DOPOD U1000 User manual

User Manual

2
Please Read Before Proceeding
THE BATTERY IS NOT FULLY CHARGED WHEN YOU TAKE IT OUT OF THE BOX.
DO NOT REMOVE THE BATTERY PACK WHEN THE DEVICE IS CHARGING.
YOUR WARRANTY IS INVALIDATED IF YOU OPEN OR TAMPER WITH THE
DEVICE’S OUTER CASING.
PRIVACY RESTRICTIONS
Some countries require full disclosure of recorded telephone conversations, and
stipulate that you must inform the person with whom you are speaking that the
conversation is being recorded. Always obey the relevant laws and regulations of
your country when using the recording feature of your Pocket PC Phone.
COPYRIGHT INFORMATION
Copyright © 2006 Dopod International Corps. All Rights Reserved.
, , , ExtUSB and VueFLO are trademarks and/or service
marks of High Tech Computer Corp.
Microsoft, MS-DOS, Windows, Windows NT, Windows Server, Windows Mobile,
ActiveSync, Excel, Internet Explorer, MSN, Hotmail, Outlook, PowerPoint, Word,
and Windows Media are either registered trademarks or trademarks of Microsoft
Corporation in the United States and/or other countries.
Bluetooth and the Bluetooth logo are trademarks owned by Bluetooth SIG, Inc.
Wi-Fi is a registered trademark of the Wireless Fidelity Alliance, Inc.
miniSD is a trademark of SD Card Association.
Java, J2ME and all other Java-based marks are trademarks or registered
trademarks of Sun Microsystems, Inc. in the United States and other countries.
Copyright © 2006, Adobe Systems Incorporated.
Copyright © 2006, Macromedia Netherlands, B.V.
Macromedia, Flash, Macromedia Flash, Macromedia Flash Lite and Reader are
trademarks and/or registered trademarks of Macromedia Netherlands, B.V. or
Adobe Systems Incorporated.

3
Copyright © 2006, JATAAYU SOFTWARE (P) LTD. All Rights Reserved.
Copyright © 2006, Dilithium Networks, Inc. All Rights Reserved.
ArcSoft MMS Composer™ Copyright © 2003-2006, ArcSoft, Inc. and its licensors.
All Rights Reserved. ArcSoft and the ArcSoft logo are registered trademarks of
ArcSoft, Inc. in the United States and/or other countries.
Licensed by QUALCOMM Incorporated under one or more of the following
patents:
4,901,307 ; 5,490,165 ; 5,056,109 ; 5,504,773 ; 5,101,501 ; 5,778,338 ; 5,506,865
5,109,390 ; 5,511,073 ; 5,228,054 ; 5,535,239 ; 5,710,784 ; 5,267,261 ; 5,544,196
5,267,262 ; 5,568,483 ; 5,337,338 ; 5,659,569 5,600,754 ; 5,414,796 ; 5,657,420
5,416,797
All other company, product and service names mentioned herein are trademarks,
registered trademarks or service marks of their respective owners.
Dopod shall not be liable for technical or editorial errors or omissions contained
herein, nor for incidental or consequential damages resulting from furnishing
this material. The information is provided “as is” without warranty of any kind and
is subject to change without notice. Dopod also reserves the right to revise the
content of this document at any time without prior notice.
No part of this document may be reproduced or transmitted in any form or by any
means, electronic or mechanical, including photocopying, recording or storing
in a retrieval system, or translated into any language in any form without prior
written permission of Dopod.

