Echo Power Pruner 99944200532 User manual

X7702092207
© 2/2017 ECHO Inc.
ENGLISH
Operator’s Manual
Specifications, descriptions and illustrative material in this literature are
as accurate as known at the time of publication, but are subject to
change without notice. Illustrations may include optional equipment and
accessories, and may not include all standard equipment.
99944200532
Power PrunerTM
Attachment
FOR MODELS: SRM-2100SB, 2400SB, 210SB, 211SB, 225SB, 260SB,
261SB, PAS-2100, 2400, 2601, 210, 211, 225, 225VP, 225VPB, 230, 231,
260, 261, 265, 266, 280, 2620
Users of this equipment risk injury to them-
selvesandothersiftheunitis used improperly
and/or safety precautions are not followed.
ECHO provides an operator’s manual and a
safety manual. Both must be read and understood for
proper and safe operation. Failure to do so could result in
serious injury.

TABLE OF CONTENTS SRM-225
2 X7702092207
© 2/2017 ECHO Inc.
TABLE OF CONTENTS
Introduction ................................................................................................. 3
Servicing Information.................................................................................. 3
Parts/Serial Number ............................................................................ 3
Service................................................................................................. 3
Echo Consumer Product Support........................................................ 4
Product Registration ............................................................................ 4
Additional or Replacement Manuals.................................................... 4
Safety.......................................................................................................... 4
Manual Safety Symbols and Important Information............................. 4
International Symbols.......................................................................... 5
Personal Condition and Safety Equipment .......................................... 7
Guide Bar and Saw Chain ................................................................. 11
Kickback............................................................................................. 12
Equipment.......................................................................................... 13
Description................................................................................................ 15
Contents.................................................................................................... 16
Assembly................................................................................................... 16
Power Head Shaft To Lower Shaft Assembly..................................... 16
Support Handle Removal................................................................... 17
Saw Chain Adjustment....................................................................... 18
Operation .................................................................................................. 19
Lubricating the Guide Bar and Saw Chain......................................... 19
Note: Very little visible oil on the saw chain will provide sufficient
lubrication. ......................................................................................... 20
Pruning Techniques ........................................................................... 20
Maintenance ............................................................................................ 22
Skill Levels......................................................................................... 22
Maintenance Intervals........................................................................ 23
Lubrication ......................................................................................... 23
Guide Bar and Saw Chain Replacement........................................... 24
Filing Standard Saw Chain ................................................................ 25
Storage...................................................................................................... 28
Storage Hook Installation................................................................... 28
Specifications............................................................................................ 28
Notes......................................................................................................... 29
Product Registration.................................................................................. 30

SRM-225 INTRODUCTION
X7702092207 3
© 2/2017 ECHO Inc.
ENGLISH
INTRODUCTION
Welcome to the ECHO family. This ECHO product was designed and manu-
factured to provide long life and on-the-job dependability. Read and under-
stand this manual and the safety manual. Keep the manuals in a safe place
for future reference.
The operators manual contains specifications and information for safety,
operation, maintenance, storage and assembly specific to this product.
Scan the QR codes throughout the operator’s manual for more information.
The safety manual explains possible hazards and the measures you should
take to insure safe operation.
SERVICING INFORMATION
Parts/Serial Number
Genuine ECHO Parts and Assem-
blies for your ECHO products are
available only from an Authorized
ECHO Dealer. When you do need to
buy parts always have the Model
Number and Serial Number of the
unit with you. For future reference
write them in the space provided
below.
Model No. _________________
Serial No. _________________
Service
Service of this product during the warranty period must be performed by an
Authorized ECHO Service Dealer. For the name and address of the Autho-
rized ECHO Service Dealer nearest you, ask your retailer or call:
1-800-432-ECHO (3246). Dealer information is also available on our Web
Site. www.echo-usa.com. When presenting your unit for Warranty service/
repairs, proof of purchase is required.

