Dräger Narkomed 3 Operating manual

DrägerService®
Technical
Service
Manual
Part Number: S002013
Rev: V
Date: 20 May 2002
© 2002 Draeger Medical, Inc.
Narkomed 3
Anesthesia System
RETURN TO CD-ROM TABLE OF CONTENTS
RETURN TO THIS MANUAL'S TABLE OF CONTENTS

RETURN TO CD-ROM TABLE OF CONTENTS
RETURN TO THIS MANUAL'S TABLE OF CONTENTS

DrägerService®
Narkomed 3 Service Manual Table of Contents
Summary of What's New in Rev. B
DESCRIPTION PAGE
SECTION 1:
Introduction ........................................................1-1
SECTION 2:
Diagnostics .........................................................2-1
2.1 Service Selection Screen .....................................2-2
2.2 Configuration Screen .......................................2-3
2.3 Service Data Screen ........................................2-4
SECTION 3:
Troubleshooting ......................................................3-1
3.1 Power Supply and Voltage Distribution .........................3-1
3.2 Multispec Analyzer Power Supply .............................3-4
3.3 Troubleshooting Guide Flow Charts ............................3-5
SECTION 4:
Replacement Procedures ...............................................4-1
4.1 Cylinder Yoke Assemblies ...................................4-2
4.2 Cylinder Pressure Regulators .................................4-5
4.3 Cylinder Cutoff Valves (Canada) ..............................4-9
4.4 Cylinder and Pipeline Pressure Gauges ........................ 4-12
4.5 Flowmeters ............................................. 4-16
4.6 Flow Control Valves ....................................... 4-20
4.7 Oxygen Supply Pressure Failure Protection Device ............... 4-23
4.8 Oxygen Supply Pressure Alarm Switch ........................ 4-26
4.9 Oxygen Supply Pressure Alarm Whistle (Canada) ................ 4-29
4.10 Oxygen Ratio Monitor/Controller ............................. 4-31
4.11 Vaporizers .............................................. 4-37
4.12 O2Flush Valve ........................................... 4-40
4.13 Ventilator Controller Assembly .............................. 4-44
4.14 Ventilator Solenoid Valve ................................... 4-47
4.15 Convenience Outlet AC Power Filter .......................... 4-50
4.16 Inspiratory Flow Regulator ................................. 4-53
4.17 Ventilator Bellows Valve and Guide Assembly ................... 4-56
4.18 Alarm Channel .......................................... 4-66
4.19 Multispec Analyzer ....................................... 4-69
4.20 ECC (Serial Interface) Module ............................... 4-77
4.21 Sphygmomed Module ...................................... 4-79
4.22 Monitors (Typical) ........................................ 4-82
4.23 Trend Assembly .......................................... 4-85
4.24 CCC (Central Communications Controller) Assembly .............. 4-88
Rev. P i
RETURN TO CD-ROM TABLE OF CONTENTS

