Dometic PerfectWall PW1000 User manual

PW1000, PW1500, PW1750
Awning
Installation Manual. . . . . . . . . . . . . . . . . . . . . 3
Markise
Montageanleitung. . . . . . . . . . . . . . . . . . . . 16
Store extérieuru
Instructions de montage . . . . . . . . . . . . . . .30
Told o
Instrucciones de montaje . . . . . . . . . . . . . .44
Told o
Instruções de montagem . . . . . . . . . . . . . .57
Tenda d a sole
Indicazioni di montaggio . . . . . . . . . . . . . . 71
Zonnescherm
Montagehandleiding . . . . . . . . . . . . . . . . .85
Markise
Monteringsvejledning. . . . . . . . . . . . . . . . .99
Markis
Monteringsanvisning. . . . . . . . . . . . . . . . . 112
Markise
Monteringsanvisning. . . . . . . . . . . . . . . . .125
Markiisi
Asennusohje . . . . . . . . . . . . . . . . . . . . . . . 138
Синусоидальный инвертор
Инструкция по монтажу. . . . . . . . . . . . . . 151
Markiza
Instrukcja montażu . . . . . . . . . . . . . . . . . . 166
Markíza
Návod na montáž . . . . . . . . . . . . . . . . . . . 180
Markýza
Návod k montáži . . . . . . . . . . . . . . . . . . . . 193
Előtető
Szerelési útmutató . . . . . . . . . . . . . . . . . . 206
Markiza
Navodilo za montažo . . . . . . . . . . . . . . . . 220
Τέντα
Οδηγίες τοποθέτησης. . . . . . . . . . . . . . 233
EN
DE
FR
ES
PT
IT
NL
DA
SV
NO
FI
RU
PL
SK
CS
HU
SL
EL
AWNINGS
PERFECTWALL
DometicPW1000-PW1500-PW1750_INM_4445101838_EMEA18_202x-xx-xx.book Seite 1 Freitag, 5. März 2021 8:30 20

© 2021 Dometic Group. The visual appearance of the contents of this manual is
protected by copyright and design law. The underlying technical design and the
products contained herein may be protected by design, patent or be patent
pending. The trademarks mentioned in this manual belong to Dometic Sweden AB.
All rights are reserved.
DometicPW1000-PW1500-PW1750_INM_4445101838_EMEA18_202x-xx-xx.book Seite 2 Freitag, 5. März 2021 8:30 20

EN
PW1000, PW1500, PW1750
3
Please read these instructions carefully and follow all instructions, guidelines, and warnings included in this product manual in order to ensure
that you install, use, and maintain the product properly at all times. These instructions MUST stay with this product.
By using the product, you hereby confirm that you have read all instructions, guidelines, and warnings carefully and thatyou understand and
agree to abide by the terms and conditions as set forth herein. You agree to use this product only for the intended purpose and application
and in accordance with the instructions, guidelines, and warnings as set forth in this product manual as well as in accordance with all appli-
cable laws and regulations. A failure to read and follow the instructions and warnings set forth herein may result in an injury to yourself and
others, damage to your product or damage to other property in the vicinity. This product manual, including the instructions, guidelines, and
warnings, and related documentation, may be subject to changes and updates. For up-to-date product information, please visit
dometic.com.
!
Table of contents
1 Explanation of symbols. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
2 Important safety and installation instructions. . . . . . . . . . . . . . . . . . . . . . . . . .4
3 Scope of delivery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
4 Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
5 Intended use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
6 Installing the awning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
7 Connecting the awning (PW1500 and PW1750) . . . . . . . . . . . . . . . . . . . . .13
8 Disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
WARNING!
• This installation manual must be read and understood before
installation, set up, operation and servicing. This device must be
installed by a specialist. Improper installation can lead to serious
injury. Alterations to the device can be extremely dangerous and
lead to serious injury or damage to the device.
• Keep this installation manual with the device. The owner must read it
carefully.
DometicPW1000-PW1500-PW1750_INM_4445101838_EMEA18_202x-xx-xx.book Seite 3 Freitag, 5. März 2021 8:30 20

