Edco SEC-HD User manual

Page 1
Tool Rental Center
MANUAL
EDCO
Single-Disc
Grinder
50200-HD-12.17 REVISED STARTING SERIAL # 171210255

Page 2
READ AND UNDERSTAND THE OPERATORS INSTRUCTION MANUAL THOROUGHLY
BEFORE ATTEMPTING TO OPERATE THIS EQUIPMENT.
Death or serious injury could occur if this machine is used improperly.
Extreme care must be taken when operating electric
models with water present: Ensure power cord is prop-
erly grounded, is attached to a Ground-Fault-Interrupter
(GFI) outlet, and is undamaged.
•Check all electrical cables - be sure connections are tight and
cable is continuous and in good condition. Be sure cable is
correctly rated for both the operating current and voltage of
this equipment.
•Improper connection of the equipment-grounding conductor can
result in a risk of electric shock. Check with qualied electri-
cian or service person if there is any doubt as to whether the
outlet is properly grounded. Adhere to all local codes and
ordinances.
•NOTE: In the event of a malfunction or breakdown, grounding
provides a path of least resistance for the electric current to
dissipate. The motor is equipped with a grounded plug and
must be connected to an outlet that is properly installed and
properly grounded. DO NOT modify the plug provided on the
motor. If the plug does not t the outlet have a qualied electri-
cian install the proper receptacle.
•Switch motor OFF before disconnecting power.
•Engine exhaust from this product contains
chemicals known to the State of California to
cause cancer, birth defects or other reproduc-
tive harm.
• Gasoline is extremely ammable and poisonous.
It should only be dispensed in well ventilated areas,
and with a cool engine.
•Small gasoline engines produce high concentra-
tions of carbon monoxide (CO) example: a 5 HP 4 cycle
engine operation in an enclosed 100,000 cu. ft. area with
only one change of air per hour is capable of providing
deadly concentrations of CO in less than fteen minutes.
Five changes of air in the same area will produce noxious
fumes in less than 30 minutes. Gasoline or propane pow-
ered equipment should not be used in enclosed or partially
enclosed areas. Symptoms of CO poisoning include, head-
ache, nausea, weakness, dizziness, visual problems and
loss of consciousness. If symptoms occur - get into fresh
air and seek medical attention immediately.
SAFETY
MESSAGES
SAFETY MESSAGES
Indicates an imminent hazard which, if not
avoided, will result in death or serious injury.
Indicates an imminent hazard which, if not
avoided, can result in death or serious injury.
Indicates hazards which, if not avoided, could
result in serious injury and or damage to the
equipment.
•Safety Instructions are proceeded by a graphic alert symbol
of DANGER, WARNING, or CAUTION.
ELECTRICAL POWERED EQUIPMENT
GASOLINE/PROPANE POWERED EQUIPMENT
•Equipment should only be operated by trained personnel in
good physical condition and mental health (not fatigued). The
operator and maintenance personnel must be physically able
to handle the bulk weight and power of this equipment.
•This is a one person tool. Maintain a safe operating distance
to other personnel. It is the operators’ responsibility to keep
other people (workers, pedestrians, bystanders, etc.) away
during operation. Block off the work area in all directions with
roping, safety netting, etc. for a safe distance. Failure to do so
may result in others being injured by ying debris or exposing
them to harmful dust and noise.
•This equipment is intended for commercial use only.
•For the operator’s safety and the safety of others, always keep
all guards in place during operation.
•Never let equipment run unattended.
•Personal Protection Equipment and proper safety attire must
be worn when operating this machinery. The operator must
wear approved safety equipment appropriate for the job such
as hard hat and safety shoes when conditions require. Hear-
ing protection MUST be used (operational noise levels of this
equipment may exceed 85db). Eye protection MUST be worn
at all times.
Keep body parts and loose clothing away from moving
parts. Failure to do so could result in dismemberment
or death.
•Do not modify the machine.
•Stop motor/engine when adjusting or servicing this equipment.
Maintain a safe operating distance from ammable
materials. Sparks from the cutting-action of this machine
can ignite ammable materials or vapors.
GENERAL INSTRUCTIONS
DUST WARNING
Some dust created by power sanding, sawing,
grinding, drilling, and other construction activi-
ties contains chemicals known to cause cancer,
birth defects, or other reproductive harm. Some
examples of these chemicals are:
•Lead from lead-based paints, and
•Crystalline silica from bricks and concrete and other
masonry products.
Your risk of exposure to these chemicals varies depending
on how often you do this type of work. To reduce your risk:
work in a well ventilated area, use a dust control system, such
as an industrial-style vacuum, and wear approved personal
safety equipment, such as a dust/particle respirator designed
to lter out microscopic particles.
•Do not disconnect power by pulling cord. To disconnect, grasp
the plug, not the cord.
•Unplug power cord at the machine when not in use and before
servicing.

