DURAVIT SensoWash Starck f Plus User manual

7,47 mm
2
4
5
6
1
3
Order.-Nr. 57314/19.07.1.1 ·
We reserve the right to make technical improvements and enhance the appearance of the products shown.
Duravit AG
P.O. Box 240
Werderstr. 36
78132 Hornberg
Germany
Phone [phone]
Fax [phone]
[e-mail]
www.duravit.com
SensoWash
®
Starck f Plus
Kleben Sie das beiliegende Produkt-Etikett mit der Seriennummer in dieses Feld.
Affix the enclosed product label with serial number in this area.
Collez l‘étiquette de produit ci-jointe avec le numéro de série dans ce champ.
Plak het bijgevoegde product-etiket met het serienummer in dit veld.
Pegue la etiqueta de producto suministrada con el número de serie en esta casilla.
Incollare in questo spazio l‘etichetta del prodotto in dotazione con il numero di serie.
Bedienungsanleitung
Operating instructions
Notice d’utilisation
Gebruikshandleiding
Manual de instrucciones
Istruzioni d’uso
Compact Dusch-WC
Compact shower toilet
WC douche compact
Compacte douche-WC
Inodoro con lavado compacto
Vaso compatto con sedile
elettronico

www.sensowash.com
20
29
22
24
26
28
27
21
7
10
12
14
19
9
11
13
15
16
17
18
8
23
25
7,47mm 148 mm
146 mm135 mm


EN
Contents
. Brief overview..........................................................................................
. Toilet unit .......................................................................................
. Remote control ...............................................................................
. App.................................................................................................
. Functional area ..............................................................................
. Descaling connection ......................................................................
. Description of symbols.............................................................................
. For your safety.........................................................................................
. Normal use .....................................................................................
. Safety instructions..........................................................................
. Basic product information ........................................................................
. About this manual...........................................................................
. Operation........................................................................................
. LED indication ................................................................................
. Energy saving and water efficiency.................................................
. Initial operation .......................................................................................
Switch SensoWash® on/off ...................................................................
Download app......................................................................................
Pairing app..........................................................................................
Change batteries .................................................................................
. Operating.................................................................................................
Open/close lid......................................................................................
Activate/deactivate Rearwash..............................................................
Activate/deactivate Ladywash..............................................................
Activate/deactivate warm air dryer .....................................................
Adjust spray wand position..................................................................
Adjust water spray intensity ................................................................
Adjust water temperature ...................................................................
Set user profile....................................................................................
Activate user profile.............................................................................
Activate flushing functions (optional) ..................................................
Activate/deactivate odor extraction (optional) .....................................
. Cleaning and care.....................................................................................
Cleaning recommendations .................................................................
Manual cleaning mode (spray wand and nozzle) .................................
Self-cleaning (spray wand and nozzle)................................................


EN
Holiday mode.......................................................................................
Descaling.............................................................................................
. Disposal ...................................................................................................
. Troubleshooting support..........................................................................
. Technical data .........................................................................................


EN
. Toilet unit
1Seat sensor
2Auto opening lid
3Seat heating
4Night light
5Power/status indication (LED)
6Bluetooth
. Remote control
7User profile 1
8User profile 2
9Full flush*
10 Eco flush*
11 Rearwash
12 Ladywash
13 Odor extraction*
14 Warm air dryer
15 Water temperature
16 Water spray intensity
17 Spray wand position
18 Open/close lid
19 Stop
. App
20 Menu
21 Add/delete device
22 Ladywash
23 Warm air dryer
24 Rearwash
25 Odor extraction*
26 Eco flush*
27 Open/close lid
28 Full flush*
29 Stop
. Brief overview
*Only in combination with DuraSystem®installation frame and A2 actuator plate.