EN
Explanation of symbols PW1000, PW1500, PW1750
4
1 Explanation of symbols
!
A
I
2 Important safety and installation
instructions
Please observe the safety instructions and stipulations issued by the
vehicle manufacturer and service workshops.
!WARNING! Failure to obey these warnings could result in death
or serious injury.
Electrocution hazard
• If you do not have sufficient technical knowledge for installing
components in vehicles, you should have a specialist fit the awning to
your vehicle.
• The electrical power supply may only be connected by a specialist.
3Scopeofdelivery
WARNING!
Safety instruction: Indicates a hazardous situation that, if not avoided,
could result in death or serious injury.
NOTICE!
Indicates a situation that, if not avoided, can result in property damage.
NOTE
Supplementary information for operating the product.
No. in
fig. 1,
page 1
Awning width
Description
2.6 m,
3 m, 3.5 m 4 m, 4.5 m 5 m, 5.5 m
11x1x1xAwning
2 – – 2x Mounting plate (400 mm)
3 – 2x 2x Mounting plate (160 mm)
4 2x 2x – Mounting plate (80 mm)
DometicPW1000-PW1500-PW1750_INM_4445101838_EMEA18_202x-xx-xx.book Seite 4 Freitag, 5. März 2021 8:30 20

EN
PW1000, PW1500, PW1750 Scope of delivery
5
5 1x – – Mounting plate (35 mm)
6 5x 8x 12x Counter plate
7 5x 8x 12x Square-head bolt
8 2x 4x 6x Countersunk bolt
9 7x 12x 18x Serrated lock washer
10 7x 12x 18x Hexagon nut
11 5x 8x 12x Cover for the counter plate
12 11x 14x 18x Self-tapping screw
13 2x 2x 2x Mounting bracket (lower section)
14 2x 2x 2x Mounting bracket (upper section)
15 1x 1x 1x Crank bracket (lower section)
16 1x 1x 1x Crank bracket (upper section)
(only PW1500, PW1750)
17 4x 4x 4x Rivets
18 4x 4x 4x Pegs
19 1x 1x 1x Crank (only awnings without
motor)
20 – 1x 1x Latch for tension rafter
21 – 1x 1x Hexagon head bolt
22 – 1x 1x Tension rafter
23 – 1x 1x Hexagon nut
24 1x 1x 1x Remote control with connection
material (only PW1500, PW1750,
optional)
25 1x 1x 1x Switch (only PW1500, PW1750,
optional)
No. in
fig. 1,
page 1
Awning width
Description
2.6 m,
3 m, 3.5 m 4 m, 4.5 m 5 m, 5.5 m
DometicPW1000-PW1500-PW1750_INM_4445101838_EMEA18_202x-xx-xx.book Seite 5 Freitag, 5. März 2021 8:30 20

EN
Accessories PW1000, PW1500, PW1750
6
4Accessories
A
Available as accessories (not included in the scope of delivery):
If you have questions regarding the accessories, please contact your local service
partner.
NOTICE!
Only use mounting rails recommended by Dometic fitting both to your
vehicle and to your awning. Using the wrong mounting rails leads to
danger while operating the awning. If you need support in choosing the
correct mounting rails fitting to your vehicle, please ask your local
service partner or visit dometic.com.
Description
TieDown Kit
Straps for anchoring the awning
CampRoom
Awning tent front panel and sides for various models with support legs in different sizes
RainProtect
Front panel and sides available in different sizes
SunProtect
Front panel and sides available in different sizes
Rollo+ (not for PW1750)
Roller blind
Dometic Light LK120
LED light kit with remote control for installation on the awning arms
LED LightStrip
LED strip available in different lengths for installation on the underside of the awning
Led Profile
LED lighting available in different lengths for installation on the underside of wall-mounted
awnings
Awning cleaner
Special awning cleaner
Repair Kit
Awning repair patch
DometicPW1000-PW1500-PW1750_INM_4445101838_EMEA18_202x-xx-xx.book Seite 6 Freitag, 5. März 2021 8:30 20

