Dometic PerfectWall PW1000 Instruction Manual

1
==
2.6m
3.0m
3.5m
4.0m
4.5m
5.0m
5.5m
6.0m
1215
1415
40
1585
120 1585
1250
1500 1500
200 1010 1250
1500
1750
2450
240 1430
530
1500
1750
2450
1215
1415
25
1.
2.
2.
1.
280
32
4 5 6 7 8 9 10
11 12 13 14 15 16 17 18
19
20
22
23
21
1
PW
1500/
PW
1750
24
!
!
!
!
!
15 – 20 Nm
PW1000,
PW1500, PW1750
1
2
5
6
3
4
8
9
7
0
ab c
leaflet_figures.fm Seite 1 Montag, 8. Oktober 2018 11:00 11
More information https://www.caravansplus.com.au

2
www.dometic.com
Dometic WAECO International GmbH
Hollefeldstrasse 63
D-48282 Emsdetten
dometic.com
AB
1.
2.
Ø3 mm
4.
1.
2. 3.
Ø 3 mm
2.
1.
on
rd
bk
rd
bk
bu
T15A
bn
T3A
D+
bu
bnbu
bn
2
43
5
6
7
8
810 11
1
+12 Vg
1
1
2
1
2
3
3
1
2
j
k
hi
g
def l
m
no
4445101839 0700297 09/2018
leaflet_figures.fm Seite 2 Montag, 8. Oktober 2018 11:00 11
More information https://www.caravansplus.com.au

PW1000, PW1500, PW1750
Awning
Installation Manual. . . . . . . . . . . . . . . . . . . . . 3
Markise
Montageanleitung. . . . . . . . . . . . . . . . . . . . 15
Store extérieuru
Instructions de montage . . . . . . . . . . . . . . .28
Toldo
Instrucciones de montaje . . . . . . . . . . . . . . 41
Tol do
Instruções de montagem . . . . . . . . . . . . . .54
Ten da d a sole
Indicazioni di montaggio . . . . . . . . . . . . . .67
Zonnescherm
Montagehandleiding . . . . . . . . . . . . . . . . .80
Markise
Monteringsvejledning. . . . . . . . . . . . . . . . .92
Markis
Monteringsanvisning. . . . . . . . . . . . . . . . .104
Markise
Monteringsanvisning. . . . . . . . . . . . . . . . . 116
Markiisi
Asennusohje . . . . . . . . . . . . . . . . . . . . . . .128
Синусоидальный инвертор
Инструкция по монтажу. . . . . . . . . . . . . . 140
Markiza
Instrukcja montażu . . . . . . . . . . . . . . . . . . 153
Markíza
Návod na montáž. . . . . . . . . . . . . . . . . . . 166
Markýza
Návod k montáži . . . . . . . . . . . . . . . . . . . . 178
Előtető
Szerelési útmutató . . . . . . . . . . . . . . . . . . 190
Markiza
Navodilo za montažo . . . . . . . . . . . . . . . . 202

 
EN
DE
FR
ES
PT
IT
NL
DA
SV
NO
FI
RU
PL
SK
CS
HU
SL
EL
AWNINGS
PERFECTWALL

More information https://www.caravansplus.com.au

EN
PerfectWall Explanation of symbols
3
!
Table of contents
1Explanationofsymbols...........................................3
2Importantsafetyandinstallationinstructions..........................4
3Scopeofdelivery...............................................4
4Accessories....................................................5
5Intendeduse...................................................6
6Installingtheawning.............................................6
7Connectingtheawning(PW1500andPW1750).....................12
8Disposal......................................................14
1 Explanation of symbols
!
A
I
WARNING!
This operating manual must be read and understood before
installation, set up, operation and servicing. This device must be
installed by a specialist. Improper installation can lead to serious
injury. Alterations to the device can be extremely dangerous and
lead to serious injury or damage to the device.
Keep this operating manual with the device. The owner must read it
carefully.
WARNING!
Safety instruction: Failure to observe this instruction can cause fatal or
serious injury.
NOTICE!
Failure to observe this instruction can cause material damage and impair
the function of the product.
NOTE
Supplementary information for operating the product.