SAFETY SRM-225
4 X7702092207
© 2/2017 ECHO Inc.
Echo Consumer Product Support
If you require assistance or have questions concerning the application,
operation, or maintenance of this product, call the ECHO Consumer Prod-
uct Support Department at 1-800-673-1558 from 8:00 am to 5:00 pm (Cen-
tral Standard Time) Monday through Friday. Before calling, please know the
model and serial number of your unit.
Product Registration
Register your ECHO equipment on-line at www.echo-usa.com or by filling
out the product registration sheet included in this manual. Registering your
product confirms warranty coverage and provides a direct link to ECHO if
we find it necessary to contact you.
Additional or Replacement Manuals
Replacement Operator or Safety Manuals, and Parts
Catalogs, are available from your Authorized ECHO Ser-
vice Dealer, or at www.echo-usa.com, or by contacting
ECHO Inc., 400 Oakwood Road, Lake Zurich, IL 60047
(800-673-1558). Always check www.echo-usa.com for
updated information.
Safety Videos are available from your Authorized ECHO Service Dealer. A
$5.00 shipping charge is required for each video.
SAFETY
Manual Safety Symbols and Important Information
Throughout this manual and on the product itself, you will find safety alerts
and helpful, informational messages preceded by symbols or key words.
The following is an explanation of those symbols and key words and what
they mean to you.
The safety alert symbol accompanied by the word “DANGER”
calls attention to an act or condition which WILL lead to serious
personal injury or death if not avoided.

SRM-225 SAFETY
X7702092207 5
© 2/2017 ECHO Inc.
ENGLISH
The safety alert symbol accompanied by the word “WARNING”
calls attention to an act or condition which CAN lead to serious
personal injury or death if not avoided.
The safety alert symbol accompanied by the word “CAUTION”
calls attention to an act or condition which may lead to minor or
moderate personal injury if not avoided.
The enclosed message provides information necessary for the pro-
tection of the unit.
Note: This enclosed message provides tips for use, care and maintenance
of the unit.
CIRCLE AND SLASH SYMBOL
This symbol means the specific action shown is prohibited.
Ignoring these prohibitions can result in serious or fatal injury.
International Symbols
Symbol Description Symbol Description
Warning, See
Operator’s Manual Carburetor
Adjustment - High
Speed Mixture
Wear Eye, Ear
and Head
Protection
Carburetor
Adjustment - Idle
Speed
Wear Hand and
Foot Protection Carburetor
Adjustment - Low
Speed Mixture
Safety / Alert Emergency Stop

SAFETY SRM-225
6 X7702092207
© 2/2017 ECHO Inc.
Hot Surface Fuel and Oil Mixture
AVOID KICKOUT
Keep Bystanders At Least
15 m (50 ft.) Away
Beware Thrown Objects
Wear Eye Protection
Keep Bystanders and Helpers
Away 15 m (50 ft.)
DO NOT Allow
Flames or Sparks
Near Fuel Ignition
ON / OFF
DO NOT Smoke
Near Fuel Primer Bulb
Choke Control
“RUN” Position
(Choke Open)
Choke Control
“COLD START”
Position (Choke
Closed)
Keep Feet Away
From Blade Rotating Cutting Attachment
Thrown Objects Wear Face Shield
Finger Severing WearSlipResistant
Footwear
Symbol Description Symbol Description

SRM-225 SAFETY
X7702092207 7
© 2/2017 ECHO Inc.
ENGLISH
Personal Condition and Safety Equipment
Users of this product risk injury to themselves and others if the
unit is used improperly and/or safety precautions are not fol-
lowed. Proper clothing and safety gear must be worn when op-
erating unit.
Physical Condition
Your judgment and physical dexterity may not be good:
• If you are tired or sick.
• If you are taking medication.
Do not operate
closer than 15 m
(50 ft.) from
electricalhazards.
Keep bystanders
at least 15 m
(50 ft.) away.
DO NOT USE
BLADES - Line
Head Only
Plan retreat path
from falling
objects.
Symbol Description Symbol Description