Page 3
TOOL RENTAL CENTER MANUAL
SINGLE-DISC GRINDER
Section Page Number
Safety Messages and General Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
How To Order Replacement Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Operational Keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Troubleshooting and Servicing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Important Notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6, 7
Lubricating Flange Bearings and Attaching a Vacuum . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Procedure for Adjusting and replacing Drive Belt . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Operating Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Getting Started . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11-12
Notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
lllustration 1: Main Grouping . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14,15
Illustration 2: Water Valve Grouping . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Illustration 3: Head Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Illustration 4: Motor & Belt Drive Grouping . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18,19
Illustration 5: Leveling System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Switch Wiring Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Motor Wiring Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Maintenance Schedule . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
HOW TO ORDER REPLACEMENT PARTS
 To insure product safety and reliability, always use
genuine EDCO replacement parts when making
repairs to the equipment.
 When calling for parts, specify the MODEL and
SERIAL number of the machine, which can be found
on the NAME PLATE. Keep that information in the
space provided. In addition to this information, give
part number, description, and quantity as listed on
the parts list to your parts representative.
 Please note: Due to improvements and changes
in the equipment, the illustrations shown may be
di󰀨erent than the actual machine.
FILL IN INFORMATION BELOW
Date of Purchase ______________________________
Model # _____________________________________
Serial # ______________________________________
SKU # ______________________________________
TABLE OF CONTENTS

Page 4
SINGLE DISC GRINDER
Operational Keys to good machine care and long life...
1. Before each use, check and insure all hardware, nuts, bolts and ttings are tight
and not worn or damaged. If damaged or missing hardware is noted, it should be
replaced before the machine is put back into service.
2. If using attachments such as a vacuum for dust control, insure lters are clean and
the vacuum is empty before each use and empty often for best vacuum performance.
Check hoses, gaskets, seals and lters for damage. If any damage is found the part
or parts should be replaced. Dirty or damaged lters and leaking gaskets or seals will
cause poor vacuum performance, penetrate and shorten the life of any motor and
cause uncontrollable dust which is hazardous to ones health.
3. Check the maintenance schedule for important information about lubrication
intervals. Remember, machines used in a dusty environment have a more frequent
lubrication requirement than a machine that is not used in a dusty environment.
4. Machines that have electric motors should be checked for proper voltage settings
by checking the name plate on the motor for the di󰀨erent electrical congurations i.e.:
single phase, three phase and the voltage settings available. This is not required on
single voltage motors i.e.: 120 Volt Single Phase. The power cords and/or extension
cords should be checked for proper length and gauge, remember, the longer the cord
a heavier gauge wire is required. Too small a gauge wire causes a voltage drop which
in turn causes motor overheating and damage. Check all wiring for cuts, bare or ex-
posed wire and damaged connectors or plugs. These items can cause fatal shocks
under the right conditions. It is current that kills, not voltage.
5. After each days use, the machine should be cleaned. When cleaning electric
powered machines, cover any openings to prevent contaminants from entering the
motor.
MODEL SEC-HD

