Ecoflam MAX 15 TC User manual

Technical data
Dati tecnici
Données techniques
Datos técnicos
Технические характеристики
Operating instructions
Istruzioni per l’uso
Notice d’emploi
Manual de uso
Руководство по эксплуатации
Electric and hydraulic diagrams
Schemi elettrico e idraulico
Schémas électrique et hydraulique
Esquemas eléctrico e hidráulico
Электрические игидравлические схемы
Spare parts list
Pièces de rechange
Parti ricambi
Запчасти
Piezas de recambio
www.ecoflam-burners.com
LIGHT OIL BURNERS
EN
IT
FR
ES
RU
MAX 15
MAX 20
MAX 30
MAX 15 TC 3142729
MAX 15 TL 3142730
MAX 20 TC 3142731
MAX 20 TL 3142732
MAX 30 TC 3142733
MAX 30 TL 3142734

3
www.ecoflam-burners.com
420010371901
EN
IT
FR
ES
RU
Technical data - Dati tecnici - Données techniques - Datos técnicos - Технические характеристики MAX 15 MAX 20 MAX 30
Burner output max/min kW - kcal/h Potenza bruciatore
max/min kW - kcal/h Puissance du brûleur
max/min kW - kcal/h
Potencia del quemador máx/min kW - kcal/h
Мощность горелки макс./мин., кВт -ккал/час
190 73,4 237 86,4 319 110
163800 63240 204000 74460 275400 94860
Oil throughput max/min kg/h Portata gasolio
max/min kg/h Débit de fuel
max/min kg/h Caudal de gasóleo
máx/min kg/h Расход топлива
макс./мин., кг/ч16 6,2 20 7,3 27 9,3
Hydraulic system 1 stage Sistema idraulico
1 stadio Système hydraulique
1 allure Sistema hidráulico
1 etapa Гидросистема
1 ступень 1 1 1
Regulating ratio Rapporto di
regolazione Rapport de régulation Relación de
regulación Коэффициент
регулирования 1:1
Fuel oil Combustibile Fuel Combustible Топливо
Light oil (L.C.V. 10.200 kcal/kg max. visc 1,5°E at 20°C)
(EL) Hu = 11,86 kWh/kg
Emission class Classe di emissione Classe d’émission Tipo de emisión Класс выделения
загрязняющих веществ Standard Class 2 - OIL EN267 (NOx < 185 mg/kWh)
Control box Apparecchiatura di
controllo Coffret de sécurité Cajetín de seguridad Блок управления и
безопасности E-BCU Ecoflam
Air regulation Air flap Regolazione aria
Serranda dell'aria Réglage de l’air
Volet d’air Ajuste del aire
Válvula de aire
Настройка подачи воздуха Воздушная заслонка
---
Flame monitor Rivelatore di fiamma Surveillance
de flamme Vigilancia de llama Контроль пламени photoresistor photoresistor photoresistor
Ignition transformer Trasformatore
d'accensione Allumeur Encendedor Устройство розжига danfoss / cofi danfoss / cofi danfoss / cofi
Fuel-oil pump Pompa di pressione
gasolio Pompe de
pulvérisation fuel
Bomba de pulverización de gasóleo
Насос распыления дизельного топлива danfoss / suntec danfoss / suntec danfoss / suntec
Electric motor rpm - watt Motore elettrico
giri motore - watt Moteur
rpm - watt Motor
rpm - watt Электродвигатель
об/мин - watt 2800 rpm 2800 rpm 2800 rpm
130 W 200 W 200 W
Voltage Tensione Tension Tensión Напряжение 230 V / 50 Hz
Power consumption (operation) Potenza elettrica
assorbita (Esercizio) Puissance électrique
absorbée (en service)
Pot. eléctrica absorbida
(en funcionamiento)
Потребляемая электрическая мощность: (при работе)400 W 450 W 450 W
Net weight Peso netto Poids net Peso neto Приблизительная масса 11,6 kg 11,8 kg 12,6 kg
Protection level Classe di protezione Indice de protection Índice de protección Класс электрозащиты IP40
Sound pressure level dB(A) Livello pressione
sonora dB(A) Niveau presion
acoustique dB(A) Nivel de presion
acústico dB(A) Уровень шума, dB(A) 70 70 70
Ambient temp. for storage Temperatura ambiente
di stoccaggio Température ambiante
de stockage Temperatura ambiente
de almacenamiento температура хранения -20°…+70° C
Temperature for use Temperatura
d’utilizzazione Température
d’utilisation Temperatura ambiente
de utilización Рабочая температура -10°…+60° C
Overview / Panoramica / Vue d'ensemble / Descripción / Обзор

