PW1000, PW1500, PW1750
Awning
Installation Manual. . . . . . . . . . . . . . . . . . . . .3
Markise
Montageanleitung. . . . . . . . . . . . . . . . . . . . 16
Store extérieuru
Instructions de montage . . . . . . . . . . . . . . .29
Toldo
Instrucciones de montaje . . . . . . . . . . . . . .42
Toldo
Instruções de montagem . . . . . . . . . . . . . .55
Tenda da sole
Indicazioni di montaggio . . . . . . . . . . . . . .68
Zonnescherm
Montagehandleiding . . . . . . . . . . . . . . . . . 81
Markise
Monteringsvejledning. . . . . . . . . . . . . . . . .94
Markis
Monteringsanvisning. . . . . . . . . . . . . . . . .106
Markise
Monteringsanvisning. . . . . . . . . . . . . . . . . 118
Markiisi
Asennusohje . . . . . . . . . . . . . . . . . . . . . . . 130
Синусоидальный инвертор
Инструкция по монтажу. . . . . . . . . . . . . . 142
Markiza
Instrukcja montażu . . . . . . . . . . . . . . . . . . 155
Markíza
Návod na montáž . . . . . . . . . . . . . . . . . . . 168
Markýza
Návod k montáži . . . . . . . . . . . . . . . . . . . . 180
Előtető
Szerelési útmutató . . . . . . . . . . . . . . . . . . 192
Markiza
Navodilo za montažo . . . . . . . . . . . . . . . . 205
Τέντα
Οδηγίες τοποθέτησης. . . . . . . . . . . . . . 217
EN
DE
FR
ES
PT
IT
NL
DA
SV
NO
FI
RU
PL
SK
CS
HU
SL
EL
AWNINGS
PERFECTWALL
PW1000_PW1500_PW1750-I-18s.book Seite 1 Dienstag, 12. Juni 2018 4:37 16

PW1000_PW1500_PW1750-I-18s.book Seite 2 Dienstag, 12. Juni 2018 4:37 16

EN
PW1000, PW1500, PW1750 Explanation of symbols
3
!
Table of contents
1 Explanation of symbols. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
2 Important safety and installation instructions. . . . . . . . . . . . . . . . . . . . . . . . . .4
3 Scope of delivery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
4 Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
5 Intended use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
6 Installing the awning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
7 Connecting the awning (PW1500 and PW1750) . . . . . . . . . . . . . . . . . . . . .12
8 Disposal. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
1 Explanation of symbols
!
A
I
WARNING!
•This operating manual must be read and understood before
installation, set up, operation and servicing. This device must be
installed by a specialist. Improper installation can lead to serious
injury. Alterations to the device can be extremely dangerous and
lead to serious injury or damage to the device.
•Keep this operating manual with the device. The owner must read it
carefully.
WARNING!
Safety instruction: Failure to observe this instruction can cause fatal or
serious injury.
NOTICE!
Failure to observe this instruction can cause material damage and impair
the function of the product.
NOTE
Supplementary information for operating the product.
PW1000_PW1500_PW1750-I-18s.book Seite 3 Dienstag, 12. Juni 2018 4:37 16

EN
Important safety and installation instructions PW1000, PW1500, PW1750
4
2 Important safety and installation
instructions
Please observe the safety instructions and stipulations issued by the
vehicle manufacturer and service workshops.
The manufacturer accepts no liability for damage in the following cases:
•Faulty assembly or connection
•Damage to the product resulting from mechanical influences
•Alterations to the product without express permission from the manufacturer
•Use for purposes other than those described in the operating manual
!WARNING!
•If you do not have sufficient technical knowledge for installing
components in vehicles, you should have a specialist fit the awning to
your vehicle.
3Scopeofdelivery
No. in
fig. 1,
page 1
Awning width
Description
2.6 m,
3 m, 3.5 m 4 m, 4.5 m 5 m, 5.5 m
1 1x 1x 1x Awning
2 – – 2x Mounting plate (400 mm)
3 – 2x 2x Mounting plate (160 mm)
4 2x 2x – Mounting plate (80 mm)
5 1x – – Mounting plate (35 mm)
6 5x 8x 12x Counter plate
7 5x 8x 12x Square-head bolt
8 2x 4x 6x Countersunk bolt
9 7x 12x 18x Serrated lock washer
10 7x 12x 18x Hexagon nut
11 5x 8x 12x Cover for the counter plate
12 11x 14x 18x Self-tapping screw
PW1000_PW1500_PW1750-I-18s.book Seite 4 Dienstag, 12. Juni 2018 4:37 16