4
Important Health Information and Safety
Precautions
When using this product, the safety precautions below must be taken to
avoid possible legal liabilities and damages. Retain and follow all product
safety and operating instructions. Observe all warnings in the operating
instructions on the product.
To reduce the risk of bodily injury, electric shock, fire, and damage to the
equipment, observe the following precautions.
ELECTRICAL SAFETY
This product is intended for use when supplied with power from the
designated battery or power supply unit. Other usage may be dangerous
and will invalidate any approval given to this product.
SAFETY PRECAUTIONS FOR PROPER GROUNDING INSTALLATION
CAUTION: Connecting to an improperly grounded equipment can result in
an electric shock to your device.
This product equipped with a USB Cable for connecting with desk-top or
notebook computer. Be sure your computer is properly grounded (earthed)
before connecting this product to the computer. The power supply cord of
a desktop or notebook computer has an equipment-grounding conductor
and a grounding plug. The plug must be plugged into an appropriate outlet
which is properly installed and grounded in accordance with all local codes
and ordinances.
SAFETY PRECAUTIONS FOR POWER SUPPLY UNIT
• Use the correct external power source
A product should be operated only from the type of power source
indicated on the electrical ratings label. If you are not sure of the type
of power source required, consult your authorised service provider or
local power company. For a product that operates from battery power
or other sources, refer to the operating instructions that are included
with the product.
This product should be operated only with the following designated
power supply unit(s):

5
1. Delta, Model ADP-5FH X
2. Tamura, Model JHA050100Uabb
3. Phihong, Models PSAA05X-050 and PSC05R-050
Car Adapter
1. Phihong, Model CLM10D-050
2. Hwa Ying, Model AP-03
• Handle battery packs carefully
This product contains a Li-ion battery. There is a risk of fire and burns
if the battery pack is handled improperly. Do not attempt to open or
service the battery pack. Do not disassemble, crush, puncture, short
external contacts or circuits, dispose of in fire or water, or expose a
battery pack to temperatures higher than 60˚C (140˚F).
WARNING: DANGER OF EXPLOSION IF BATTERY IS INCORRECTLY
REPLACED. TO REDUCE RISK OF FIRE OR BURNS, DO NOT
DISASSEMBLE, CRUSH, PUNCTURE, SHORT EXTERNAL CONTACTS,
EXPOSE TO TEMPERATURE ABOVE 60˚C (140˚F), OR DISPOSE OF IN
FIRE OR WATER. REPLACE ONLY WITH SPECIFIED BATTERIES. RECYCLE
OR DISPOSE OF USED BATTERIES ACCORDING TO THE LOCAL
REGULATIONS OR REFERENCE GUIDE SUPPLIED WITH YOUR PRODUCT.
SAFETY PRECAUTIONS FOR DIRECT SUNLIGHT
Keep this product away from excessive moisture and extreme temperatures.
Do not leave the product or its battery inside a vehicle or in places where
the temperature may exceed 60°C (140°F), such as on a car dashboard,
window sill, or behind a glass that is exposed to direct sunlight or strong
ultraviolet light for extended periods of time. This may damage the product,
overheat the battery, or pose a risk to the vehicle.

6
PREVENTION OF HEARING LOSS
CAUTION: Permanent hearing loss may occur if
earphones or headphones are used at high volume for
prolonged periods of time.
NOTE: For France, mobile headphones, earphones, and wired remote
controllers for this device have been tested to comply with the Sound
Pressure Level requirement laid down in NF EN 50332-1:2000 and NF EN
50332-2:2000 standards as required by French Article L. 5232-1.
SAFETY IN AIRCRAFTS
Due to the possible interference caused by this product to an aircraft’s
navigation system and its communications network, using this device’s
phone function on board an airplane is against the law in most countries. If
you want to use this device when on board an aircraft, remember to turn off
the phone by switching to Flight Mode.
ENVIRONMENT RESTRICTIONS
Do not use this product in gas stations, fuel depots, chemical plants or
where blasting operations are in progress, or in potentially explosive
atmospheres such as fuelling areas, fuel storehouses, below deck on
boats, fuel or chemical transfer or storage facilities, and areas where the
air contains chemicals or particles, such as grain, dust, or metal powders.
Please be aware that sparks in such areas could cause an explosion or fire
resulting in bodily injury or even death.
EXPLOSIVE ATMOSPHERES
When in any area with a potentially explosive atmosphere or where
flammable materials exist, the product should be turned off and the user
should obey all signs and instructions. Sparks in such areas could cause an
explosion or fire resulting in bodily injury or even death. Users are advised
not to use the equipment at refueling points such as service or gas stations,
and are reminded of the need to observe restrictions on the use of radio
equipment in fuel depots, chemical plants, or where blasting operations
are in progress. Areas with a potentially explosive atmosphere are often,
but not always, clearly marked. These include fueling areas, below deck on
boats, fuel or chemical transfer or storage facilities, and areas where the air
contains chemicals or particles, such as grain, dust, or metal powders.