5
www.ecoflam-burners.com
420010371901
EN
IT
FR
ES
RU
Overview - Dimensions / Panoramica - Dimensioni / Vue d'ensemble - Dimensions / Descripción - Dimensiones / Обзор - Размеры
X
Y
Z
Packaging
MAX 15 - 20 - 30
d..°
Ø a Ø b
Ø c
M
Model A B C D D1 E F G I L M
MAX 15 392 202 190 160 260 276 107 201 120/131 120/131 M8 MAX 20 392 202 190 160 260 276 125 201 120/131 120/131 M8 MAX 30 392 202 190 160 260 276 125 201 120/131 120/131 M8
Model Ø a Ø b Ø c d°..
MAX 15 117 153 190 45° MAX 20 135 153 190 45° MAX 30 135 153 190 45°
Model X Y Z Kg
MAX 15 450 610 390 14,8 MAX 20 450 610 390 15 MAX 30 450 610 390 15,7
D / D1 E
M
L
F
G
125
I
E
D-D1
F
G
B C
A
I
L
M
153
190

7
www.ecoflam-burners.com
EN
420010371901
A1 E-BCU OIL control box
M1 Electric motor for pump and
blower wheel
T1 Ignition transformer
Y Graduated rod
Y1 Solenoid valve
3 Air regulation in the burner head
5 Fastening screws for equipment plate
9 Wieland socket
15 Burner flange
16 Release knob
102 Fuel-oil pump
103B Air regulation
113 Air intake
MAX 15 LNTWTC - 230V/50Hz
MAX Light oil
RANGE NAME BY FUEL TYPE
MAX 15 16 kg/h
MODEL SIZE (Gas: kW; Oil: kg/h)
MAX Low NOx Low NOx Class 3 yellow flame (<120 mg/kWh)
MAX Standard Class 2-OIL EN267 (<185 mg/kWh)
EMISSION COMBUSTION TYPE
- 1 stage
TW Thermowatt E-BCU
OPERATION TYPE
TC Short head
TL Long head
HEAD TYPE
- Light oil
KER Kerosene
BIODIESEL Biodiesel
D Heavy oil: max visc. 50° E at 50°C
FUEL
230V/50Hz 230 Volt, 50Hz
ELECTRICAL SUPPLY TO THE SYSTEM
Contents - Burner description
Scope of delivery
CB: COMPLETE BURNER
- 1 bag including :
- multilanguage technical manual.
- filter and hoses.
- wieland plug.
- nozzle and spanner.
- screws, nuts and washer.
KIT & ACS delivered separately
15 14
113 103B
5
Y1
A1
M1 T1
15
16
102 9Y
3

8www.ecoflam-burners.com
EN
420010371901
Function - General safety functions
Operating function
- If heat is requested by the boiler
thermostat, the automatic oil
combustion control unit starts the
program sequence.
- The motor starts, the igniter is switched
on and the preventilation period of 15
seconds commences.
- During the preventilation period, the
furnace is monitored for flame signals.
- At the end of the preventilation period,
the fuel-oil solenoid valve opens and the
burner starts.
- The igniter remains switched off while
the burner is in operation.
Controlled shutdown
- Boiler thermostat interrupts heat
request.
- The fuel-oil solenoid valve closes and
the flame is extinguished.
- Burner motor switches off.
- Burner enters standby.
Safety function
A safety shutdown occurs:
- if a flame signal is present during
preventilation (parasitic flame
monitoring).
- if no flame is produced within 5 seconds
(safety time) of start-up (fuel
authorisation).
- if no flame is produced after an
unsuccessful restart attempt in the
event of flame failure during operation.
A safety shutdown is indicated by the
malfunction lamp lighting up and it is then
only possible to reenable the burner by
pressing the reset button after the cause
of the malfunction has been rectified.
For further information, see the
automatic combustion control unit
description.
M
M1
118
103 101
T1
104
102
106
105
Y1
M1 Burner motor
T1 Ignition Transformer
Y1 Solenoid valve
101 Blower / Fan
102 Oil pump
103 Air damper
104 Oil pressure regulator
105 Hoses
106 Filter
118 Nozzle