EN
PW1000, PW1500, PW1750 Intended use
7
5 Intended use
The PerfectWall PW1000, PW1500 and PW1750 awnings are suitable for installing
on motorhomes or caravans.
The awnings must only be used whilst the vehicle is stationary. Please observe the
operating manual.
This product is only suitable for the intended purpose and application in accordance
with these instructions.
This manual provides information that is necessary for proper installation and/or
operation of the product. Poor installation and/or improper operating or mainte-
nance will result in unsatisfactory performance and a possible failure.
The manufacturer accepts no liability for any injury or damage to the product
resulting from:
• Incorrect assembly or connection, including excess voltage
• Incorrect maintenance or use of spare parts other than original spare parts
provided by the manufacturer
• Alterations to the product without express permission from the manufacturer
• Use for purposes other than those described in this manual
Dometic reserves the right to change product appearance and product
specifications.
6 Installing the awning
6.1 Required installation material
For the installation of the awning, you will need:
• Various tools, e.g. screwdriver
• A suitable flexible adhesive/sealant, e.g. Sikaflex®-252
• A cleaning agent that is recommended for use with the adhesive
• A primer that is recommended for use with the adhesive
• Acid-free silicone
DometicPW1000-PW1500-PW1750_INM_4445101838_EMEA18_202x-xx-xx.book Seite 7 Freitag, 5. März 2021 8:30 20

EN
Installing the awning PW1000, PW1500, PW1750
8
6.2 Notes on the installation position
When choosing the installation location, observe the following:
!WARNING!
• Keep a sufficient distance from objects or other vehicles. Once it is
retracted, it should be at least 40 cm away from other objects and
vehicles.
• Ensure the wall of the motorhome can safely take the weight of the
awning before installation. Otherwise, the awning may become unsta-
ble and bend or break.
ANOTICE!
• Make sure that the inner screw joints are accessible.
• Only attach the awning to flat and vertical wall surfaces (fig. 2and
fig. 3, page 1). On curved wall surfaces, the mounting plates need to
be adequately lined under the fastening points.
• If there is insufficient space above the door after the awning is
mounted, the door must remain closed when retracting or extending
to avoid the door making contact with the arms or the lead rail.
The required space depends on the design of the door (door width,
swing or sliding door) as well as the set awning angle of inclination
(fig. 4, page 1).
• The cables and cabinets in the interior of the vehicle may not be
damaged by drilling the holes.
INOTE
• Ensure the user of the vehicle is aware that the screws onthe rear hinge
(fig. 5, page 1) must be tightened up (see operating manual). The
arms must not bear any load. This must be done by the service partner.
DometicPW1000-PW1500-PW1750_INM_4445101838_EMEA18_202x-xx-xx.book Seite 8 Freitag, 5. März 2021 8:30 20

EN
PW1000, PW1500, PW1750 Installing the awning
9
6.3 Installing the awning
During installation, observe the following general information:
• The awning can be attached in two ways:
– to the side of the vehicle using mounting plates
– to the existing piping rail on the side of the vehicle
• The mounting plates are bolted to the vehicle in the area of the rear hinge. In
addition, they are glued with installation adhesive (e.g. Sikaflex®-221 or a similar
product) to ensure the load is evenly spread and an optimal level of protection
from moisture is maintained.
• Observe the sealant manufacturer's instructions.
• Before installation, check the access to the screw joints. Make sure no cables or
cabinets are damaged when drilling.
• Contact your local service partner if you wish to have an angle of inclination
different to the default setting.
• If you want to use an awning tent with the awning at a later date, ensure that the
vent windows and hatches remain accessible with erected tent when choosing
the awning size and installation position (fig. 6, page 1).
• Clean the adhesive surfaces on the mounting rails and the wall.
• Prepare the adhesive surfaces with the primer.
• After gluing, wait until the adhesive has set. For further details, please refer to the
information provided by the sealant manufacturer.
• Carefully seal the drill holes to prevent moisture from entering the motorhome
wall.
• Do not open the awning or leave it unattended, before the awning has been
fastened to the mounting rails.
• As part of the regular maintenance procedure, the screws on the rear hinge must
be tightened up by a service partner. Ensure the users of the vehicle are aware of
this.
Installing the awning with mounting plates
➤Select the location of the installation.
In particular, check that there is enough space in the interior to mount the counter
plates at the points where the screws will be.
INOTE
Recommended mounting position for each counter plate: fig. 7,
page 1.
DometicPW1000-PW1500-PW1750_INM_4445101838_EMEA18_202x-xx-xx.book Seite 9 Freitag, 5. März 2021 8:30 20

