INSTALLATION & OPERATING
INSTRUCTIONS
PATTY O’ROOMTM
MODELS
93500X.120 STANDARD
93500X.130 TALL
MODELS
935000.120 PATTY O’ROOMTM SIDE & DOORASM STD
935002.120 PATTY O’ROOMTM 2 FT. FRONT PANEL STD
935004.120 PATTY O’ROOMTM 4 FT. FRONT PANEL STD
935008.120 PATTY O’ROOMTM 8 FT. FRONT PANEL STD
935000.130 PATTY O’ROOMTM SIDE & DOORASM TALL
935002.130 PATTY O’ROOMTM 2 FT. FRONT PANEL TALL
935004.130 PATTY O’ROOMTM 4 FT. FRONT PANEL TALL
935008.130 PATTY O’ROOMTM 8 FT. FRONT PANEL TALL
FOR USE WITH
8500 9000
ONE STEP TWO STEP
SUNCHASER WEATHERPRO
SERIES A&E AWNINGS
Important:Instructionsmust staywithunit.
Owner read carefully

PATTYO’ROOMTM
2
SAFETY INSTRUCTIONS
Thismanualhassafetyinformationandinstructions
to help users eliminate or reduce the risk of acci-
dentsandinjuries.
RECOGNIZE SAFETY INFORMATION
Thisisthesafety-alertsymbol. Whenyouseethis
symbolin thismanual, bealertto thepotentialfor
personalinjury.
Followrecommendedprecautionsand safeoper-
atinginstructions.
UNDERSTAND SIGNAL WORDS
Asignal word ,WARNING OR CAUTIONis used
withthesafety-alertsymbol.Theygive the levelof
riskforpotentialinjury.
WARNING:means if the safety information is
not followed someone could be injured or killed
and/ordamageto equipmentcould occur.
CAUTION: means if the safety information is
notfollowedsomeonemightbeinjuredand/ordam-
ageto equipment mightoccur.
Readandfollowallsafetyinformationandinstruc-
tions.
!

PATTYO’ROOMTM
3
STANDARD HEIGHT PATTY O’ROOMTM
Ground to awning rail 93” to 110”
935000.120 Patty O’Room Side & Door Asm.- Standard
Consists of:
(1)ZipperedDoor-Standard(34” x93-1/2”)*
(1)LeftSide Panel -Standard
(1)RightSide Panel - Standard
(2)RafterPoles
(2)PoleHolder
(2)PoleHolderScrews
(11)Tent Stakes
(8)Poly Rope Clips
(13)TwistFasteners
(2)LoopFastenersAdhesiveBacked 1x3 “
(2)HookFastenersAdhesive Backed 1x3”
(1)CarryBag
(1) Vehicle skirt (28” x 300”)*
(2) Wheel Well Skirt (15” x 42”)*
935002.120 Patty O’Room 2’ Front Panel - Standard
Consists of:
(1) 2’Front Panel - Standard (24” x 93-1/2”)*
(2)Tent Stakes
935004.120 Patty O’Room 4’ Front Panel - Standard
Consists of:
(1) 4’Front Panel - Standard (48” x 93-1/2”)*
(2)Tent Stakes
935008.120 Patty O’Room 8’ Front Panel - Standard
Consists of:
(1) 8’Front Panel - Standard (96” x 93-1/2”)*
(3)Tent Stakes
TALLHEIGHT PATTY O’ROOMTM
Ground to awning rail 110” to 120”
935000.130 Patty O’Room Side & Door Asm. - Tall
Consists of:
(1)ZipperedDoor-Tall (34” x 103-1/2”)*
(1) Left Side Panel -Tall
(1) Right Side Panel - Tall
(2)RafterPoles
(2)PoleHolder
(2)PoleHolderScrews
(11)Tent Stakes
(8)Poly Rope Clips
(13)Twist Fasteners
(2)LoopFastenersAdhesive Backed 1x3 “
(2)HookFastenersAdhesiveBacked1x3”
(1)CarryBag
(1) Vehicle skirt (36” x 300”)*
(2) Wheel Well Skirt (15” x 42”)*
935002.130 Patty O’Room 2’Front Panel - Tall
Consists of:
(1) 2’Front Panel Tall (24” x 103-1/2”)*
(2) Tent Stakes
935004.130 Patty O’Room 4’Front Panel - Tall
Consists of:
(1) 4’Front Panel - Tall (48” x 103-1/2”)*
(2) Tent Stakes
935008.130 Patty O’Room 8’Front Panel - Tall
Consists of:
(1) 8’Front Panel - Tall (96” x 103-1/2”)*
(3) Tent Stakes
*DesignatesFinishedDimensions
PATTY O’ROOMTM SPECIFICATIONS
PATTYO’ROOMTM IDENTIFICATION
MODEL LETTER
935000.120 Side & Door Asm.- Std. AS
935000.130 Side & Door Asm. - Tall AT
935002.120 2’ Front Panel - Std. BS
935002.130 2’ Front Panel - Tall BT
935004.120 4’ Front Panel - Std. CS
935004.130 4’ Front Panel - Tall CT
935008.120 8’ Front Panel - Std. DS
935008.130 8’ Front Panel - Tall DT
AWNING SUGGESTEDPANELQTY
SIZE
Standard Tall
8’ AS, CS AT,CT
9’ AS, CS AT,CT
10’ AS, BS, CS AT, BT, CT
11’ AS, BS, CS AT, BT, CT
12’ AS, DS AT,DT
13’ AS, DS AT,DT
14’ AS, BS,DS AT, BT, DT
15’ AS, BS, DS AT, BT, DT
16’ AS, CS, DS AT, CT,DT
17’ AS, CS, DS AT, CT,DT
18’ AS, BS, CS, DS AT, BT, CT, DT
19’ AS, BS, CS, DS AT, BT, CT, DT
20’ AS, DS, DS AT, DT,DT
21’ AS, DS, DS AT, DT,DT
22’ AS, BS, DS, DS AT, BT, DT, DT
23’ AS, BS, DS, DS AT, BT, DT, DT
24’ AS, CS, DS, DS AT, CT, DT,DT
25’ AS, CS, DS, DS AT, CT, DT,DT
See Patty O’Room Panel Identificaton Letter Chart.
*DesignatesFinishedDimensions

PATTYO’ROOMTM
4
In order to correctly match the Patty O’Room to a particu-
larawning-RVcombination, the following information must
beknown:
A. centerofarm to centerofarmdimension,less4’ side
panelanddoorallowance.Dividethisfigurebythe2’
4’and 8’ panelsand/or;
B. Optional Length divide by 2’ 4’ and 8’ panels
C. the height of the awning rail (93” to 110” Standard
height - 110” to 120” Tall Height). See FIG. 1.
FIG. 1
(A) A&E Awning Size
Center of Arm To Center of Arm
For Full Length Patty O’Room
(B) Optional Length
(C) Measure Awning Rail Height
Determines Standard or Tall
Patty O’Room
The Patty O’Room front panel length is a combination of
thedoorpanel plus frontpanels.Thesizeofthe front panels
is based on customer preference and the steps A, or B
listedabove.
Forexample:
19’Awning less 4’ = 15
15dividedby 8=1 with 7 left over
7dividedby 4=1 with 3 left over
3dividedby2=1
1 can not be divided by any panel size.
The results is a 19’ awning needs (1ea) 8’ panel, (1ea) 4’
paneland(1ea)2ftpanel.
Ifthecustomerpreferred4’panelsthen(3ea)4’panelsand
(1ea) 2’ panel are used. If 2’ panels are used the same
awningrequires7.
Seechartonpage3forA&E Suggested awning length and
panelsrequired.
APPLICATION:
TheA&EPattyO'Roomis designedtofitontheA&E8500,
9000, Sunchaser, One Step, Two Step and WeatherPro
awningsandisavailabletofitmostotherrecreationalvehicle
awnings.TherafterpolesenablethePattyO'Roomtobethe
full length of the awning or (with the use of shorter front
panels) the Room can be used on a portion of the awning.