EN
PW1000, PW1500, PW1750 Scope of delivery
5
13 2x 2x 2x Mounting bracket (lower section)
14 2x 2x 2x Mounting bracket (upper section)
15 1x 1x 1x Crank bracket (lower section)
16 1x 1x 1x Crank bracket (upper section)
(only PW1500, PW1750)
17 4x 4x 4x Rivets
18 4x 4x 4x Pegs
19 1x 1x 1x Crank (only awnings without
motor)
20 – 1x 1x Latch for tension rafter
21 – 1x 1x Hexagon head bolt
22 – 1x 1x Tension rafter
23 – 1x 1x Hexagon nut
24 1x 1x 1x Remote control with connection
material (only PW1500, PW1750,
optional)
25 1x 1x 1x Switch (only PW1500, PW1750,
optional)
No. in
fig. 1,
page 1
Awning width
Description
2.6 m,
3 m, 3.5 m 4 m, 4.5 m 5 m, 5.5 m
PW1000_PW1500_PW1750-I-18s.book Seite 5 Dienstag, 12. Juni 2018 4:37 16

EN
Accessories PW1000, PW1500, PW1750
6
4Accessories
Available as accessories (not included in the scope of delivery):
If you have questions regarding the accessories, please contact your local service
partner.
5 Intended use
The PerfectWall PW1000, PW1500 and PW1750 awnings are suitable for installing
on motorhomes or caravans.
The awnings must only be used whilst the vehicle is stationary. Please observe the
operating manual.
Description
TieDown Kit
Straps for anchoring the awning
CampRoom
Awning tent front panel and sides for various models with support legs in different sizes
RainProtect
Front panel and sides available in different sizes
SunProtect
Front panel and sides available in different sizes
Rollo+ (not for PW1750)
Roller blind
Dometic Light LK120
LED light kit with remote control for installation on the awning arms
LED LightStrip
LED strip available in different lengths for installation on the underside of the awning
Led Profile
LED lighting available in different lengths for installation on the underside of wall-mounted
awnings
Awning cleaner
Special awning cleaner
Repair Kit
Awning repair patch
PW1000_PW1500_PW1750-I-18s.book Seite 6 Dienstag, 12. Juni 2018 4:37 16

EN
PW1000, PW1500, PW1750 Installing the awning
7
6 Installing the awning
6.1 Required installation material
For the installation of the awning, you will need:
•Various tools, e.g. screwdriver
•A suitable flexible adhesive/sealant, e.g. Sikaflex®-252
•A cleaning agent that is recommended for use with the adhesive
•A primer that is recommended for use with the adhesive
•Acid-free silicone
6.2 Notes on the installation position
When choosing the installation location, observe the following:
!WARNING!
•Keep a sufficient distance from objects or other vehicles. Once it is
retracted, it should be at least 40 cm away from other objects and
vehicles.
•Ensure the wall of the motorhome can safely take the weight of the
awning before installation. Otherwise, the awning may become
unstable and bend or break.
ANOTICE!
•Make sure that the inner screw joints are accessible.
•Only attach the awning to flat and vertical wall surfaces (fig. 2and
fig. 3, page 1). On curved wall surfaces, the mounting plates need to
be adequately lined under the fastening points.
•If there is insufficient space above the door after the awning is
mounted, the door must remain closed when retracting or extending
to avoid the door making contact with the arms or the lead rail.
The required space depends on the design of the door (door width,
swing or sliding door) as well as the set awning angle of inclination
(fig. 4, page 1).
•The cables and cabinets in the interior of the vehicle may not be
damaged by drilling the holes.
PW1000_PW1500_PW1750-I-18s.book Seite 7 Dienstag, 12. Juni 2018 4:37 16