EN
Installing the awning PW1000, PW1500, PW1750
10
➤Align the mounting plates on the vehicle and mark where the holes are to be
drilled (fig. 8, page 1).
➤At the marked points, drill holes with a diameter of 6.5 mm from the outside
through the external wall.
➤Clean the outer sides of the mounting plates and the installation surface on the
vehicle.
➤Fill the drill holes in the vehicle wall with an acid-free silicone.
➤Insert the square-head bolts through the relevant holes in the mounting plates
(fig. 9, page 1).
➤To glue and seal, apply an elastic adhesive, such as Sikaflex®-221 for example, to
the back of the mounting plates (fig. 9, page 1).
➤Place all of the mounting plates through the drill holes and fasten them with
counter plate, serrated lock washers and hexagon head bolts (fig. 0, page 1).
➤Only for awnings with a width of 2.6 m to 3.5 m:
Fasten all of the mounting plates using a countersunk bolt, counter plate, ser-
rated lock washer and hexagon nut (fig. a, page 1).
➤Only for awnings with a width of 4 m to 5.5 m:
Fasten the inner (narrow) mounting plates using a countersunk bolt, counter
plate, serrated lock washer and hexagon nut (fig. a, page 1).
➤Wait until the glue has set. For further details, please refer to the information
provided by the sealant manufacturer.
➤Use two people to hook the awning on to the mounting plates (fig. b, page 1).
➤Extend the awning about 50 cm using the crank.
➤Only for awnings with a width of 4 m to 5.5 m:
Drill one hole with a diameter of 6.5 mm through the left and the right side of the
awning. The hole has to be in a distance of 280 mm to the respectiveedge of the
awning and be on the same level as its counterpart in the long mounting plate
(fig. c, page 1).
➤Only for awnings with a width of 4 m to 5.5 m:
Fasten the awning using a countersunk bolt, counter plate, serrated lock washer
and hexagon nut (fig. d, page 2).
➤Insert the cover caps on the counter plates (fig. e, page 2).
➤Drill two holes with a diameter of 3 mm through the awning and each of the long
mounting plates (fig. f, page 2).
DometicPW1000-PW1500-PW1750_INM_4445101838_EMEA18_202x-xx-xx.book Seite 10 Freitag, 5. März 2021 8:30 20

EN
PW1000, PW1500, PW1750 Installing the awning
11
➤Drill one hole with a diameter of 3 mm through the awning and each of the short
mounting plates (fig. f, page 2).
➤Fasten the awning with drill screws (fig. f, page 2).
➤Retract the awning completely using the crank.
Installing awning on the piping rail
➤Select the location of the installation.
In particular, check that there is enough space in the interior to mount the counter
plates at the points where the screws will be.
I
➤Use two people to hook the awning on to the piping rail.
➤Extend the awning about 50 cm using the crank.
➤Mark where the holes are to be drilled (fig. h, page 2).
➤Retract the awning completely using the crank.
➤Use two people to lift the awning from the piping rail.
➤At the marked points, drill holes with a diameter of 6.5 mm from the outside
through the external wall.
➤Fill the drill holes in the vehicle wall with an acid-free silicone.
➤Use two people to hook the awning on to the piping rail.
➤Extend the awning about 50 cm using the crank.
➤Fasten the awning using a countersunk bolt, counter plate, serrated lock washer
and hexagon nut (fig. i, page 2).
➤Insert the cover caps on the counter plates (fig. e, page 2).
➤Retract the awning completely using the crank.
NOTE
Measure the recommended mounting position for each counter plate
against the drill hole in the lower section of the awning.
DometicPW1000-PW1500-PW1750_INM_4445101838_EMEA18_202x-xx-xx.book Seite 11 Freitag, 5. März 2021 8:30 20