7
ROAD SAFETY
Vehicle drivers in motion are not permitted to use telephony services with
handheld devices, except in the case of emergency. In some countries,
using hands-free devices as an alternative is allowed.
SAFETY PRECAUTIONS FOR RF EXPOSURE
•Avoid using your device near metal structures (for example, the steel
frame of a building).
•Avoid using your device near strong electromagnetic sources, such as
microwave ovens, sound speakers, TV and radio.
•Use only original manufacturer-approved accessories, or accessories
that do not contain any metal.
•Use of non-original manufacturer-approved accessories may violate
your local RF exposure guidelines and should be avoided.
INTERFERENCE WITH MEDICAL EQUIPMENT FUNCTIONS
This product may cause medical equipment to malfunction. The use of this
device is forbidden in most hospitals and medical clinics.
If you use any other personal medical device, consult the manufacturer
of your device to determine if it is adequately shielded from external
RF energy. Your physician may be able to assist you in obtaining this
information.
Turn the phone OFF in health care facilities when any regulations posted in
these areas instruct you to do so. Hospitals or health care facilities may be
using equipment that could be sensitive to external RF energy.
HEARING AIDS
Some digital wireless phones may interfere with some hearing aids. In the
event of such interference, you may want to consult your service provider,
or call the customer service line to discuss alternatives.

8
NONIONIZING RADIATION
This product should be operated in the suggested normal condition only
to ensure the radiative performance and safety of the interference. As
with other mobile radio transmitting equipment, users are advised that for
satisfactory operation of the equipment and for the safety of personnel, it
is recommended that no part of the human body be allowed to come too
close to the antenna during operation of the equipment.
General Precautions
• Heed service markings
Except as explained elsewhere in the Operating or Service
documentation, do not service any product yourself. Service needed
on components inside these compartments should be done by an
authorized service technician or provider.
• Damage requiring service
Unplug the product from the electrical outlet and refer servicing to
an authorized service technician or provider under the following
conditions:
• Liquid has been spilled or an object has fallen into the product.
• The product has been exposed to rain or water.
• The product has been dropped or damaged.
• There are noticeable signs of overheating.
• The product does not operate normally when you follow the
operating instructions.
• Avoid hot areas
The product should be placed away from heat sources such as
radiators, heat registers, stoves, or other products (including, but
limited to, amplifiers) that produce heat.
• Avoid wet areas
Never use the product in a wet location.

9
• Avoid using your device after a dramatic change in temperature
When you move your device between environments with very
different temperature and/or humidity ranges, condensation may
form on or within the device. To avoid damaging the device, allow
sufficient time for the moisture to evaporate before using the device.
Note:
When taking the device from low-temperature conditions into a
warmer environment or from high-temperature conditions into a cooler
environment, allow the device to acclimate to room temperature before
turning on the power.
• Avoid pushing objects into product
Never push objects of any kind into cabinet slots or other openings
in the product. Slots and openings are provided for ventilation. These
openings must not be blocked or covered.
• Mounting Accessories
Do not use the product on an unstable table, cart, stand, tripod,
or bracket. Any mounting of the product should follow the
manufacturer’s instructions, and should use a mounting accessory
recommended by the manufacturer.
• Avoid unstable mounting
Do not place the product with an unstable base.
• Use product with approved equipment
This product should be used only with personal computers and
options identified as suitable for use with your equipment.
• Adjust the volume
Turn down the volume before using headphones or other audio
devices.
• Cleaning
Unplug the product from the wall outlet before cleaning. Do not use
liquid cleaners or aerosol cleaners. Use a damp cloth for cleaning, but
NEVER use water to clean the LCD screen.