More information https://www.caravansplus.com.au

EN
Important safety and installation instructions PerfectWall
4
2 Important safety and installation
instructions
Please observe the safety instructions and stipulations issued by the
vehicle manufacturer and service workshops.
The manufacturer accepts no liability for damage in the following cases:
Faulty assembly or connection
Damage to the product resulting from mechanical influences
Alterations to the product without express permission from the manufacturer
Use for purposes other than those described in the operating manual
!WARNING!
If you do not have sufficient technical knowledge for installing
components in vehicles, you should have a specialist fit the awning to
your vehicle.
3Scopeofdelivery
No. in
fig. 1,
page 1
Awning width
Description
2.6 m,
3m,3.5m 4m,4.5m 5m,5.5m
11x1x1xAwning
2 – – 2x Mounting plate (400 mm)
3 – 2x 2x Mounting plate (160 mm)
4 2x 2x – Mounting plate (80 mm)
5 1x – – Mounting plate (35 mm)
6 5x 8x 12x Counter plate
7 5x 8x 12x Square-head bolt
8 2x 4x 6x Countersunk bolt
9 7x 12x 18x Serrated lock washer
10 7x 12x 18x Hexagon nut
11 5x 8x 12x Cover for the counter plate
12 11x 14x 18x Self-tapping screw

More information https://www.caravansplus.com.au

EN
PerfectWall Accessories
5
4Accessories
Available as accessories (not included in the scope of delivery):
13 2x 2x 2x Mounting bracket (lower section)
14 2x 2x 2x Mounting bracket (upper section)
15 1x 1x 1x Crank bracket (lower section)
16 1x 1x 1x Crank bracket (upper section)
(only PW1500, PW1750)
17 4x 4x 4x Rivets
18 4x 4x 4x Pegs
19 1x 1x 1x Crank (only awnings without
motor)
20 – 1x 1x Latch for tension rafter
21 – 1x 1x Hexagon head bolt
22 – 1x 1x Tension rafter
23 – 1x 1x Hexagon nut
24 1x 1x 1x Remote control with connection
material (only PW1500, PW1750,
optional)
25 1x 1x 1x Switch (only PW1500, PW1750,
optional)
Description
TieDown Kit
Straps for anchoring the awning
CampRoom
Awning tent front panel and sides for various models with support legs in different sizes
RainProtect
Front panel and sides available in different sizes
No. in
fig. 1,
page 1
Awning width
Description
2.6 m,
3m,3.5m 4m,4.5m 5m,5.5m

More information https://www.caravansplus.com.au

EN
Intended use PerfectWall
6
If you have questions regarding the accessories, please contact your local service
partner.
5 Intended use
The PerfectWall PW1000, PW1500 and PW1750 awnings are suitable for installing
on motorhomes or caravans.
The awnings must only be used whilst the vehicle is stationary. Please observe the
operating manual.
6 Installing the awning
6.1 Required installation material
For the installation of the awning, you will need:
Various tools, e.g. screwdriver
A suitable flexible adhesive/sealant, e.g. Sikaflex®-252
SunProtect
Front panel and sides available in different sizes
Rollo+ (not for PW1750)
Roller blind
Dometic Light LK120
LED light kit with remote control for installation on the awning arms
LED LightStrip
LED strip available in different lengths for installation on the underside of the awning
Led Profile
LED lighting available in different lengths for installation on the underside of wall-mounted
awnings
Awning cleaner
Special awning cleaner
Repair Kit
Awning repair patch
Description