EN
. Functional area
. Descaling connection
Internal overflow Spray wand
Warm air dryer
Spray nozzle
Night light
Descaling connection


EN
. Description of symbols
The following warning signs warn you of dangerous situations and
their severity:
Indicates a hazardous situation which, if not avoided, could result
in death or serious injury.
WARNING
Indicates a hazardous situation which, if not avoided, may result in
minor or moderate injury.
NOTICE Addresses practices not related to physical injury.
The following symbols are used:
Hints and tips are provided here.
> This is a prompt requesting your input.
Functions/settings controlled on seat unit.
Functions/settings controlled via remote control.
Functions/settings controlled via app.
CAUTION


EN
. For your safety
To ensure that you will enjoy your SensoWash®, read these operating
instructions carefully, particularly the safety instructions.
Keep the operating instructions in a safe place and in the case of a
change in ownership, ensure they are given to the new owner.
These operating instructions correspond to the device’s state of
technology at the time of printing. Duravit reserves the right to
make changes in terms of further development.
. Normal use
SensoWash®is a shower toilet with spray attachment for Rearwash
and Ladywash cleansing functions and additional comfort features.
Its use is limited exclusively to enclosed spaces.
Any other usage will be deemed as not corresponding with normal
usage. Duravit undertakes no liability for abnormal usage.
. Safety instructions
Read and observe the following safety instructions carefully!
Requirements for the user
This appliance is not intended for use by persons (including children)
with reduced physical, sensory or mental capabilities, or lack of
experience and knowledge, unless they have been given supervision
or instruction concerning use of the appliance by a person
responsible for their safety.
> Children should be supervised to ensure that they do not play with
the appliance.
WARNING Damage to health caused by electric shock and/
or product damage
> The product must be earthed. Compare with the mounting
instructions.
Only use the device when it is fully functional.
> Make sure that the power cord is not damaged.
> The power cord must not become jammed or pinched.
> Keep the power cord away from hot surfaces and sharp edges.


EN
Do NOT use the product if it is not working properly.
> Disconnect from the power supply immediately. Close the stop
valve to interrupt the water supply. Contact [e-mail].
> Avoid malfunctions and damage to the product as a result of
improper use.
CAUTION Health damage and potential product damage!
> Supply the device with cold drinking water from the main water
system.
> The new hose-sets supplied with the appliance are to be used and
old hose-sets should not be reused.
> The product itself does not have electrical leakage protection
function, it must be installed in circuit where there is leakage
protection device installed.
> Means for disconnection must be incorporated in the fixed wiring
in accordance with the wiring rules and having a contact
separation in all poles that provide full disconnection under
overvoltage category III conditions.
> Do NOT sit, stand or lean on the lid.
> Do NOT connect any waste water, grey water, industrial water, sea
water or other untreated or semi-treated water.
> Do NOT detach seat and lid for any purpose.
> Do NOT damage the surface of seat. If the surface of the seat is
damage, contact [email protected]om.
> DO NOT open and close seat with excessive force.
> Open and close the lid via remote control and app only. Do not open
and close the lid manually.
> If the SensoWash®is moved from a cold location to a warm
location, condensation may form. Leave the unit switched off for a
few hours.
> Do NOT install the SensoWash®in rooms where there is a danger
of frost. The room temperature must not be less than 4°C (39°F).
> Do NOT place open fire sources, candles, cigarettes, or similar, on
the SensoWash®.
> Do NOT expose the SensoWash®directly to water or sunlight.
> Do NOT climb on or stand on the product.
> Do NOT place any heavy objects on the lid.
> Do NOT deliberately soil, spray or block the spray wand.


EN
Repairs must only be carried out by a person with the necessary
expertise and qualification.
> Do NOT carry out modifications, tamper with, install additional
equipment or attempt to repair the SensoWash®.
> If the supply cord is damaged, it must be replaced by the
manufacturer, its service agent or similarly qualified persons in
order to avoid a hazard.
> Repairs must be carried out by qualified electricians or technicians.
> Improperly performed repairs can lead to accidents, damage and
malfunctions.
> Do NOT use attachments not recommended by Duravit.
Use of batteries
Risk of fatal injury if swallowed/Chemical burn
hazard
This product contains coin/button cell batteries. Do not ingest
battery! If the cell battery is swallowed, it can cause severe internal
burns in just 2 hours and can lead to death.
> Do not ingest battery, Chemical Burn Hazard.
> Keep new and used batteries away from children. If the battery
compartment does not close securely, stop using the product and
keep it away from children.
> If you think batteries might have been swallowed or placed inside
any part of the body, seek immediate medical attention.
Damage to health caused by leaking battery acid
> Avoid contact with skin, eyes and mucous membranes if battery
acid has leaked.
> In case of contact with the acid, flush the affected areas with large
amounts of clean water and consult a doctor immediately.
> Do not expose the batteries to extreme conditions: avoid contact
with hot surfaces or direct sunlight. Otherwise there is a risk of
leakage.
> The cells shall be disposed of properly, including keeping them
away from children. Even used cells may cause injury.
WARNING
CAUTION


