echoflex ERUSB-C User manual

ERUSB-C
echoflex
ERUSB-C
User Guide
Product Overview
Echoex’s ERUSB-C is a wireless Passive Infrared (PIR) occupancy sensor and
switch in a small package perfect for cubicle switch staon applicaons.
Powered through a USB connecon and mounng at desk level or on a cubicle
paron wall, the ERUSB-C detects moon and transmits the occupancy status
via an EnOcean telegram.
The cubicle switch staon can be linked to any of Echoex’s line of embedded
controllers or other EnOcean receivers. Assigning the ERUSB-C to overhead
lighng xtures or task lighng can automate each cubicle space with individual
lighng control. The built-in toggle switch allows manual override of the light.
The ERUSB-C comes with a 1 meter USB 2.0 cable for connecon to laptops
and computers.

2
Using the Cubicle Controller
The cubicle controller can be used as a manual light switch and as a cubicle
occupancy sensor. The buon switch on the cubicle controller sends PTM
switch telegrams (press and release) alternang between On and O telegrams.
Pressing the buon once simulates pressing a EnOcean wall switch ON. Pressing
the buon again sends an OFF telegram. A green LED near the cable port will be
ON when last ON, o when last OFF
The occupancy sensor is a passive infrared (PIR) sensor and is designed for small
areas like an oce or cubicle space. The sensors range is cone shaped, 2m (6½
feet)in length from the sensor and 2.5m (8 feet) in diameter.
Within this range small movements such as hand gestures or picking up the phone
or coee mug will trigger occupancy. A red LED will light when detecng moon.
• The cubicle controller will transmit on a change of occupancy state
immediately when changing from unoccupied to an occupied state.
• The sensor will pause 20 seconds aer last occupancy before transming
on un-occupied state.
• A 100 second heartbeat mer will transmit the sensors current state.
Planning the Installaon
The ERUSB-C is a wireless transmier intended to be used with Echoex
lighng control products. Locang the wireless transmiers to work with
the lighng controller requires planning. Careful consideraon should be
made for locang the controllers and transmiers based on the construcon
materials in the space and possibility of tenant’s furniture disrupng the
transmissions. Fire doors, elevator shas or any large metal products will disrupt
wireless transmissions.
Installing the ERUSB-C
The cubicle controller is powered through a USB port. The cubicle controller
comes with a USB 2.0 cable type A to type mini-B
1. Plug the USB cable’s mini-B end into the ERUSB and the other end into a
computers USB port or alternavely into a wall plug adapter.
2. The controller can be mounted with double-sided tape or Velcro™. Adhere
to the cubicle wall facing the work staon or underneath the desk where
the occupants legs rest.

3
Linking the ERUSB-C to a Receiver
The cubicle controller can send two data telegrams. The buon sends a switch
telegram and the sensor which sends an occupancy telegram. Each telegram
must be linked to a receiver separately.
Linking the occupancy sensor
• Place the receiver in LINK mode, consult the manufactures instrucons
if necessary.
• Press and hold the buon on the ERUSB for ve (5) seconds. The ERUSB
will transmit the TEACH command for the occupancy sensor.
• Exit LINK mode
Linking the switch
• Place the Echoex receiver in LINK mode, consult the receivers instrucons
if necessary.
• Press the buon on the ERUSB once then press and hold for (5) ve
seconds, both within seven (7) seconds. The ERUSB will send three (3) PTM
ON commands.
• Exit LINK mode

4
Echoex Soluons, Inc.
#1, 38924 Queens Way | Squamish | BC | Canada | V8B 0K8
Toll Free: 888-324-6359 | Phone: [phone] | Fax: [phone]
Email: info@echoexsoluons.com | www.echoexsoluons.com
echoflex
© 2010-2014 Echoex Soluons, Inc. | Specicaons subject to change without noce.
Part # 8DC-5151 | Revision 2.0 | 8188M21-5151-01 | Rev A
Specicaons
Equipment Proles
EEP: A5-07-01 Occupancy Sensor
EEP: F6-02-02 Light & Blind Control
Communicaons 902 or 868 MHz
Power USB 2.0 Port
Weight 1.2 oz. (34 gms.)
Dimensions 3.2”x 2.1”x 0.7” (82 x 54 x 17 mm)
Antenna Integrated
Input Buon Switch
Output Power LED
Agency Lisng and Compliance
(902 MHz models only)
FCC Part 15.231 - Remote Control Transmier IC RSS-210
Contains FCC ID: SZV-STM300U
The enclosed device complies with Part 15 of the FCC Rules.
Operaon is subject to the following two condions:
(I.) this device may not cause harmful interference and
(ii.) this device must accept any interference received, including
interference that may cause undesired operaon.
Contains IC: 5713A-STM300U