EN
Installing the awning PW1000, PW1500, PW1750
8
INOTE
•Ensure the user of thevehicle is aware that the screws on the rear hinge
(fig. 5, page 1) must be tightened up (see operating manual). The
arms must not bear any load. This must be done by the service partner.
6.3 Installing the awning
During installation, observe the following general information:
•The awning can be attached in two ways:
– to the side of the vehicle using mounting plates
– to the existing piping rail on the side of the vehicle
•The mounting plates are bolted to the vehicle in the area of the rear hinge. In
addition, they are glued with installation adhesive (e.g. Sikaflex®-221 or a similar
product) to ensure the load is evenly spread and an optimal level of protection
from moisture is maintained.
•Observe the sealant manufacturer's instructions.
•Before installation, check the access to the screw joints. Make sure no cables or
cabinets are damaged when drilling.
•Contact your local service partner if you wish to have an angle of inclination
different to the default setting.
•If you want to use an awning tent with the awning at a later date, ensure that the
vent windows and hatches of the erected tent remain accessible when choosing
the awning size and installation position (fig. 6, page 1).
•Clean the adhesive surfaces on the mounting rails and the wall.
•Prepare the adhesive surfaces with the primer.
•After gluing, wait until the adhesive has set. For further details, please refer to the
information provided by the sealant manufacturer.
•Carefully seal the drill holes to prevent moisture from entering the motorhome
wall.
•Do not open the awning or leave it unattended, before the awning has been
fastened to the mounting rails.
•As part of the regular maintenance procedure, the screws on the rear hinge must
be tightened up by a service partner. Ensure the users of the vehicle are aware of
this.
PW1000_PW1500_PW1750-I-18s.book Seite 8 Dienstag, 12. Juni 2018 4:37 16

EN
PW1000, PW1500, PW1750 Installing the awning
9
Installing the awning with mounting plates
➤Select the location of the installation.
In particular, check that there is enough space in the interior to mount the counter
plates at the points where the screws will be.
I
➤Align the mounting plates on the vehicle and mark where the holes are to be
drilled (fig. 8, page 1).
➤At the marked points, drill holes with a diameter of 6.5 mm from the outside
through the external wall.
➤Clean the outer sides of the mounting plates and the installation surface on the
vehicle.
➤Fill the drill holes in the vehicle wall with an acid-free silicone.
➤Insert the square-head bolts through the relevant holes in the mounting plates
(fig. 9, page 1).
➤To glue and seal, apply an elastic adhesive, such as Sikaflex®-221 for example, to
the back of the mounting plates (fig. 9, page 1).
➤Place all of the mounting plates through the drill holes and fasten them with
counter plate, serrated lock washers and hexagon head bolts (fig. 0, page 1).
➤Only for awnings with a width of 2.6 m to 3.5 m:
Fasten all of the mounting plates using a countersunk bolt, counter plate,
serrated lock washer and hexagon nut (fig. a, page 1).
➤Only for awnings with a width of 4 m to 5.5 m:
Fasten the inner (narrow) mounting plates using a countersunk bolt, counter
plate, serrated lock washer and hexagon nut (fig. a, page 1).
➤Wait until the glue has set. For further details, please refer to the information
provided by the sealant manufacturer.
➤Use two people to hook the awning on to the mounting plates (fig. b, page 1).
➤Extend the awning about 50 cm using the crank.
NOTE
Recommended mounting position for each counter plate: fig. 7,
page 1.
PW1000_PW1500_PW1750-I-18s.book Seite 9 Dienstag, 12. Juni 2018 4:37 16