More information https://www.caravansplus.com.au

EN
PerfectWall Installing the awning
7
A cleaning agent that is recommended for use with the adhesive
A primer that is recommended for use with the adhesive
Acid-free silicone
6.2 Notes on the installation position
When choosing the installation location, observe the following:
!WARNING!
Keep a sufficient distance from objects or other vehicles. Once it is
retracted, it should be at least 40 cm away from other objects and
vehicles.
Ensure the wall of the motorhome can safely take the weight of the
awning before installation. Otherwise, the awning may become
unstable and bend or break.
ANOTICE!
Make sure that the inner screw joints are accessible.
Only attach the awning to flat and vertical wall surfaces (fig. 2and
fig. 3, page 1). On curved wall surfaces, the mounting plates need to
be adequately lined under the fastening points.
If there is insufficient space above the door after the awning is
mounted, the door must remain closed when retracting or extending
to avoid the door making contact with the arms or the lead rail.
The required space depends on the design of the door (door width,
swing or sliding door) as well as the set awning angle of inclination
(fig. 4, page 1).
The cables and cabinets in the interior of the vehicle may not be
damaged by drilling the holes.
INOTE
Ensure the user of the vehicle is aware that the screwson the rear hinge
(fig. 5, page 1) must be tightened up (see operating manual). The
arms must not bear any load. This must be doneby the service partner.
6.3 Installing the awning
During installation, observe the following general information:
The awning can be attached in two ways:
– to the side of the vehicle using mounting plates
– to the existing piping rail on the side of the vehicle

More information https://www.caravansplus.com.au

EN
Installing the awning PerfectWall
8
The mounting plates are bolted to the vehicle in the area of the rear hinge. In
addition, they are glued with installation adhesive (e.g. Sikaflex®-221 or a similar
product) to ensure the load is evenly spread and an optimal level of protection
from moisture is maintained.
Observe the sealant manufacturer's instructions.
Before installation, check the access to the screw joints. Make sure no cables or
cabinets are damaged when drilling.
Contact your local service partner if you wish to have an angle of inclination
different to the default setting.
If you want to use an awning tent with the awning at a later date, ensure that the
vent windows and hatches remain accessible with erected tent when choosing
the awning size and installation position (fig. 6, page 1).
Clean the adhesive surfaces on the mounting rails and the wall.
Prepare the adhesive surfaces with the primer.
After gluing, wait until the adhesive has set. For further details, please refer to the
information provided by the sealant manufacturer.
Carefully seal the drill holes to prevent moisture from entering the motorhome
wall.
Do not open the awning or leave it unattended, before the awning has been
fastened to the mounting rails.
As part of the regular maintenance procedure, the screwson the rear hinge must
be tightened up by a service partner. Ensure the users of the vehicle are aware of
this.
Installing the awning with mounting plates
➤Select the location of the installation.
In particular, check that there is enough space in the interior to mount the counter
plates at the points where the screws will be.
I
➤Align the mounting plates on the vehicle and mark where the holes are to be
drilled (fig. 8, page 1).
➤At the marked points, drill holes with a diameter of 6.5 mm from the outside
through the external wall.
NOTE
Recommended mounting position for each counter plate: fig. 7,
page 1.

More information https://www.caravansplus.com.au

EN
PerfectWall Installing the awning
9
➤Clean the outer sides of the mounting plates and the installation surface on the
vehicle.
➤Fill the drill holes in the vehicle wall with an acid-free silicone.
➤Insert the square-head bolts through the relevant holes in the mounting plates
(fig. 9, page 1).
➤To glue and seal, apply an elastic adhesive, such as Sikaflex®-221 for example, to
the back of the mounting plates (fig. 9, page 1).
➤Place all of the mounting plates through the drill holes and fasten them with
counter plate, serrated lock washers and hexagon head bolts (fig. 0, page 1).
➤Only for awnings with a width of 2.6 m to 3.5 m:
Fasten all of the mounting plates using a countersunk bolt, counter plate,
serrated lock washer and hexagon nut (fig. a, page 1).
➤Only for awnings with a width of 4 m to 5.5 m:
Fasten the inner (narrow) mounting plates using a countersunk bolt, counter
plate, serrated lock washer and hexagon nut (fig. a, page 1).
➤Wait until the glue has set. For further details, please refer to the information
provided by the sealant manufacturer.
➤Use two people to hook the awning on to the mounting plates (fig. b, page 1).
➤Extend the awning about 50 cm using the crank.
➤Only for awnings with a width of 4 m to 5.5 m:
Drill one hole with a diameter of 6.5 mm through the left and the right side of the
awning. The hole has to be in a distance of 280 mm to the respective edge of the
awning and be on the same level as its counterpart in the long mounting plate
(fig. c, page 1).
➤Only for awnings with a width of 4 m to 5.5 m:
Fasten the awning using a countersunk bolt, counter plate, serrated lock washer
and hexagon nut (fig. d, page 2).
➤Insert the cover caps on the counter plates (fig. e, page 2).
➤Drill two holes with a diameter of 3 mm through the awning and each of the long
mounting plates (fig. f, page 2).
➤Drill one hole with a diameter of 3 mm through the awning and each of the short
mounting plates (fig. f, page 2).
➤Fasten the awning with drill screws (fig. f, page 2).
➤Retract the awning completely using the crank.

