POWER VISION
PLEASE READ ALL DIRECTIONS BEFORE STARTING INSTALLATION
98200124.06
Honda Talon Installation Guide
1 POWER VISION
1 REFLASH HARNESS
1 USB CABLE
2 VELCRO
2 DYNOJET DECAL
PARTS LIST

2 HONDA TALON INSTALLATION GUIDE
INTRODUCTION
INSTALLING THE POWER VISION
POWER VISION OVERVIEW—SIDE VIEW
Thank you for purchasing the Power Vision from Dynojet
Research. The Power Vision is the device to interface
between your computer and vehicle ECU allowing you
to tune your stock ECU to achieve optimal performance
from your vehicle.
Use the buttons to navigate the device menus, make
selections, cycle through the four available gauge
screens, and log data. Connect to the diagnostic port
to flash a tune; use the USB connection to interface
between the Power Vision and your computer.
For state of the art technical support, please visit
www.dynojet.zendesk.com.
SCROLL
USB CABLE PORT
CONNECT TO COMPUTER
DIAGNOSTICS CABLE PORT
CONNECT TO VEHICLE
POWER VISION OVERVIEW—FRONT VIEW
HOME/LOG
SCROLL
ENTER
RETURN
1 Secure the Power Vision to the vehicle using the supplied
Velcro
. Make sure the Power Vision will not interfere with
the operation and steering of the vehicle.
Note: The Power Vision does not need to be mounted
to the vehicle.
2 Attach the diagnostic cable to the diagnostic port on the
Power Vision and to the diagnostic port on the vehicle.
Talon Four Seat Models: located under the driver’s seat.
Talon Two Seat Models: located under the driver’s seat,
under a rubber flap cover.
DIAGNOSTIC PORT— TWO SEAT
INSTALL POWER VISION DIAGNOSTIC PORT—FOUR SEAT

98200124.06
GETTING STARTED
Use the Tune File Wizard to prepare your Power Vision
device with the stock (stk) and tune (djt) files needed to
flash your vehicle.
1 Connect the Power Vision to the vehicle.
2 Turn the key on. The Power Vision will scan for files.
There are three possible file states:
File State 1: No compatible tune or stock files.
File State 2: No compatible tune files.
File State 3: All required files found.
3 Gauges are displayed.
Connect the Power Vision to the
vehicle diagnostic port to collect
ECU information. Turn the key on.
File State 2:
Go to www.tunes.dynojet.com to
download tune files.
File State 3:
All required files found. The Power
Vision is ready to flash a tune to the
connected vehicle.
File State 1:
Go to www.tunes.dynojet.com to
download stock and tune files.
FLASHING YOUR VEHICLE
The Power Vision must be paired to the connected vehicle ECU
to function properly.
Note: Once paired to the vehicle ECU, the Power Vision will
not work on another vehicle without purchasing a tune
license.
1 From the Main Menu, select Flash Tune.
2 Select the tune file (.djt) and press Enter to view the Tune Info.
The Tune Info screen contains the technical notes showing what
was changed in the tune.
Note: The PV3 filters out files which are not compatible
with the connected vehicle based on year/trim delivered
direct from the factory and result in varied tune Compat and
CheckSum within the ECU. Additional files may be visible
on the device when connected via USB or on the website;
however, the PV3 will only display files which directly fit your
vehicle.
Note: The Dynojet tune file (.djt) is a tune file which is
different (better than stock performance or the necessary file
when bolting on an exhaust, for example); the stock file (.stk)
is the direct duplicate of what the OEM shipped.
3 Press Enter to accept the tune, or restore the ECU to original
stock (.stk) file, and pair the Power Vision to the vehicle.
Note: Pair to vehicle will only happen on the first flash.
4 Press Enter to pair and lock the Power Vision to the ECU and to
begin the flash. Do not turn off the key switch or disconnect the
Power Vision during the flash.
5 After the flash is complete, turn the key off and wait 45 seconds
before turning the key back on to start.