EN
Installing the awning PW1000, PW1500, PW1750
10
➤Only for awnings with a width of 4 m to 5.5 m:
Drill one hole with a diameter of 6.5 mm through the left and the right side of the
awning. The hole has to be in a distance of 280 mm to the respective edge of the
awning and be on the same level as its counterpart in the long mounting plate
(fig. c, page 1).
➤Only for awnings with a width of 4 m to 5.5 m:
Fasten the awning using a countersunk bolt, counter plate, serrated lock washer
and hexagon nut (fig. d, page 2).
➤Insert the cover caps on the counter plates (fig. e, page 2).
➤Drill two holes with a diameter of 3 mm through the awning and each of the long
mounting plates (fig. f, page 2).
➤Drill one hole with a diameter of 3 mm through the awning and each of the short
mounting plates (fig. f, page 2).
➤Fasten the awning with drill screws (fig. f, page 2).
➤Retract the awning completely using the crank.
Installing awning on the piping rail
➤Select the location of the installation.
In particular, check that there is enough space in the interior to mount the counter
plates at the points where the screws will be.
I
➤Use two people to hook the awning on to the piping rail.
➤Extend the awning about 50 cm using the crank.
➤Mark where the holes are to be drilled (fig. h, page 2).
➤Retract the awning completely using the crank.
➤Use two people to lift the awning from the piping rail.
➤At the marked points, drill holes with a diameter of 6.5 mm from the outside
through the external wall.
➤Fill the drill holes in the vehicle wall with an acid-free silicone.
➤Use two people to hook the awning on to the piping rail.
➤Extend the awning about 50 cm using the crank.
NOTE
Measure the recommended mounting position for each counter plate
against the drill hole in the lower section of the awning.
PW1000_PW1500_PW1750-I-18s.book Seite 10 Dienstag, 12. Juni 2018 4:37 16

EN
PW1000, PW1500, PW1750 Installing the awning
11
➤Fasten the awning using a countersunk bolt, counter plate, serrated lock washer
and hexagon nut (fig. i, page 2).
➤Insert the cover caps on the counter plates (fig. e, page 2).
➤Retract the awning completely using the crank.
Installing the mounting bracket
The mounting bracket must be installed if the awning is to be attached to the side of
the vehicle when extended.
➤Select the location of the installation.
➤Mark where the holes are to be drilled.
➤At the marked points, drill holes with a diameter of 3 mm from the outside into
the external wall (fig. j, page 2).
➤Put the upper and lower sections of the mounting bracket together.
➤Clean the outer sides of the lower section and the installation surface in the
vehicle.
I
➤To glue and seal, apply an elastic adhesive, such as Sikaflex®-221 for example, to
the back of the mounting bracket.
➤Fasten the mounting bracket with drill screws (fig. j, page 2).
or
➤Rivet the mounting bracket (fig. j, page 2).
Installing the crank bracket
➤Mount the mounting bracket for the crank at a suitable location inside the vehicle
(fig. k, page 2).
NOTE
Make sure that no glue gets on to the movable upper section of the
mounting bracket.
PW1000_PW1500_PW1750-I-18s.book Seite 11 Dienstag, 12. Juni 2018 4:37 16

EN
Connecting the awning (PW1500 and PW1750) PW1000, PW1500, PW1750
12
Mounting the tension rafter
Awnings with a width of 4 m to 5.5 m must be secured with a tension rafter.
➤Attach the pre-drilled end of the tension rafter to the latch for the tension rafter
using the hexagon head bolt and the hexagon nut (fig. l, page 2).
➤Insert the lower section of the tension rafter into the upper section (fig. l,
page 2).
7 Connecting the awning (PW1500 and
PW1750)
!
A
There are two options for the electrical connection of the awning:
•Awning switch with an integrated main switch
•Main switch and receiver for the remote control
Observe the following installation instructions:
•Fit the supplied main switch and fuse (15 A) to the positive line of the power
supply. The main switch is required to switch off the awning when side walls are
fitted to the awning, for example, or if the vehicle is taken out of service for an
extended period of time (otherwise the standby consumption may drain the
battery).
•Install the receiver on the inside of the vehicle to protect it from moisture.
•Observe the length of the cable between the awning motor and receiver when
choosing a place to install it.
•Do not shorten the antenna cable.
•Connect the ignition (D+ signal) to the orange line of the receiver. This is the only
way to ensure that the awning cannot be opened while driving.
•When installing the supplied plug, use a suitable tool (crimping tool) to ensure
that the connection is secure and durable.
WARNING!
•Disconnect the power supply before starting the assembly.
•Only permit a qualified electrician to connect the awning to the elec-
trical power.
CAUTION!
The cables and cabinets in the interior of the vehicle must not be
damaged through drilling the holes.
PW1000_PW1500_PW1750-I-18s.book Seite 12 Dienstag, 12. Juni 2018 4:37 16