EN
Installing the awning PW1000, PW1500, PW1750
12
Installing the mounting bracket
The mounting bracket must be installed if the awning is to be attached to the side of
the vehicle when extended.
➤Select the location of the installation.
➤Mark where the holes are to be drilled.
➤At the marked points, drill holes with a diameter of 3 mm from the outside into
the external wall (fig. j, page 2).
➤Put the upper and lower sections of the mounting bracket together.
➤Clean the outer sides of the lower section and the installation surface in the
vehicle.
I
➤To glue and seal, apply an elastic adhesive, such as Sikaflex®-221 for example, to
the back of the mounting bracket.
➤Fasten the mounting bracket with drill screws (fig. j, page 2).
or
➤Rivet the mounting bracket (fig. j, page 2).
Installing the crank bracket
➤Mount the mounting bracket for the crank at a suitable location inside the vehicle
(fig. k, page 2).
Mounting the tension rafter
Awnings with a width of 4 m to 5.5 m must be secured with a tension rafter.
➤Attach the pre-drilled end of the tension rafter to the latch for the tension rafter
using the hexagon head bolt and the hexagon nut (fig. l, page 2).
➤Insert the lower section of the tension rafter into the upper section (fig. l,
page 2).
NOTE
Make sure that no glue gets on to the movable upper section of the
mounting bracket.
DometicPW1000-PW1500-PW1750_INM_4445101838_EMEA18_202x-xx-xx.book Seite 12 Freitag, 5. März 2021 8:30 20

EN
PW1000, PW1500, PW1750 Connecting the awning (PW1500 and PW1750)
13
7 Connecting the awning (PW1500 and
PW1750)
!
A
There are two options for the electrical connection of the awning:
• Awning switch with an integrated main switch
• Main switch and receiver for the remote control
Observe the following installation instructions:
• Fit the supplied main switch and fuse (15 A) to the positive line of the power sup-
ply. The main switch is required to switch off the awning when side walls are fitted
to the awning, for example, or if the vehicle is taken out of service for an extended
period of time (otherwise the standby consumption may drain the battery).
• Install the receiver on the inside of the vehicle to protect it from moisture.
• Observe the length of the cable between the awning motor and receiver when
choosing a place to install it.
•Donot shorten the antenna cable.
• When installing the supplied plug, use a suitable tool (crimping tool) to ensure
that the connection is secure and durable.
• If you want to connect an awning light (accessory), make sure that its maximum
power consumption is 30 W. When connecting, make sure the polarity is cor-
rect.
WARNING!
•Connecttheignition(D+ signal) to the orange line of the receiver.
This is the only way to ensure that the awning cannot be opened
while driving.
• Only use the original remote control supplied and optional original
wall switch.The use of original parts is the only way to ensure that
with connected D+ signal the power supply is disconnected and the
awning cannot be opened while driving.
• Disconnect the power supply before starting the assembly.
• Only permit a qualified electrician to connect the awning to the elec-
trical power.
NOTICE!
The cables and cabinets in the interior of the vehicle must not be dam-
aged through drilling the holes.
DometicPW1000-PW1500-PW1750_INM_4445101838_EMEA18_202x-xx-xx.book Seite 13 Freitag, 5. März 2021 8:30 20

EN
Connecting the awning (PW1500 and PW1750) PW1000, PW1500, PW1750
14
• Observe the required cable cross section when connecting to the power supply:
Legend to fig. m, page 2:
Installing the wall switch
➤Find a suitable location inside the motor home, out of direct sunlight, to install the
switch.
Installing the receiver of the remote control and connecting the electrical
connections
➤Find a suitable location inside the motor home, out of direct sunlight, to install the
mounting bracket for the remote control.
➤Connect the motor with the remote control in accordance with the applicable
electrical engineering regulations and the circuit diagram (fig. m, page 2).
Cable length Required cable cross section
2 m 1.5 mm²
4 m 2.5 mm²
6 m 4.0 mm²
8 m 6.0 mm²
No. Description
1 Receiver
2 3 A fuse for LED awning light (optional)
3 on Orange line for D+ connection
4 rd Red line for LED awning light (optional)
5 bk Black line for LED awning light (optional)
6 bu Blue line for motor connection
7 bn Brown line for motor connection
8 bk Black line for power supply
9 rd Red line for power supply
10 Main switch
11 15 A fuse for main switch
DometicPW1000-PW1500-PW1750_INM_4445101838_EMEA18_202x-xx-xx.book Seite 14 Freitag, 5. März 2021 8:30 20