EN
NOTICE Product and/or property damage
> Batteries may not be recharged, reactivated by other means,
dismantled or exposed to fire.
> The supply terminals are not to be short-circuited.
> Always remove empty batteries from the remote control
immediately. They may leak and cause damage.
> Do not insert new and old batteries together in the remote control.
> Different types of batteries are not to be mixed.
> Clean the battery and contacts before inserting the battery.
> Batteries are to be inserted with the right polarity.
> Remove the batteries if you do not use the remote control for an
extended period.


EN
Functions and Settings
The full range of functions is available whether the product is operated via remote
control or app. Functions are set according to default settings ( Table: Default
settings). Download app to make adjustments on the extended setting range
(Ch. 5: Download app).
Controlled via
basic range extended range
On/off SensoWash® • - -
Bluetooth (connect app) • - -
Open/close lid
(electromotive)
- • •
Auto opening lid - - •
Auto closing lid - - •
Full flush - •* •*
Eco flush - •* •*
Rearwash - • •
Ladywash - • •
Comfortwash - - •
Warm air dryer - • •
Warm air dryer temperature - - •
. Basic product information
. About this manual
This manual contains safety and general product information and information on how to
operate SensoWash® via remote control (basic setting range).
> See Quick Guide in app ( App: Menu - Device Guide - Quick Guide 20 ) for
information on the full range of setting options available for this product.
. Operation
SensoWash® is operated via remote control (basic setting range) and/or app (extended
setting range).
A number of settings can be adjusted via app only ( Table: Functions and settings).
> Download app to adjust the full range of setting options available for this product
(Ch. 5: Download app).


EN
Functions and Settings
Controlled via
basic range extended range
Spray wand position - • •
Water spray intensity - • •
Water temperature - • •
Odor extraction - •* •*
User profile - • -
Seat heating - - •
Seat heating temperature - - •
Energy saving (seat heating) - - •
Night light - - •
Confirmation tone - - •
Holiday mode - - •
Manual cleaning mode - - •
Self-cleaning - - •
Descaling - - •
Reset default setting - - •
Table: Functions and settings
*Only in combination with DuraSystem®installation frame and A2 actuator plate.


EN
Default Settings
setting range default setting
Auto opening lid on/off off
Auto closing lid on/off off
Comfortwash on/off on
Warm air dryer temperature off/low/medium/high medium
Spray wand position front 1, 2, 3, 4, 5 back 3
Water spray intensity low/medium/high medium
Water temperature off/low/medium/high medium
Seat heating on/off on
Seat heating temperature low/medium/high medium
Energy saving mode on/off off
Night light off/auto/on auto
Confirmation tone on/off off
Table: Default settings
. LED indication
Power button
Red light Indicates stand-by mode.
Switch SensoWash® on to activate seat unit
(Ch. 5: Switch SensoWash® on/off).
Green light Indicates on mode.
Energy saving mode is off.
Orange light Indicates on mode.
Energy saving mode is on.
Flashing Malfunction.
Deactivate seat unit, close stop valve, contact
[email protected]om ( Ch. 9: Troubleshooting).
Bluetooth button
Blue light Bluetooth is available or connected.
Off Bluetooth is not available.
Flashing Device is in pairing mode ( Ch. 5: Pairing app).
Table: LED indication (seat unit)