Page 5
TROUBLESHOOTING AND SERVICING
AN SEC SINGLE DISC GRINDER
The Grinder and Other System Components:
On any concrete surface preparation equipment
there are numerous components that could be
the root cause of any type of problem. Therefore
take time to analyze any problem that might arise,
a little thought and patience can save many hours
of down time and frustration.
It is simply a mechanical device designed to ef-
ciently remove trowel marks, rain spots, excess
concrete, rough nishes or high spots. Remove
1/32” (1mm) of material per pass.
If the machine is forced into the work surface it
can cause unnecessary vibration and noise. The
expected results will not be attained.
As with any mechanical equipment, an ounce of
prevention is worth a pound of cure. You can pre-
vent most problems and need for repair with routine
preventative maintenance. Much like maintaining
your automobile, many preventative measures are
simple visual checks of oil, lters, lubrication points,
loose hardware and leaks.
Seals around the skirt assembly are provided for
dust control, worn, broken or maladjusted seals
will not provide this control.
Guards are provided for personal as well as ma-
chine safety and protection. They are intended to
be in place at all times during storage, turn around,
operation and only removed for servicing. Foreign
objects could fall into the works of the machine
unnoticed and cause personal injury and damage
when the machine is turned on.
Most parts of the machine cannot be seen from
the outside. For a complete breakdown of the
machine, any single component or troubleshooting
refer to the following pages for detailed informa-
tion.
System Checklist:
Begin with this simple checklist:
1. Is the source power what it should be or is the
voltage too high, too low or nonexistent?
2. Is the drive system loose or worn?
3. Are the insert mounted rmly on the disc?
4. Are any of the insert missing or damaged
and all of the same type.
5. Are the lubrication points lubricated properly?
6. Is all the hardware tight?
7. Are the inserts wearing evenly?
Common Problems:
If you have checked these items and a problem
still exists, you should analyze the nature of the
problem and the possible causes. While we will
not cover all of the possibilities, these are the most
common problems and their probable causes.
Excessive Noise:
Excessive noise is most often caused by loose
components of the machine to include bolts or
any adjustable function that is not tightened after
adjustment is made.
Excessive Vibration:
Vibration can be caused by a loose motor mount,
out of balance grinding disc or missing and worn
inserts. Motor and drive shaft sheaves out of align-
ment.
Leaking Lubricants:
Leaking lubricants can be caused by over heating,
worn or bad bearings and over lubrication.
Loss of Power:
A loss of power can be caused by over tightened
belts, low voltage, defective wiring or pushing the
machine into the work to forcefully and/or adding
to much weight to the machine.
Poor Grinding or Cutting:
Worn or missing inserts. Mixed inserts on the same
disc. Wrong insert for the type of surface you are
working on or the type of material you are trying
to remove. Is the right machine being used for the
job?

Page 6
NOTE:
This is the lifting bail
for this machine.
NOTE:
Motor overload reset
on bottom of box.
IMPORTANT NOTES

Page 7
NOTE:
Adjust dust skirt so
there is 1/8” gap with
work surface before
use.
NOTE:
If overload protection on motor trips make sure this
switch is in the o󰀨 position and power cord is dis-
connected from power source before resetting.
IMPORTANT NOTES

Page 8
PROCEDURE FOR LUBRICATING FLANGE BEARINGS
To grease the ange bearings attach the grease gun to the grease ttings as shown in the above photos
and give only two (2) pumps on the grease gun weekly. If excessive over lubrication is done grease will
leak onto the work surface causing possible damage and wasted cleanup time.
If using a vacuum for dust control attach it to the vacuum port located on the rear of the handle securing
it as shown in photo above.
PROCEDURE FOR ATTACHING A VACUUM
Water
Hook-up
Vacuum
Hook-up

Page 9
PROCEDURE FOR ADJUSTING OR REPLACING DRIVE BELT
To adjust the drive belt loosen four (4) bolts securing
the motor mount to the frame.
Slide the motor mount to the rear of the machine to
increase belt tension.
Tighten the four (4) bolts loosened earlier maintaining
pressure on the motor mount to prevent loosening.
To replace the belt, remove the hood by removing two
(2) bolts, one on each side of the machine.
Loosen the four (4) bolts as in the rst step and slide
the motor mount all the way forward.
Remove the belt from the motor and driven shaft
sheaves as shown in the photo on the left.
Reverse the previous step to install new belt. Slide mo-
tor mount towards the rear of the machine and adjust
belt tension, tighten all four (4) bolts as explained above.
Replace hood and tighten bolts.
NOTE:
While cover is removed check to see if there are any
remnants of grease from servicing on any of the sur-
faces, remove and dispose of properly.