CONTENTS (continued) NM3
DESCRIPTION PAGE
4.25 CRT Asemblies .......................................... 4-91
4.26 Keypads ................................................ 4-94
4.27 Pulse Oximeter Module .................................... 4-97
4.28 Power Controller Assembly ................................. 4-99
4.29 Multispec Power Supply ................................... 4-101
4.30 Primary Power Supply .................................... 4-103
4.31 Battery Pack ........................................... 4-105
4.32 Caster ................................................ 4-107
4.33 Spiromed Respiratory Volume Sensor ........................ 4-110
4.34 Oxygen Sensor .......................................... 4-112
4.35 Manual Sphygmomanometer ............................... 4-114
4.36 Auxiliary Oxygen Flowmeter ............................... 4-116
4.37 PEEP Valve Magnet Assembly Replacement ................... 4-118
SECTION 5:
Adjustment and Calibration Procedures ...................................5-1
5.1 Cylinder Pressure Regulator Adjustment (except CO2) ..............5-2
5.1A CO2Cylinder Pressure Regulator Adjustment ....................5-4
5.2 Oxygen Supply Pressure Alarm Switch Adjustment ................5-5
5.3 Oxygen Ratio Monitor/Controller Adjustment .....................5-8
5.4 Oxygen Monitor Calibration ................................. 5-12
5.5 Baromed Monitor Calibration ................................ 5-15
5.6 Multispec Analyzer Calibration and Flowrate Adjustment .......... 5-17
5.6A Multispec 4610 Analyzer Calibration and Flowrate Adjustment .....5-23A
5.7 CRT Alignment .......................................... 5-24
5.8 Vaporizer Interlock Adjustment .............................. 5-27
5.9 Vaporizer Select Switch Adjustment ........................... 5-29
5.10 Capnomed (B) Barometric Pressure Adjustment for High Altitudes . . . 5-31
5.11 Capnomed Span Calibration ................................. 5-34
SECTION 6:
PMS Procedure ......................................................6-1
6.1 Manual Sphygmomanometer .................................6-2
6.2 Yoke Assemblies and Gauges .................................6-3
6.3 High Pressure Leak Test ....................................6-5
6.4 Oxygen Supply Pressure Alarm ...............................6-8
6.5 Oxygen Supply Failure Protection .............................6-9
6.6 O2Med Offset Calibration ................................... 6-12
6.7 O2Med Calibration, Accuracy and Alarms Test ................... 6-12
6.8 Oxygen Concentration Test ................................. 6-14
6.9 Flowmeter Test .......................................... 6-16
6.10 Freshgas Leak Test ....................................... 6-19
6.11 Repack MAN/AUTO Selector Valve ........................... 6-20
6.12 Absorber System Inspection ................................. 6-21
6.13 Lubrication, Spiromed Sensor ............................... 6-22
6.14 Breathing System Leak Test ................................ 6-23
6.15 Absorber Flow Direction and Leak Test ........................ 6-23
6.16 APL Valve Test .......................................... 6-25
Rev. T
ii
RETURN TO CD-ROM TABLE OF CONTENTS
RETURN TO THIS MANUAL'S TABLE OF CONTENTS

NM3 CONTENTS (continued)
DESCRIPTION PAGE
6.17 PEEP Bypass Valve ....................................... 6-25
6.18 Ventilator Test ........................................... 6-26
6.19 Ventilator Relief Valve Test ................................. 6-29
6.20 Bellows Drive Gas Leak Test ................................ 6-29
6.21 Bellows PEEP Valve Test ................................... 6-30
6.22 Pressure Limit Control Test ................................. 6-30
6.23 Trace Functions .......................................... 6-31
6.24 Trend Functions .......................................... 6-32
6.25 Spiromed Monitor ........................................ 6-33
6.26 Alarm Circuit Delay Test ................................... 6-35
6.27 BAROMED Monitor Calibration .............................. 6-36
6.28 Continuing Pressure Alarm ................................. 6-37
6.29 High Pressure Alarm ...................................... 6-37
6.30 Sub-Atmospheric Pressure Alarm ............................. 6-37
6.31 Oxygen Ratio Monitor Control Test ........................... 6-38
6.32 Scavenger Interface ....................................... 6-40
6.33 Scavenger, A/C ........................................... 6-43
6.34 Open Reservoir Scavenger .................................. 6-45
6.35 Sphygmomed ............................................ 6-47
6.36 Nellcor O2SatMed ......................................... 6-48
6.36A Novametrix O2SatMed ....................................6-49A
6.37 Capnomed CO2Monitor .................................... 6-50
6.38 Vapor Exclusion System and Indicator Lamps ................... 6-53
6.39 Multispec Accuracy Test ................................... 6-54
6.40 Accessory Attachments and Visual Inspection ................... 6-58
6.41 Battery Circuit Test ....................................... 6-58
6.42 Ground Continuity Test .................................... 6-59
6.43 Chassis Leakage Current Test ............................... 6-60
6.44 Service Data ............................................ 6-60
6.45 Oxygen Flush Test ........................................ 6-61
6.46 Operator’s Manual ........................................ 6-62
6.47 Final Check ............................................. 6-62
SECTION 7:
Software Update Procedure .............................................7-1
7.1 Monitors Firmware Replacement (Typical) .......................7-2
7.2 CCC Assembly Firmware Replacement .........................7-4
7.3 Trend Assembly Firmware Replacement ........................7-6
7.4 ECC (Serial Interface) Module Firmware Replacement ..............7-8
7.5 CRT Assembly (Typical) Firmware Replacement ................. 7-10
7.6 Gas Analyzer Interface PCB (4610) Firmware Replacement ......... 7-12
Rev. P iii
RETURN TO CD-ROM TABLE OF CONTENTS
RETURN TO THIS MANUAL'S TABLE OF CONTENTS