9
www.ecoflam-burners.com
EN
420010371901
The E-BCU OIL fuel oil control and safety unit controls and monitors the forced draught burner. The microprocessor- controlled
program sequence ensures maximum stability of time periods, regardless of fluctuations in the power supply or ambient temperature.
The design of the automatic combustion control unit protects it from the effects of brownouts. Whenever the supply voltage drops
below its rated minimum level (170 V), the control unit shuts down - even in the absence of a malfunction signal. The control unit
switches itself back on again once the voltage has exceeded the 178 V.
Locking and unlocking the system
The control unit can be locked (switched to malfunction) and unlocked (malfunction cleared) by pressing the R reset button, provided
the system is connected to the mains power supply.
R
RJ45
R-Reset button + lock-out led.
RJ45 - Connector for PC interface (diagnostic, separate item).
LINE Electrical supply
BV... Fuel valve
FS Flame signal
M Burner motor
OW Release contact of oil preheater
W Control thermostat or pressurestat
Z Ignition transformer
1 No voltage
2 Power supply on, no heat request
4 Preventilation: motor ON, ignition ON
4’ Parasitic flame monitoring
5 Burner start: solenoid valve OFF, flame
production, safety time
6 Flame present, post-ignition period
7 Burner operation
8 End of heat request, solenoid valve
closes, burner stop
9 Standby
!Always disconnect the power supply before installing or removing the control unit. Do not attempt to open or carry out repairs
on the control unit.
Function - E-BCU OIL control and safety unit
KIT E-BCU
DIAGNOSTIC TOOL
(not supplied)
W
M
Z
BV1
FS
LINE
1
17s 5s
5s 5s --- -< 1s
24 4’ 5 6 7 8 9

10 www.ecoflam-burners.com
EN
420010371901
Function - Oil burner pump
1 suction intake connection.
2 return connection.
3 pressure connection.
4 oil pressure gauge connection.
5 negative pressure gauge connection.
6 oil pressure regulator.
10 Solenoid valve electrical connection.
Y1 fuel-oil solenoid valve.
6
12
3
45
Y1 10
PV
SUNTEC
AS V 47 A
21
4
5
6
P
-+ V
P
3
10
Y1
DANFOSS
BFP 21 R3
The oil burner pump used is a self-priming
gear pump, which must be connected as
two-line pump via a bleed filter. There is an
intake filter and an oil pressure regulator
integrated in the pump. Pressure gauges
for pressure measurements and negative
pressure measurements must be
connected before the equipment is
commissioned.
NB: before starting the burner, check that
the return pipe is open. An eventual
obstraction could damage the pump
sealing device.
3
2
11
3
2
1
1
1 Hoses
2 Filter
3 Oil cock
4 Plug
5 By-pass plug
5
4
One-pipe system ONE PIPE SYSTEM: If the oil supply
circuit is one-pipe system, the pump
needs to be modified following intructions
in the picture.
3
2
13
2
1
SUNTEC
DANFOSS
SUNTEC
DANFOSS

11
www.ecoflam-burners.com
EN
420010371901
Installation - Burner assembly
Oil connection
The filter must be located in such a way
that the correct hose routing cannot be
impaired. The hoses must not kink.
Burner assembly
The burner is fixed by mean of connecting
flange and therefore to the boiler.
Installation:
• To fix the flange 3to the boiler with
the screws 4.
• Turn the burner slightly, guide it into
the flange and secure using screw 5.
Removal:
• Loosen screw 5.
• Turn the burner out and pull it out of
the flange.
Burner pipe insertion depth and
brickwork
Unless otherwise specified by the boiler
manufacturer, heat generators without a
cooled front wall require brickwork or
insulation 5 as shown in the illustration.
The brickwork must not protrude beyond
the leading edge of the flame tube, and
should have a maximum conical angle of
60°. Gap 6 must be filled with an elastic,
non-combustible insulation material. For
boilers with reverse firing, the minimum
burner tube insertion depth A as
specified in the boiler manufacturer’s
instructions must be observed.
Exhaust system
To avoid unfavourable noise emissions,
right-angled connectors should not be
used on the flue gas side of the boiler.
1
3
4
–
+
2
3
5

