Drawell TDD4-MC User manual

Operation Manual
PPP (Plasma) Gel Maker
Model: TDD4-MC
Thanks for using our equipment! In order to get quick and sincere service,
please read the operation manuals carefully before you operate.

Contents
1. Product Name....................................................................................... 1
2. Application............................................................................................. 1
3. Features................................................................................................. 2
4. Technical Parameters.......................................................................... 2
5. Structure.................................................................................................3
6. Operation............................................................................................... 3
7. How to make PPP autologous........................................................... 6
8. Trouble shooting................................................................................... 6
9. Notice......................................................................................................7
Warranty..................................................................................................... 9
Quality Certificate....................................................................................11
Packing List............................................................................................. 12
Warranty Card......................................................................................... 13
Service Records......................................................................................13

1
1. Product Name
PPP (Plasma )gel Maker, also called PPP autologous collagen
transplantation machine
2. Application
PPP filling technology is made the plasma that extract from
litigant’s blood into gel, and then inject into body. During the
process, our model TDD3-MC is the important equipment to made
blood plasma into autologous collagen, TDD3-MC adopt advanced
cooling and heat system, it can control the temperature accurately,
the autologous collagen made by TDD4-MC replaced the high cost
filler. With good features of no toxic and no side effect, at the same
time, can extract PRP (Platelet Rich Plasma) inject into dermis,
promote skin recovery, help to eliminate wrinkles, enhance the face,
shrink pores , tender skin etc.
1. Fill all kinds of wrinkles
2. Sculpture body
3. Fill the scar
4. Solve the check depression
5. Modify the chin outline
6. Fill the nose

2
7. Improve the profile of body part
3. Features
1). Digital display, adjustable time and temperature.
2). Two rows independent holes for cooling and heating, each row
for 10 holes, its Work separately and without impact each other.
High efficiency for sample handling,
3). Adopt the advanced cooling system, make the cooling simple.
4). Microprocessor with PTD control together, good effect for
temperature control.
5). Naturally outlook and metal structure.
6). Safety and reliable performance, with automatic timing alarm
function.
4. Technical Parameters
1. Power : AC 220V(110V)±22V 50Hz±1Hz 2A (refer
nameplate)
2. Room temperature: 10~37℃
3.Max temperature control: 90℃±0.1℃
4. Capacity: 10 holes (for variety capacity syringes from 1-10ml)

3
5. Dimension: 25×25×14（cm）
6. Rated power: 445W
7. Weight: 5.26Kg
5. Structure
6. Operation
1). Please check the appearance of packing case after
receiving, and the goods should not be happened with sharp hitting
and upending during delivery. Please contact with forwarding agent
and inform our company immediately if occurring above accidents.
2). Unpack the carton, and fetch it out. Then put it into stable
table.
3). check if the power in nameplate is the same with the power

4
you use.
4). Set the parameters. Control panel as follow:
1-Save 2-Time display 3-Temperature display
4-Stop indicator light 5-Start indicator light
6-Start/Stop button 7-Set button 8-Time increase button
9-Time decrease button 10-Temperature increase button
11-Temperature decrease button 12-Cooling indicator light
13-Heating indicator light
a. Set the heating time:
Press [cold/heat] button, when the left red indicator lighten,
press the [set] button and adjust the time by pressing [+] or [-] that
under Time window, long press for quickly increase or decrease.
Then press [Save] to confirm the setting, press [set] to cancel the
setting.

