DrBrowns natural flow Insta-Feed AC184 User manual

Insta-Feed™
Bottle Warmer
Model Number AC184
Use distilled water only.
INSTRUCTIONS FOR USE

1
READ AND SAVE THESE INSTRUCTIONS
Package Contents:
Insta-Feed™ Bottle Warmer
Quick Reference Guide
2x Storage Caps
WARNING: Read the ENTIRE instruction manual to become familiar with the features of
the product before operating. Failure to operate the product correctly can result in dam-
age to the product, personalproperty and cause serious injury. Failure to operate this
product in a safe and responsible manner could result in injury or damage to the prod-
uct or otherproperty. This product is notintended for use by children. Do not attempt
disassembly or use with incompatible components. This manual contains instructions for
safety, operation and maintenance. It is essential to read and follow all the instructions
and warnings inthe manual, prior to setup or use, in order to operate correctlyand avoid
damage or serious injury.
IMPORTANT SAFETY INSTRUCTIONS
READ AND SAVE THESE IMPORTANT SAFETY INSTRUCTIONS BEFORE USING THIS APPLIANCE
WHEN USING ELECTRICAL APPLIANCES, PRECAUTIONS SHOULD ALWAYS BE FOLLOWED TO
REDUCE THE RISK OF FIRE, ELECTRICAL SHOCK AND INJURY TO PERSONS, INCLUDING THE
FOLLOWING:
• Read all instructions.
• Do not touch hot surfaces. Use handles or knobs.
•
CAUTION: Hot surface icon indicates the part will get hot during use, including
Sterilizing Lid and Adapter Ring. Be careful to avoid touching them when in use.
• To protect against electrical shock, donot immerse cord or plug in water or other liquids.
• Close supervision is necessary when any appliance is used near children.
• This appliance shall not be used by children. Keep the appliance and its cord out of
reach of children.
• Unplug from outlet when not in use and before cleaning. Allow to cool before putting
• Do not operate any appliance with a damaged cord or plug or after the appliance
malfunctions or has been damaged in any manner. Return appliance to the nearest
authorized service facility for examination, repair or adjustment.
• Misuse of the product may cause potential injury.
• The heating element surface is subject to residual heat after use.
• The use of accessory attachments not recommended by Handi-Craft™ Company and
may cause injuries.
• Do not use outdoors. Household and indoor use only.
• Do not let cord hang over edge of table or counter or touch hot surfaces.
• Do not place on or near a hot gas or electric burner or in a heated oven.
• Extreme caution must be used when moving an appliance containing hot liquids.
remove plug from wall outlet.
• Do not use appliance for other than intended use.
• Never immerse the warmer or power cord in water.
• When in use, the warmer contains hot water. Be careful to avoid spilling or splashing
any water on yourself when removing contents from the warmer.
• Before serving, be sure food is at a safe temperature.
EN
Nominal voltage: 120VAC/60Hz 500W

2
• Warming food for long periods is not recommended.
• Food should not be heated for too long
• Before feeding, pour a few drops of the liquid content from the baby bottle on to the
back of your hand to test the temperature.
CAUTION: Always check the content temperature of the bottle or the small jar
before feeding your baby.
• This appliance has a polarized plug (one blade is wider than the other). To reduce the risk
• Before servicing, unplug cord from wall outlet. Do not leave cord within child’s reach.
• The preheating of the appliance is not necessary.
• A short power-supply cord is provided to reduce the risk resulting from becoming
entangled in or tripping over a longer cord.
CAUTION: Do not use an extension cord.
• This appliance is designed to be used for domestic and like applications such as:
— farms,
— use by hotel, motel customers and other accommodation environments,
— bed and breakfast environments.
• Appliance can be used by persons with reduced physical, sensory or mental
capabilities or lack of experience and knowledge if they have been given supervision
or instruction concerning use of the appliance in a safe way and understand the
hazards involved.
• Children shall not play with the appliance.
• If the supply cord is damaged it must be replaced by the manufacturer, its service
• Any maintenance servicing should be performed by an authorized service representative
SAVE THESE INSTRUCTIONS
Use Distilled Water Only. Using tap water may shorten the life of the unit and
result in voiding the warranty.
BOTTLE WARMER:
1. Sterilizing Lid
2. Adapter Ring
3. Warming Chamber
4. Power Button
5. Indicator Light
6. Measuring Cup
7. Lift-Out Basket
8. Storage Caps
(Narrow and
Wide-Neck)
1
3
4
8
5
2
7
6
I