EN
PW1000, PW1500, PW1750 Disposal
15
Programming the remote control and the wall switch
➤Place the battery (see fig. n1, page 2).
➤Switch on the power supply.
✔The receiver beeps once briefly.
➤Press the programming button (fig. n2, page 2) or the buttons and on
the wall switch simultaneously (fig. o1 and 2, page 2) within 4 seconds.
✔The receiver beeps once briefly.
➤Press the programming button (fig. n2, page 2) or the buttons and on
the wall switch simultaneously (fig. o1 and 2, page 2) again briefly.
✔The receiver beeps once briefly.
➤Briefly press the button (fig. o3, page 2).
✔The receiver beeps four times briefly.
✔The awning moves briefly.
Proceed as follows to pair the wall switch:
➤Press the programming button (fig. n2, page 2) twice.
✔The receiver beeps twice briefly.
➤Press the buttons and on the wall switch simultaneously (fig. o1 and 2,
page 2).
✔The receiver beeps five times briefly.
✔The remote control or wall switch and awning are now set to one another.
8Disposal
➤Place the packaging material in the appropriate recycling waste bins wherever
possible.
MIf you wish to finally dispose of the product, ask your local recycling centre
or specialist dealer for details about how to do this in accordance with the
applicable disposal regulations.
DometicPW1000-PW1500-PW1750_INM_4445101838_EMEA18_202x-xx-xx.book Seite 15 Freitag, 5. März 2021 8:30 20

DE
PW1000, PW1500, PW1750
16
Lesen und befolgen Sie bitte alle Anweisungen, Richtlinien und Warnhinweise in diesem Produkthandbuch sorgfältig, um sicherzustellen,
dass Sie das Produkt ordnungsgemäß installieren und stets ordnungsgemäß betreiben und warten. Diese Anleitung MUSS bei dem Produkt
verbleiben.
Durch die Verwendung des Produktes bestätigen Sie hiermit, dass Sie alle Anweisungen, Richtlinien und Warnhinweise sorgfältig gelesen
haben und dass Sie die hierin dargelegten Bestimmungen verstanden haben und ihnen zustimmen. Sie erklären sich damit einverstanden,
dieses Produkt nur für den angegebenen Verwendungszweck und gemäß den Anweisungen, Richtlinien und Warnhinweisen dieses Pro-
dukthandbuchs sowie gemäß allen geltenden Gesetzen und Vorschriften zu verwenden. Eine Nichtbeachtung der hierin enthaltenen Anwei-
sungen und Warnhinweise kann zu einer Verletzung Ihrer selbst und anderer Personen, zu Schäden an Ihrem Produkt oder zu Schäden an
anderem Eigentum in der Umgebung führen. Dieses Produkthandbuch, einschließlich der Anweisungen, Richtlinien und Warnhinweise,
sowie die zugehörige Dokumentation können Änderungen und Aktualisierungen unterliegen. Aktuelle Produktinformationen finden Sie
unter dometic.com.
!
Inhaltsverzeichnis
1 Erläuterung der Symbole . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
2 Wichtige Sicherheits- und Einbauhinweise . . . . . . . . . . . . . . . . . . . . . . . . . .17
3 Lieferumfang . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
4 Zubehör. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
5 Bestimmungsgemäßer Gebrauch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
6 Markise montieren . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
7 Markise anschließen (PW1500 und PW1750). . . . . . . . . . . . . . . . . . . . . . . 26
8 Entsorgung . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
WARNUNG!
• Diese Installationsanleitung muss vor der Installation, dem Einrich-
ten, dem Betrieb und der Wartung gelesen und verstanden werden.
Dieses Gerät muss von einer Fachkraft installiert werden.
Eine fehlerhafte Installation kann zu schweren Verletzungen führen.
Umbauten am Gerät können äußerst gefährlich werden und zu
schweren Verletzungen oder zu Geräteschäden führen.
• Diese Installationsanleitung muss beim Gerät verbleiben. Der Besit-
zer muss sie aufmerksam lesen.
DometicPW1000-PW1500-PW1750_INM_4445101838_EMEA18_202x-xx-xx.book Seite 16 Freitag, 5. März 2021 8:30 20