5
b. Set the heating temperature:
Press [cold/heat] button, when the left red indicator lighten,
press the [set] button and adjust the time by pressing [+] or [-]
under temperature window, long press for quickly increase or
decrease. Then press [Save] to confirm the setting, press [set] to
cancel the setting.
c. Set the cooling time:
Press [cold/heat] button, when the left yellow indicator lighten,
press the [set] button and adjust the time by pressing [+] or [-] that
under Time window, long press for quickly increase or decrease.
Then press [Save] to confirm the setting, press [set] to cancel the
setting. (When change into cooling status, time window display
“FAN”)
d. Heating timing:
Under heating condition, press [star], and the green indicator
lighten, heating timing start when temperature reach the setting
data, machine will alarm start at last 10 seconds.
e. Cooling timing:

6
Under heating condition, press [star], and the green indicator
lighten, heating timing start when temperature reach the setting
data, machine will alarm start at last 10 seconds.
7. How to make PPP autologous
Step 1: Blood collection
Step2 : Blood separation
Step 3: PPP collection
Step 4: Heat PPP at 80 ℃for 4 ~8minutes.
(Note:please pre-heat to 80 ℃before put syringes into)
Step 5: Put PPP into cooling holes for 5 minutes. , the the PPP
gel make finished.
Step 6: Inject the PPP gel into the needed place
8. Trouble shooting
Please check the problem according to the following table, if still
can not eliminate the trouble, please contact the buyer.
Display
Trouble
Measures
No display on
control board
No voltage or
over-current protection
Check the power voltage
or change the fuse
E-05
Temperature sensor
error or trouble in
Change the temperature
sensor

7
9. Notice
The machine system will store the last used parameters, if you
power on the machine and don’t operate the machine, it will
pre-heating the last temperature you set.
Note: please operate carefully to avoid burns by high-temperature.
Please don’t turn on and turn off the power frequently in short
time.
Please don’t use the common circuit with high power electric
equipment, so as to avoid to cause interference.
This machine belongs to general laboratory equipment. Should
be placed in a dry, clean environment.
The surface of this machine can be wiped by soft cloth or cotton
yarn with neutral detergent or 70% alcohol solution.
If not use for long time, please power off, unplug and covered
the surface with cloth.
If the machine is damaged and need to be sent back to the
manufacture for repaire, in order to protect the human health and
environment , its necessary to do the disinfection and
heating holes
E-09
Over-temperature more
than 5 ℃
Contact with the
manufacture or buyer

8
decontamination.We reserve the right to accept sterilized
instrument only, and we hope you can understand.

9
Warranty
Respected customers,
Thank you for purchase of our company’s product. To protect
your legal rights and avoid your worries, we provide warranty
service for one year with the main machines. If it is broken under
warranty with un-artificial reason, we will supply free maintenance
service. The customer needs to pay the prime cost of the product
parts if the product has exceeded the warranty period. We will not
supply the free maintenance if any following matter is happened:
1.Exceed of the warranty period or without the warranty card.
2.The trouble is caused by wrong installation, operation and
maintenance.
3.The trouble is caused by the unauthorized uninstalling and
repairing by our company.
4.The trouble is caused by using the rotor not equipped with this
centrifuge.
5.The trouble is caused by war or other irresistible factors.
This centrifuge has been subjected to thorough testing and
quality control before delivery. We promise to do as below:

10
1. One year warranty for this centrifuge (from the date of
delivery).
2. Our company after-service center will build up files in time and
follow up the user's information.
3. We will offer the replacement parts freely if the machine within
warranty

11
Quality Certificate
PPP Gel Maker TDD4-MC
Serial No:
It is certified that the machine is passed quality inspection &
test .
Test Department:
Date:

12
Packing List
Ser.No
Description
Quantity
Remark
1
Gel maker
1Set
√
2
Quality Certificate
1pc
√
3
Operation Instruction
1pc
√
4
Packing List
1pc
√
Packed by:
Date:

13
Warranty Card
Name & Model
PPP (plasma) gel maker TDD4-MC
Specifications
Date of Delivery
Address
Service Records
Date
Contents
Signature

Drawell International Technology Limited
Shanghai Drawell Scientific Instrument Co.,Ltd
Add : Suite 1506,Lane581 XiuChuan Rd.,PuDong New Area,Shanghai,China
Tel: [phone]
Fax: [phone]
Web : www.drawell.com.cn
Email : [e-mail]