4 HONDA TALON INSTALLATION GUIDE
This menu allows you to read and clear diagnostic trouble
codes.
1 To read codes, select Vehicle Tools>Diagnostics>Active
Codes.
2 To clear codes, select Vehicle Tools>Diagnostics>Clear
Codes.
VIEWING THE DIAGNOSTIC CODES
This menu allows you to view the device status (paired/not
paired), VIN #, Model ID, ECU serial number, tune compat, and
checksum compat.
Select Vehicle Tools>Vehicle Information.
VIEWING THE VEHICLE INFORMATION
RESTORING THE ECU
This menu allows you to restore the ECU. Use Restore ECU if
the device does not complete the flash or if your vehicle will
not start.
Select Vehicle Tools>Restore ECU.
RESET ADAPTIVES
This menu allows you to clear the trims which the narrowband
sensor has learned throughout prior drive cycles.
Select Vehicle Tools>Reset Adaptives.
RELEARN DCT
Use Relearn DCT when the MT/AT shift lights are illuminated
solid on the dash or if the vehicle’s transmission needs service
or a module was replaced. The DCT relearned sequence does
not show up right away.
1 Verify the vehicle is up to operating temperature.
2 Select Vehicle Tools>Relearn DCT.

98200124.06
CONFIGURING GAUGES
This menu allows you to configure up to four different gauge
screens. Each gauge screen has four configurable channels.
1 From the Main Menu, select Device Tools>Configure Gauges.
2 Select a gauge screen and press Enter.
3 Select a channel and press Enter.
4 Select a channel from the list and press Enter.
5 Select the precision or units for that channel and press Enter.
6 Continue setting up the remaining channels as desired.
7 Continue configuring the remaining gauge screens as desired.
LOGGING DATA
1 Press the Log button to begin logging. The Power Vision
screen will illuminate a bright red banner across the top when
logging.
2 Press the Log button again to stop logging.
3 Use the Power Core software to view log files.
Snapshot Log: Press and hold the Log button for two
seconds to record the previous two minutes of operating time.
SET DYNO MODE
This menu allows you to have the vehicle ignore the front
wheel speed sensor(s) for stationary dyno tuning while
allowing the transmission to shift as normal.
Select Vehicle Tools>Set Dyno Mode.
DELETING DATA LOGS
This menu allows you to delete data logs.
1 Select Vehicle Tools>Delete Data Log.
2 Select a specific log to delete or select *Delete All Logs*.

6 HONDA TALON INSTALLATION GUIDE
VIEWING THE DEVICE INFORMATION
This menu allows you to view the device firmware version,
serial number, and stock code.
Select Device Tools>Device Information.
REFORMATTING THE DISK
This menu allows you to reformat the disk and erase all data.
Select Device Tools>Reformat Disk.
CHANGING THE SETTINGS
This menu allows you to rotate the screen allowing you to
change the orientation of the Power Vision device along with
adjusting the screen brightness.
Select Device Tools>Settings>Rotate Screen to flip the
screen.
Select Device Tools>Settings>Brightness to change the
screen brightness.
UPDATING THE DEVICE
This menu allows you to update the device with the latest
firmware.
1 Go to www.dynojet.com/PowerVision.
2 From the top navigation menu, select Support>Downloads.
3 Click Power Vision 3.
4 Click the Firmware drop-down and download the Power Vision
3 Firmware for Honda.
5 Save the file to your device.
6 Select Device Tools>Update Device.

98200124.06
EXPORT DIAGNOSTICS
This menu allows you to create a BIN file containing device
information used by Dynojet Tech Support.
1 Select Device Tools>Export Diagnostics.
2 If requested by Dynojet Tech Support, connect your Power
Vision to a computer and email the BIN file to
[e-mail].
INSTALLING THE POWER CORE SOFTWARE
USING THE POWER VISION UPDATE CLIENT
This stand alone application will launch the Update Client
allowing you to update your Power Vision with the latest
firmware, retrieve additional tunes, or restore the Power Vision to
the original Dynojet factory settings.
1 Connect the Power Vision to your computer using the included
USB cable.
2 Navigate to the POWERVISION drive attached to your computer
and run the Update.exe file.
3 Click Update to load the current firmware. If the Update button is
grayed out, your Power Vision already has the latest firmware.
4 Click Restore to reload all original Dynojet tune and stock files.
5 Click Get Tunes to open the Dynojet Tune Finder. Follow the
instructions to Upload your PV_Info.txt file and retrieve new tunes.
6 Click Manual Firmware Update to navigate to and load a version
of firmware already saved on your computer.
Download the Power Core software and take tuning to a
whole new level.
Note: Downloading the Power Core software is optional
and not necessary to use the Power Vision.
1 Go to www.dynojet.com/PowerVision.
2 From the top navigation menu, select Support>Downloads.
3 Click Power Vision 3.
4 Click the Software drop-down and download the Dynojet
Power Core software.
5 Double-click the saved file to begin installation. Follow
the on-screen prompts. Refer to the Power Core Help for
more information.