12 www.ecoflam-burners.com
EN
420010371901
Installation - Electrical connection - Checks before commissioning
Electrical connection
The electrical installation and connection
work must only be carried out by an
authorised electrical specialist.
All applicable rules and regulations must
be observed.
The electrical installation should include a
type A circuit breaker.
The applicable guidelines and
directives must be observed, as well as
the electrical circuit diagram supplied
with the burner!
• Check to ensure that the power supply
voltage is as specified in the electric
diagram and in data plate.
• Burner fuse: 5 A.
Checks before commissioning
The following must be checked before
initial commissioning:
• That the burner is assembled in
accordance with the instructions given
here.
• That the burner is pre-set in accordance
with the values in the adjustment table.
• Setting the combustion components.
• The heat generator must be ready for
operation, and the operating regulations
for the heat generator must be observed.
• All electrical connections must be correct.
• The heat generator and heating system
must be filled with water and the
circulating pumps must be in operation.
• The thermostats, pressure regulator, low
water detectors and any other safety or
limiting devices that might be fitted must
be connected and operational.
• The exhaust gas duct must be
unobstructed and the secondary air
system, if available, must be operational.
• An adequate supply of fresh air must be
guaranteed.
• The heat request must be available.
• Fuel tanks must be full.
• The fuel supply lines must be
assembled correctly, checked for leaks
and bled.
• A standard-compliant measuring point
must be available, the exhaust gas duct
up to the measuring point must be free of
leaks to prevent anomalies in the
measurement results.
1
Electrical connection (plug-in)
It must be possible to disconnect the
burner from the mains using an
omnipolar shutdown device complying
with the standards in force. The burner
and heat generator (boiler) are connected
by a 7-pin connector (fig.1).
Position of electrodes
Note: Always check the position of
electrodes after having replaced the
nozzle (see illustration). A wrong position
could cause ignition troubles.
3 mm
5/6 mm
4 mm
Input Voltage
S3B4 T2 NT1 L1
TP
STC
PE
N
L
Q
H
LF HLB
TP
STS

H
H
(m) ø 6 mm ø 10 mm
0,5
1
1,5
2
2,5
3
3,5
15
13
11
9
7
5
-
100
99
84
68
53
37
22
H
(m) ø 6 mm ø 10 mm
0,5
1
1,5
2
2,5
3
3,5
19
21
23
25
27
29
31
ø 8 mm
47
41
34
28
22
15
9
ø 8 mm
60
66
72
79
85
91
98
100
100
100
100
100
100
100
H = x-y
y
x
H
H
(m) ø 8 mm ø 10 mm
0,5
1
1,5
2
2,5
3
3,5
30
35
40
45
50
55
60
65
70
75
80
85
90
95
H
(m) ø 8 mm ø 10 mm
0,5
1
1,5
2
2,5
3
3,5
23
21
19
17
14
9
4
55
50
45
40
34
28
22
y
x
H = x-y
13
www.ecoflam-burners.com
EN
420010371901
Installation - Oil feeding and suction line
Two-pipe siphon feed system
Two-pipe lift system Length pipe (m)
Length pipe (m)
FEEDING LINE WITH DANFOSS BFP21 R3
Two-pipe siphon feed system
Two-pipe lift system Length pipe (m)
Length pipe (m)
FEEDING LINE WITH SUNTEC AS V 47 A

A
B
+
-
A
14 www.ecoflam-burners.com
EN
420010371901
Start up - Setting data table - Air regulation
The settings above are basic settings.
These adjustment values are normally
suitable for commissioning the burner.
These values have been determined in
our test labs and are useful for the first
switch-on as final setting must be done
using a combustion analyzer.
Favourable combustion values can be
achieved using the following nozzles:
DANFOSS H÷S 80°÷60°
DELAVAN W 60°
STEINEN S 60°
NOZZLE PUMP OUTPUT FIRING HEAD SETTING AIR DAMPER SETTING
gph spry bar kg/h Pos. Pos.
1,50 60° 12 6,2 0 1,5
1,65 60° 12 7,0 1 2,0
1,75 60° 12 7,6 2 2,5
2,00 60° 12 8,3 2,5 3,0
2,25 60° 12 9,3 3 3,2
2,50 60° 12 10,4 3,5 3,5
2,75 60° 12 11,5 4 4
3,00 60° 12 12,5 4,5 4,5
3,50 60° 12 14,9 5 4,5
4,00 60° 11 16,0 5 5
1,75 60° 12 7,6 0 1,5
2,00 60° 12 8,3 1 1,7
2,25 60° 12 9,3 2 2
2,50 60° 12 10,4 2,5 2,8
2,75 60° 12 11,5 3 3
3,00 60° 12 12,5 3,5 3,6
3,50 60° 12 14,9 4,0 4,1
4,00 60° 12 16,7 4,5 4,3
4,50 60° 12 19,1 5 5
2,25 60° 12 9,3 0 1,5
2,50 60° 12 10,4 0,5 2
3,00 60° 12 12,5 1,5 2,2
3,50 60° 12 14,9 2,0 2,5
4,00 60° 12 16,7 2,5 3
4,50 60° 12 19,1 3 3,3
5,00 60° 12 21,8 3,5 3,8
5,50 60° 12 23,6 4 4
6,00 60° 12 25 4,5 4,5
6,50 60° 11 27 5 5
MAX 30 MAX 20 MAX 15
Air damper setting (A).
To act on the screw Ain figure:
• to increase output, turn screwdriver
counterclockwise.
• to reduce output, turn screwdriver
clockwise.
Note: screw B not used.
Firing head setting (B).
To act on the screw in figure:
• turnAllen key till you reach the
requested value (index 0-5).
+
-
+
-
B