More information https://www.caravansplus.com.au

EN
Installing the awning PerfectWall
10
Installing awning on the piping rail
➤Select the location of the installation.
In particular, check that there is enough space in the interior to mount the counter
plates at the points where the screws will be.
I
➤Use two people to hook the awning on to the piping rail.
➤Extend the awning about 50 cm using the crank.
➤Mark where the holes are to be drilled (fig. h, page 2).
➤Retract the awning completely using the crank.
➤Use two people to lift the awning from the piping rail.
➤At the marked points, drill holes with a diameter of 6.5 mm from the outside
through the external wall.
➤Fill the drill holes in the vehicle wall with an acid-free silicone.
➤Use two people to hook the awning on to the piping rail.
➤Extend the awning about 50 cm using the crank.
➤Fasten the awning using a countersunk bolt, counter plate, serrated lock washer
and hexagon nut (fig. i, page 2).
➤Insert the cover caps on the counter plates (fig. e, page 2).
➤Retract the awning completely using the crank.
Installing the mounting bracket
The mounting bracket must be installed if the awning is to be attached to the side of
the vehicle when extended.
➤Select the location of the installation.
➤Mark where the holes are to be drilled.
➤At the marked points, drill holes with a diameter of 3 mm from the outside into
the external wall (fig. j, page 2).
➤Put the upper and lower sections of the mounting bracket together.
NOTE
Measure the recommended mounting position for each counter plate
against the drill hole in the lower section of the awning.

More information https://www.caravansplus.com.au

EN
PerfectWall Installing the awning
11
➤Clean the outer sides of the lower section and the installation surface in the
vehicle.
I
➤To glue and seal, apply an elastic adhesive, such as Sikaflex®-221 for example, to
the back of the mounting bracket.
➤Fasten the mounting bracket with drill screws (fig. j, page 2).
or
➤Rivet the mounting bracket (fig. j, page 2).
Installing the crank bracket
➤Mount the mounting bracket for the crank at a suitable location inside the vehicle
(fig. k, page 2).
Mounting the tension rafter
Awnings with a width of 4 m to 5.5 m must be secured with a tension rafter.
➤Attach the pre-drilled end of the tension rafter to the latch for the tension rafter
using the hexagon head bolt and the hexagon nut (fig. l, page 2).
➤Insert the lower section of the tension rafter into the upper section (fig. l,
page 2).
NOTE
Make sure that no glue gets on to the movable upper section of the
mounting bracket.

More information https://www.caravansplus.com.au

EN
Connecting the awning (PW1500 and PW1750) PerfectWall
12
7 Connecting the awning (PW1500 and
PW1750)
!
A
There are two options for the electrical connection of the awning:
Awning switch with an integrated main switch
Main switch and receiver for the remote control
Observe the following installation instructions:
Fit the supplied main switch and fuse (15 A) to the positive line of the power
supply. The main switch is required to switch off the awning when side walls are
fitted to the awning, for example, or if the vehicle is taken out of service for an
extended period of time (otherwise the standby consumption may drain the
battery).
Install the receiver on the inside of the vehicle to protect it from moisture.
Observe the length of the cable between the awning motor and receiver when
choosing a place to install it.
Do not shorten the antenna cable.
When installing the supplied plug, use a suitable tool (crimping tool) to ensure
that the connection is secure and durable.
If you want to connect an awning light (accessory), make sure that its maximum
power consumption is 30 W. When connecting, make sure the polarity is
correct.
WARNING!
Connect the ignition (D+ signal) to the orange line of the receiver.
This is the only way to ensure that the awning cannot be opened
while driving.
Only use the original remote control supplied and optional original
wall switch.The use of original parts is the only way to ensure that
with connected D+ signal the power supply is disconnected and the
awning cannot be opened while driving.
Disconnect the power supply before starting the assembly.
Only permit a qualified electrician to connect the awning to the elec-
trical power.
CAUTION!
The cables and cabinets in the interior of the vehicle must not be
damaged through drilling the holes.

