Dremel DigiLab 3D45 User manual

R ad th Dr m l 3D45 manual and
th s instructions b for unclogg d
th xtrud r in your Dr m l 3D45. Failur to comply with
th warnings and instructions may r sult in fir , quip-
m nt damag , prop rty damag , or p rsonal injury.
Always unplug Dr m l 3D45 from its pow r b for p r-
forming any s rvic proc dur s. Failure to do so may re-
sult in personal injury and equipment damage.
Us only Dr m l approv d mat rials and compon nts.
Use of object materials, or 3D objects other than Dremel
approved object materials and genuine Dremel components
may void warranty.
Repairs on the Dremel 3D45 may require the use of special
tools (pulling devices and bearing press). Authorized repair
centers have trained repair technicians and equipment
necessary to perform these repairs.
For the location of the repair center near you, please call
1-844-4DRML3D (1-844-437-6533) Monday thru Friday,
8AM to 6PM CST. Or, look on our web site at
www.Dremel3D.com and follow the link for ‘Support’.
3D45 Unclog Extrud r
PRE-SERVICE PREPARATION
CONTINENTAL UNITED STATES CANADA
Dremel Service Center
4915 21st Street
Racine, WI 53406
Phone: 1-844-4DRML3D
Giles Tool Agency
47 Granger Ave,
Scarborough, O
M1K 3K9, Canada
Phone:[phone]
West Coast Tool
4008 Myrtle Street
Burnaby, B.C. V5C 4G2
Phone: [phone]
This document will outline the steps necessary to clear a
clog in the heatsink tube assembly caused by the filament
bulging up inside the tube. If the filament becomes clogged,
neither loading nor unloading will be possible. Tube clogging
can occur by either using an old filament that’s kept in the
open for a longer duration or from 3rd party filaments with
lower transition temperatures.
Tools R quir d:
• Unclog tool
• Brush
• Scissors
• Pliers
• 2mm Hex bit or Hex wrench (Allen key)
• 2.5mm Hex bit or Hex wrench (Allen key)
• T10 Torx bit or screwdriver (no longer than 4 inches).
Pr v ntativ M asur s:
In order to help avoid clogging please follow the recommen-
dations below.
1. Only use Dremel filament.
2. Always unload the filament from the printer when not in
use.
3. Always wait for the extruder to cool down see thermome-
ter icon on screen empty.
4. Store your filament in a dry environment with a desiccant
bag and clip the free end of the filament to the two holes
in the spool to prevent filament getting tangled or brittle-
ness.
Please call Dremel service center for help in unclogging
your extruder.

A) Purg Filam nt:
1. Pre-heat the extruder, go to Tools/Pre-heat. Wait until the
extruder reaches the recommended temperature for your
filament then click on purge when the icons turns green.
Check for filament extruding. If there is no filament coming
out your nozzle, please go to the next step.
2. Go to filament, select edit/view settings and increase the
temperature of the extruder by 10°C go back to preheat
and purge. Check for filament extruding. If there is no
filament coming out your nozzle, please go to step B.
Tip: A good way to speed up the pre-heat process of the
extruder is to click the pause icon on the screen for the
platform temperature, this will allow your 3D printer nozzle
to heat up faster.
B) Pull Filam nt:
1. Pre-heat the extruder, go to Tools/Pre-heat. Wait until the
extruder temperature reaches the recommended temper-
ature for your filament.
2. Grab the filament end that is available with the pliers, push
on the side lever in the extruder to release tension on the
filament and pull the filament at the same time with pliers.
C) Push Filam nt:
1. Cut filament.
2. Pre-heat the extruder, go to Tools/Pre-heat. Wait until the
extruder temperature reaches the recommended temper-
ature for your filament.
3. Push down on the lever on the side of extruder to release
tension on the filament, and push the filament with a light
force using the unclog tool. Check for filament extruding.
2
SERVICE

3
D) Ch ck for Clogs in St pp r Motor:
Us prop r anti-static pr cautions
wh n p rforming this r plac m nt.
Discharge static electricity before beginning. Work on a
static-free surface.
It is possible for filament to get stuck on the stepper motor,
or to have a buildup of filament on the stepper motor drive
gear (gear used to move filament through the extruder). To
clean up the stepper motor drive gear, it is required to disas-
semble the extruder.
Follow the instructions below to disassembly your extruder
and clean the stepper motor gear.
1. Bring Printer to Safe State for Service.
a. Turn on the printer, and verify that the temperature icon
reads cool (see thermometer icon empty), if it is not cool
(full thermometer), allow adequate time for the nozzle
and bed to cool.
b. Turn off the printer
c. Unplug the printer
2. Remove Top Cover on the Extruder.
a. Cut the filament just before the intake on the top of the
extruder.
b. Remove screw located on the right side of the hole
using the T10 Torx screwdriver. The first picture below
shows the location of the screw, the second picture a
bottom view of the area where the screw is located,
circled in red is the screw that needs to be removed.
c. Unscrew the two screws on the top of the filament guide
bracket using the 2.5mm bit or Hex wrench
d. Remove the top cover.
e. Carefully unplug filament run out switch from the
extruder circuit board, ensuring to pull from the plastic
plug and not the wires; pulling the wires can damage
the connection to the extruder. Please see picture
below.
Hot Cool

3. Removing the Extruder Motor.
a. Disconnect the white extruder terminal block from the
extruder connector as shown in the picture below.
Ensure to grab the block and avoid pinching the wires.
b. Unscrew the two motor screws below using the Torx
screwdriver, as shown in the picture below. Please
ensure that the screws once fully unscrewed, should
still be left inserted in the extruder chassis hole.
c. Pull the extruder motor assembly away from the printer
(vertically) as shown in the picture below.
4. Cleaning the stepper gear. There might be filament residue
in your stepper motor gear, use your brush to clean the
gear of the stepper motor.
5. Replace Extruder Motor.
a. Place the extruder motor on the chassis. Extruder motor
screw holes should line up with holes in the chassis.
b. Tighten the two hex screws with 2.5mm Hex wrench.
Refer picture under Step 3b.
c. Plug in the white terminal block on the extruder connec-
tor as shown in picture under Step 3a (encircled).
6. Replace Top Cover.
a. Attach the filament runout switch wires of the cover to
the extruder circuit board. Refer picture under Step 2d.
b. Place the new top cover over the extruder.
c. Replace the two 2mm screws onto the cover. Refer
picture under Step 2c.
7. Test the Machine.
a. Plug in and turn on the 3D45.
b. avigate to “Filament” and follow the on screen instruc-
tions to load filament.
c. Build a file on the machine to ensure the 3D45 printer
is working correctly.
Congratulations!
You are now ready to build. Build On.
