Installation/Operating Instructions
Targa Electric Projection Screen by Draper
Hanging Screen
General:
When locating viewing surface and checking clearance for screen’s operation, remember
surface is centered in case. Handle case carefully to protect its finish.
Regardless of mounting method, screen should be positively and securely supported so
that vibration or even abusive pulling on the viewing surface will not cause case to work
loose or fall. Installer must insure that fasteners used are of adequate strength and suit-
able for the mounting surface chosen.
Suspended Installation:
Suspend screens from holes in endcaps as shown. “S” hooks, chains (or cable) and
turnbuckles should be provided by installer. “S” hooks should go through the front holes
on the endcaps (see drawing on page 2), and both ends of the “S” hooks should be
crimped for additional safety. Chains should be attached to beams or other structural
members. Turnbuckles should be adjusted so screen hangs level.
Wall Installation:
Mount screen through holes in back of endcaps as shown. Installer should furnish
screws, toggle bolts, molly bolts, nylon or lead anchors as required.
Wall Installation with 6" Extension Brackets:
Mount the brackets (not included with screen—see diagram on page 2) using hardware
recommended for “Wall Installation” (above). Then, suspend the screen from the front
holes with “S” hooks (as in “Suspended”). For added safety, be sure to crimp both ends
of the “S” hooks so the screen cannot come off. For a more rigid installation, mount
the screen from the back holes to the front of the bracket by using the screws and nuts
provided with the brackets.
Recessed Installation:
Recess should permit access for removal of screen if necessary. Screen may be
mounted as in suspended or wall installation. Optional Ceiling Opening Trim Kit available;
see diagrams below and on page 2, and separate instruction sheet (included with Ceiling
Opening Trim Kit).
These instructions are meant as a guide only. They do not imply any responsibility on the
part of Draper, Inc. for improper installation or faulty workmanship at the jobsite.
Caution
➀Read instructions through completely before proceeding.
➁Follow instructions carefully. Installation contrary to instructions invalidates warranty.
➂Screen should be accessible for complete removal should fabric become damaged
or should other service be required.
➃Screen should be installed level (using a carpenter’s level).
➄Nothing should be fastened to screen dowel or viewing surface.
➅Operating switch(es) packed separately in screen carton. Do not discard with pack-
ing material.
➆Screen operates on 110-120V, 60 hz., 1.1 amp current draw.
NOTE: Screen has been thoroughly inspected and tested at factory and found to be
operating properly prior to shipment.
Copyright © 2009 Draper Inc. Form Targa_Inst09-R2 Printed in U.S.A.
Operation
Before operating screen remove tape securing fabric and dowel to roller. If viewing surface
hangs out of case 8"-9", tape has probably been broken by rough handling in shipment,
allowing surface to “unwrap” one turn about the roller. Manually wrap fabric back around the
roller without turning the roller itself.
110-120V Single Station Control — 3-position up-off-down switch permits operation to be
stopped at any point. Factory adjusted limit switches automatically stop screen when fully
down or fully up.
110-120V Multiple Station Control—Switches are similar in appearance to 110-120V
Single Station Control. Screen stops when switch is released and may be restarted in either
direction. Factory adjusted limit switches stop screen automatically when fully up or fully
down.
24V Control — Three-button up-stop-down switches stop at any point desired, operate in
any sequence. Factory adjusted limit switches automatically stop screen when fully up or
fully down.
Key Operated Switching — Two kinds of key-operated switches are optionally available
with this unit. ➀ The key-operated power supply switch controls power to the screen and
switches. When it is “off”, the switches will not operate screen. Key may be removed from
the switch in either “on” or “off” position. ➁ A three-position key switch permits the screen to
be operated directly by key. In this case, the screen’s operator must always have a key.
RS232/Ethernet—Serial communication and network communication optionally available
with wall switches, RF or IR remote.
Electrical Connections
Screen operates on 110-120V, 60 hz., 1.1 amp current draw. Duty cycle: On 28 seconds/
Off 4 minutes.
Junction box is located inside left endcap and cover plate is secured to endcap with
two screws. Junction box contains red, black and white pigtail leads and green internal
ground wire, per wiring diagram on reverse.
Screen is shipped with internal wiring complete and control switch(es) fully boxed. Wire
connecting screen to switch(es) and switch(es) to power supply should be furnished by
installer. Connections should be made in accordance with attached wiring diagram, and
wiring should comply with National and local electrical codes. Please Note: Do NOT wire
motors in parallel.
All operating switches should be “off” before power is connected.
®
If you encounter any difficulties installing or servicing your Targa screen, call your
dealer or Draper Inc., Spiceland, Indiana, [phone] or fax [phone].
Screen Case
Back
Ceiling Tile
(By others)
Limit Adjustments (Standard/Quiet Motors)
Tools needed: Flashlight, small flathead screwdriver/Allen wrench (4mm or 5/32").
Screen settings have been factory set as ordered and should not normally require
further adjustment. However, if you find it necessary to adjust for more or less viewing
area, proceed as follows.
CAUTION: Always be prepared to shut screen off manually when new adjustment
is being tested. Screen may be severely damaged if viewing surface is allowed
to run too far up or too far down. When running up, the dowel should never wrap
over the roller. When run to the down limit, a minimum of 1¼ wraps of fabric must
remain on the roller.
The motor limit screws are normally located on the audience left of screen roller, and
the viewing surface rolls off the back of the roller. If the viewing surface is coming off the
front of the roller (motor on left), or the motor is on the audience right of the screen roller
(with viewing surface rolling off the back), reverse the below instructions.