Page 10
OPERATING CONTROLS
PLEASE NOTE:
Controls shown are for the model indicated.
The location of these controls may vary on the di󰀨erent models.
Due to improvements and changes in the equipment,
the illustrations shown may vary from the actual machine.
ELECTRIC MODEL
Lifting Bail
Weight
Dust Skirt
On/O󰀨 Switch
Motor
Vacuum Port
Leveling
Adjustment
Water
Hook Up

Page 11
Getting Started with your New Grinder
BEGIN THE LEVELING PROCESS: BEGIN THE LEVELING PROCESS:
Check level of the oor. Lower machine to surface and match level. Adjust
height by turning leveling handle in the rear.
BEGIN THE LEVELING PROCESS: BEGIN THE LEVELING PROCESS:
When leveling do not continue to turn handle Replace the skirt leaving approximately 1/8”
past the level mark. Continued turning will disengage clearance above the oor.
lower linkage from all thread.

Page 12
Getting Started with your New Grinder
LEVELING:
Lean back slightly on the handle to get the tools
o󰀨 the surface and start the machine. Lower the
machine to the surface and do a short touch pass
on the concrete.
LEVELING: LEVELING:
You are looking for a complete circle. If you see a partial circle repeat the leveling process
until complete circle is achieved.
LEVELING:
The bubble on the machine will not necessarily
be centered once optimum operating position is
a c h i e v e d . I t w i l l a l s o  o a t b a c k a n d f o r t h d u r i n g
grinding.

Page 13
NOTES
_________________________________________________________________________________________________________________
_________________________________________________________________________________________________________________
_________________________________________________________________________________________________________________
_________________________________________________________________________________________________________________
_________________________________________________________________________________________________________________
_________________________________________________________________________________________________________________
_________________________________________________________________________________________________________________
_________________________________________________________________________________________________________________
_________________________________________________________________________________________________________________
_________________________________________________________________________________________________________________
_________________________________________________________________________________________________________________
_________________________________________________________________________________________________________________
_________________________________________________________________________________________________________________
_________________________________________________________________________________________________________________
_________________________________________________________________________________________________________________
_________________________________________________________________________________________________________________
_________________________________________________________________________________________________________________
_________________________________________________________________________________________________________________
_________________________________________________________________________________________________________________
_________________________________________________________________________________________________________________
_________________________________________________________________________________________________________________
_________________________________________________________________________________________________________________
_________________________________________________________________________________________________________________
_________________________________________________________________________________________________________________
_________________________________________________________________________________________________________________
_________________________________________________________________________________________________________________
_________________________________________________________________________________________________________________
This page intentionally left blank.

Page 14
ILLUSTRATION 1: MAIN GROUPING

Page 15
PARTS LISTING - ILLUSTRATION 1: MAIN GROUPING
ITEM # PART # DESCRIPTION QTY.
1 86901 MAIN FRAME, SEC-NG 1
2 86304S HANDLE BAR, SEC 1
3 10029 SCREW, CAP 3/8-24 X 1-3/4 4
4 10025 WASHER, FLAT 3/8 SAE ZINC 8
5 10004 NUT, HEX LOCK 3/8-24 ZINC 4
6 10608 GRIP, HAND 1” MODEL AT 2
7 86419 HOLDER, POWER CORD 1
8 10846 SCREW, CAP STSHW 1/4-20 X 1/2 2
9 10038 WASHER, LOCK 1/4 ZINC 2
10 86347 BRACKET, MULTI-VAC PORT 2-3” 1
11 65021 CAP/PLUG 2” RED PLASTIC, FLANGED 1
12 10846 SCREW, CAP STSHW 1/4-20 X 1/2 2
13 10038 WASHER, LOCK 1/4 ZINC 2
14 77113 HOSE, FLEX 2”ID X 32”L, GRINDERS 1
15 10766 CLAMP, HOSE, SAE #32, ADJ. TO 2-1/2 2
16 86426K RUBBER SKIRT W/ VELCRO LOOP & HOOK
(INCLUDES ITEMS 17 & 18 TOGETHER)
1
17 86426 RUBBER SKIRT W/ VELCRO-LOOP ONLY, 2 X 39-1/8
NOTE: CUT TO 36”
1
18 86427 VELCRO-HOOK ONLY, 1” X 39” (CUT DOWN)
NOTE: THIS PIECE IS PLACED AROUND THE BOTTOM EDGE
OF THE SHROUD.
1
19 86108 SCREW, FLAT HD SKT 3/8-24 X 3/4 4
20 77008 BEARING, BALL 1” 4-HOLE FLANGE, ND 2
21 10003 SCREW, CAP 7/16-20 X 1-1/4 ZINC 8
22 10450 WASHER, LOCK 7/16 ZINC 8
23 10481 NUT, HEX 7/16-20 ZINC 8
24 86903 SPACER, HEAD, 1-5/8”L, SEC-NG 1
25 86393 SHAFT, SEC-HD 1”DIA. X 9-11/16”L 1
26 86433 HEAD ASSY. (INCLUDES ITEMS 24-26) 1
27 10007 PIN, ROLL 3/8 X 2-1/2 1
28 19169 DIAMOND DISC, ECONOMY 10” - 20 SEG. 1
29 10907 SCREW, CAP 3/8-16 X 3/4 2
30 10811 WASHER, LOCK 3/8 ZINC 2
31 10025 WASHER, FLAT 3/8 SAE ZINC 2
32 86345 WEIGHT BLOCK, 30 LB. 1
33 10499 SCREW, CAP 1/2-13 X 3 2
34 10811 WASHER, LOCK 3/8 ZINC 2
35 10025 WASHER, FLAT 3/8 SAE ZINC 2
36 86902 HOOD, SEC-NG 1