DE
PW1000, PW1500, PW1750 Erläuterung der Symbole
17
1 Erläuterung der Symbole
!
A
I
2 Wichtige Sicherheits- und Einbau-
hinweise
Beachten Sie die vom Fahrzeughersteller und vom Kfz-Handwerk heraus-
gegebenen Sicherheitshinweise und Auflagen.
!WARNUNG! Nichtbeachtung dieser Warnungen kann zum Tod
oder schwerer Verletzung führen.
Gefahr durch Stromschlag
• Wenn Sie nicht über ausreichende technische Kenntnisse zum Ein-
bauen von Komponenten in Fahrzeugen verfügen, sollten Sie sich die
Markise von einem Fachmann ans Fahrzeug montieren lassen.
• Der elektrische Anschluss darf nur durch eine Elektrofachkraft durch-
geführt werden.
3 Lieferumfang
WARNUNG!
Sicherheitshinweis auf eine Gefahrensituation, die zum Tod oder zu
schwerer Verletzung führen kann, wenn sie nicht vermieden wird.
ACHTUNG!
Hinweis auf eine Situation, die zu Sachschäden führen kann, wenn sie
nicht vermieden wird.
HINWEIS
Ergänzende Informationen zur Bedienung des Produktes.
Nr. in
Abb. 1,
Seite 1
Markisenbreite
Beschreibung
2,6 m,
3 m, 3,5 m 4 m, 4,5 m 5 m, 5,5 m
1 1x 1x 1x Markise
2 – – 2x Montageplatte (400 mm)
DometicPW1000-PW1500-PW1750_INM_4445101838_EMEA18_202x-xx-xx.book Seite 17 Freitag, 5. März 2021 8:30 20

DE
Lieferumfang PW1000, PW1500, PW1750
18
3 – 2x 2x Montageplatte (160 mm)
4 2x 2x – Montageplatte (80 mm)
5 1x – – Montageplatte (35 mm)
6 5x 8x 12x Gegenplatte
7 5x 8x 12x Vierkantschraube
8 2x 4x 6x Senkschraube
9 7x 12x 18x Fächerscheibe
10 7x 12x 18x Sechskantmutter
11 5x 8x 12x Abdeckung für Gegenplatte
12 11x 14x 18x Bohrschraube
13 2x 2x 2x Montagehalterung (unterer Teil)
14 2x 2x 2x Montagehalterung (oberer Teil)
15 1x 1x 1x Kurbelhalterung (unterer Teil)
16 1x 1x 1x Kurbelhalterung (oberer Teil)
(nur PW1500, PW1750)
17 4x 4x 4x Niete
18 4x 4x 4x Heringe
19 1x 1x 1x Kurbel (nur Markisen ohne Motor)
20 – 1x 1x Verriegelung für Spannstange
21 – 1x 1x Sechskantschraube
22 – 1x 1x Spannstange
23 – 1x 1x Sechskantmutter
24 1x 1x 1x Fernbedienung mit Anschlussma-
terial (nur PW1500, PW1750, opti-
onal)
25 1x 1x 1x Schalter (nur PW1500, PW1750,
optional)
Nr. in
Abb. 1,
Seite 1
Markisenbreite
Beschreibung
2,6 m,
3 m, 3,5 m 4 m, 4,5 m 5 m, 5,5 m
DometicPW1000-PW1500-PW1750_INM_4445101838_EMEA18_202x-xx-xx.book Seite 18 Freitag, 5. März 2021 8:30 20