EN
PW1000, PW1500, PW1750 Connecting the awning (PW1500 and PW1750)
13
•If you want to connect an awning light (accessory), make sure that its maximum
power consumption is 30 W. When connecting, make sure the polarity is
correct.
•Observe the required cable cross section when connecting to the power supply:
Legend to fig. m, page 2:
Installing the wall switch
➤Find a suitable location inside the motor home, out of direct sunlight, to install the
switch.
Cable length Required cable cross section
2 m 1.5 mm²
4 m 2.5 mm²
6 m 4.0 mm²
8 m 6.0 mm²
No. Description
1 Receiver
2 3 A fuse for LED awning light (optional)
3 on Orange line for D+ connection
4 rd Red line for LED awning light (optional)
5 bk Black line for LED awning light (optional)
6 bu Blue line for motor connection
7 bn Brown line for motor connection
8 bk Black line for power supply
9 rd Red line for power supply
10 Main switch
11 15 A fuse for main switch
PW1000_PW1500_PW1750-I-18s.book Seite 13 Dienstag, 12. Juni 2018 4:37 16

EN
Connecting the awning (PW1500 and PW1750) PW1000, PW1500, PW1750
14
Installing the receiver of the remote control and connecting the electrical
connections
➤Find a suitable location inside the motor home, out of direct sunlight, to install the
mounting bracket for the remote control.
➤Connect the motor with the remote control in accordance with the applicable
electrical engineering regulations and the circuit diagram (fig. m, page 2).
Programming the remote control and the wall switch
➤Place the battery (see fig. n1, page 2).
➤Switch on the power supply.
✓The receiver beeps once briefly.
➤Press the programming button (fig. n2, page 2) or the buttons and on
the wall switch simultaneously (fig. o1 and 2, page 2) within 4 seconds.
✓The receiver beeps once briefly.
➤Press the programming button (fig. n2, page 2) or the buttons and on
the wall switch simultaneously (fig. o1 and 2, page 2) again briefly.
✓The receiver beeps once briefly.
➤Briefly press the button (fig. o3, page 2).
✓The receiver beeps four times briefly.
✓The awning moves briefly.
Proceed as follows to pair the wall switch:
➤Press the programming button (fig. n2, page 2) twice.
✓The receiver beeps twice briefly.
➤Press the buttons and on the wall switch simultaneously (fig. o1 and 2,
page 2).
✓The receiver beeps five times briefly.
✓The remote control or wall switch and awning are now set to one another.
PW1000_PW1500_PW1750-I-18s.book Seite 14 Dienstag, 12. Juni 2018 4:37 16

EN
PW1000, PW1500, PW1750 Disposal
15
8Disposal
➤Place the packaging material in the appropriate recycling waste bins wherever
possible.
MIf you wish to finally dispose of the product, ask your local recycling centre
or specialist dealer for details about how to do this in accordance with the
applicable disposal regulations.
PW1000_PW1500_PW1750-I-18s.book Seite 15 Dienstag, 12. Juni 2018 4:37 16

