Dunster House Utopia User manual

InstallationManual
For
UtopiaGazebo2x2mMKII
UniqueGazeboReferenceNumber.
____________________
www.dunsterhouse.co.uk
WallPanels
(optionalextra)

Utopia Gazebo2x2m MKIIInstallationManual
Page1of9
Please note: Please readtheseassembly instructionscarefully beforeproceedingwith the
constructionof your gazebo.These instructions willassistyou withtheconstructionof your
gazebo,however, youwillalso requirefurtherinstructions foryourspecificproductsaswellas
the instructions for anyoptionalextrase.g.shinglesetc.that youmayhavepurchased.
Ifyouthinkthatyouaremissinganyofthenecessaryassemblyinstructionspleasecontactour
Customer Servicedepartment,beforeyoubegintheconstructionofyourgazebo.
Please retainall documentationwithregardstoyourpurchase;this gazebo comeswitha unique
reference number, shownatthe bottomof your gazeboinstructionsandonthe outside
packagingofyourgazebo, whichmay beneeded at alater date.
In theunlikelyeventthatyouneed tocontact us,pleasedoso in writingto:
E-Mail: [e-mail]
Fax: [phone]
Post: DunsterHouse Ltd., CaxtonRoad,Elms FarmIndustrial Estate,BedfordMK41
0EB,
England.
OurCustomer Serviceis aimto respondwithin 2-3hours of receipt,however,this maybe longer
duringbusy periods. Please include your Sales Order(SO)number inanycorrespondencewith
Customer Services toenable themto locateyourfile.
www.dunsterhouse.co.uk

Utopia Gazebo2x2m MKIIInstallationManual
Page2of9
TheNatureofWood
Thewood provided foryourgazeboissoftwoodwhich hasbeen kilndriedandispressure
treated.Woodisanaturalproduct,which may have knots,knotholes,imperfections, cracksand
warping.
• Duetotheinherentpeculiaritiesofwood wemake no guaranteeswithregardstotheabove,
norwill wereplace any lengthsoftimberforany ofthe followingreasons:
• Anytimberthathasbeen treated,paintedorstainedbythe purchaser.
• Anytimberthatcontainsknotswherethey do notinfluence the structuralstabilityofthe
gazebo.
• Cosmeticappearances-colourvariationscaused by thestructureorageofthetimber.
• Timberthathasshakes,cracksorgapsthatdo notinfluence the structuralstrengthofthe
gazebo.
• Twisted timberthatcanbeinstalled.
• Queriesarising fromaneglectfulmannerofconstruction,be it withthefoundation orerection
ofthegazebo.
• Queriesduetomodificationsby theowner, suchasintroduction ofownguttering,etc,
causing timbertodeform.
• Anyvalidquerieswillbesatisfied by theexchangeor replacementofthedefective parts
only.
GETTINGREADY
Priortoassembly,storeall components inacool,dry place away fromdirectcontact with the
ground, sunlightor moisture. When selecting thelocation for yourgazebo,ensurethat the
gazebowillnot besubjectedto extremeweatherconditions. If your gazebois in an isolated
area where strongwinds often occur,then youshould takeprecautionsto securethe gazeboto
theground.
• Always checkallparts arepresent andcorrectprior to commencingthe gazeboconstruction
• Allowsufficient timeto familiarize yourself, or the customersbuilders,with theinstructions
prior tothe building ofthegazebo
• Checkcarefully thatall instructions areincluded.
Pre-drill allscrewsto avoidsplitting thetimber.

Utopia Gazebo2x2m MKIIInstallationManual
Page3of9
Preparation forAssembly
Tobuildyourgazebo youwillneed:
Twopeople,astepladder,hammer,sharpknife,drill withdrill bits,spiritlevel, screwdriver, saw,
pair of pliersandameasuringtape.Asaprecautionarymeasure,protectivegloves canbeworn.
Foundation
Acorrectfoundation is paramount to installingyour gazebocorrectly. Onlyacompletely level
andsquare loadbearing foundationwill ensure astable andproblemfreeinstallation.
Ifyoubuildafullconcretebase pleasemakesure that it is approximately 100mmlarger than the
gazebo base with runoffs.