3
WARMING BOTTLES AND FOOD JARS
1. Remove the Measuring Cup from the rear of the warmer.
2. Add DISTILLED water to the Measuring Cup, following
the Warming Guide on page 5 to determine the
amount of water to add based on your bottle type.
NOTE: These amounts are a guide only. There
temperature of the bottle or food jar you are
warming, such as starting temperature, size, and
shape. Always test the temperature before feeding
your baby.
3. Pour the DISTILLED water from the Measuring Cup directly into the Warming
or may cause damage to the unit.
4. Replace the Measuring Cup and plug in the power cord.
automatically. If the Indicator Light is on upon plugging unit in, wait for the
down for 10 minutes before using.
5. Place the bottle or food jar inside the Warming Chamber as outlined below.
• Wide Neck Bottle: Place bottle directly into Warming Chamber.
• Narrow Bottle: Place Adapter Ring on top of Warming Chamber, then place
bottle in Warming Chamber. The Adapter Ring will keep your bottle centered
over the heating plate for even warming.
NOTE: To prevent leakage when warming Dr. Brown’s®
bottles, remove the internal parts, collar, and nipple/teat,
and replace with the included Storage Cap.
• Food Jar: Place food jar into the Lift-Out Basket, then place Lift-Out Basket in
Warming Chamber.
NOTE: Always remove the lid of the food jar prior to warming. After
warming cycle is complete, be sure to stir food thoroughly until it is an
even temperature throughout.
6. Press the Power Button. The Indicator Light will turn on, indicating the warming cycle
has begun.
CAUTION: Always add water and then press Power Button. If the Power
NOTE: If the Power Button is pressed without water added, the unit will shut
to allow warmer to cool before adding water and starting warming cycle.
7.
bottle/food jar promptly to avoid overheating.
NOTE: Always test the temperature before feeding your baby. Adjust the
amount of water added to the warming chamber as needed; if the
bottle/food jar is too cold, add slightly more water next time. If the
bottle/food jar is too warm, use slightly less water next time.
8. Wait at least 10 minutes to allow warmer to cool before using again.
USE DISTILLED
WATER ONLY!
Tap water and bottled
water contain minerals
that shorten the life of this
appliance. Damage from
use of non-distilled water
will void the warranty.

4
1
4
6
2
5
Wide-Neck
Bottle
Narrow
Bottle
Food
Jar
7
3
8
10

5
Bottle/Jar Type Volume Temperature* Fill Line (ml)
*Room Temp = 72 º F/22 ºC, Refrigerator = 39ºF/4ºC
WARNING: THIS TIME CHART IS APPROXIMATE FOR DR. BROWN'S®BOTTLE VESSELSIZES.
WARMING TIMES WILL VARY DEPENDING ONTHE BOTTLE VESSELSHAPE AND VOLUME.
DO NOT USE THIS WARMER FORFROZEN MILKORFOOD. ALWAYS THAW FROZEN MILKOR
FOODOVERNIGHT INTHE REFRIGERATOR FIRST BEFORE WARMING.
ALWAYS TEST TEMPERATURE BEFORE FEEDING!
Plastic
Glass
Plastic
Glass
Glass
4 oz / 120 ml
4 oz / 120 ml
8 oz / 250 ml
8 oz / 250 ml
Room Temp
Refrigerator
Room Temp
Refrigerator
8
14+2
8
14+2
5
10
4
7
14+4
14+14+2
14+7
14+14+14+4
8
14+2
10
14+8
14+2
Room Temp
Refrigerator
Room Temp
Refrigerator
Room Temp
Refrigerator
Room Temp
Refrigerator
Room Temp
Refrigerator
Room Temp
Refrigerator
Room Temp
4 oz / 120 ml
4 oz / 120 ml
8 oz / 250 ml
8 oz / 250 ml
5 oz / 150 ml
5 oz / 150 ml
9 oz / 270 ml
9 oz / 270 ml
5 oz / 150 ml
5 oz / 150 ml
9 oz / 270 ml
9 oz / 270 m
4 oz / 120 ml
WARMING GUIDE