CONTENTS (continued) NM3
SECTION 8:
Spare and Replacement Parts
ASSEMBLY/PART PAGE
Monitor Chassis, Monitors, CCC, Trend/MUX, CRT Assemblies .............. 8-2, 8-3
Front Bezel Assembly, Serial Interface Assembly ........................ 8-4, 8-5
Multispec Analyzer Assembly, incl. PCB Assembly ....................... 8-6, 8-7
Sphygmomed Module, Pulse Oximeter Module ........................... 8-8, 8-9
Ventilator Box Assembly ..........................................8-10, 8-11
Ventilator Bellows Valve & Guide Assembly ...........................8-12, 8-13
Pipeline Inlet, Failsafe, Alarm Channel Assemblies ......................8-14, 8-15
ORMC, Vaporizer Select Switches ...................................8-16, 8-17
Flow Tubes, Gauges, Flow Control Valves, Alarm Channel Items ...........8-18, 8-19
Yoke, Regulator, Flush Valve Assemblies .............................8-20, 8-21
Interface Panels, Power Supply Assemblies, Casters .....................8-22, 8-23
Absorber Assembly, Breathing Pressure Hoses, Oxygen Sensor .............8-24, 8-25
Man/Auto Selector Valve ..........................................8-26, 8-27
Man/Auto Selector Valve (Later Design) ..............................8-28, 8-29
Auxiliary O2Flowmeter Assembly ...................................8-30, 8-31
Open Reservoir Scavenger .........................................8-32, 8-33
Open Reservoir Scavenger, old style .................................8-34, 8-35
A/C Scavenger ..................................................8-36, 8-37
Suction Scavenger ...............................................8-38, 8-39
Rev. K
iv
RETURN TO CD-ROM TABLE OF CONTENTS
RETURN TO THIS MANUAL'S TABLE OF CONTENTS

RETURN TO CD-ROM TABLE OF CONTENTS
RETURN TO THIS MANUAL'S TABLE OF CONTENTS

NARKOMED 3 ANESTHESIA SYSTEM
ALARM AND DATA
DISPLAY SCREENS
PATIENT
INTERFACE
PANEL
MANUAL
SPHYGMOMANOMETER
(OPTIONAL)
BREATHING SYSTEM
SENSOR INTERFACE
PANEL
BOOM ARM
SYSTEM
CONTROL
KEYPAD
MONITORS
SV30101
1-0
RETURN TO CD-ROM TABLE OF CONTENTS
RETURN TO THIS MANUAL'S TABLE OF CONTENTS

