DrBrowns 850T User manual

Deluxe Bottle Warmer
Model Number 850T

2 3
• Read all instructions.
• Do not touch hot surfaces.
• To protect against electrical shock, do not immerse appliance in water or other liquid.
Never immerse the warmer or power cord in water.
• Close supervision is necessary when any appliance is used near children.
• Unplug from outlet when not in use and before cleaning. Allow to cool before putting
on or taking off parts.
• Do not operate any appliance with a damaged cord or plug or after the appliance
malfunctions or has been damaged in any manner.
• Misuse of the product may cause injury.
• The heating element surface is subject to residual heat after use.
• The use of accessory attachments not recommended by Handi-Craft Company may
cause injuries.
• Do not use outdoors. Household and indoor use only.
• Do not let cord hang over edge of table or counter or touch hot surfaces.
• Do not place on or near a hot gas or electric burner or in a heated oven.
• Extreme caution must be used when moving an appliance containing hot liquids.
• To operate, plug cord into wall outlet. To disconnect, turn any control to “off”, then
remove plug from wall outlet.
• Do not use appliance other than for intended use.
• When in use, the warmer contains hot water. Be careful to avoid spilling or splashing
any water on yourself when removing contents from the warmer.
• Before serving, be sure food is at a safe temperature.
• Warming food for long periods is not recommended.
• Before feeding, pour a few drops of the liquid content from the baby bottle on to the
back of your hand to test the temperature.
CAUTION: Always check the content temperature of the bottle or the small jar before
feeding your baby.
• This appliance has a polarized plug (one blade is wider than the other). To reduce the
risk of electric shock, this plug is intended to fit into a polarized outlet only one way. If
the plug does not fit fully into the outlet, reverse the plug. If it still does not fit, contact a
qualified electrician. Do not attempt to modify the plug in any way.
• Before servicing, unplug cord from wall outlet. Do not leave cord within child’s reach.
• Always UNPLUG the warmer before removing and installing the reservoir. Do not
add water directly to the chamber, only add water to the reservoir. Do not remove the
reservoir while working.
• The preheating of the appliance is not necessary.
• A short power-supply cord is provided to reduce the risk resulting from becoming
entangled in or tripping over a longer cord.
CAUTION: Do not use an extension cord.
• Use Distilled Water Only. Using tap water may shorten the life of the unit.
Parts:
A. Hinged lid
B. Main housing
C. Removable water reservoir
D. Control panel and
LCD timer display
E. Removable basket
F. Reversible riser
G. Storage Caps
KEY FEATURES:
1. A water reservoir that is refillable so the user only needs to add water to the
appliance every 6-12 bottle warming cycles. Plus the added benefit of not needing
to empty the remaining water after each use.
2. An adjustable removable basket that configures for easy, fast and reliable warming
of Dr. Brown’s bottle sizes. Standard size food jars can also be heated. The unit will
also hold many competitors’ bottle sizes.
3. A hinged lid on top of the heating chamber is always closed during the warming
cycle to keep steam inside the appliance which creates more efficient and safer
heating in less time. Opens for easy access to remove the bottle or jar.
A
B
C
D
E
F
G
Package Contents:
Deluxe Bottle Warmer
2x Storage Caps
Specifications:
Nominal voltage: 120V AC/60 Hz 300W
READ AND SAVE THESE INSTRUCTIONS
EN
WARNING: Read the ENTIRE instruction manual to become familiar with the features
of the product before operating. Failure to operate the product correctly can result in
damage to the product, personal property and cause serious injury. Failure to operate
this product in a safe and responsible manner could result in injury or damage to the
product or other property. This product is not intended for use by children. Do not
attempt disassembly or use with incompatible components. This manual contains
instructions for safety, operation and maintenance. It is essential to read and follow all
the instructions and warnings in the manual, prior to setup or use, in order to operate
correctly and avoid damage or serious injury.
IMPORTANT SAFETY INSTRUCTIONS
READ AND SAVE THESE IMPORTANT SAFETY INSTRUCTIONS BEFORE USING THIS APPLIANCE
WHEN USING ELECTRICAL APPLIANCES, PRECAUTIONS SHOULD ALWAYS BE FOLLOWED
TO REDUCE THE RISK OF FIRE, ELECTRICAL SHOCK AND INJURY TO PERSONS, INCLUDING
THE FOLLOWING:

4. Position the short neck of the fill opening (with the
reservoir’s flat side up) into the bottom of the slot on the
appliance’s right side. Pivot the reservoir up to a vertical
position and snap into place. (SEE FIGURE 3) Make sure
it’s held firmly in place.
5. The water reservoir will now automatically fill the heating
chamber inside the appliance to the proper level.
NOTE: The Dr. Brown’s Natural Flow®Deluxe Bottle Warmer is unique and
convenient because you don’t have to fill the reservoir every time you want to
use it. The translucent reservoir also acts as a gauge. Simply keep your eye on
the fluid level and refill the reservoir when you can no longer see water inside
the reservoir. During each refill, unplug warmer, empty heating chamber and
rinse with clean water. Do not immerse warmer base in water!
6. Insert the polarized plug into a standard 120V wall outlet.
TO PROGRAM THE CYCLE TIME:
The following times are to be used as a preliminary guide only. There are many
variables that can affect how fast this appliance warms a bottle or food container,
such as the size of the container, the exact starting temperature of the contents
and the type of liquid/food being warmed. All of these factors will impact how the
appliance heats the contents and the final temperature that is reached.
When you begin to use this appliance, you will need to make adjustments to the
length of time to achieve the most appropriate final temperature. The appliance
will keep the “last time used” in memory.* Once you determine the best time for
a specific amount of liquid, you can simply insert another bottle and press the
start button.
Note: When restarting an already warm appliance, one (1) minute is
automatically reduced from the “last time used” to prevent over heating of
bottle.
*Disconnecting the appliance from power will clear the “last time used” from memory.
4. A user programmable warming cycle. This appliance allows the user to
determine the appropriate heating time based on the starting temperature of
the formula and the amount of liquid and keeps that time stored in the unit’s
memory. This results in a 1-button start function for quicker bottle warming.
5. A 4-button digital keypad to set time and turn the appliance on/off. The “last time
programmed” is stored in memory and is displayed when the appliance is turned
on. The LCD timer counts down. There is an audible 5-beep alarm with flashing
LCD when the heating cycle is complete.
6. A backlit display for use at night.
7. Automatic power off after 8 minutes.
8. Automatic over-heating shutdown switch.
9. A polarized plug.
10. Soft feet for stability.
11. Convenient cord storage on the bottom of the unit.
12. ETL listed.
UNPACKING:
When unpacking the appliance for the first time, carefully remove and dispose of all
packing materials. Simply snap the hinged lid in place making sure the parts are fully
engaged, and you’re ready to start to use. (SEE FIGURE 1)
PREPARING FOR USE:
1. Position the Dr. Brown’s Natural Flow®Deluxe Bottle Warmer
on any convenient flat surface. Be sure to place
it and the electrical cord out of the reach of children.
NOTE: Always ensure the appliance is unplugged
when inserting the water reservoir.
2. Remove the water reservoir from the right side of the
main housing.
3. Turn the water reservoir upside down so the small fill opening
is facing up. Fill the reservoir with water through that opening.
(SEE FIGURE 2)
NOTE: Use only distilled water. Using tap water may shorten the life of the unit.
DO NOT EXCEED the recommended amount of water.
54
FIGURE 2
FIGURE 3
FIGURE 1

76
5 oz / 9 oz Wide-Neck
1oz/30mL 1:30 2:20
8 oz Narrow
2 oz / 4 oz Narrow
2oz/60mL 2:00 3:20
3oz/90mL 2:30 3:40
4oz/120mL 3:00 4:00
5oz/150mL 4:00 4:45
6oz/180mL 4:20 5:00
7:40
Room Temp Refrigerator Frozen*
9:45
11:00
12:00
1oz/30mL 2:20 3:15
2oz/60mL 2:45 3:30
3oz/90mL 3:10 4:00
4oz/120mL 3:35 4:30
7:30
9:00
10:00
11:00
12:00
13:00
7oz/210mL 4:25 5:15 13:30
8oz/250mL 4:35 5:30 14:00
1oz/30mL 1:20 3:00
2oz/60mL 1:40 3:45
3oz/90mL 2:00 4:45
4oz/120mL 2:20 5:00
5oz/150mL 2:50 5:15
6oz/180mL 3:00 5:30
2:30
5:15
8:00
9:15
11:00
11:05
7oz/210mL 3:20 5:45 11:15
8oz/250mL 3:30 6:00 11:20
9oz/270mL 3:40 6:05 11:30
Dr. Brown’s Plastic Bottle
Warming Time Chart
*Frozen: Multiple cycles are required for times exceeding 8 minutes (cycle 1 + cycle 2=total time) Room Temp Refrigerator Frozen*Food Jar
1oz/30mL 1:40 2:10
2oz/60mL 1:50 2:50
3oz/90mL 2:00 3:20
4oz/120mL 2:10 3:30
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
2:10 3:30
4oz/120mL
5 oz / 9 oz Wide-Neck
1oz/30mL 2:00 2:15
2oz/60mL 2:15 2:30
3oz/90mL 2:35 3:00
4oz/120mL 2:45 3:15
5oz/150mL 3:00 3:20
6oz/180mL 3:15 3:30
7oz/210mL 3:30 4:00
8oz/250mL 3:40 4:15
9oz/270mL 3:45 4:30
1oz/30mL 1:10 1:40
2oz/60mL 1:30 2:10
3oz/90mL 1:40 2:30
4oz/120mL 1:50 2:50
5oz/150mL 2:00 3:30
6oz/180mL 2:20 3:40
7oz/210mL 2:30 4:00
8oz/250mL 2:40 4:30
8 oz Narrow
Room Temp Refrigerator FrozenDr. Brown’s Glass Bottle
2 oz / 4 oz Narrow
WARNING: THIS TIME CHART IS APPROXIMATE FOR DR. BROWN’S™ VESSEL SIZES.
WARMING TIMES WILL VARY DEPENDING ON THE VESSEL MATERIAL, SHAPE AND VOLUME.
TEMPERED GLASS HAS BEEN TESTED FOR USE IN THE DR. BROWN’S NATURAL FLOW® DELUXE BOTTLE WARMER.
WE DO RECOMMEND GRADUAL WARMING TO PREVENT BREAKAGE.
ALWAYS TEST TEMPERATURE BEFORE FEEDING! DO NOT FREEZE GLASS BOTTLES!