6
STERILIZING SMALL PARTS
1. Add 2 oz / 60 ml of DISTILLED water directly into the Warming Chamber. Do not
2.
Lift-Out Basket.
3. Place the Lift-Out Basket with small parts into the Warming Chamber.
4. Place the Adapter Ring on top of the Warming Chamber.
5. Place the Sterilizing Lid on top of the Adapter Ring.
6. Plug in the power cord and press the Power Button. The Indicator Light will turn on,
indicating the sterilizing cycle has begun.
7.
8. Allow the unit to cool for at least 10 minutes before removing the Sterilizing Lid,
Adapter Ring, and Lift-Out Basket.
NOTE: Be sure to observe the 10-minute cooling time as warmer parts and
sterilized parts will be hot. Always remove the Sterilizing Lid carefully by the
handle. Take care when removing the Sterilizing Lid as there may be some
residual steam—keep hands and face away. Allow the steam to clear before
reaching into the unit. Always retrieve the sterilized parts by removing the
Lift-Out Basket.
1
4
7
2
5
8
10
3
6

7
TROUBLESHOOTING TIPS
• If the warmer is not operating, check that the power cable is connected to the
power outlet and water has been added to warming chamber.
• If Indicator Light does not come on/warming cycle does not start, warmer may be
cooling down. Wait 10 minutes and try again.
• If Indicator Light comes on upon plugging in but before Power Button is pressed, it
is possible the Power Button was pressed while the warmer was unplugged. Wait
cool down for 10 minutes before using.
• If bottle/food is too warm/too cold after warming cycle, note the Warming Guide
only shows approximate amount of water needed. Warming times are impacted
by many variables, so adjust the amount of water added as needed. If the bottle/
food jar is too cold, add slightly more water next time. If the bottle/food jar is too
warm, use slightly less water next time.
ALWAYS TURN OFF, UNPLUG, AND ALLOW THE UNIT TO COOL BEFORE CLEANING.
Bottle Warmer Unit: Wipe outer surface and inside the Warming Chamber with a
damp cloth or sponge using mild liquid soap. Wipe with clean water and allow unit to
air dry. DO NOT SUBMERGE UNIT IN WATER.
Lift-Out Basket, Adapter Ring, Sterilizing Lid, and Measuring Cup: Dishwasher safe
(top rack only) or wash with soapy water. Rinse with clean water and allow to air dry.
It is recommended to de-scale you Insta-Feed™ Bottle Warmer every four weeks to
ensure the unit continues to work properly. To de-scale, follow the steps below.
1. Unplug the appliance from power.
2. Mix 2 oz / 60 ml of white vinegar with 4 oz / 120 ml of distilled water.
DO NOT USE BLEACH.
3. Pour the white vinegar and water mixture directly into the Warming Chamber.
4. Allow the mixture to stand in the unit until any mineral deposits dissolve.
5. Discard the cleaning mixture and rinse with clean water.
6. Wipe the Warming Chamber dry with cloth or allow to air dry.
NOTE: DO NOT USE BLEACH, HARSH ABRASIVES OR SOLVENTS TO CLEAN THE
WARMING CHAMBER OR HEATING ELEMENTS AS THEY MAY CAUSE PERMANENT
DAMAGE AND WILL VOID THE WARRANTY.

8
LIMITED PRODUCT WARRANTY:
Dr. Brown’s Natural Flow® Insta-Feed™ Bottle Warmer includes a one-year warranty
against defects in material and workmanship from date of purchase. In the unlikely
event of a malfunction or defect during the warranty period, please contact
Handi-Craft’s Customer Service. If outside of the US or Canada, please contact your
local distributor. You will be required to provide proof of purchase.
PLEASE NOTE: This warranty does not cover a defect that has been caused by
negligence, accidents or improper use of the appliance. To keep your Insta-Feed™
Bottle Warmer in good condition and retain your warranty, USE ONLY DISTILLED
WATER.
CUSTOMER SERVICE
If you experience unsatisfactory operation or have questions/comments, please call
Handi-Craft’s Customer Service at 1-800-778-9001, send anemail to info@handi-craft.
com, or write to Handi-Craft Company, Customer Service, 4433 Fyler Avenue, St. Louis,
Missouri 63116 USA. Our Customer Service Representative will advise you how to correct
the problem yourself or will ask you to return the product for repair or replacement.
If outside of the US or Canada, please contact your local distributor.
FCC Compliance Statement
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause
harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired
operation.
Importer: Handi-Craft Company
Address: 4433 Fyler Ave., St. Louis, MO63116
Phone: [phone]
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the
FCC Rules.These limits are designed to provide reasonable protection against harmful interference in a residential installation.This
equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no guarantee that interference will notoccur in a
particular installation.
If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the
•Reorient or relocate the receiving antenna.
• Increase the separationbetween the equipment and receiver.
• Consult the dealer or an experienced radio/TV technician for help.
void the user’s authority to operate the equipment.
WSW007_F1