10
Contents
Chapter 1 Getting Started 15
1.1 Getting to Know Your Device and Its Accessories.......... 16
1.2 About the USIM/SIM Card and Battery ........................... 21
1.3 Starting Up........................................................................ 23
1.4 The Today Screen.............................................................. 25
1.5 The Subdisplay ................................................................. 29
1.6 Using the Programs.......................................................... 30
1.7 Device Settings................................................................. 32
Chapter 2 Entering and Searching
for Information 37
2.1 Using the Hardware Keyboard ........................................ 38
2.2 Entering Information ....................................................... 40
2.3 Using the On-screen Keyboard........................................ 41
2.4 Using Letter Recognizer................................................... 41
2.5 Using Block Recognizer.................................................... 42
2.6 Using Transcriber.............................................................. 42
2.7 Using Symbol Pad............................................................. 44
2.8 Using Notes to Draw, Write, and Record Voice Notes .... 45
2.9 Searching for Information ............................................... 45

11
Chapter 3 Using Phone Features 47
3.1 Using the Phone ............................................................... 48
3.2 Making a Call .................................................................... 49
3.3 Receiving a Call................................................................. 52
3.4 Making a Video Call.......................................................... 52
3.5 Receiving a Video Call ...................................................... 56
3.6 Smart Dialing.................................................................... 56
3.7 In-call Options .................................................................. 59
3.8 Additional Dialing Information....................................... 61
3.9 Setting Up Bluetooth SIM Access for Car Kit Phones..... 61
Chapter 4 Synchronizing Information
and Setting Up E-mail Security 63
4.1 Setting Up ActiveSync...................................................... 64
4.2 Synchronizing Information ............................................. 68
4.3 Synchronizing via Bluetooth........................................... 73
4.4 Synchronizing Music, Video, and Pictures...................... 73
4.5 Setting Up E-mail Security............................................... 75

12
Chapter 5 Managing Your Pocket PC Phone 77
5.1 Personalizing Your Pocket PC Phone .............................. 78
5.2 Adding and Removing Programs.................................... 87
5.3 Managing Memory........................................................... 88
5.4 Copying Files..................................................................... 90
5.5 Protecting Your Pocket PC Phone ................................... 91
5.6 Resetting Your Pocket PC Phone ..................................... 93
Chapter 6 Getting Connected 95
6.1 Connecting to the Internet .............................................. 96
6.2 Using VueFLO.................................................................... 99
6.3 Internet Explorer Mobile ............................................... 100
6.4 Using Comm Manager.................................................... 103
6.5 Using Bluetooth.............................................................. 104
6.6 Using Wi-Fi ...................................................................... 114
6.7 Using Internet Sharing................................................... 117
6.8 Using Spb GPRS Monitor ............................................... 118

13
Chapter 7 Exchanging Messages and Using
Outlook 125
7.1 E-mail and Text Messages .............................................. 126
7.2 MMS Messages ............................................................... 135
7.3 Pocket MSN ..................................................................... 140
7.4 Calendar.......................................................................... 142
7.5 Contacts .......................................................................... 143
7.6 Tasks ................................................................................ 148
7.7 Notes ............................................................................... 149
7.8 Voice Recorder................................................................ 152
Chapter 8 Using GPS 155
8.1 Guidelines and Preparation for Using GPS................... 156
8.2 Downloading Satellite Data via QuickGPS................... 158
8.3 Using GPS Software........................................................ 160
8.4 GPS Controls ................................................................... 160
Chapter 9 Experiencing Multimedia 161
9.1 Using Camera.................................................................. 162
9.2 Using Pictures & Videos ................................................. 176
9.3 Using Windows Media Player Mobile............................ 181
9.4 Using Streaming Media.................................................. 188

14
Chapter 10 Using Other Applications 191
10.1 Word Mobile ................................................................... 192
10.2 Excel Mobile.................................................................... 193
10.3 Viewing Slide Shows with PowerPoint Mobile............. 193
10.4 Using Adobe Reader LE.................................................. 194
10.5 Using MIDlet Manager ................................................... 197
10.6 Using ZIP ......................................................................... 200
10.7 Using Voice Commander................................................ 202
Appendix 205
A.1 Regulatory Notices......................................................... 206
A.2 PC Requirement to Run ActiveSync 4.x ........................ 211
A.3 Specifications ................................................................. 212
A.4 Customer Service Information ...................................... 216