8 9
FIGURE 4
TO OPERATE THE APPLIANCE:
1. Bottle: Remove all bottle components,
fill the bottle with milk, apply storage
cap (included) and secure, position
bottle in the basket and then place
it into the heating chamber.
Food Jar: Loosen lid and position jar in the
basket and then put it into the heating chamber.
NOTE: The basket has 2 parts. The bottom section can be turned upside
down so that smaller bottles sit higher up in the heating chamber and are
easier to remove. (SEE FIGURE 4)
CAUTION: To prevent the bottle from leaking, always remove all bottle
components and use the included storage cap during warming.
NOTE: To empty the heating chamber, unplug the product and remove the
reservoir from the side. With the cover open, tip the unit over a sink with the
reservoir opening facing up and drain any remaining fluid from inside the
heating chamber through the top opening.
2. Close the cover. Never use this appliance without the basket insert in place
and properly adjusted for the bottle or jar size.
CAUTION: DO NOT open the lid of the heating chamber once the heating cycle
has been started. DO NOT reach over the top of the unit while it is in operation
as this could cause injury.
3. Press any button on the keypad (except O) to display the
“last time used”. If correct, press >. If you want to adjust
the time, press the up arrow button to increase the length
of time or the down arrow button to decrease the time.
NOTE: Pressing and holding an arrow button will cause
the timer display to change very fast. To change the
timer slowly, push and release the arrow button so the numbers move
incrementally. Once the display shows the desired time, press start button.
(SEE FIGURE 5)
4. When the heating cycle is complete the display will flash 00:00 for 60 seconds
and then shut off. At that time, there will be 5 audible beeps that indicate
the cycle time you selected is complete and the bottle or food is ready to be
removed from the appliance. You can open the top of the product at this point.
NOTE: You can turn the appliance off any time by pressing the O button.
CAUTION: Be careful of the steam rising out from the heating chamber.
DO NOT put your hands on or around the heating chamber during or
immediately after the heating cycle.
FIGURE 5
5. Grasp the side tabs of the basket and remove it immediately
to prevent residual heating. Place it on the countertop and
remove the bottle or jar. (SEE FIGURE 6)
6. Gently swish the fluid in the bottle around or stir the food
thoroughly so the temperature becomes uniform throughout
the container.
7. ALWAYS TEST THE TEMPERATURE OF THE FLUID OR FOOD
BEFORE FEEDING YOUR BABY.
NOTE: The appliance is programmed to automatically reduce the time for an
additional heating cycle started within 15 minutes of the end of the previous
cycle. If you heat a second bottle immediately, you will see that time is reduced
by a pro-rated amount unless you override the feature and set a new time
yourself.
NOTE: The appliance is equipped with an internal sensor that will automatically
shut the unit off if it gets too hot or runs out of water. The switch will
automatically reset once the unit cools down.
NOTE: For microbiological and hygienic reasons, once milk or food is heated,
it should not be re-heated again and should be discarded if not used
immediately. Please consult your health professional for further guidance
about safety recommendations on feeding.
TO CLEAN THE APPLIANCE:
• Always unplug the appliance and ensure it is cool before cleaning any part.
• Remove water reservoir and empty all water out of the unit.
• Rinse reservoir with mild soapy water and rinse with clean water.
• Wipe the exterior surfaces as well as the inside of the heating chamber with a
damp cloth or sponge using mild soap. DO NOT submerge the unit in any water
or liquid.
• Removable baskets are dishwasher safe (top rack) or wash with soapy water.
Rinse with clean water. Air dry.
• DO NOT use scouring pads, abrasives, bleach or solvents for cleaning.
• DO NOT disassemble the product. There are no serviceable parts inside.
FIGURE 6
WSW004_F2