DE
PW1000, PW1500, PW1750 Zubehör
19
4Zubehör
A
Als Zubehör erhältlich (nicht im Lieferumfang enthalten):
ACHTUNG!
Verwenden Sie nur von Dometic empfohlene Montageschienen, die
sowohl zu Ihrem Fahrzeug als auch zu Ihrer Markise passen. Die Verwen-
dung falscher Montageschienen führt zu einer Gefährdung beim
Betrieb der Markise. Wenn Sie Unterstützung bei der Auswahl der rich-
tigen Montageschienen für Ihr Fahrzeug benötigen, wenden Sie sich
bitte an Ihren Kundendienst oder besuchen Sie dometic.com.
Beschreibung
TieDown Kit
Gurte zum Abspannen der Markise
CampRoom
Vorzelt-Frontblende und -Seitenwände für verschiedene Modelle mit Stützfüßen in unter-
schiedlichen Größen
RainProtect
Frontblende und Seitenwände in verschiedenen Größen erhältlich
SunProtect
Frontblende und Seitenwände in verschiedenen Größen erhältlich
Rollo+ (nicht für PW1750)
Rollo
Dometic Light LK120
LED-Beleuchtungssatz mit Fernbedienung zur Montage an den Markisenarmen
LED LightStrip
LED-Leiste in verschiedenen Längen für die Montage an der Unterseite der Markise erhält-
lich
LED-Profil
LED-Beleuchtung in verschiedenen Längen für die Montage an der Unterseite der Markise
erhältlich
Markisenreiniger
Spezial-Markisenreiniger
Repair Kit
Markisen-Reparaturflicken
DometicPW1000-PW1500-PW1750_INM_4445101838_EMEA18_202x-xx-xx.book Seite 19 Freitag, 5. März 2021 8:30 20

DE
Bestimmungsgemäßer Gebrauch PW1000, PW1500, PW1750
20
Bei Fragen zu Zubehör wenden Sie sich bitte an Ihren Service-Partner.
5 Bestimmungsgemäßer Gebrauch
Die Markisen PerfectWall PW1000, PW1500 und PW1750 sind geeignet zum
Anbau an Wohnmobile oder Wohnwagen.
Die Markisen dürfen nur im Stand benutzt werden. Bitte beachten Sie die Bedie-
nungsanleitung.
Dieses Produkt ist nur für den angegebenen Verwendungszweck und die Anwen-
dung gemäß dieser Anleitung geeignet.
Dieses Handbuch enthält Informationen, die für die ordnungsgemäße Installation
und den ordnungsgemäßen Betrieb des Produkts erforderlich sind. Installationsfeh-
ler und/oder ein nicht ordnungsgemäßer Betrieb oder nicht ordnungsgemäße War-
tung haben eine unzureichende Leistung und u. U. einen Ausfall des Geräts zur
Folge.
Der Hersteller übernimmt keine Haftung für Verletzungen oder Schäden am Pro-
dukt, die durch Folgendes entstehen:
• Unsachgemäße Montage oder falscher Anschluss, einschließlich Überspannung
• Unsachgemäße Wartung oder Verwendung von anderen als den vom Hersteller
gelieferten Original-Ersatzteilen
• Veränderungen am Produkt ohne ausdrückliche Genehmigung des Herstellers
• Verwendung für andere als die in der Anleitung beschriebenen Zwecke
Dometic behält sich das Recht vor, das Erscheinungsbild des Produkts und dessen
technische Daten zu ändern.
6Markisemontieren
6.1 Benötigtes Montagematerial
Für die Montage der Markise benötigen Sie:
• Diverses Werkzeug, z. B. Schraubendreher
• Geeigneter elastischer Kleber/Dichtmittel wie z. B. Sikaflex®-252
• Reiniger, der zur Verwendung mit dem Kleber empfohlen ist
• Primer, der zur Verwendung mit dem Kleber empfohlen ist
• Säurefreies Silikon
DometicPW1000-PW1500-PW1750_INM_4445101838_EMEA18_202x-xx-xx.book Seite 20 Freitag, 5. März 2021 8:30 20