SAFETY SRM-225
8 X7702092207
© 2/2017 ECHO Inc.
• If you have taken alcohol or drugs.
Operate unit only if you are physically and mentally well.
Eye Protection
◆Eye protection that meets ANSI Z87.1 or CE requirements
must be worn whenever you operate the unit.
◆For additional safety, a full-face shield may be worn over
safety glasses or goggles to provide protection from sharp
branches or flying debris.
Hand Protection
Wear sturdy, no-slip, rubber work gloves to improve your grip on the han-
dles. Gloves also provide protection against cuts and scratches, cold envi-
ronments, and reduce the transmission of machine vibration to your hands.
Hearing/Ear Protection
ECHO recommends wearing hearing protection whenever unit is used.
Breathing Protection
Operators who are sensitive to dust or other common airborne allergens
may need to wear a dust mask to prevent inhaling these materials while
operating unit. Dust masks can provide protection against dust, plant debris,
and other plant matter such as pollen. Make sure the mask does not impair
your vision, and replace the mask as needed to prevent air restrictions.
Proper Clothing
Wear snug-fitting, durable clothing:
• Pants should have long legs, shirts should have long sleeves.
• DO NOT WEAR SHORTS.
• DO NOT WEAR TIES, SCARVES, JEWELRY, or clothing with loose or
hanging items that could become entangled in moving parts or surround-
ing growth.
• Keep clothing buttoned or zipped, and keep shirt tails tucked in.
Wear sturdy work shoes with nonskid rubber soles:
• DO NOT WEAR OPEN TOED SHOES.
• DO NOT OPERATE UNIT BAREFOOTED.

SRM-225 SAFETY
X7702092207 9
© 2/2017 ECHO Inc.
ENGLISH
Keep long hair away from engine and air intake. Retain hair with cap or net.
Heavy protective clothing can increase operator fatigue, which may lead to
heat stroke. Schedule heavy work for early morning or late afternoon hours
when temperatures are cooler.
The components of this machine generate an electromagnetic
field during operation, which may interfere with some pacemak-
ers. To reduce the risk of serious or fatal injury, persons with
pacemakers should consult with their physician and the pace-
maker manufacturer before operating this machine. In the ab-
sence of such information, ECHO does not recommend the use
of this machine by anyone who has a pacemaker.
Extended Operation / Extreme Conditions
Prolonged exposure to cold and/or vibration may result in inju-
ry. Read and follow all safety and operation instructions to min-
imize risk of injury. Failure to follow instructions may result in
painful wrist/hand/arm injuries.
It is believed that a condition called Raynaud’s Phenomenon, which affects
the fingers of certain individuals, may be brought about by exposure to
vibration and cold. Exposure to vibration and cold may cause tingling and
burning sensations, followed by loss of color and numbness in the fingers.
The following precautions are strongly recommended, because the mini-
mum exposure, which might trigger the ailment, is unknown.
• Keep your body warm, especially
the head, neck, feet, ankles,
hands, and wrists.
• Maintain good blood circulation by
performing vigorous arm exer-
cises during frequent work
breaks, and also by not smoking.
• Limit the hours of operation. Try to
fill each day with jobs where oper-
ating the unit or other hand-held
power equipment is not required.