Separatefront panels inshorter lengths are availablefrom
yourdealer.ThePattyO'Roomincludesintegratedprivacy
panels.
Note: ThePattyO'Roomfrontfortheawningisdesignedso
therewillbeapproximately3ormoreinchesofawningfabric
overhanging the Patty O'Room on each side. This is
providedtokeeprainwaterfromrunningofftheedgeofthe
awning to the inside of the Patty O'Room.
Tools & Supplies Required for Installation:
Tape Measure Electric Drill
Step Ladder 3/8” Drill Bit
Marking Pen 1/8“ Drill Bit
Caulking Gun Round File
Silicone Sealant Straight Edge
Hammer String & Plumb Bob
Phillips Screw Driver Scissors
Important: Read ALL of the following steps before
beginning installation.
Dometic Corporation reserves the right to modify appear-
ances and specifications without notice.
During installation, care must be taken not to scrape and
damage the panels and skirts.
Do not operate appliances venting into this
room enclosure with privacy panels closed.
At least one panel must be open for ventila-
tion when using appliances. Death or seri-
ous injury from Carbon Monoxide Poison-
ing could occur if not operated properly.
During rain, lower the end furthest from the
doortoallowwatertoflowoffawning.When-
ever heavy or prolonged rain or wind is an-
ticipated or you will leave the awning and
screenroomunattended,itisbesttoremove
thescreenroomandclosethe awning.Dam-
age as a result of weather is not covered by
warranty.

PATTYO’ROOMTM
5
FIG. 5
MEASUREFROM
EDGEOFAWNING
FABRIC
DRILL 1/8”
PILOTHOLE
POLEHOLDER
SCREW
AWNING RAIL
PATTY O’ROOMTM INSTALLATION
PROCEDURE:
1. The first step to insure a good installation of a Patty
O’Room is to park the RV on flat and level surface.
2. Open the awning so that the slope of the canopy ap-
proximates the angle of the side panels. (The Patty
O’Roommaybeenjoyedwiththeawningsupportarms
in the Patio Position as well as in the RV Pivot Posi-
tion.)Make certain that awning fabricisstretched taut,
and the roller tube is level. See FIG. 2.
3. There is a 3/16” diameter poly rope sewn into the top
edgeofthefrontpanels.The frontpanelsaretobehung
from the roller tube by inserting the poly rope into the
groove/slot in the left hand end cap and sliding it the
entire length of the roller tube. This groove should be
facingtheground.
4. Checkthegroove/slot intheendcapforburrsand sharp
edges.Removeany burr or sharp edges usingaflator
round file. See FIG. 3.
5. Zip door and panels together to make the front screen
assembly. The door may be installed on either end of
thefrontorbetweenpanels.
6. Whileonepersonpulls on the leading edge of thefront
assembly, a second person feeds and guides the pan-
els into the groove. Spray the groove with a dry Teflon
spraylubricant to make this operation easier.See FIG.
3.
FIG. 3
FRONT
PANEL
AWNING
FABRIC
SLIDE FRONT PANELIN
GROOVEONEND CAP
7. For full width Patty O’Room place the front panel as-
sembly so that it is centered in relationship to the front
ofthe awning. Mark theroller tube 3/4” fromthe zipper
edge of the front panel and 3/4” from the groove in the
rollertubewhereawningfabricattaches.Centerpunch
where the lines cross. Use the 1/8” drill bit and electric
drilltomakea pilot hole intherollertube.Changetothe
3/8” drill bit and enlarge the hole.
NOTE:Asmaller Patty O’Room usedwith a larger aw-
ning may be located in a similar fashion as long as the
zipperateach end of the front panel isusedasa guide
to locate the hole for the rafter pole.
8. Measurethedistancefromtheedge of the awning fab-
rictothe center of the hole intherollertube. This is the
dimension for the location of the pole holder. See FIG.
4.