NM3 INTRODUCTION
1.0 Recommendations
Because of the sophisticated nature of Draeger Medical, Inc. anesthesia equipment and itscritical
importance in the operating room setting, it is highly recommended that only appropriately
trained and experienced professionals be permitted to service and maintain this equipment.
Please contact DrägerService®at [phone] for service of this equipment.
Draeger Medical, Inc. also recommends that its anesthesia equipment be serviced at three-month
intervals. Periodic Manufacturer’s Service Agreements are available for equipmentmanufactured
by Draeger Medical, Inc. For further information concerning these agreements, please contact us
at [phone].
Draeger Medical, Inc. products/material in need of factory repair shall be sent to:
DrägerService
3124 Commerce Drive
Telford, PA 18969
(Include RMA Number)
HOW TO USE THIS MANUAL
The manual is divided into several sections. The DIAGNOSTICS section describes self-test and
service diagnostics for checking the system functions. An understanding of the on-board service
capabilities is necessary before any attempt is made to troubleshoot the unit. The
TROUBLESHOOTING section lists error codes and provides troubleshooting guides to assist the
TSR in locating the source of a problem. The REPLACEMENT PROCEDURES section contains
instructions for removal and replacement of the assemblies that are considered field-replaceable.
The ADJUSTMENT AND CALIBRATION PROCEDURES section contains the field procedures
needed to restore original system specifications. The Periodic Manufacturer’s Service (PMS)
PROCEDURE section outlines the steps required to verify the electrical, mechanical and
pneumatic safety of the unit and also identifies components requiring periodic replacement.
GENERAL TROUBLESHOOTING GUIDELINES
Troubleshooting the Narkomed 3 should always begin by communicating with those who observed
or experienced a problem with the unit. This may eliminate unnecessary troubleshooting steps.
Once a general problem is identified, refer to the troubleshooting flow charts in Section 3 to
determine the proper corrective action to be taken.
After a component has been replaced, verify that the unit is operating properly by running the
appropriate diagnostic procedure. The PMS PROCEDURE in Section 6 must also be performed
after any component has been replaced.
The general arrangement of the Narkomed 3 Anesthesia System is shown on the opposite page.
WARNINGS are used in this manual before procedures which if not performed correctly could
result in personal injury.
CAUTIONS are used in this manual to alert service personnel to the possibility of damage to the
equipment if a procedure is not performed correctly.
Rev. H 1-1
RETURN TO CD-ROM TABLE OF CONTENTS
RETURN TO THIS MANUAL'S TABLE OF CONTENTS

INTRODUCTION NM3
Copyright
Copyright © 1997 by Draeger Medical, Inc. All rights reserved. No part of this publication
may be reproduced, transmitted, transcribed, or stored in a retrieval system in any form or
by any means, electronic or mechanical, including photocopying and recording, without the
written permission of Draeger Medical, Inc.
Trademark Notices
CliniDAS, Datagrip, NAD Information Systems, NAD Logo, Narkomed, O.R. Data Manager,
O.R. Link, ORM, PC Prep/View, Quality Service For Life, Vigilance Audit, Vitalert, Vitalink
and Narkomed GS are registered trademarks of Draeger Medical, Inc. All other products or
name brands are trademarks of their respective owners.
Disclaimer
The content of this manual is furnished for informational use only and is subject to change
without notice. Draeger Medical, Inc. assumes no responsibility or liability for any errors or
inaccuracies that may appear in this manual.
Rev. K
1-2
RETURN TO CD-ROM TABLE OF CONTENTS
RETURN TO THIS MANUAL'S TABLE OF CONTENTS

NM3 DIAGNOSTICS
2.0 DIAGNOSTICS
When the Narkomed 3 is powered up, each of the monitors performs a six-second self-
diagnostic check and lamp test. The display window on each monitor should show a power-up
code number, and all LED indicators and backlit labels should illuminate. The left-hand CRT
will then show the Centralert Alarm display and the right-hand CRT will show the Data
display.
Table 2-1 lists the possible error codes that may appear in monitor display windows at power-
up or during subsequent use. Record any error codes that appear and communicate them to
the NAD Service Department, or AuthorizedService center during any troubleshooting effort.
Followingthecompletionofthemonitorself-tests,theTechnicalServiceRepresentative(TSR)
can call up service screens at the display panel. The following paragraphs describe each
service screen. If no display is present on the Centralert Alarm CRT or the Data CRT, refer
to Section 3 of this manual for troubleshooting assistance.
TABLE 2-1: NARKOMED 3 ERROR CODES
ERROR CODE DESCRIPTION
E00
E01
E02
E03
E04
E05
E06
E07
E08
E09
E10
ROM error
RAM error
ADC did not start conversion
ADC conversion too long
ADC reading out of range (overflow)
CTC error
Calibration error
Communication lost
Shorted switch (switch closed for >30 seconds)
Non-functional pneumatic control element
ADC reference out of range
2-1
RETURN TO CD-ROM TABLE OF CONTENTS
RETURN TO THIS MANUAL'S TABLE OF CONTENTS