SAFETY SRM-225
10 X7702092207
© 2/2017 ECHO Inc.
• If you experience discomfort, redness, and swelling of the fingers followed
by whitening and loss of feeling, consult your physician before further
exposing yourself to cold and vibration.
Repetitive Stress Injuries
(RSI)
It is believed that overusing the
muscles and tendons of the fingers,
hands, arms, and shoulders may
cause soreness, swelling, numb-
ness, weakness, and extreme pain
in those areas. Certain repetitive
hand activities may put you at a high
risk for developing a Repetitive
Stress Injury (RSI). An extreme RSI
condition is Carpal Tunnel Syn-
drome (CTS), which could occur
when your wrist swells and
squeezes a vital nerve that runs
through the area. Some believe that
prolonged exposure to vibration may contribute to CTS. CTS can cause
severe pain for months or even years.
To reduce the risk of RSI/CTS, do the following:
• Avoid using your wrist in a bent, extended, or twisted position. Instead try
to maintain a straight wrist position. Also, when grasping, use your whole
hand, not just the thumb and index finger.
• Take periodic breaks to minimize repetition and rest your hands.
• Reduce the speed and force with which you do the repetitive movement.
• Do exercises to strengthen the hand and arm muscles.
• Immediately stop using all power equipment and consult a doctor if you
feel tingling, numbness, or pain in the fingers, hands, wrists, or arms. The
sooner RSI/CTS is diagnosed, the more likely permanent nerve and mus-
cle damage can be prevented.
All over head electrical conductors and communications wires
can have electricity flow with high voltages. This unit is not in-
sulated against electrical current. Never touch wires directly or
indirectly, otherwise serious injury or death may result.

SRM-225 SAFETY
X7702092207 11
© 2/2017 ECHO Inc.
ENGLISH
Do not operate this product indoors or in inadequately ventilat-
ed areas. Engine exhaust contains poisonous emissions and
can cause serious injury or death.
Guide Bar and Saw Chain
◆Serious injury may result from the use of non approved
guide bar and saw chain combinations. Read and comply
with all safety instructions listed in this manual.
◆ECHO, INC. will not be responsible for the failure of cutting
devices or accessories which have not been tested and
approved by ECHO for use with this unit.
• Never adjust the guide bar or saw chain when the engine is operating.
• Check that the cutting attachment, guide bar and saw chain is firmly
attached and in safe operating condition.
• Only use ECHO approved guide bar and saw chain.
• Do not hit rocks, stones, tree
stumps and other foreign objects
with the saw chain.
• Do not cut into the ground with
the saw chain.
• If saw chain strikes an
obstruction, stop engine
immediately and inspect saw
chain for damage.
• Do not operate with a dull, broken or discolored saw chain.
• Remove all foreign objects from work area.
• Always cover the guide bar and saw chain with guide bar cover during
transportation and in storage.
Read the Manuals
• Provide all users of this equipment with the Operator’s Manual and Safety
Manual for instructions on Safe Operation.

SAFETY SRM-225
12 X7702092207
© 2/2017 ECHO Inc.
Clear the Work Area
• Spectators and fellow workers must be warned, and children and animals
prevented from coming nearer than 15 m (50 ft.) while the unit is in use.
Use Proper Clothing & Equipment
• Always wear head protection with full face shield to help protect against
falling branches and debris.
Keep a Firm Grip
• Always hold throttle handle and support handle with thumbs and fingers
tightly encircling the handles.
Keep a Solid Stance
• Maintain footing and balance at all times. Do not stand on slippery,
uneven or unstable surfaces. Do not work in odd positions or on ladders.
Do not over reach.
Avoid Hot Surfaces
• During operation, the drive shaft
housing and attachment bearing
housing may become very hot, too
hot to touch. Avoid contact during
and immediately after operation.
Kickback
Kickback can lead to dangerous loss of control of the Power
Pruner and result in serious injury to the operator or any one
standingclose by. HoldthePower Prunerfirmlywithboth hands
with thumbs and fingers encircling the front and rear handles.
Be aware of the down and outward path the pruner will take after
the cut is made.