EN
. Energy saving and water efficiency
In order to minimize the cost of natural resources, SensoWash®includes an instant
heating system and an Auto Stop feature for all washing and drying functions. To save
energy in the everyday usage of the product, it is possible to adjust the following
settings:
> Energy saving mode (seat heating)
Deactivates seat heating for a specific period of time (e. g. during daytime, while at
work) and automatically reactivats seat heating after that time ( App: Menu -
Settings - Seat 20 ).
> Holiday mode
If you do not use SensoWash® for two weeks or above, drain the water and deactivate the
product ( Ch. 7: Holiday mode) ( App: Menu - Care - Holiday mode 20 ).
. Initial operation
Switch SensoWash® on/off
SensoWash® can be switched on/off via the side control button. Requirement:
SensoWash®must be connected to the main power supply.
> Green LED: seat
ready to use.
> Red LED: seat
not ready to use
(standby).
> Press button
shown to switch
seat on or off.
2
1


EN
Download app
Search for “SensoWash“ in Play Store (Android) or App Store (iOS).
Pairing app
SensoWash®is connected to the app via bluetooth. SensoWash®and bluetooth have
to be switched on ( 5and 6) to establish the connection. Follow step-by-step
instructions in app to connect app to the product.
Change batteries
Insert batteries into the remote control.
1
M2x4
4
> Attach screw.
> Insert batteries
(CR2450).
> Remove screw
and open
battery
compartment.
> Close battery
compartment.
CR 2450
+
3V
CR 2450
+
3V
2
CR 2450
+
3V
CR 2450
+
3V
1
2
3


EN
. Operating
Use this QR-Code to see a video of the operating functions
or visit
www.duravit.com/vid_sensowash_starck_f
Open/close lid
The SensoWash®lid opens/closes automatically when a person approaches/leaves the
toilet. Alternatively open/close lid via remote control or app.
NOTICE Damage of seat and lid!
Lid can be damaged if it is opened/closed manually.
> Open and close lid via remote control or app only.
> Do not open and close the lid manually.
> Do NOT open and close seat with excessive force.
Open/close lid
Auto opening (activate/deactivate)
Auto closing (activate/deactivate)
> Press icon
shown to open
or close lid.
1


EN
Activate/deactivate Rearwash
Gentle and safe rear cleansing.
SensoWash®automatically cleans the retracted spray wand when the seat sensor is
activated and also before and after washing functions are used.
Rearwash (activate/deactivate)
Adjust spray wand position, adjust water spray intensity, adjust
water temperature
Comfortwash (activate/deactivate)
Activate/deactivate Ladywash
Spray wand functions for feminine cleansing.
> Ladywash is
active, the spray
wand extracts
slowly.
1
> Press icon
shown to
activate
Ladywash.
> Press stop to end
or after 2 min.
auto stop.
2 3
SensoWash®automatically cleans the retracted spray wand when the seat sensor is
activated and also before and after washing functions are used.
> Rearwash is
active, the spray
wand extracts
slowly.
1
> Press icon shown
to activate
Rearwash.
> Press stop to end
or after 2 min.
auto stop.
2 3


EN
Ladywash (activate/deactivate)
Adjust spray wand position, adjust water spray intensity, adjust
water temperature
Comfortwash (activate/deactivate)
Activate/deactivate warm air dryer
Pleasant drying through warm air after washing function.
Warm air dryer (activate/deactivate)
Warm air dryer temperature
Adjust spray wand position
Spray wand position can be set individually to 5 different positions (front 1, 2, 3, 4,
5 back).
1
> Press right
arrow to move
spray wand
back.
> LEDs indicate
setting.
Adjust spray wand position (Rearwash)
Adjust spray wand position (Ladywash)
1> Press icon
shown to
activate dryer.
2> Press stop to end
or after 5 min.
auto stop.
23
> Press left arrow
to move spray
wand to the
front.


EN
Adjust water spray intensity
Water spray intensity can be set individually to 3 different levels (low/medium/high).
3
1
2
> Press minus to
decrease spray
intensity.
> LEDs indicate
setting.
Adjust water spray intensity (Rearwash)
Adjust water spray intensity (Ladywash)
Adjust water temperature
Water temperature can be set individually to 4 different levels (off/low/medium/high).
3
1 2
> Press plus to
increase water
temperature.
> LEDs indicate
setting.
If you choose level off, the water has the temperature of inlet water and the LEDs
are off.
Adjust water temperature (Rearwash)
Adjust water temperature (Ladywash)
> Press plus to
increase spray
intensity.
> Press minus to
decrease water
temperature.