1
Chapter
1.1 Getting to Know Your Device and Its
Accessories
1.2 About the USIM/SIM Card and Battery
1.3 Starting Up
1.4 The Today Screen
1.5 The Subdisplay
1.6 Using the Programs
1.7 Device Settings
Getting Started

16
1
Getting Started
1.1 Getting to Know Your Device and Its
Accessories
3
4
1
10
57
89
6
2
11 12

17
1
Getting Started
No. Item Function
1 Navigation Control/
CENTER OK button
Press this multi-directional control up, down,
left, or right to move through menus and
program instructions; carry out the selection by
pressing the CENTER OK button.
2 Notification LED 1 This LED shows battery charging status.
3 Touch Screen Tap the screen with the stylus to write, draw, or
make a selection.
4 Notification LED 2 This LED shows the GSM/UMTS standby/
network status (Green). and GPS indicator
(amber)
5 Notification LED 3 This LED shows the following:
•A flashing Blue light for Bluetooth system
notification of powered-up and ready to
transmit radio frequency signal.
•A flashing Green light for Wi-Fi status.
•When both Bluetooth and Wi-Fi are enabled,
their lights flash alternately.
6 Notification LED 4 This LED shows messages and notifications.
7 Second Camera Use this camera for video call conversations or
to take self landscape photos.
8 OK Button Press to confirm your data entries, or to exit the
program in use.
9 START Button Press to open the Start menu.
10 INTERNET EXPLORER
MOBILE/VueFLO Button
Press to launch Internet Explorer Mobile. Press
this button to activate VueFLO when browsing
the Web.
11 Battery Compartment Open this compartment to insert the SIM/USIM
card, miniSD™ card and battery.
12 Keyboard Copper
Connector
Attach the copper part of the keyboard to this
to be able to use the keyboard. See "Using the
Hardware Keyboard" in chapter 2 to learn how
to attach the keyboard to the main unit.

18
1
Getting Started
16
17
21
22
14
18
19
20
15
25 26
24
23 27

19
1
Getting Started
No. Item Function
14 Stylus Use the stylus to write, draw, or select items on the touch
screen.
15 CAMERA Button Press to launch the Camera; press again to take a photo or
video clip, depending on the specified capture mode.
16 Speaker Listen to audio files and voice calls here.
17 COMM MANAGER/
Voice Commander
button
Press to open Comm Manager. Press and hold to open the
Voice Notes program.
18 POWER Button •Press to turn off the display temporarily. This switches
your device to Sleep mode. You can still receive calls and
messages when your device is in Sleep mode.
•Press and hold (for about 5 seconds) to turn off the
power completely. All functions including the phone will
be unavailable for use.
19 Volume Slider •Slide up or down to adjust the speaker volume.
•During a call, slide up or down to adjust the earpiece
volume.
20 VGA Out/USB port Use this connection to output the contents on the screen to
an external device using the provided VGA out cable. This
also acts as a USB 1.1 host to connect USB peripherals.
21 HTC ExtUSB™ port Use this connector to synchronize data by connecting the
provided USB Sync cable or to recharge the battery via the
provided AC adapter. You can also connect the provided
USB stereo headset for hands-free conversation or for
listening to audio media.
22 3.5 mm Earphone
Jack
Lets you listen to audio media, use a hand-free kit or plug in
a microphone.
23 Car Antenna
Connector
Connect your device to the car antenna while in a car to
have better reception quality.
24 RESET Button With the stylus, press the RESET button to soft-reset your
device.
25 Camera Use the camera to take still photos and record video clips.
26 Flash Light When turned on, it illuminates your subject and allows
you to capture clear photos or video even in a dark
environment. It also flashes when a photo is taken.
27 GPS Antenna
Connector
If you need better GPS signal reception, you can connect an
external GPS antenna.

20
1
Getting Started
No. Item Function
QWERTY keyboard This is similar to a standard PC keyboard.
Connect to the device to use the keyboard
(Please see chapter 2). This also acts as a
protective cover for the device screen.
Accessories (with referred pictures)
2
13
45
6