6
12
3
45
Y1 10
SUNTEC
SUNTEC
PV
15
www.ecoflam-burners.com
EN
420010371901
Start up - Adjusting burner output - Oil pressure regulation
Burner start
Before starting the burner, draw oil in until
the filter is completely filled.
Then start the burner by switching on the
boiler regulator. Open the bleed screw on
the oil filter to allow the oil line to bleed
fully during the preventilation phase. The
negative pressure must not fall below 0.4
bar. Close the bleed screw when the filter
is completely filled with oil and oil is
flowing out without bubbles.
Burner output adjustment
Use the pressure regulator to adjust the oil
pressure in accordance with the burner
output desired. Monitor the combustion
values continuously as you do so (CO,
CO2, soot test). Adjust the airflow
gradually if necessary.
1 suction intake connection.
2 return connection.
3 pressure connection.
4 oil pressure gauge connection.
5 negative pressure gauge connection.
6 oil pressure regulator.
10 Solenoid valve electrical connection.
Y1 fuel-oil solenoid valve.
SUNTEC
AS V 47 A
21
4
5
6
P
-+ V
P
3
10
Y1
DANFOSS
BFP 21 R3
Optimising combustion values
If the combustion values are not
satisfactory modify the position of the
combustion head. By doing this the burner
ignition conditions and the combustion
values change. Compensate for the
change in airflow if necessary by adjusting
the air flap position.
Note: observe the minimum required
flue gas temperature specified by the
boiler manufacturer and the
requirements demanded of flue gas
ducts for avoiding condensation.
Oil pressure regulation
The oil pressure, and therefore burner
output, is adjusted using oil pressure
regulator 6in the pump.
Turn to
- right: to increase pressure
- left: to reduce pressure
Connect a pressure gauge at point 4(with
R1/8" thread).
Checking negative pressure
The vacuum meter for checking negative
pressure must be connected to point 5,
R1/8". Maximum permissible negative
pressure is 0.4 bar. At higher negative
pressures, the fuel oil gasifies, which
causes scraping noises in the pump and
ultimately leads to pump damage.
Cleaning the pump filter
The filter is located under the pump
cover(SUNTEC) or in appropriate
cartridge(DANFOSS). To be able to clean
the filter, it is necessary to loosen the
screws and remove the cover first
(SUNTEC) or to unscrew the screw
(DANFOSS).
• Check the pump cover seal and replace
the gasket if necessary.
Operating check
Flame monitoring must be checked for
safety as part of initial commissioning and
also after servicing or if the system has
been out of operation for any significant
period of time.
- Starting attempt with flame monitor unlit:
the automatic combustion control unit
must switch to malfunction at the end of
the safety time
- Start with flame monitor lit: the
automatic combustion control unit
must switch to malfunction after 10
seconds of preventilation
- Normal start-up: flame monitor goes out
when burner in operation; the automatic
combustion control unit must switch to
malfunction after the restart and end of
the safety time
!Risk of air blast!
Continuously check CO, CO2and soot emissions when adjusting the output of
the burner. Optimise combustion values in the event of CO formation. CO must
not exceed 50 ppm.

16 www.ecoflam-burners.com
EN
420010371901
Service - Maintenance
Fan assembly
Observe the positioning diagram below
when replacing the motor and blower
wheel. The inside flangeAof the blower
wheel must be fitted at the same level as
the equipment plate B. Insert a straight
edge between the wing of the blower wheel
and set Aand Bto the same height, tighten
the set screw on the blower wheel
(maintenance position 1).
Burner and boiler servicing must only
be carried out by qualified personell.
The system operator is advised to take
out a service contract to guarantee
regular servicing.
Attention
• Disconnect the electrical supply before
carrying out any maintenance or
cleaning work.
• The blast tube and firing head may be
hot.
Checking the exhaust gas temperature
• Check the flue gas temperature at
regular intervals.
• Clean the boiler if the flue gas
temperature is more than 30°C above
the value measured at the time of
commissioning.
• To simplify the check, use a flue gas
temperature indicator.
Burner maintenance positions
• After removing the screws 5 turn the
burner and pull it out of the flange. It is
possible to fix the burner in three positions
for maintenance.
Position 1
Maintenance line air
(cleaning/substitution fan)
Position 2
Burner head maintenance.
Position 3
Maintenance components (filter and light
oil pump).
Maintenance on the burner
Maintenance position 1
• Clean fan and housing and check for
damage.
Maintenance position 2
• Check and clean the combustion head.
• Replace oil nozzle.
• Check ignition electrodes, readjust or
replace as necessary.
• Fit combustion head. Observe
adjustment dimensions.
• Fit burner.
• Start burner, check flue gas data, correct
burner settings if necessary.
Maintenance position 3
• Check oil supply components (tubes,
pumps, oil feed tube) and their
connections for leaks or signs of wear,
replace if necessary.
• Check electrical connections and
connection cables for damage, replace if
necessary.
• Check pump filter and clean if
necessary.
1 2 3
Nozzle and cleaning replacement
Use only the suitable box wrench provided
for this operation to remove the nozzle,
taking care to not damage the electrodes.
Fit the new nozzle by the same care.
Note: Always check the position of
electrodes after having replaced the
nozzle (see illustration). A wrong position
could cause ignition troubles.
–
+
2
3
5