DIAGNOSTICS (continued) NM3
2.1 Service Selection Screen
To access the Service Selection Screen, press and hold the LOG DATA key and
the hidden key directly to the right of the LOG DATA key, then press the
CHECKOUT key. The Service Selection screen appears as shown in Figure 2-1.
The Service Selection Screen displays the available service functions. Access
to these service functions is gained through the Centralert CRT control keys
below the service screen which temporarily function according to their
corresponding on-screen labels. The SELECT key advances the cursor to the
desired menu option, and the ENTER key opens the selected service screen.
Pressing the END CONFIGURE key exits the Service Selection Screen. This
screen also exits automatically after two minutes have elapsed.
Figure 2-1: SERVICE SELECTION SCREEN
CONFIGURE DEFAULTS
> SERVICE DATA
SELECT ENTER END
CONFIGURE
>
Rev. E
2-2
RETURN TO CD-ROM TABLE OF CONTENTS
RETURN TO THIS MANUAL'S TABLE OF CONTENTS

NM3 DIAGNOSTICS (continued)
2.2 Configuration Screen
To access the Configuration Screen, press the SELECT key (see Figure 2-1) to
advance the cursor to the CONFIGURE DEFAULTS option, and then press the
ENTER key. Figure 2-2 shows the Configuration Screen.
This screen allows the TSR to set power-up default alarm limits and display
selections for each monitor in the machine. The default values are stored with
the SAVE key. Press the END CONFIGURE key to return to the Service
Selection Screen. The Configuration Screen also exits automatically after two
minutes have elapsed.
Figure 2-2: CONFIGURATION SCREEN
USING THE MONITOR FRONT PANELS SELECT
THE DEFAULT DISPLAYS AND ALARM LIMITS
THEN PRESS THE SAVE KEY.
SAVE END
CONFIGURE
2-3
RETURN TO CD-ROM TABLE OF CONTENTS
RETURN TO THIS MANUAL'S TABLE OF CONTENTS

DIAGNOSTICS (continued) NM3
2.3 Service Data Screen
To access the Service Data Screen, press the SELECT key (see Figure 2-1) to
advance the cursor to the SERVICE DATA option, and then press the ENTER
key. This screen allows the TSR to view and reset the last service date and
shows the total number of hours of machine usage. It also displays the
software versions of the system subassemblies. A typical Service Data Screen
is shown in Figure 2-3.
The Hours Since Serviced and Service Date are reset by pressing the RESET
key. Pressing the END CONFIGURE key returns the TSR to the Service
Selection Screen.
Figure 2-3: SERVICE DATA SCREEN
LAST SERVICE DATE: 8-AUG-91
HOURS SINCE SERVICED: 00002.0
TOTAL HOURS: 00111.0
CO2/AGT VER 1.03
O2MED VER 1.04
OXIMETER VER 1.07
SPIROMED VER 1.04
SPHYGMOMED VER 2.05
BAROMED VER 1.06
CCC VER 1.08
ECC VER 1.03
ALARMS CRT VER 2.02
RESET END
CONFIGURE
2-4
RETURN TO CD-ROM TABLE OF CONTENTS
RETURN TO THIS MANUAL'S TABLE OF CONTENTS