Page 16
ITEM # PART # DESCRIPTION QTY.
1 80021 CONN., SWIVEL FEM. 3/4HOSE X 1/2MPT
(INCLUDES HOSE WASHER)
1
2 10711 VALVE, BALL 1/2 FPT 1
3 50075 BARB, 3/8 HOSE X 1/4MPT (BRASS) 1
4 50069 CLAMP, HOSE, SAE #6, ADJ. TO 13/16 2
5 86424 HOSE 3/8”ID X 20”L 1
6 11562 BARB ELBOW 90, 3/8HOSE X 1/8MPT (BRASS) 1
7 10864 NUT 1/8-27 PIPE THREAD (BRASS) 1
ILLUSTRATION 2: WATER VALVE GROUPING

Page 17
ITEM # PART # DESCRIPTION QTY.
1-13 86433 HEAD ASSEMBLY (INCLUDES ITEMS 1 THRU 13) 1
1 86393 SHAFT, SEC-HD 1”DIA. X 9-11/16”L 1
2 10063 PIN, ROLL 3/8 X 2 1
3 77010 HUB, ALUMINUM 6-HOLE (GRINDER) 1
4 10112 RING, RUBBER, 4-1/2”OD X 1/2”THK 2
5 77020 RING, HUB CARRIER, 6-HOLE 1
6 86431 MOUNTING DISC, DIAMOND HEAD, SEC-HD 1
7 10354 SCREW, SKT. HD. CAP 3/8-24 X 1-3/4 3
8 10012 SCREW, SKT. HD. CAP 3/8-24 X 2 3
9 10113 SPACER, STEEL 9/16OD X 3/8ID X 7/32 3
10 10011 SPACER, STEEL 5/8OD X 3/8ID X 3/8T 6
11 10014 NUT, HEX 3/8-24 ZINC (USE RED LOCTITE) 3
12 11725 NUT, HEX JAM 3/8-24 ZINC (USE RED LOCTITE) 3
13 86903 SPACER, 1”ID X 1-1/2”OD X 1-5/8”L 1
ILLUSTRATION 3: HEAD ASSEMBLY