17
www.ecoflam-burners.com
EN
420010371901
Fault diagnosis and repair
In the event of a malfunction, first check
that the prerequisites for correct operation
are fulfilled:
1. is the system connected to the power
supply?
2. is there oil in the tank?
3. are all shut-off valves open?
4. are all control and safety devices,
such as the boiler thermostat, low-water
detector, limit switch, etc.
adjusted correctly?
If the malfunction persists, use the
following table.
It is not permitted to repair any
components relevant to safety. These
components must be replaced by parts
with the same order number.
Only use original spare parts.
NB: after each operation:
• under normal operating conditions
(doors closed, hood fitted, etc.), check
combustion and check the individual
lines for leaks.
• Record the results in the relevant
documents.
E-BCU display interface must be used
to read the faults by service personell.
Service - Troubleshooting
Fault Symbol fault Cause Remedy
No heat request Thermostats defective or
incorrectly adjusted Adjust the thermostats, replace if necessary.
Burner does not start after
thermostat shutdown.
No malfunction indicated
on the automatic
combustion control unit.
Drop in supply voltage or
power failure.
Control unit malfunction
Check the cause of the fall in voltage or the
power failure.
Replace the control unit.
Burner starts at switch-on
for very short period and
then shuts down and the red
LED lights up
The control unit has been
intentionally locked Reset control unit.
Burner starts and then
shuts down after
preventilation
Flaring during pre-ventilation or
pre-ignition
Check ignition sparks/adjust or replace
electrode
Check/replace fuel-oil solenoid valve
Burner starts and then shuts
down after the solenoid
valves have opened
No flame signal at end of
safety time
Check the oil level in the tank.
Top tank up as required.
Open the valves.
Check the oil pressure and the operation of
the pump, coupling, filter, solenoid valve.
Check ignition circuit, electrode adjustment.
Clean/replace electrodes.
Clean/replace flame monitor.
Replace the following items as required:
Ignition electrodes/ignition cables/ignition
transformer/nozzle/pump/solenoid valve/
automatic combustion control unit.
Flame extinguishing
during operation Flame goes out during operating phase

