Dynojet power commander III User manual

i216-411 www.powercommander.com 2004 Kawasaki ZX12R - PCIII USB - 1i216-411
2004 Kawasaki ZX12R
Installation Instructions
Dynojet Research 2191 Mendenhall Drive North Las Vegas, NV 89031 [phone] www.powercommander.com
Parts List
1Power Commander
1USB Cable
1CD-ROM
1Installation Guide
1Power Adapter
2Power Commander Decals
2 Dynojet Decals
2 Velcro®Strip
1Alcohol Swab
You can also download the Power
Commander software and latest maps
from our web site at:
www.powercommander.com
The ignition MUST be turned
OFF before installation!
PLEASE READ ALL DIRECTIONS BEFORE STARTING INSTALLATION
Button Adjustment Display
Faceplate Buttons
Expansion Port USB Port

i216-411 www.powercommander.com 2004 Kawasaki ZX12R - PCIII USB - 2
1. Remove the main seat and
the passenger seat
2Prop the front of the fuel
tank up.
3Place the Power
Commander in the tail sec-
tion and route the wiring
harness on the inside of the
tail section towards the front
of the bike.
4Locate the 16 pin grey con-
nector underneath the fuel
tank (Fig. A). Unplug this
connector.
5Plug the black connectors
from the PCIII in-line of the
stock grey connectors (Fig.
B).
6. Locate the 2 pin white con-
nector underneath the fuel
tank towards the rear of the
bike (Fig. C). Unplug this
connector.
Fig. AFig. B
Fig. C
Unplug this connector
Stock connectors
Unplug this connector
PCIII connectors

i216-411 www.powercommander.com 2004 Kawasaki ZX12R - PCIII USB - 3
7. Plug the red connectors
from the PCIII in-line of the
stock white connectors (Fig.
D).
8. Connect the ground wire off
of the PCIII to the negative
side of the battery (Fig. E).
9. Install the PCIII in the tail
section of the bike. You can
use the supplied velcro to
attach the unit to the inside
of the tool tray if desired.
10 Bolt the fuel tank back into
place and all removed body-
work.
Fig. DFig. E
Fig F
Ground wire from PCIII
Stock connectors
PCIII connectors
