Dynojet LCM User manual

LCM
INSTALLATION GUIDE
1MODULE
1SWITCH
1USB CABLE
2VELCRO
1ALCOHOL SWAB
2016-2021 Polaris XPT
PARTS LIST 96070002
2191 MENDENHALL DRIVE, NORTH LAS VEGAS, NV 89081
800-992-4993 WWW.DYNOJET.COM
PLEASE READ ALL DIRECTIONS BEFORE STARTING INSTALLATION

96070002 - LCM 16-21 POLARIS XPT
INSTALLATION INSTRUCTIONS
INSTALL MODULE
1 Remove the driver’s seat.
2 Remove the small plastic panel behind the driver’s
seat to access the ECU.
3 Remove the panel at the bottom of the cargo bed to
access the top of the engine.
4 Feed the LCM wiring harness through the hole in
the firewall by the ECU.
5 Use the supplied Velcro strips to secure the LCM
module to the top of the ECU.
Clean the surface on the ECU with the supplied
alcohol swab prior to applying the Velcro.
ATTACH GROUND
6 Route the LCM ground wire with the ring lug to the
forward left corner of the engine case.
7 Secure the LCM ground wire to the engine case
bolt.
UNPLUG IGNITION COIL
8 Unplug the stock wiring harness from the vehicle’s
Ignition Coil.

INSTALLATION GUIDE
INSTALLATION INSTRUCTIONS
9 Plug the pair of 3-pin PCV connectors with GREEN
and BLUE colored wires in-line of the vehicle’s
Ignition Coil and stock wiring harness.
CONNECT TO COIL
10 Locate and unplug the stock pair of connectors for
the engine’s Crank Position Sensor.
This pair of connectors is located on the right hand
side of the gear box. You can trace the harness from
the sensor at the top of the flywheel cover to this pair
of connectors.
UNPLUG CPS
11 Plug the pair of LCM connectors with the BROWN
colored wires in-line of the stock CPS and wiring
harness.
CONNECT CPS

96070002 - LCM 16-21 POLARIS XPT
12 Wire the switch into the module. The polarity of
the wires from the switch does not matter.
To input wires into the LCM first remove the rubber
plug on the backside of the unit and loosen the screw
for the corresponding input. Strip about 10mm from
its end. Push the wire into the hole of the LCM until
is stops and then tighten the screw. Make sure to
reinstall the rubber plug.
If you tin the wires with solder it will make
inserting them easier.
You can alter the launch RPM if desired by using the
Power Core software suite. Go to dynojet.com to
download.
To prevent wear and or damage to the clutch
assembly make sure that the launch RPM matches
your clutch engagement RPM.
SWITCH WIRING
WIRE IN SWITCH
INSTALLATION INSTRUCTIONS

INSTALLATION GUIDE