66 www.ecoflam-burners.com 420010371901
EN
IT
FR
ES
RU
ELECTROVALVULA DE GASOLEO ELCTROVANNE MAZOUT OIL SOLENOID VALVE ELETTROVALVOLA GASOLIO
YVg STS STC HLB TV
TERMOSTATO DE SEGURIDAD THERMOSTAT DE SECURITE SAFETY THERMOSTAT TRANSFORMATEUR D'ALLUMAGE IGNITION TRANSFORMER TERMOSTATO CALDERA THERMOSTAT CHAUDIERE TERMOSTATO DI SICUREZZA TERMOSTATO CALDAIA LAMPE DE SECURITE BOILER THERMOSTAT ESPIA DE BLOQUEO TRANSFORMADOR LOCK-OUT LAMP LAMPADA DI BLOCCO TRASFORMATORE
MV Q B
FOTORESISTENCIA INTERRUPTOR GENERAL CON FUSIBLE INTERRUPTEUR GENERAL AVEC FUSIBLE MAIN SWITCH WITH FUSE INTERRUTTORE GENERALE CON FUSIBILE MOTOR VENTILADOR MUTEUR VENTILATEUR MOTOR FAN MOTORE VENTILATORE PHOTORESISTANCE PHOTO-RESISTOR FOTORESISTENZA
TV
BYVg
M
1
MV
HLF LAMPADA DI FUNZIONAMENTO
WORKING LAMP LAMPE DE FONCTIONNEMENT ESPIA DE FUNCIONAMIENTO
CN01 CN02 CN03 CN08 CN07
MODELLO / MODEL
50Hz 220V/240V
50/60 Hz 220V/240V
MAX 15-20-30 MAX 1-4-8-12
ALIMENTAZIONE / POWER SUPPLY
Tensione di alimentazione / Input Voltage
Input Voltage
11 1 11
Z FILTRO ANTIDISTURBO
ANTJAMMING FILTER FILTRE ANTIPARASITES FILTRO DE PTOTECION ANTIDISTURBIO
Z
S3B4 T2 NT1 L1 S3B4 T1T2 N L1
TP
STC
PE
N
L
Q
HLF HLB
TP
STS
THERMOWATT E-BCU OIL
TOT. SHEET
SHEET
DESIGNER
DESCRIPTION
DATE FIST CREATION
CODE
SIGNATURE
R&D DEPARTMENT
CONTROLLER
Ecoam Bruciatori
SERVOMOTOR FLAME SENSOR
S.p.A
ECN FIRST CREATION
BY TERM LAWS WE RESERVED THE PROPERTY OF THIS WIRING DIAGRAM WITH PROHIBITION OF USE AND REPRODUCTION
LEAKAGE CONTROL
CONTROL BOX
DATE ECN MODICATIONMODIFICATION DESCRIPTIONECN MODIFICATION
MAX 1-4-8-12-15-20-30
A.POZZOBON
24-09-2010
1
420110042301
1
A.RIGONI
B
RBA10NP009
THERMOWATT E-BCU OIL
20-04-2011RBA11PM012
F
1
E
D
2 3 4
C
B
A
12 3 4
5 6 7 8
F
E
D
5 6 7
C
B
8
A
Overview - Electric diagrams / Panoramica - Schemi elettrici / Vue d'ensemble - Schémas électrique / Descripción - Esquemas eléctrico / Обзор - Электрические схемы

67
www.ecoflam-burners.com
420010371901
EN
IT
FR
ES
RU
Overview - Spare parts list / Panoramica - Parti di ricambio / Vue d'ensemble - Pièces de rechange / Descripción - Piezas de recambio / Обзор - Запчасти
6 1
7
2 3
30
24
23
21
8
14
29 32 31
410 9
18
17
20
19
MAX 15 - MAX 20 - MAX 30
27
25
26 28
22
34
34
35
12
16 15
11
13
33