SRM-225 SAFETY
X7702092207 13
© 2/2017 ECHO Inc.
ENGLISH
Kickback may occur when the moving saw
chain at the nose or tip of the guide bar
touches an object, or when the wood
closes in and pinches the saw chain in the
cut. In some cases this may cause a light-
ning-fast reverse action, kicking the guide
bar and saw chain up and back or down
and back towards the operator. Either of
these reactions may cause the operator to
lose control of the Power PrunerTM which
could result in serious personal injury.
With a basic understanding of kickback,
you can reduce or eliminate the element of
surprise which contributes to accidents.
Avoid contact of the guide bar tip with any object while the saw chain is mov-
ing.
Cut only wood. Avoid striking concrete, metal, wire, or other obstructions
which could cause kickback or damage to the saw chain.
If the saw chain does strike a foreign object, immediately stop the engine,
inspect and repair the Power PrunerTM if necessary.
Equipment
Use this attachment with ECHO approved models only. Serious
injury may result from the use of this attachment combined
with a non approved ECHO product.
• Check unit for loose/missing nuts, bolts, and screws. Tighten and/or
replace as needed.
• Inspect shield for damage and that shield is securely in place. Replace if
shield is damaged or missing.
• Check that the cutting attachment is firmly attached and in safe operating
condition.
Note: ECHO, INC. will not be responsible for the failure of cutting devices,
attachments or accessories which have not been tested and approved by
ECHO.

SAFETY SRM-225
14 X7702092207
© 2/2017 ECHO Inc.
Moving parts can amputate fingers or cause severe injuries.
Keep hands, clothing and loose objects away from all openings.
◆ALWAYS stop engine, disconnect spark plug, and make
sure all moving parts have come to a complete stop before
removing obstructions, clearing debris, or servicing unit.
◆DO NOT start or operate unit unless all guards and
protective covers are properly assembled to unit.
◆NEVER reach into any opening while the engine is running.
Moving parts may not be visible through openings.

SRM-225 DESCRIPTION
X7702092207 15
© 2/2017 ECHO Inc.
ENGLISH
DESCRIPTION
Locate the safety decal(s) on your unit. Make sure the decal(s) is legible and
that you understand and follow the instructions on it. If a decal cannot be
read, a new one can be ordered from your ECHO dealer.
1. SUPPORT HANDLE - FOR LEFT HAND - Cushioned grip.
2. LOWER DRIVE SHAFT ASSEMBLY - Contains a specially designed
liner and the flexible drive shaft.
3. CUTTING ATTACHMENT - Sealed, gear ratio is 1.5:1 reduction.
4. AUTOMATIC OILER ASSEMBLY - Self oiling. Use high quality, low
viscosity, non-detergent bar and chain oil.
5. SAW CHAIN - Chain, serving as a cutting tool.
6. GUIDE BAR
7. CUTTING SHOE - Used to capture and stabilize branch while cutting.
Placecutting shoeagainstbranch,accelerateand lowersaw chaininto
branch.
8. SHOULDER HARNESS - An adjustable strap that suspends the unit
from the operator.
9. GUIDE BAR COVER - Used to cover guide bar and saw chain during
transport and storage. Remove guide bar cover before using unit.
15 m
50 ft
1
8
9
2
3
4
5,6
7

CONTENTS SRM-225
16 X7702092207
© 2/2017 ECHO Inc.
CONTENTS
The ECHO product you purchased has been factory pre-assembled for your
convenience. Due to packaging restrictions, some assembly may be neces-
sary.
After opening the carton, check for damage. Immediately notify your retailer
or ECHO Dealer of damaged or missing parts. Use the contents list to check
for missing parts.
ASSEMBLY
Power Head Shaft To Lower Shaft Assembly
Do not perform maintenance or assembly procedures with en-
gine running.
1. Set Power Head/Shaft Assembly on a level surface.
2. Pull locater pin (A) out, and turn counter-clockwise ¼
turn to lock-out position.
3. Remove vinyl cap from attachment drive shaft.
4. Remove cardboard spacer, if necessary.
Note: Your coupler may appear different than coupler
shown.
1 Power Pruner Attachment
1 Guide Bar Cover
1 Shoulder Harness
1 Storage Hook Assembly
1 Operator’s Manual
1 Safety Manual
1 Warranty Statement
Parts Required: PAS or SRM-SB Power Head Shaft and Coupling