NM3 TROUBLESHOOTING GUIDE
3.0 TROUBLESHOOTING
This section contains information to assist the Draeger Medical, Inc. qualified
Technical Service Representative (TSR) in locating electrical faults affecting the
NARKOMED 3 monitoring and display devices. Since most troubleshooting efforts
begin with verifying power supply voltages, the following paragraphs outline the
voltagedistributionschemewithinthemachinealongwithconnectorpinidentification
and wire colors.
Also contained in this section are troubleshooting guide flow charts that provide a
method of tracing faults to specific field replaceable assemblies or sub-assemblies in
response to observed failure modes or symptoms.
3.1 Power Supply and Voltage Distribution
In the NARKOMED 3, power for the monitors and CRT displays is distributed
from a terminal block located in the rear of the monitor housing. This terminal
block is accessible by opening the back cover of themonitor housing. Figure 3-1
shows the terminal block inputs and main DC power wiring harness
connections to the power controller PCB assembly.
Table 3-1 shows the nominal DC voltages at the power distribution block and
their acceptable tolerances , under normal load with rated AC voltage applied
to the machine and the System Power switch set to ON.
Table 3-1: DISTRIBUTION BLOCK VOLTAGES
WIRE
COLOR NOMINAL VOLTAGE WITH RESPECT TO COMMON ACCEPTABLE RANGE
Gray +7.4 Unswitched Memory Backup +7.1 to +7.7
Purple -8 Vital -7.75 to -8.25
Yellow +12 Non-Vital +11.7 to +12.3
Orange +8 Non-Vital +7.75 to +8.25
Red +8 Vital +7.75 to +8.25
Figure 3-2 shows the power distribution from the terminal block to the field
replaceable assemblies and CRTs, and also to the backplanes which provide
power distribution to the monitors.
Rev. F 3-1
RETURN TO CD-ROM TABLE OF CONTENTS
RETURN TO THIS MANUAL'S TABLE OF CONTENTS

TROUBLESHOOTING GUIDE (continued) NM3
POWER DISTRIBUTION TERMINAL BLOCK
IN MONITOR HOUSING
POWER CONTROLLER
PCB ASSEMBLY
COM
+8 VITAL
+7.4
-8
COM
+8
+8 VITAL
+12
BLK
RED
GRY
VIO
BLK
ORN
RED
YEL
GND
GRN/YEL
J6-1
J6-2
J6-3
J6-4
J5-1
J5-5
J5-3
J5-4
BLK
RED
GRY
VIO
BLK
ORN
RED
YEL
GRN/YEL
12 34 567 1011 12 14151617 18192021222324 252689 13
+7.4 V -8 V +12 V NV +8 V NV +8 V VITAL COMMON GND
SV30001
Figure 3-1: INPUTS TO POWER DISTRIBUTION BLOCK
3-2
RETURN TO CD-ROM TABLE OF CONTENTS
RETURN TO THIS MANUAL'S TABLE OF CONTENTS

NM3 TROUBLESHOOTING GUIDE (continued)
BACKPLANES
SV30004
+8 VITAL
COM
+12
RED
YEL
J5-1
J5-2
J5-3
BLK
+8 VITAL
COM
+12
RED
YEL
J5-1
J5-2
J5-3
BLK
COM
+8 VITAL
+7.4
-8
BLK
RED
GRY
VIO
J5-1
J5-2
J5-3
J5-4
COM
+8 VITAL
+7.4
-8
BLK
RED
GRY
VIO
J5-1
J5-2
J5-3
J5-4
GND
COM
+8
+8 VITAL
COM
BLK
ORG
RED
BLK
J1-1
J1-2
J2-1
J2-2
PULSE OXIMETER MODULE
SPHYGMOMED
MODULE
COM
+8 VITAL
BLK
RED
J10-1
J10-2
CCC
ASSEMBLY
COM
+8
BLK
ORN
J3-2
J3-1
SERIAL INTERFACE
(ECC MODULE)
COM
+8 VITAL
BLK
RED
J5-1
J5-2
TREND
ASSEMBLY
J5-3 +12 YEL
12 34 5 67 10 11 12 14 15 16 17 18 19 20 21 22 23 24 25 2689 13
+7.4 V -8 V +12 V NV +8 V NV +8 V VITAL COMMON GND
DATA CRT ALARM CRT
Figure 3-2: POWER DISTRIBUTION - NM3 MONITOR HOUSING
3-3
RETURN TO CD-ROM TABLE OF CONTENTS
RETURN TO THIS MANUAL'S TABLE OF CONTENTS

