GRAPEVINE TRELLIS
ASSEMBLY INSTRUCTIONS
TOOLS NEEDED
Drill with #2 Phillips drill bit or
Phillips Screwdriver
Super or Crazy Glue
Hammer or Mallet
TRELLIS ASSEMBLY
(Refer to Drawing 1)
On clean flat surface lay both of the trellis legs so pilot holes for screws are facing up and routed
holes for cross rails are facing each other. Take one of the top/bottom rails and the center rail and
insert the rails into the routed holes on legs. Next slide the 5 tubes through the center rail and into
the bottom rail that you just inserted into the trellis legs. Insert the top cross rail into one leg, then
slide tube ends into the holes as you bring the top rail down to insert it into the other leg. Make
sure cross rails are inserted completely into both legs and fasten with screws. Snap screw caps over
screw heads. Place the 7/8 x 1 ½” end caps on top legs. Household glue may be used if caps are
loose.
INSTALLATION
In desired location set the trellis in place and mark where ground anchors will need to be inserted.
Using a block of wood to protect the flared edges of ground anchors; pound the anchors into place.
(If ground is extremely hard, loosen or soak soil before inserting ground anchors). Set trellis into
ground anchors.
If you encounter missing or defective parts, please contact manufacturer direct at
toll free # below.

Dura-Trel, Inc. ~ PO Box 122, Sheboygan Falls, WI 53085 ~ Toll Free 877-258-6020
PACKING LIST
PARTS CONTAINED:
QTY. PART NO. PART DESCRIPTION
2 47815-59500 ⅞x 1½x 59½” LEG
2 47815-28002 ⅞x 1½x 28” TOP/BOTTOM RAIL (holes in 1 side)
1 47815-28003 ⅞x 1½x 28” CENTER RAIL (holes in 2 sides)
5 60058-53000 ⅝x 53” TUBE
2 57815-12000 ⅞x 1½x 12” FLARED GROUND ANCHOR
:Hardware Bag Includes
2 7CAPS-7815E ⅞x 1½” END CAP
6 7HDWR-K8034 ¾” KAPPET SCREW
6 7HDWR-K8000 KAPPET SCREW CAP
1 GRAPEVINE ARCH TRELLIS INSTRUCTIONS
NOTE: Some parts may be packed inside of others.
.If you encounter missing or defective parts, please contact manufacturer direct at toll free # below
#11105 grapevine trellis
