e-con Systems e-CAM52 35x Instructions for use

e-CAM52_35x Hardware User Manual 04-Jan-12
Confidential Page 1 of 10
e-con Systems India Pvt Ltd
17, 54th Street,
Ashok Nagar
Chennai-600083
www.e-consystems.com
e-CAM52_35x
Hardware User Manual
Revision 1.0
Monday, January 4, 2012
Customer/Partner

e-CAM52_35x Hardware User Manual 04-Jan-12
Confidential Page 2 of 10
Contents
1Revision History ....................................................................................................................... 3
2Introduction............................................................................................................................... 4
3Scope ....................................................................................................................................... 4
4Disclaimer................................................................................................................................. 4
5Description................................................................................................................................ 5
5.1 Block diagram:................................................................................................................. 6
5.2 Interface Connector Pin Description................................................................................ 6
6Mechanical Specification.......................................................................................................... 8
6.1 Camera Board outline...................................................................................................... 8
7E-CAM52_35x board handling procedure................................................................................ 8

e-CAM52_35x Hardware User Manual 04-Jan-12
Confidential Page 3 of 10
eCAM52_35x
1 Revision History
Rev
Date
Major Changes
Author
1.0
4–Jan –2012
Based on eCAM52_35x Rev A hardware
Selva Raj

e-CAM52_35x Hardware User Manual 04-Jan-12
Confidential Page 4 of 10
2 Introduction
e-CAM52_35x camera daughter board has been designed and developed by e-con Systems
India Pvt Ltd. The eCAM52_35x camera daughter board uses a 5MP flexible PCB Autofocus
camera module based on OV5640 CMOS sensor from Omnivision. This camera daughter board
can be directly interfaced to the OMAP3530 Evaluation board from Texas Instruments (TI). e-con
Systems also provides Linux and Windows CE camera drivers and sample applications for these
camera daughter boards. This document describes how to interface the e-CAM52_35x camera
daughter board on TI’s OMAP3530 EVM board and how to use the same.
This camera daughter board is designed for the TI’sSitara/DaVinci family of processors and can
easily be adapted to interface with other Application Processors with similar CMOS Image sensor
interface.
This camera daughter board is also supplied with the sample applications. The DirectShow
compliant Windows CE camera driver and the Sample Camera Application are provided as is
without any warranties, implied or explicit.
3 Scope
The scope of this document is limited to the description of the camera daughter board and how to
interface this daughter board on the TI OMAP3530 EVM board. This also lists down any
precautions to be taken, if any.
4 Disclaimer
The specifications of the camera daughter board and instructions on how to use this daughter
board with OMAP3530 EVM are provided as reference only and e-con Systems reserves the right
to edit/modify this document without any prior intimation of whatsoever.

e-CAM52_35x Hardware User Manual 04-Jan-12
Confidential Page 5 of 10
5 Description
The e-CAM52_35x camera daughter board designed to interface with the standard Micron
camera header of OMAP3530 Rev-G EVM from TI. The e-CAM52_35x camera board
accommodates the OV5640 5M pixel auto-focus camera module. OV5640 is a low voltage high
performance color CMOS sensor from Omnivision. This board contains an onboard oscillator, the
necessary voltage source, powers and reset sequence to support the functionality of this camera
module on the TI OMAP3530 EVM.
Figure 1:eCAM52_35x camera daughter board

e-CAM52_35x Hardware User Manual 04-Jan-12
Confidential Page 6 of 10
5.1 Block diagram:
The following block diagram explains the camera daughter board design in brief.
Figure 2: eCAM52_35x daughter board block diagram
5.2 Interface Connector Pin Description
The e-CAM52_35x camera daughter board connects to the OMAP3530 EVM board through a 26-
pin Micron camera header. The following table lists down the pin numbers and signal names of
this Micron camera header.

e-CAM52_35x Hardware User Manual 04-Jan-12
Confidential Page 7 of 10
Signal Name
Pin type
Description w.r.t camera
Pin
No
1
D2
O
DVP out bit 2
2
D3
O
DVP out bit 3
3
D4
O
DVP out bit 4
4
D5
O
DVP out bit 5
5
D6
O
DVP out bit 6
6
D7
O
DVP out bit 7
7
D8
O
DVP out bit 8
8
D9
O
DVP out bit 9
9
D0
O
DVP out bit 0
10
D1
O
DVP out bit 1
11
GND
PWR
Ground
12
GND
PWR
Ground
13
HSYNC
O
DVP Horizontal sync output
14
NC
NC
Do not connect
15
NC
NC
Do not connect
16
RESET#
I
Active low reset input
17
VSYNC
O
DVP Vertical sync output
18
SDA
I/O
SCCB Serial Data signal
19
SCL
I
SCCB Serial Clock signal
20
NC
NC
Do not connect
21
VCAM
PWR
Camera Power in
22
VCAM
PWR
Camera Power in
23
PCLK
I/O
DVP Pixel clock output
24
GND
PWR
Ground
25
GND
PWR
Ground
26
NC
NC
Do not connect
Table 1:Micron Camera interface connector pin detail

e-CAM52_35x Hardware User Manual 04-Jan-12
Confidential Page 8 of 10
6 Mechanical Specification
6.1 Camera Board outline
Figure 3: eCAM52_35x board outline dimensions (in mm).
7 E-CAM52_35x board handling procedure
The e-CAM52_35x board should be mounted to Micron Camera header (J31) of the OMAP 3530
EVM Rev G as indicated in the following steps

e-CAM52_35x Hardware User Manual 04-Jan-12
Confidential Page 9 of 10
1. Put the jumper connecting Pin 2 and 3 of JP1 header on OMAP 3530 EVM Rev G. This is
required to connect the camera signals to Micron connector (J31). This is illustrated in
the picture below
Figure 4: JP1 jumper setting
2. The camera board’s pin one is indicated as below.
Figure 5: eCAM52_35x CN2 pin 1 indication
3. Insert the camera board into the Micron header (J31) of the OMAP EVM board as shown
in the image below. Note that the camera module should face outside the board.
Pin 1

e-CAM52_35x Hardware User Manual 04-Jan-12
Confidential Page 10 of 10
Figure6: eCAM52_35x interfaced with OMAP3530 Rev G EVM