TROUBLESHOOTING GUIDE (continued) NM3
3.2 Multispec Analyzer Power Supply
The multispec analyzer is powered by a separate supply located in the
secondary power supply compartment directly above the power controller PCB
assembly. Table 3-2 lists the nominal DC voltages at the output connector on
the multispec power supply and their acceptable tolerances, under normal load
with rated AC voltage applied to the machine and the System Power switch set
to ON.
Table 3-2: MULTISPEC POWER SUPPLY VOLTAGES
CONNECTOR
AND PIN NOMINAL VOLTAGE ACCEPTABLE RANGE
J2-1
+5 VDC
+4.88 to +5.12
J2-2
J2-3
J2-4
J2-5
+5 V return
J2-6
J2-7
J2-8
+15 VDC
+14.66 to +15.34
J2-9
J2-10
J2-11 +15 V return
J2-12
J2-13 -15 V return -14.09 to -15.91
J2-14 -15 VDC
3-4
RETURN TO CD-ROM TABLE OF CONTENTS
RETURN TO THIS MANUAL'S TABLE OF CONTENTS

NM3 TROUBLESHOOTING GUIDE (continued)
3.3 Troubleshooting Guide Flow Charts
Table3-3lists severalcommonpossible failuremodesandsymptoms(excluding
simultaneous multiple faults) for the monitoring devices in the NARKOMED
3. Each failure mode or symptom is keyed to a troubleshooting guide flow chart
to assist the Technical Service Representative in locating a problem. These
flow charts assume that the machine is plugged into an AC outlet with the
correct voltage, and the machine is not running on its backup battery.
Table 3-3: NARKOMED 3 TROUBLESHOOTING GUIDES
FAILURE MODE / SYMPTOM CORRECTIVE ACTION
CRT Screen Blank or Incorrect Display Guide 1
O2MED Monitor Inoperative Guide 2
BAROMED Monitor Inoperative Guide 3
SaO2 Monitor Inoperative Guide 4
SPIROMED Monitor Inoperative Guide 5
SPHYGMOMED Monitor Inoperative Guide 6
MULTISPEC Monitor and Analyzer Errors Guide 7
Serial Interface Communication Failure Guide 8
Loss of Keypad Response Guide 9
3-5
RETURN TO CD-ROM TABLE OF CONTENTS
RETURN TO THIS MANUAL'S TABLE OF CONTENTS

TROUBLESHOOTING GUIDE (continued) NM3
GUIDE 1: CRT Screen Blank or Incorrect Display
Y
N
N
Y
N
Y
N
Y
Y
N
Y
N
Y
N
Y
N
START
MACHINE IS
FUNCTIONAL
DOES
MACHINE PASS
PMS?
PERFORM A
COMPLETE PMS
ON THE MACHINE
CONTACT NAD
SERVICE DEPARTMENT
REINSTALL ORIGINAL
CCC ASM
IS
DISPLAY
CORRECT?
REINSTALL ORIGINAL
TREND ASM
--------------------------------
REPLACE CCC ASM
AS OUTLINED IN
PROCEDURE 4.24
IS
DISPLAY
CORRECT?
REPLACE
TREND ASM
AS OUTLINED IN
PROCEDURE 4.23
IS
DISPLAY
CORRECT?
CHECK POWER
SUPPLIES AND
ASSOCIATED
WIRING HARNESSES
CONNECT ALL
CRT ASM
CABLES
REINSTALL
ORIGINAL
CRT ASM
CRT
SCREEN
BLANK?
REPLACE CRT ASM
AS OUTLINED IN
PROCEDURE 4.25
VOLTAGE
PRESENT AT J5 ON
CRT?
ALL CRT ASM
CABLES PLUGGED IN
AT BOTH ENDS?
CRT
SCREEN
BLANK?
3-6
RETURN TO CD-ROM TABLE OF CONTENTS
RETURN TO THIS MANUAL'S TABLE OF CONTENTS
