Green Alternating Armed OK Fault Unknown
No Light Unknown Fault Unknown Unknown
Table 3: Logo Color and Behavior

Digital Monitoring Products, Inc | 9000 Series Installation and Programming Guide6
User Options Menu
To access the Options menu, press and hold the back arrow and CMD keys for 2 seconds.
Backlighting Brightness
Adjust the brightness, power and armed LEDs, green keyboard, and logo backlighting.
At SET BRIGHTNESS, use the left and right select keys to adjust the brightness. The
brightness reverts to maximum intensity whenever a key is pressed. If no keys are pressed
and the speaker has not sounded for 10seconds, the user-selected brightness restores.
Note: During primary power loss, the backlighting turns completely o after
10seconds of no activity to conserve the standby battery.
Internal Speaker Tone
Adjust the keypad internal speaker tone. At SET TONE, use the left select key to decrease
the tone and the right select key to increase the tone.
Internal Volume Level
Adjust the keypad internal speaker volume for key presses and entry delay tone
conditions. During alarm and trouble conditions, the volume is always at maximum level.
At SET VOLUME LEVEL, use the left select key to decrease the volume and the right select
key to increase the volume.
Model Number
Display the keypad model number, firmware version, and date.
Serial Number
Display the keypad’s serial number.

9000 Series Installation and Programming Guide | Digital Monitoring Products, Inc. 7
SELECT A LOCATION
Before installing the keypad, ensure that it will be able to communicate with the panel
from the location where you want to mount it. To test wireless communication with the
keypad’s built-in RF survey, complete the following steps.
1. Power the keypad.
2. Hold down the back arrow and CMD keys for two seconds.
3. Enter 3577 (INST) and press CMD.
4. Select KPD RF (wireless survey).
For more information, see Keypad Wireless Survey.

Digital Monitoring Products, Inc | 9000 Series Installation and Programming Guide8
INSTALL THE KEYPAD
Remove the Cover
The keypad housing is made up of two parts: the cover,
which contains the circuit board and components, and
the base.
To separate the keypad cover from the base, insert a
flathead screwdriver into one of the slots on the bottom
of the keypad and gently lift the screwdriver upward.
Repeat with the other slot. Gently separate the cover
from the base and set the cover containing the keypad
components aside. See Figure 2.
1
Figure 2: Separate the
Keypad Housing
Cover
Base

9000 Series Installation and Programming Guide | Digital Monitoring Products, Inc. 9
Mount the Keypad
All DMP keypads are designed to install on any desk stand, 4” plastic square box,
3-gang plastic switch box, or a flat surface. Do not install the keypad near metal
objects or other sources of interference.
Insert the included screws
into the mounting holes and
secure the keypad to the
wall, ensuring that the wall
tamper switch makes proper
contact. See Figure 3.
2
Black (-)
Black/White
stripe (+)
Wall
Tamper
Surface and Backbox Mounting Holes
Surface and Backbox Mounting Holes
Combined 4-Square and
3-Gang Switch Box
Mounting Holes
Figure 3: Mounting Holes on Keypad Back

Digital Monitoring Products, Inc | 9000 Series Installation and Programming Guide10
3Power the Keypad
Primary DC Power Supply
Locate the keypad near a wall outlet to allow connection of the Model 371-500
plug-in DC power supply. See Figure 4 for a diagram of the DC power supply
connector. In addition to powering the keypad, the power supply also charges the
internal back-up battery. The plug-in power supply includes a six foot cord. The cord
can be lengthened but should be located within 100feet of the keypad using 22AWG
wire.
Caution: Observe polarity when extending
the power supply cord.
When the power supply connector is plugged
into the keypad, the internal battery is
automatically connected. The keypad can
operate from battery only as long as the power
supply connector is plugged into the keypad.
Standby Battery
The keypad rechargeable battery provides 24hours of backup battery power when
primary DC power is unavailable. It is shipped already installed inside the keypad. The
battery is intended for backup power only and not to operate the keypad on a daily
basis. If the battery is low, or not plugged into the internal battery connector, a low
battery condition is indicated by the panel when the battery falls below 3.62VDC. To
restore the keypad from a low battery state, the voltage must be above 3.62 VDC.
Black (-)
Black/White
Stripe (+)
Figure 4: DC Power Supply Connector

9000 Series Installation and Programming Guide | Digital Monitoring Products, Inc. 11
PAIR THE KEYPAD
You can program up to 7 wireless keypads in a panel with XR Series Version 191 (3/8/19) or
higher and XT Series Version (11/15/19) or higher.
9000 Series wireless keypads can be programmed into the control panel by using the
wireless keypad pairing operation or by entering the serial number in Device Setup.
The keypad logo is red when it is not paired to a panel. The keypad logo turns green when
it is paired to a panel. If the light is not on, the keypad is not receiving DC power. For more
information, refer to Table 3.
Note: If you’re programming the keypad as a device type manually, skip this section
and go to Device Setup.
During pairing, unaddressed keypads are automatically assigned to the first open device
address based on the order in which they are detected.