SRM-225 ASSEMBLY
X7702092207 17
© 2/2017 ECHO Inc.
ENGLISH
5. Carefully fit attachment drive
shaft assembly into coupler (B)
to decal assembly line (C),
making sure that the inner
lower drive shaft engages the
square upper drive shaft
socket.
Note: Earlier model power heads
may have shorter couplings.
Note: Lower bearing housing and
head assembly must be in line with
the engine.
6. Rotate locater pin (A) ¼ turn
clockwise to engage lower shaft
hole. Insure locater pin is fully
engaged by twisting lower drive
shaft. Locater pin should snap
flush in coupler. Full engage-
ment will prevent further shaft
rotation.
7. Secure lower shaft assembly to
coupler by tightening clamping
knob (D).
Support Handle Removal
Note: Support handles or support handles with barrier bars are not recom-
mended for use with this attachment.
1. Remove support handle
assembly, barrier bar (if
installed), and mounting hard-
ware from PAS or SRM-SB
power head.
2. Retain parts for future use.
B
A
C
D
A

ASSEMBLY SRM-225
18 X7702092207
© 2/2017 ECHO Inc.
Saw Chain Adjustment
Always disconnect spark plug wire before servicing cutting at-
tachment. Wear gloves when handling saw chain, otherwise se-
rious personal injury may result.
1. Move stop switch to STOP posi-
tion.
2. Disconnect spark plug lead.
3. Loosen two guide bar nuts (A)
until finger tight.
Always loosen guide bar nuts before turning the chain tension
adjuster, otherwise the clutch cover and tensioner will be damaged.
4. Hold the bar nose up, and turn the adjuster screw (B) clockwise until
the chain fits snugly against the underside of the bar, as shown. Cold
Chain Only - turn adjuster screw CW an additional 1/8 - 1/4 turn.
5. Tighten both guide bar nuts
with nose held up. Tighten rear
nut first.
6. Pull the chain around the guide
bar by hand. Reduce the chain
tension if you feel tight spots.
7. When chain is properly ten-
sioned, tighten guide bar nuts
securely.
C
A
B
C
A
B

SRM-225 OPERATION
X7702092207 19
© 2/2017 ECHO Inc.
ENGLISH
Tighten guide bar nuts to 8 - 9 N•m (71 - 80 in. lbs.). DO NOT over-
tighten nuts or damage may result.
8. Keep chain properly tensioned at all times.
Note: All chains require frequent adjustment.
9. Connect spark plug lead.
OPERATION
Note: Refer to your PAS power source Operator's Manuals for correct
engine fueling, starting and stopping instructions.
Moving parts can amputate fingers or cause severe injuries.
Keep hands, clothingand loose objects away fromall openings.
Always stop engine, disconnect spark plug, and make sure all
moving parts have come to a complete stop before removing
obstructions, clearing debris, or servicing unit. Allow unit to
cool before performing service.
Lubricating the Guide Bar and Saw Chain
Automatic Oiling System
1. Wipe debris from around oil fill
cap.
2. Remove oil fill cap and fill reser-
voir with a quality, low viscosity
guide bar and saw chain oil.
To prevent plastic deterioration, do not use synthetic or silicone
based oil.

OPERATION SRM-225
20 X7702092207
© 2/2017 ECHO Inc.
Adjusting Automatic Oiler
1. From bottom of gear case, turn
adjustment screw (A) clock-
wise to decrease oil volume, or
counterclockwiseto increase oil
volume.
Note: The automatic oiler is preset
to deliver a sufficient oil discharge
volume during normal operating
conditions. During heavy or dry cut-
ting conditions, the oil discharge vol-
ume may be increased to assure
adequate lubrication. If oil is leaking
from the bar cover area, reduce the
oil discharge volume. Refill the oil
reservoir with each tank of fuel.
Note: Very little visible oil on the saw chain will provide sufficient lubrication.
Pruning Techniques
Shoulder Harness (if included)
Your harness may appear different than the harness shown.
1. Loosen the harness clamp
screw.
2. Put the harness on and attach it
to the unit.
3. Adjust the harness for comfort-
able operation.
4. Tighten the harness clamp
screw.
A
A