DE
Erklärung der Symbole PW1000, PW1500, PW1750
16
!
Inhaltsverzeichnis
1 Erklärung der Symbole . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
2 Wichtige Sicherheits- und Einbauhinweise . . . . . . . . . . . . . . . . . . . . . . . . . .17
3 Lieferumfang . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
4 Zubehör. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
5 Bestimmungsgemäßer Gebrauch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
6 Markise montieren . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
7 Markise anschließen (PW1500 und PW1750). . . . . . . . . . . . . . . . . . . . . . . 25
8 Entsorgung . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
1 Erklärung der Symbole
!
A
I
WARNUNG!
•Diese Anleitung muss vor der Installation, dem Einrichten, dem
Betrieb und der Wartung gelesen und verstanden werden. Dieses
Gerät muss von einer Fachkraft installiert werden. Eine fehlerhafte
Installation kann zu schweren Verletzungen führen. Umbauten am
Gerät können äußerst gefährlich werden und zu schweren
Verletzungen oder zu Geräteschäden führen.
•Diese Anleitung muss beim Gerät verbleiben. Der Besitzer muss sie
aufmerksam lesen.
WARNUNG!
Sicherheitshinweis: Nichtbeachtung kann zu Tod oder schwerer
Verletzung führen.
ACHTUNG!
Nichtbeachtung kann zu Materialschäden führen und die Funktion des
Produktes beeinträchtigen.
HINWEIS
Ergänzende Informationen zur Bedienung des Produktes.
PW1000_PW1500_PW1750-I-18s.book Seite 16 Dienstag, 12. Juni 2018 4:37 16

DE
PW1000, PW1500, PW1750 Wichtige Sicherheits- und Einbauhinweise
17
2 Wichtige Sicherheits- und
Einbauhinweise
Beachten Sie die vom Fahrzeughersteller und vom Kfz-Handwerk
vorgeschriebenen Sicherheitshinweise und Auflagen!
Der Hersteller übernimmt in folgenden Fällen keine Haftung für Schäden:
•Montage- oder Anschlussfehler
•Beschädigungen am Produkt durch mechanische Einflüsse
•Veränderungen am Produkt ohne ausdrückliche Genehmigung vom Hersteller
•Verwendung für andere als die in der Anleitung beschriebenen Zwecke
!WARNUNG!
•Wenn Sie nicht über ausreichende technische Kenntnisse zum
Einbauen von Komponenten in Fahrzeugen verfügen, sollten Sie sich
die Markise von einem Fachmann ans Fahrzeug montieren lassen.
3 Lieferumfang
Nr. in
Abb. 1,
Seite 1
Markisenbreite
Bezeichnung
2,6 m,
3 m, 3,5 m 4 m, 4,5 m 5 m, 5,5 m
1 1x 1x 1x Markise
2 – – 2x Montageplatte (400 mm)
3 – 2x 2x Montageplatte (160 mm)
4 2x 2x – Montageplatte (80 mm)
5 1x – – Montageplatte (35 mm)
6 5x 8x 12x Gegenplatte
7 5x 8x 12x Vierkantschraube
8 2x 4x 6x Senkschraube
9 7x 12x 18x Fächerscheibe
10 7x 12x 18x Sechskantmutter
11 5x 8x 12x Abdeckung für Gegenplatte
12 11x 14x 18x Bohrschraube
PW1000_PW1500_PW1750-I-18s.book Seite 17 Dienstag, 12. Juni 2018 4:37 16

DE
Lieferumfang PW1000, PW1500, PW1750
18
13 2x 2x 2x Wandhalterung (unterer Teil)
14 2x 2x 2x Wandhalterung (oberer Teil)
15 1x 1x 1x Kurbelhalterung (unterer Teil)
16 1x 1x 1x Kurbelhalterung (oberer Teil)
(nur PW1500, PW1750)
17 4x 4x 4x Niete
18 4x 4x 4x Hering
19 1x 1x 1x Kurbel (nur Markisen ohne Motor)
20 – 1x 1x Arretierung für Spannstange
21 – 1x 1x Sechskantschraube
22 – 1x 1x Spannstange
23 – 1x 1x Sechskantmutter
24 1x 1x 1x Fernbedienung mit Anschluss-
material (nur PW1500, PW1750,
optional)
25 1x 1x 1x Schalter (nur PW1500, PW1750,
optional)
Nr. in
Abb. 1,
Seite 1
Markisenbreite
Bezeichnung
2,6 m,
3 m, 3,5 m 4 m, 4,5 m 5 m, 5,5 m
PW1000_PW1500_PW1750-I-18s.book Seite 18 Dienstag, 12. Juni 2018 4:37 16