70x70x1900.C
4ofrequired
70x35x350.C
8ofrequired 70x35x650.C
8ofrequired
bottomcap
1ofrequired 65x35x2000.C
4ofrequired
70x35x1700.C
4ofrequired
SHIPx2175 BottomRoofboards
4ofrequired
RoofPanel
4ofrequired
Utopia Gazebo2x2m MKIIInstallationManual
1900 70
70
350 70
35
650 35
70
120Ø 19
2000 35
65
1694 30
70
2175 15
121
85
1135
Page4of9
2000
Accessories
Description Qty
35mm Screws 30
70mm Screws 100
95mm Screws 20

Utopia Gazebo2x2m MKIIInstallationManual
Page5of9
70x70x1900.C
65x35x2000.C
Makesurenotcheson
components'70x70x1900.C'
arefacinginsidethe Gazebo.
70x70x1900.C
Secureusing2x70mm
screwsperend.
Startbyassemblingthemainframefor the
UtopiaGazebo.
Pleaseremembertopre-drillallholes
beforefixing,toavoidthesplittingof
timber.
Atthenotchedendof'70x70x1900.C'fix
components'65x35x2000.C'inthepositions
shownusing2x70mm screwsper end.Ensure
thatthenotch isfacinginwardsin all4corners
beforefixing.
Werecommendtosecurethegazebolegsto
thegroundusingmetalbrackets,metal
connectorsetc.(notsupplied).
Flushwith
topofpost
Nooverlap
Fixthesupports.
Oncetheframeisassembledfixthesupports
'70x35x650.C'inthepositionsshownusing
3x70mm screwsand1x95mmscrewper
component.Youwillneedtofix
8x'70x35x650.C'intotal.
70x35x650.C
70x35x650.C
70mmScrews
70mm Screw
95mm Screw

Utopia Gazebo2x2mMKIIInstallationManual
Page6of9
Fixthe'roofpanels'totheGazeboframe.
Liftthe'roofpanels'intoposition andfixthe
supportsofthepanelstotheframeofthe
gazebo.
Foreach corneryou arerequiredtouse
1x95mm screwpercornerandfixbyscrewing
throughthetimber ontheframeandintothe
endsofthecornersupportsofthe'roof
panels'.
Themiddlesupportsoftheroofpanelsarefixed
intoplacebyscrewingthroughthegazebo
frameandintothemiddlesupportusing
2x70mm screwsperroofpanel.
Thisprocess isrequiredforall'roofpanels'.
Viewfromunderneath,lookingup
1x95mmscrew. Fixatan angle,
intothe roofsectionsupport.
2x70mm Screws
70mm Screws
RoofPanel
Cornersupport
Roofpanel
MiddleSupport
Jointhe'roofpanels'together.
Use4x70mm screwstojointheroofpanels
together,in thepositionsshown inthediagram.
Makesurethatthesupportsin theroofframe
lineupandthen fixintoplace.

Utopia Gazebo2x2mMKIIInstallationManual
Page7of9
Fixthe'SHIPx2175.A'tothe'RoofPanel'.
Use4x35mmscrewspershiplapboardtofix
intoposition.Equallyspaceoutthescrewsand
fixbyscrewingthroughtheshiplapandinto
'65x35x2000.C'.
Repeatthisprocess onall 4'Roofpanels'
SHIPx2175 SHIPx2175
SHIPx2175
SHIPx2175
Fix the'Bottomcap'totheundersideoftheroof,at
thepeak.
Intheposition shownin thediagram,fixthe'Bottom
cap'intoplaceusing2x70mm screws.
bottomcap
Viewfromunderneath,lookingup
70mm Screws

Utopia Gazebo2x2mMKIIInstallationManual
Page8of9
FixingShinglestotheRoof.
When fixingshingles,youwillberequiredto
positionandfixthebottomrowwiththecut-outs
pointingtowardsthetopoftheroof.
Pleaseoverhangtheshinglesfromtheedgeof
theroofboardsbyapproxmiately 50mm.
Repeatthisprocesson all4sidesofthegazebo.
70x35x350.C
70x70x1900.C
70x35x350.C
70x35x350.C
Fix '70x35x350.C'tothebottomoftheGazebo
posts.
Onthebaseofthemainsupportposts,fix2x
'70x35x350.C'toeachpostontheoutsideofthe
gazebo.Theangledendofthiscomponentneeds
tobepointingupwards.Use2x70mm screwsper
componenttofixintoposition.
Forthe bottomrowofshingles,the cutoutsoneach stripof
shinglesneedtobepointingtowardsthe topofthe roof.
Topofroof.

Utopia Gazebo2x2mMKIIInstallationManual
Page9of9
Finally, fix4x'70x35x1700.C'in thepositions
shownusing4x70mmscrewsper component.
Screwthrough '70x35x1700.C'andintothe
purlins. 70x35x1700.C
70x35x1700.C
70x35x1700.C
70x35x1700.C
Onceyou havefixedthebottomrowon shingles
(with thecutoutspointingtowardstheroof)you
cannowfully covertheroofofyourgazebowith
shingles.
Allofthestripsofshingleswillnowhavethecut
outspointingtowardstheground.
Start byfixingtheshinglestripsdirectly on topof
thebottomrowsthatwerefixedintheprevious
step,untilyour gazeboresemblesthediagram.