9. Using a measuring tape, measure and mark the same
dimension on the side of the coach below the awning
rail as measured in step 8. Place pole holder directly
belowawning rail. See FIG. 5
10. Place the pole holder under the awning rail on the line
and mark its center point. Use 1/8” drill bit to make a
pilot hole. See FIG. 5.
FIG. 2 ADJUSTAWNING HEIGHT TO MATCH
THE SLOPE OF THE SIDE PANELS
SIDE
PANEL AWNING
FABRIC
SUPPORT
ARM
FIG. 4 MEASUREFROM
EDGEOFAWNING
FABRIC TOHOLE
FRONTPANEL
DRILL 3/8” HOLE
ROLLER
TUBE
3/4”
FROM
ZIPPER
3/4”

PATTYO’ROOMTM
6
11. Applysiliconesealant toscrewthreadsandsecure pole
holdertosidewallofcoach. See FIG.5.Repeatsteps7
to 11 for opposite side.
12. The rafter poles are in 2 pieces for easy storage when
not in use. Assemble the rafter by inserting the pole
with the metal pin into the pole with the rubber tip. Be
sure the metal pin is visible. See FIG. 6.
13. Slide therafterpoleassembly through one of the three
pockets on the top edge of the side panels. The top
pocketisfor mostvehicleswiththeawning high enough
to be sloped down. The middle and lower pocket are
used on RV’s that need the awning to be flat. See FIG.
7.
NOTE:Whenthe awningisrelativelyflatandthescreen
room pole is in the lowest position; it should be rolled-
up if rain is anticipated to prevent damages.
14. With the rafter pole still in the side panel, place the
rubber tip into the pole holder under the awning rail.
Applypressureontherafterpoletowardthecoach wall
FIG. 7 RAFTER
POLE
LOCATIONS
SIDE
PANEL
FIG. 6
METAL
PIN
RUBBER
TIP
SLIDEPOLES
TOGETHER
compressing the spring and put the metal pin in the
3/8”holedrilled in the roller tube. Repeat onotherend.
15. Slide 3 poly rope clips onto the poly rope sewn on the
side panel. Position the top poly rope clip about 4” di-
rectlybelowthepoleholderanddrilla1/8”pilotholefor
the installation of the twist fastener. Use a string and
plumbbobto placetheremainingtwistfasteners evenly
spaced in a straight line down the wall of the coach.
See Fig. 8 & 9.
NOTE: The side panel assembly comes with 8 Poly
ropeclipsandtwistfasteners.Only3clipsarerequired
for each side. The extra are spares and can be used if
necessary.Ifthesidepanelisoverawindoworstorage
compartmentdoor,thepoly rope clipsshouldbe placed
immediatelyaboveand below.
16. Apply silicone sealant to the back and threads of the
twist fasteners before screwing them to the side wall.
17. Slide the poly rope clips to mate up with its twist fas-
tenerand attach it to thesidewall. Repeat on opposite
side.
FIG. 8
DRILL A 1/8” PILOT
HOLE FOR TWIST
FASTENER 4”BELOW
POLEHOLDER
TWIST
FASTENER
POLE
HOLDER
18. The steps to enter the RV should be in the extend or
downposition.
19. Thevehicleskirtingisone piece offabric300”long.The
skirt is to be cut to fit the Patty O’Room on which it is
installed. The twist fasteners for the skirt should be
screwedintosolid structure of 1 -2”fromthe bottom of
thecoach wall. The skirt shouldextendpast the end of
the right/left side panel 3 to 4 inches. See FIG. 10.
SPACE TWIST
FASTENERSFOR
POLY ROPE CLIPS
IN A STRAIGHT
LINE ON THE WALL
OFCOACH
FIG. 9
If RV is equipped with an automatic entry
step, make sure the automatic operation is
disabled. The step should remain in the
“down”or“extended”position whileinstall-
ing and using the Patty O’Room.