Page 18
ILLUSTRATION 4: MOTOR & BELT DRIVE GROUPING

Page 19
PARTS LISTING - ILLUSTRATION 4: MOTOR & BELT DRIVE GROUPING
ITEM # PART # DESCRIPTION QTY.
116077
16178
16174
16179
MOTOR, 1.5HP-1PH-60HZ-1725RPM-115/230V-13/6.5A
LEESON CAT. NO. 113769.00 WATT-SAVER
REPLACEMENT PARTS:
.....CAPACITOR, START, LEESON 003025.15 (500MFD 125V)
.....CAPACITOR, RUN, LEESON 003014.02 (50MFD 240V)
.....RESET BUTTON, LEESON 300033.02 (CED2705)
1
1
1
1
2 86404 MOUNT, MOTOR 1
3 10806 SCREW, CAP 5/16-18 X 1 4
4 10213 WASHER, FLAT 5/16 SAE ZINC 4
5 10801 WASHER, LOCK 5/16 ZINC 4
6 10054 NUT, HEX 5/16-18 ZINC 4
7 10055 SCREW, CAP 3/8-16 X 1 4
8 10811 WASHER, LOCK 3/8 ZINC 4
9 10025 WASHER, FLAT 3/8 SAE ZINC 4
10 3613 SHEAVE, 3”OD X 1 GR. B X 5/8’ BORE
11 ----- KEY 3/16”SQ. X 1-3/8 (INCLUDED W/ MOTOR) 1
12 10290 BELT B-35 1
13 86009 SHEAVE 9” OD X 1GR.B X 1” BORE 1
14 40317 KEY 1/4SQ X 1-5/8 1
15 77042 BRACKET, LOVATO ROTARY CAM SWITCH 1
16 10846 SCREW, CAP STSHW 1/4-20 X 1/2 2
17 10038 WASHER, LOCK 1/4 ZINC 2
18 11663 SCREW, MACHINE 8-32 X 1/2 RHCD ZINC 4
19 10462 NUT, KEPS LOCK 8-32 ZINC 4
20 77043
77043-2.....
77043-4.....
SWITCH, ROTARY CAM ON/OFF, LOVATO
REPLACEMENT PARTS:
.....SWITCH HANDLE, PADLOCKABLE, LOVATO
.....GASKET RING, OPERATOR, LOVATO
1
1
1
21 77043-1 SWITCH ADAPTER, PG16 TO 1/2”NPT 2
22 40066 STRAIN RELIEF 1/2NPT X .350-.450” 2
23 11690 CLAMP, LOOM, 3/8” 1
24 77045 WIRE HARNESS 12/3 X 42”LOA 1
25 16176 STRAIN RELIEF 3/4NPT X .350-.450” 1
26 10740 CONDUIT LOCK NUT 3/4 NP (LOCATED INSIDE JUNCTION BOX) 1
27 11565 CLAMP, LOOM, 5/8” (SAE SIZE 10) 2
28 86422 CORD W/ PLUG, 25FT. POWER, STRAIGHT STYLE PLUG 1

Page 20
ILLUSTRATION 5: LEVELING SYSTEM GROUPING
ITEM # PART # DESCRIPTION QTY.
186905 KNOB, WHEEL HEIGHT CONTROL 1
214023 KNOB, BALL 1-3/8 W/ 1/2-13THD, 1
310411 SCREW, SKT. HD. CAP 1/2-13 X 4 1
450550 SLEEVE, BRASS 1/2” TAPERED 1
580009 BEARING, BALL 5/8” 2-HOLE 1
655010 SPACER, HANDWHEEL 5/8”ID X3/4”L 1
710046 NUT, HEX 5/8-11 ZINC 1
810412 BOLT, CARRIAGE 1/4-20 X 1 2
910861 NUT, KEPS LOCK 1/4-20 ZINC 2
10 86702 FORK 1
11 10355 SCREW, CAP 1/2-13 X 11 1
ITEM # PART # DESCRIPTION QTY.
12 10312 WASHER, FLAT 1/2 SAE ZINC 2
13 10407 NUT, HEX LOCK 1/2-13 ZINC 1
14 86705 SPACER 2-9/16”L, WHEEL 2
15 79013SH WHEEL, STL.HUB 8 X 2-1/2 X 3/4”B 2
16 10428 COLLAR, LOCKING 3/4”ID 2
17 86904 LINKAGE, FORK, SEC-NG 1
18 10329 SCREW, CAP 1/2-20 X 6 1
19 10205 NUT, HEX LOCK 1/2-20 ZINC 1
20 59117 LEVEL, SCREW ON 1
21 11871 SCREW, MACHINE FHP 8-32 X 1-1/4 2
22 10462 NUT, KEPS LOCK 8-32 ZINC 2