"DOWN" LIMIT ADJUSTMENT
To Reduce Screen Drop
➀Raise screen surface about 1' above desired setting and turn off.
➁Turn the DOWN limit screw (I) clockwise (three screw turns = ½ roller revolution).
➂Test by running screen down and repeat steps 1 and 2 until desired position is
reached.
To Increase Screen Drop
➀Run screen to the down limit.
➁With the down switch on, turn the DOWN limit screw (I) counterclockwise (three
turns of screw equals ½ roller revolution) to increase drop.
➂Test by running screen up about 1' and back down to new down limit.
➃Repeat steps 2 and 3 until desired position is reached.
CAUTION: At least 1¼ wraps of fabric must remain on the roller when screen is
at the down limit!
"UP" LIMIT ADJUSTMENT
Screen is Running Too Far Up
➀Lower screen surface about 1' below desired setting and turn off.
➁Turn the UP limit screw (II) clockwise (three screw turns = ½ roller revolution).
➂Test by running screen up.
➃Repeat steps 1 through 3 until desired position is reached.
Screen Needs to Run Up More
➀Run screen down about 1' and turn off.
➁With the up switch on, turn the UP limit screw (II) counterclockwise (three turns
of screw equals ½ roller revolution).
➂Repeat steps 1 and 2 until desired position is reached.
CAUTION: Do NOT allow the dowel to wrap up over the roller when the screen is
running up! This could damage the screen.
Limit Adjustments (Built-in Low Voltage Motors)
➀Connect the ILT switch to the motor via the terminal blocks, or via the modular port
using four conductor modular cable. When using modular cable, the cable connectors
MUST NOT be crimped in reverse, as with standard telephone cable.
➁Set the slide switch to the lower position. Press and hold the DOWN button on the
switch to move the viewing surface to the desired lower limit. If the screen moves in
the opposite direction, release the DOWN button and press and hold down the STOP
button for four seconds. This will reverse the operation of the UP and DOWN
switches.
➂Set the slide switch to the higher position. Move the viewing surface to the desired
upper limit by pressing and holding the UP button on the wall switch.
➃Return the slide switch to the center position to return to normal operation.
Continued on Page 2

ILT Limit Adjustment Continued from Page 1
➄To set the viewing surface to an alternate format
position, move the viewing surface to the desired
position and press the STOP button. Press and
hold STOP for at least three seconds to record
the position.
Please Note: Pressing and
releasing the UP button on the
switch will move the screen to its
upper limit. Pressing and releas-
ing the DOWN button will move
the screen to its lower limit.
While the motor is in motion, pressing STOP for
less than two seconds will stop the viewing surface at its present position.
Once the motor is stopped, pressing the STOP button will move the viewing
surface to its alternate format position.
Pressing and holding the STOP button, when the motor is at rest or in motion,
for at least three seconds will record a new
alternate format position.
Targa by Draper
Fabric width + 7"
Viewing
surface
31/2"
7/8" dia.
electrical
connection
hole
57/8"
25/16"
51/4"
Case Dimensions
Page 2 of 2
Wall Mounted
Appropriate hardware
provided by installer.
Suspended
Appropriate hardware
provided by installer.
Types of Installation
Optional Ceiling Opening Trim Kit
(Dims-Side View)
21/8"
21/16"
4"
63/4"
11/16"
8"
7/8" hole for
electrical
connection.
Fasteners for
wall mounting
by others.
S Hooks for
suspended
installation
by others.
Methods of Installation
www.draperinc.com (765) 987-799
9
Single Station Control
Internal Screen Wiring
White (Common)
Black (Down)
Red (Up)
Green (Ground)
Dashed wiring
by electrician
Control
switch
Single gang box by others
Min. 4" x 2
1
/ 8 " x 1
7
/ 8 " deep
Blue
Black
Red
Location of key
operated on-off
switch if furnished
To 110-120V Line
Multiple Station Control
Internal Screen Wiring
White (Common)
Black (Down)
Red (Up)
Green (Ground)
Dashed wiring
by electrician
Red
Red
Black
Blue
Blue
Cap off with wire
nut and tape
Black
Red Blue
Black Single gang box by others
Min. 4" x 2
1
/ 8 " x 1
7
/ 8 " deep.
3 shown. More or less equally
feasible.
Location of key
operated on-off
switch if furnished
To 110-120V Line
Wiring Diagrams—110-120V Motor and Quiet Motor
Wiring Diagrams—110-120V Motor and Quiet Motor
with Built-in Low Voltage Controller
Single Low Voltage Control
Internal Screen Wiring
White (Neutral)
Black
Green (Ground)
Dashed wiring
by electrician
To 110-120V Line
Multiple Low Voltage Controls
Internal Screen Wiring
White (Neutral)
Black
Green (Ground)
Dashed wiring
by electrician
To 110-120V Line
Wall Switch,
RF or IR
Receiver,
or integrated
control system
Wall Switches,
RF or IR
Receivers,
or integrated
control systems
Data Cable
Data
Cables
6" Extension
Bracket
S
S
T
T
O
O
P
P
To Motor
with
Built-In
Low Voltage
Slide
Switch
Back View
U
pD
o
w
n
C
o
m
m
o
n
+
5V
DC
To Motor
with
Built-In
Low Voltage
POSITION FUNCTION
DOWN
UP
CENTER
Set LOWER limit
Set UPPER limit
Normal Operation
STOP
Please Note: Do not wire motors in parallel.
