Dometic A&E Systems ELITE User manual

1
FormNo.3309862.005
©2005DometicCorporation
LaGrange,IN 46761
OPERATINGINSTRUCTIONS WINDOW
AWNINGS
USA
SERVICEOFFICE
DometicCorporation
2320IndustrialParkway
Elkhart,IN46516
574-294-2511
CANADA
DometicDistribution
866LangsDrive
Cambridge,Ontario
CANADAN3H2N7
519-653-4390
For Service Center
AssistanceCall:
800-544-4881
This manual must be read and un-
derstood before installation, ad-
justment, service, or maintenance
is performed. This unit must be in-
stalled by a qualified service tech-
nician.Modificationofthisproduct
can be extremely hazardous and
could result in personal injury or
property damage.
Lire et comprendre ce manuel avant de
procéderàl'installation,àdesréglages,
de l'entretien ou des réparations.
L'installation de cet appareil doit être
effectuée par un réparateur qualifié.
Toute modification de cet appareil peut
être extrêmement dangereuse et
entraîner des blessures ou dommages
matériels.
Important:TheseInstructions
must stay with unit.
Owner read carefully.
ELITE, DELUXE PLUS
WINDOWAWNINGS

2
SAFETY INSTRUCTIONS
This manual has safety information and instruc-
tionsto helpusers eliminateor reducethe riskof
accidentsand injuries.
RECOGNIZE SAFETY INFORMATION
Thisisthesafety-alertsymbol.Whenyou see this
symbolinthis manual,bealert tothepotentialfor
personalinjury.
Follow recommended precautions and safe op-
eratinginstructions.
UNDERSTAND SIGNAL WORDS
Asignal word ,WARNING OR CAUTION isused
withthesafety-alertsymbol.Theygivethelevelof
riskforpotentialinjury.
indicates a potentiallyhazard-
oussituation which, ifnotavoided, couldresultin
deathorseriousinjury.
indicates a potentially hazard-
ous situation which, if not avoided may result in
minorormoderate injury.
used without the safety alert
symbol indicates, a potentially hazardous situa-
tion which, if not avoided may result in property
damage.
Readandfollowallsafetyinformationandinstruc-
tions.
!
WARNING
!
CAUTION
CAUTION
!
1. OPERATION
A. TOOPENAWNING
1. Grasp the loop on the pull strap and pull
downtoextendawningthenhooktheloop
ontothewindowstraphanger.FIG.1&2.
B. TOCLOSEAWNING
1. Remove loop on pull strap from window
hanger.FIG2
CAUTION
!
Do not release strap as window awning is
under tension. It may snap back against
vehicle.
2. Slowlyallowawningtoclosebyfeedingpull
strap upwards and diagonally. This pre-
ventsthestrapfrombuildingupandcreat-
ing a bulge in the fabric.
3. The awning is now ready for travel with no
furtherlockingrequired.
FIG.1 FIG.2