More information https://www.caravansplus.com.au

EN
PerfectWall Connecting the awning (PW1500 and PW1750)
13
Observe the required cable cross section when connecting to the power supply:
Legend to fig. m, page 2:
Installing the wall switch
➤Find a suitable location inside the motor home, out of direct sunlight, to install the
switch.
Installing the receiver of the remote control and connecting the electrical
connections
➤Find a suitable location inside the motor home, out of direct sunlight, to install the
mounting bracket for the remote control.
➤Connect the motor with the remote control in accordance with the applicable
electrical engineering regulations and the circuit diagram (fig. m, page 2).
Cable length Required cable cross section
2 m 1.5 mm²
4 m 2.5 mm²
6 m 4.0 mm²
8 m 6.0 mm²
No. Description
1Receiver
2 3 A fuse for LED awning light (optional)
3 on Orange line for D+ connection
4 rd Red line for LED awning light (optional)
5 bk Black line for LED awning light (optional)
6 bu Blue line for motor connection
7 bn Brown line for motor connection
8 bk Black line for power supply
9 rd Red line for power supply
10 Main switch
11 15 A fuse for main switch

More information https://www.caravansplus.com.au

EN
Disposal PerfectWall
14
Programming the remote control and the wall switch
➤Place the battery (see fig. n1, page 2).
➤Switch on the power supply.
✓The receiver beeps once briefly.
➤Press the programming button (fig. n2, page 2) or the buttons and on
the wall switch simultaneously (fig. o1 and 2, page 2) within 4 seconds.
✓The receiver beeps once briefly.
➤Press the programming button (fig. n2, page 2) or the buttons and on
the wall switch simultaneously (fig. o1 and 2, page 2) again briefly.
✓The receiver beeps once briefly.
➤Briefly press the button (fig. o3, page 2).
✓The receiver beeps four times briefly.
✓The awning moves briefly.
Proceed as follows to pair the wall switch:
➤Press the programming button (fig. n2, page 2) twice.
✓The receiver beeps twice briefly.
➤Press the buttons and on the wall switch simultaneously (fig. o1 and 2,
page 2).
✓The receiver beeps five times briefly.
✓The remote control or wall switch and awning are now set to one another.
8Disposal
➤Place the packaging material in the appropriate recycling waste bins wherever
possible.
MIf you wish to finally dispose of the product, ask your local recycling centre
or specialist dealer for details about how to do this in accordance with the
applicable disposal regulations.