TC = Testa corta / Short Head / Tete courte / Cabeza corta / !О#О$!АЯ О'()*АЯ 'О+О*!А TL = Testa lunga / Long Head / Tete longue / Cabeza larga / ,+-((АЯ О'()*АЯ 'О+О*!А
Overview - Spare parts list / Panoramica - Parti di ricambio / Vue d'ensemble - Pièces de rechange / Descripción - Piezas de recambio / Обзор - Запчасти
RU
ES
FR
IT
EN
420010371901
www.ecoflam-burners.com
68
MAX 15 MAX 20 MAX 30
N° DESCRIPTION DESCRIZIONE DESIGNATION DESCRIPCIÓN (А-.)(О*А(-) code code code 1 OIL PUMP POMPA POMPE COMPLETE POMPA )А5О5 DANFOSS BFP21 R3 65322971 65322971 65322971
SUNTEC ASV 47 A 65325111 65325111 65325111
2 COIL BOBINA BOBINE ELECTROVANNE BOBINA $А,У&$А DANFOSS 65323773 65323773 65323773
SUNTEC 65323767 65323767 65323767
3 OIL VALVE VALVOLA VANNE VALVULA $'А8А) DANFOSS 65323751 65323751 65323751
SUNTEC 65323744 65323744 65323744
4 COUPLING GIUNTO JOINT D'ACCOUPLEMEN ACOPLAMIENTO 9У*,А 65322920 65322920 65322920
5 NIPPLE RACCORDO PER FLESSIBILE MAMELONS TUERCA *",")! :'Я !"#$. &'А)!А - - - 6 HOSES TUBO FLESSIBILE FLEXIBLES LATIGUILLOS !"#$"% &'А)! PARIGI NW 4 MG 65323216 65323216 65323216
7 FILTER FILTRO FILTRE FILTRO *"'Ь,- ART.70451-006AV 65325046 65325046 65325046 8 COVER COPERCHIO COUVERCLE TAPA $-<&$А 65325278 65325278 65325278
9 MOTOR MOTORE MOTEUR MOTOR :="!А,>'Ь 130 W 65322873 - -
200 W - 65322876 65322876
10 CAPACITOR CONDENSATORE CONDENSATEUR CONDENSADOR $О):>)5А,О- 3 µF AEG 65321857 - -
6,3 µF SIMEL 65325000 65325000 65325000
6 µF AEG - 65321850 65321850
11 IGNITION TRANSFORMER TRASFORMATORE TRANSFORMATEUR TRANSFORMADOR ,-А)5*О-9А,О- 65323257 65323257 65323257 12 SUPPORT SUPPORTO SOCLE DE COFFRET BASE DEL EQUIPO 9О),А?)АЯ 8'А5,")А 65325251 65325251 65325251 13 CONTROL BOX APPARECCHIATURA COFFRET DE SECURITE EQUIPO CONTROL LLAMA $О),-О'Ь)АЯ А88А-А,У-А Thermowat E-BCU OIL 65325255 65325255 65325255
14 PHOTORESISTOR FOTORESISTENZA CELLULE FOTORRESISTENCIA *О,О->@"5,О- SATRONIC 65320083 65320083 65320083
15 SOCKET WIELAND PRESA WIELAND BORNES REGLETA DE CONEXIÓN $'>99)"$ 65322070 65322070 65322070
16 PLUG WIELAND SPINA WIELAND COUVERCLE DE BORNES CAJA DE PROTECCIÓN $-<&$А $'>99)"$А 65322069 65322069 65322069
17 FAN VENTOLA TURBINE VENTILADOR =>),"'Я,О- 160 x 52 65323819 - -
160 x 62 - 65323820 65323820
18 ORING GUARNIZIONE ORING ORING У8'О,)",>'Ь)АЯ 8-О$'А:$А 65321061 65321061 65321061
19 AIR DAMPER SERRANDA VOLET D'AIR REGISTRO AIRE =О@:У&)АЯ @А5'О)$А 65321223 65321223 65321223
20 COVER AIR INLET CASSETTO BOITE DʼAIR CIERRE EN ASPIRACIÓN =О@:УAО@А#О- 65320126 65320126 65320126
21 CABLES CAVI ACCENSIONE CABLE HT CABLES 8-О=О:А -О@?"!А TC 65325264 65325264 65325264
TL 65325277 65325277 65325277
22 ELECTRODES ELETTRODI ELECTRODE ELECTRODOS Э'>$,-О:< 65320924 65320924 65320924
23 BLAST TUBE BOCCAGLIO GUEULARD TUBO LLAMA 5,А$А) TC 65320376 65320396 65320396
TL 65320377 65320397 65320397
24 FIRING HEAD TESTA DI COMBUSTIONE TETE DE COMBUSTION CABEZA DE COMBUSTIÓN О!)>=АЯ !О'О=$А TC
TL
25 NOZZLE HOLDER SUPPORT CROCIERA SUPPORT PORTE GICLEUR SOPORTE PORTAINYECTOR $->5,О=")А 65320692 65320690 65320690
26 NOZZLE HOLDER PORTA UGELLO PORTE GICLEUR PORTAINYECTOR :>-?А,>'Ь *О-5У)$" 65320707 65320707 65320707
27 DIFFUSER DIFFUSORE DEFLECTEUR DIFUSOR -А55>$А,>'Ь 65320759 65320789 65320790 28 ROD ASTA SUPPORTO TESTA SUPPORT SOPORTE CABEZADE COMBUSTIÓN $->8>?)АЯ ,-У#$А !О'О=$" TC 65320191 65320191 65320191
TL 65320192 65320192 65320192
29 WAISTBAND ROD ASTA SUPPORTO FASCIA TIGE DE SUPPORT POUR CHAPE SOPORTE DELCILINDRODEAJUSTE DELAIRE $->8>?)АЯ ,-У#$А 9А)?>,< TC 65320195 65320195 65320195
TL 65320196 65320196 65320196
30 WAISTBAND FASCIA CHAPE METALLIQUE CILINDRO DE AJUSTE DEL AIRE 9А)?>,А 65320225 65320224 65320224
31 FLANGE FLANGIA BRIDE BRIDA *'А)>C 65320970 65320971 65320971 32 GASKET GUARNIZIONE BRUCIATORE JOINT DE BRULEUR JUNTA 8-О$'А:$А !О->'$" 65321105 65321106 65321106
33 ANTIJAMMING FILTER FILTRO ANTIDISTURBO FILTRE ANTIPARASITES FILTRO ANTITRASTORNO *"'Ь,- 8О:А='>)"Я 8О9>A 34 PIPE GASKET GUARNIZIONE TUBO JOINT DE TUYATERIE JUNTA DE TUBO PIPE GASKET 65321065 65321065 65321065
35 PIPE TUBO TUYATERIE TUBO PIPE 65321504 65321504 65321504