Digital Monitoring Products, Inc | 9000 Series Installation and Programming Guide12
Step 1: Enable Pairing at the Keypad
Hold down the back arrow and CMD keys for two seconds. Enter 3577 (INST) and press
CMD. Select KPD RF (wireless survey). For more information, see Keypad Wireless Survey.
Step 2: Initiate Pairing at the Panel
Select one of the following methods to initiate pairing with the panel:
Pair Automatically (XTL Series Only)
Reset or power up the panel. For 60seconds, the panel listens for wireless keypads that
are in wireless survey and have not been programmed or paired to another panel.
Pair Manually (Any Compatible Panel Model)
Reset the panel 3times within 12seconds, allowing the panel’s Keypad Bus LEDs to turn
back on between each reset.

9000 Series Installation and Programming Guide | Digital Monitoring Products, Inc. 13
PROGRAM THE PANEL
Note: If you completed the steps in Pair the Keypad, you may skip this section unless
you need to configure device options like Supervision Time.
To access the Programmer menu, reset the panel, press Keypad in the carousel menu,
enter 6653 (PROG), then press CMD.
After completing each of the following steps, press CMD to advance to the next option.
Refer to the panel programming guide as needed.
DEVICE SETUP
Advance to DEVICE SETUP, then press a select area to enter
the setup menu.
Device Number
Set the keypad address at 1-16 for XR550 Series panels or 1-8
for other compatible panels.
Device Name
Press any select area, then enter a name for the wireless
keypad.
DEVICE SETUP
DEVICE SETUP
DEVICE NO: -
DEVICE SETUP
*UNUSED*

Digital Monitoring Products, Inc | 9000 Series Installation and Programming Guide14
Device Type
For use as a standard keypad, select KPD. For use as an access
control keypad, press any select area, then select DOOR.
Communication Type
Press any select area, then select WLS (Wireless) as the
communication type.
Serial Number
Enter the eight-digit wireless serial number. Range is
14500000-14999999.
Supervision Time
Press any select area and choose a supervision time. Options
are 0, 60, or 240 minutes.
DEVICE SETUP
TYPE: KEYPAD
DEVICE SETUP
COMM TYPE: WLS
DEVICE SETUP
SERIAL#:-
DEVICE SETUP
SUPRVSN TIME: 240
Configure additional options as needed. To configure custom card options for the keypad,
do not program CARD OPTIONS in Device Setup.

9000 Series Installation and Programming Guide | Digital Monitoring Products, Inc. 15
PROGRAM KEYPAD OPTIONS
Keypad Options and Keypad Diagnostic menus allow install and service technicians to
configure and test keypad operation. To access the installer options:
Hold down the back arrow and CMD keys for two seconds. At SET BRIGHTNESS, enter
3577 (INST) and press CMD.
The display changes to KPD OPT KPD DIAG and STOP. The Keypad Options menu allows
you to set the keypad address, select Supervised or Unsupervised mode, change the
default keypad message, selectively enable the 2-button Panic keys, Bypass, REX, and set
entry card options.
Note: All programming options display on all keypads. However, actual operation for
some programming options is restricted to the appropriate model.
KEYPAD OPTIONS
To program keypad options, press KPD OPT.
Serial Number
The keypad displays its serial number.
KPD KPD KPD
OPT DIAG RF STOP
SERIAL #:XXXXXXXX

Digital Monitoring Products, Inc | 9000 Series Installation and Programming Guide16
Default Keypad Message
Enter a custom message of up to 16characters to appear at
the top of the keypad display. Press any select key, enter a new
message, and press CMD.
Arm Panic Keys
Use this option to configure the select keys as two-button
panic keys. To enable or disable a panic option, press
the select key under the desired name: PN (panic), EM
(emergency), and FI (fire). Press the select key again to
disable the panic option. Once the panic option is enabled, an
asterisk displays next to the selected option(s).
ALL? NO YES (9063 Only)
Select the number of seconds (1-9) the keypad should
wait when an area system displays ALL? NO YES during
arming/disarming or a HOME/SLEEP/AWAY system waits
during arming only. If NO or YES, or HOME, SLEEP, or AWAY
is not manually selected before the delay expires, the keypad
automatically selects YES or AWAY. Select zero (0) to disable
this feature. The delay also occurs when any credential is
presented for arming the Home/Sleep/Away system. Default
is 2.
Enable Tamper?
Select YES to enable wall tamper protection. Default is NO.
DEFAULT KPD MSG:
ARM PANIC KEYS:
*PN EM *FI
ALL?: NO YES
DELAY: 2
ENABLE TAMPER?
NO YES
