ECR 4 Kids ELR-17254 User manual

Use the
Hex Tool
Use a Phillips
Screwdriver
Use a Phillips
Screwdriver
C
D
EF
G
H
I
J
Top Panel (1)
Left & Right
Side Panels (1/1)
Parts List
A
B
BEFORE ASSEMBLING, MAKE SURE YOU HAVE ALL THE PARTS
Back Panel (5)Vertical Dividers (4)
Hanger Hook Posts
& Screws(24/24)
Hanger Hooks (20)
Hex Screws (28)
Cam Posts & Cam Locks (8/8)
H1 H2
I1 I2
Middle Shelf (3)
Bottom Shelf (1)
Batch ID Sticker
located on underside
Children climbing on furniture
can lead to death or serious
injury due to tipping secure unit
to wall using appropriate
hardware
10 Section Storage Locker
Model# ELR-17254
Adult Assembly Required.
Two adults recommended.
- Contains small parts, sharp points and edges.
- Do not stand, sit, kneel, climb, lean or pull on unit for support.
- Never leave children unattended.
- Do not place unit near high heat or moisture.
- Adult supervision recommended.
WARNING:
TOOLS INCLUDED
Hex Tool (1) TOOLS NEEDED
Phillips Screwdriver
San Diego, CA 92110 USA
www.ecr4kids.com
A1 A2

1Pre-Install the Hanger Hooks (optional)
Install the Shelves to the Dividers
2
3Install the Top Panel
Slide the Center Back Panels into Place
4
Install two Hanger Hooks (J) to each Side Panel (A) by threading the Hanger Hook Posts and
Screws (I1/I2) together from both sides of the divider.
Install four Hanger Hooks (J) to each Vertical Divider (E) by threading the Hanger Hook
Posts and Screws (I1/I2) together from both sides of the divider.
Align the slit on Vertical Dividers (E) with the slits on Middle Shelves (C) as shown, and
slide together until seated.
Place two Cam Locks (H2) into the recessed holes on each Grooved Divider (E), with the arrow
facing the closest edge.
Install eight Cam Posts (H1) into the threaded plastic inserts on the underside of Top Panel (B)with
a Phillips screwdriver. Reminder: Do not overtighten, as the plastic threads can be stripped.
Insert the Top Panel (B)Cam Posts into the holes on the top edge of the Vertical Dividers (E).
Turn the Cam Locks clockwise with a Phillips screwdriverto lock the Vertical Dividers (E)onto the
posts.
Slide three Back Panels (F) into the grooves on the Vertical Dividers (E) as shown,
until fully seated into the groove on the underside of the Top Panel (B).
Tip: If the Back Panels (F) do not slide in easily, wiggle the panels while pushing into
place.
See Next Page

5Install the Bottom Shelf
Slide the Outer Back Panels into Place
6
7Install the Right Side Panel
Install the Left Side Panel
8
C
a
r
e
f
u
l
l
y
R
o
t
a
t
e
U
p
r
i
g
h
t
Install the Bottom Shelf (D) onto the Vertical Dividers (E) with eight Hex Screws (G) using the
Hex Tool.
Slide the remaining Back Panels (F) into the grooves on the Top Panel (B) and Bottom Shelf (D)
as shown, until fully seated into the groove on the inside of the Vertical Dividers (E).
Tip: If the Back Panels (G) do not slide in easily, wiggle the panels while pushing into place.
Install the Right Side Panel (A2) onto the Top Panel (B), Middle Shelves (C) and
Bottom Shelf (D) with ten Hex Screws (G) using the Hex Tool.
Install the Left Side Panel (A1) onto the Top Panel (B), Middle Shelves (C) and
Bottom Shelf (D) with ten Hex Screws (G) using the Hex Tool.
Two Adults Recommended:
Carefully rotate the unit upright.
See Next Page

1Install the Hanger Hooks
©2016 ECR4KIDS, LP Version: ELR-17254_2016.04.14
Care and Cleaning
Clean wood with a damp cloth or sponge
using warm water and mild soap. Wipe dry.
Do not place near heat, moisture or
vaporizer which may cause wood to warp
and peel.
Check for loose or worn parts periodically
and tighten or replace as necessary.
Record the manufacture date here.
Information is located on the Batch ID
sticker and on the shipping carton.
Save this sheet in an accessible place.
Model Number: ELR-17254
Factory Code: EP
Manufacture Date:
Batch ID Number: ECR2016-1184
(Located on Part #)
We appreciate your purchase of the 10 Section Storage Locker.
ECR4KIDS has made every effort to supply a quality product that with proper
use and care, will provide many years of trouble-free use.
Warranty: Visit our website for product specific warranty information at:
www.ecr4kids.com
If you experience any difficulties with this product, please email us at
[email protected] or call toll-free at (855) ECR-4KIDS
(Monday - Friday, 7:00am - 4:00pm Pacific Standard Time)
Please do not return to place of purchase as ECR4KIDS will
replace defective part(s) and/or product.
To prevent a tip-over tragedy:
Buy and install low-cost anchoring devices that can prevent TVs,
dressers, bookcases and other furniture from tipping. For more
information please visit www.ecr4kids.com/resources
If you did not pre-install the Hanger Hooks in Step 1; Install four Hanger Hooks (J)
to each section of the Vertical Dividers (E) by threading the Hanger Hook Posts and
Screws (I1/I2) together from both sides of the divider.
Install two Hanger Hooks (J) to each Side Panel (E) by threading the Hanger Hook
Posts and Screws (I1/I2) together from both sides of the panel.