PATTYO’ROOMTM
7
MEASUREDOWN
FROM TOP OF SKIRT
TO LOWEST PART OF
STEP
FIG. 10 SIDE PANEL POSITIONS
WHEELWELL
SKIRTS
VEHICLESKIRT
HOOK&
LOOP
FASTENERS
20. Drilla1/8”pilothole for the twistfastenerattheright/left
corner of the Patty O’Room. Mark the opposite end of
the fabric to be trimmed 3 to 4 inches past the end of
the Patty O’Room. Square and cut off. Pull the skirt
tautandfinishinstalling the twist fasteners in a straight
line along the bottom of the coach. The remaining cor-
ner(ifeyeletiscut off when skirt is cut to length) isheld
in place by attaching the 1x3” hook and loop fasteners
supplied in the kit.
Skirting must not interfere with appliance
venting.Donot start or operate motor home
engine or RV generator if exhaust vents are
located behind skirting. Death or serious
injury from Carbon Monoxide Poisoning
could occur if not operated properly.
21. Locate the step, determine the uppermost part of it by
feeling. Mark the edges of the step on each side. See
FIG. 11.
22.Measuredown from the top edge oftheskirt to the low-
estpartofthestep.Add1/4”to thismeasurement. Mark
alineforthecutforthestep on the skirt fabric. See FIG.
11.
FIG. 11
MARKTHE
WIDEST
PART OF
STEP ON
FABRIC
TOP OF
SKIRT
23. Draw theoutlineforthe step flap on theskirtfabricand
cut with scissors. See FIG. 12.
FIG. 12
DRAW LINEAND CUT
FLAP
MARKS FOR THE TOP AND
WIDEST PART OF STEP
MEASURE
DOWNFROM
TOP OF SKIRT
TO LOWEST
PART OF STEP
SKIRT
TOP
24. Tuck flap of skirt behind step to keep out insects.
25. The wheel well skirts are installed in the same way as
the main skirt. They are centered on the wheel well.
Peel the backing of the hook and loop fasteners and
attach to the coach. Two skirts are provided with the
PattyO’Room doorandsidepanelassembly.Bothare
used on dual axle, triple axles will require 3 wheel well
skirts. Order additional wheel well skirt part number
3307975.007.
26. Adjust the height of the roller tube so that all panels
hang straight and level. See FIG.’s. 13 & 14.
FIG. 13
CORRECT
FIG. 14
INCORRECT
27. Secureallpanelsand vehicle skirtingbydrivingthetent
stakes inside the room, through the grommets into the
ground.
TWIST
FASTENERS

PATTYO’ROOMTM
8
SincethePattyO’Room comes in anadjustableheight,
it is designed such that adjustment for height can be
achieved by shortening the bottom of the panels. This
isdonebyfoldingtheexcessfabricatthebottomofthe
panels so that the grommets line up with one another.
Thefabricmay be foldedbyfoldingbackandforth upon
itself as shown in FIG. 15, or by rolling the fabric as
shown in FIG. 16. Either step is repeated until fabric
reachesthecorrectlengthforthevehicle.Afterthecor-
rect length has been established from inside the room
through the grommets stake to the ground.
28. The privacy panels can be rolled up and fastened with
the use of straps to allow for ventilation of the Patty
O’Room.
STORAGE:
Fold the side panels by laying them with the privacy
panelsclosedand the screen side up onaflatsurface.
Foldthepanel intoasquarebyfolding theupperportion
containing the pole pockets over the screened area.
Fold the bottom of the side up until it is even with the
first fold. Fold in half one more time before it is folded
into a size convenient to fit into the bag. Repeat this
with the other side panels and the front.
NOTE: IfthePattyO’Room must be folded when wet it
should be removed from the storage bag as soon as
possible and set up to be dried.
CLEANING:
Periodicallycleanthefabricusingamildlaundrydeter-
gentoranapproved awning or vinyl cleaner.Whenus-
ing a commercial cleaner be sure to follow the manu-
facturersinstructions.
Useonlyasoftbristledbrushforcleaningorscrubbing.
Besureto clean both sides of the fabricandrinsethor-
oughly.
Allowthe fabrictodrybeforestoringyourPattyO’Room.
FIG. 16
FIG. 15