More information https://www.caravansplus.com.au

AUSTRALIA
Dometic Australia Pty. Ltd.
1 John Duncan Court
Varsity Lakes QLD 4227
1800 212121
[phone]
Mail: [email protected]
AUSTRIA
Dometic Austria GmbH
Neudorferstraße 108
A-2353 Guntramsdorf
[phone]
[phone]
Mail: [email protected]
BENELUX
Dometic Branch Office Belgium
Lourdesstraat 84
B-8940 Geluwe
[phone]
[phone]
Mail: [email protected]
BRAZIL
Dometic DO Brasil LTDA
Avenida Paulista 1754, conj. 111
SP 01310-920 Sao Paulo
[phone]
[phone]
Mail: [email protected]
DENMARK
Dometic Denmark A/S
Nordensvej 15, Taulov
DK-7000 Fredericia
[phone]
[phone]
Mail: [email protected]
FINLAND
Dometic Finland OY
Mestarintie 4
FIN-01730 Vantaa
[phone]
[phone]
Mail: [email protected]
FRANCE
Dometic SAS
ZA du Pré de la Dame Jeanne
B.P. 5
F-60128 Plailly
[phone]
[phone]
Mail : [e-mail]
HONG KONG
Dometic Group Asia Pacific
Suites 2207-11 · 22/F · Tower 1
The Gateway· 25 Canton Road,
Tsim Sha Tsui · Kowloon
[phone]
[phone]
Mail: [email protected]
HUNGARY
Dometic Zrt. Sales Office
Kerékgyártó u. 5.
H-1147 Budapest
[phone]
[phone]
Mail: [e-mail]
ITALY
Dometic Italy S.r.l.
Via Virgilio, 3
I-47122 Forlì (FC)
[phone]
[phone]
Mail: [email protected]
JAPAN
Dometic KK
Maekawa-Shibaura, Bldg. 2
2-13-9 Shibaura Minato-ku
Tokyo 108-0023
[phone]
[phone]
Mail: [e-mail]
MEXICO
Dometic Mx, S. de R. L. de C. V.
Circuito Médicos No. 6 Local 1
Colonia Ciudad Satélite
CP 53100 Naucalpan de Juárez
Estado de México
[phone]
[phone]
Mail: [email protected].mx
NETHERLANDS
Dometic Benelux B.V.
Ecustraat 3
NL-4879 NP Etten-Leur
[phone]
[phone]
Mail: [e-mail]
NEW ZEALAND
Dometic New Zealand Ltd.
PO Box 12011
Penrose
Auckland 1642
[phone]
[phone]
Mail: [e-mail]
NORWAY
Dometic Norway AS
Østerøyveien 46
N-3232 Sandefjord
[phone]
[phone]
Mail: [e-mail]
POLAND
Dometic Poland Sp. z o.o.
Ul. Puławska 435A
PL-02-801 Warszawa
[phone]
[phone]
Mail: [email protected]
PORTUGAL
Dometic Spain, S.L.
Branch Office em Portugal
Rot. de São Gonçalo nº 1 – Esc. 12
2775-399 Carcavelos
[phone]
[phone]
Mail: [email protected]
RUSSIA
Dometic RUS LLC
Komsomolskaya square 6-1
RU-107140 Moscow
[phone]
[phone]
Mail: [email protected]
SINGAPORE
Dometic Pte Ltd
18 Boon Lay Way
06–141 Trade Hub 21
Singapore 609966
[phone]
[phone]
Mail: [e-mail]
SLOVAKIA
Dometic Slovakia s.r.o.
Sales Office Bratislava
Nádražná 34/A
900 28 Ivánka pri Dunaji
/[phone]
Mail: [e-mail]
SOUTH AFRICA
Dometic (Pty) Ltd.
Regional Office
South Africa & Sub-Saharan Africa
2 Avalon Road
West Lake View Ext 11
Modderfontein 1645
Johannesburg
[phone]
Mail: [e-mail]
SPAIN
Dometic Spain S.L.
Avda. Sierra del Guadarrama, 16
E-28691 Villanueva de la Cañada
Madrid
[phone]
[phone]
Mail: [e-mail]
SWEDEN
Dometic Scandinavia AB
Gustaf Melins gata 7
SE-42131 Västra Frölunda
[phone]
[phone]
Mail: [e-mail]
SWITZERLAND
Dometic Switzerland AG
Riedackerstrasse 7a
CH-8153 Rümlang
[phone]
[phone]
Mail: [e-mail]
UNITED ARAB EMIRATES
Dometic Middle East FZCO
P. O. Box 17860
S-D 6, Jebel Ali Freezone
Dubai
[phone]
[phone]
Mail: [e-mail]
UNITED KINGDOM
Dometic UK Ltd.
Dometic House, The Brewery
Blandford St. Mary
Dorset DT11 9LS
[phone]
[phone]
Mail: [e-mail]
USA
Dometic RV Division
1120 North Main Street
Elkhart, IN 46515
[phone]
GERMANY
Dometic WAECO International GmbH
Hollefeldstraße 63 · D-48282 Emsdetten
[phone] · [phone]
Mail: [email protected]
dometic.com
4445101838 09/2018

More information https://www.caravansplus.com.au
