Operator’s Instruction Manual
TG-10
TURBO GRINDERS
Available in Gasoline, Propane and Electric
TG10-I-0915
E-SPTS-I-0809
EQUIPMENT DEVELOPMENT CO., INC.
EQUIPMENT DEVELOPMENT CO., INC.
100 Thomas Johnson Drive, Frederick, MD 21702-4600 USA
Phone: [phone] • 301-663-1600
Fax: [phone] • 301-663-1607
edcoinc.com • [email protected]

Page 2
TG10-I-0915
800-638-3326 • edcoinc.com • [email protected]
EQUIPMENT DEVELOPMENT CO., INC.
READ AND UNDERSTAND THE OPERATORS INSTRUCTION MANUAL THOROUGHLY
BEFORE ATTEMPTING TO OPERATE THIS EQUIPMENT.
Death or serious injury could occur if this machine is used improperly.
Extreme care must be taken when operating electric
models with water present: Ensure power cord is prop-
erly grounded, is attached to a Ground-Fault-Interrupter
(GFI) outlet, and is undamaged.
•Check all electrical cables - be sure connections are tight and
cable is continuous and in good condition. Be sure cable is
correctly rated for both the operating current and voltage of
this equipment.
•Improper connection of the equipment-grounding conductor can
result in a risk of electric shock. Check with qualified electri-
cian or service person if there is any doubt as to whether the
outlet is properly grounded. Adhere to all local codes and
ordinances.
•NOTE: In the event of a malfunction or breakdown, grounding
provides a path of least resistance for the electric current to
dissipate. The machine is equipped with a grounded plug
and must be connected to an outlet that is properly installed
and properly grounded. DO NOT modify the plug provided on
the motor. If the plug does not fit the outlet have a qualified
electrician install the proper receptacle.
•Switch motor OFF before disconnecting power.
•Engine exhaust from this product contains
chemicals known to the State of California to
cause cancer, birth defects or other reproductive
harm.
•Gasoline is extremely flammable and poisonous. It
should only be dispensed in well ventilated areas,
and with a cool engine.
•Small gasoline engines produce high concentrations of car-
bon monoxide (CO) example: a 5 HP 4 cycle engine opera-
tion in an enclosed 100,000 cu. ft. area with only one change
of air per hour is capable of providing deadly concentrations
of CO in less than fifteen minutes. Five changes of air in the
same area will produce noxious fumes in less than 30 min-
utes. Gasoline or propane powered equipment should not be
used in enclosed or partially enclosed areas. Symptoms of
CO poisoning include, headache, nausea, weakness, dizzi-
ness, visual problems and loss of consciousness. If symp-
toms occur - get into fresh air and seek medical attention
immediately.
SAFETY
MESSAGES
SAFETY MESSAGES
Indicates an imminent hazard which, if not avoid-
ed, will result in death or serious injury.
Indicates an imminent hazard which, if not avoid-
ed, can result in death or serious injury.
Indicates hazards which, if not avoided, could
result in serious injury and or damage to the
equipment.
•Safety Instructions are proceeded by a graphic alert symbol
of DANGER, WARNING, or CAUTION.
ELECTRICAL POWERED EQUIPMENT
GASOLINE/PROPANE POWERED EQUIPMENT
•Equipment should only be operated by trained personnel in
good physical condition and mental health (not fatigued). The
operator and maintenance personnel must be physically able
to handle the bulk weight and power of this equipment.
•This is a one person tool. Maintain a safe operating distance
to other personnel. It is the operators’ responsibility to keep
other people (workers, pedestrians, bystanders, etc.) away
during operation. Block off the work area in all directions with
roping, safety netting, etc. for a safe distance. Failure to do so
may result in others being injured by flying debris or exposing
them to harmful dust and noise.
•This equipment is intended for commercial use only.
•For the operator’s safety and the safety of others, always keep
all guards in place during operation.
•Never let equipment run unattended.
•Personal Protection Equipment and proper safety attire must
be worn when operating this machinery. The operator must
wear approved safety equipment appropriate for the job such
as hard hat and safety shoes when conditions require. Hear-
ing protection MUST be used (operational noise levels of this
equipment may exceed 85db). Eye protection MUST be worn
at all times.
Keep body parts and loose clothing away from moving
parts. Failure to do so could result in dismemberment
or death.
• Do not modify the machine.
•Stopmotor/enginewhenadjustingorservicingthisequipment.
Maintain a safe operating distance from flammable
materials. Sparks from the cutting-action of this machine
can ignite flammable materials or vapors.
GENERAL INSTRUCTIONS
DUST WARNING
Some dust created by power sanding, sawing,
grinding, drilling, and other construction activi-
ties contains chemicals known to cause cancer,
birth defects, or other reproductive harm. Some
examples of these chemicals are:
•Lead from lead-based paints, and
•Crystalline silica from bricks and concrete and other
masonry products.
Your risk of exposure to these chemicals varies depending
on how often you do this type of work. To reduce your risk:
work in a well ventilated area, use a dust control system, such
as an industrial-style vacuum, and wear approved personal
safety equipment, such as a dust/particle respirator designed
to filter out microscopic particles.
•Donotdisconnectpowerbypullingcord.Todisconnect,grasp
the plug, not the cord.
•Unplug power cord at the machine when not in use and before
servicing.

Page 3
TG10-I-0915
E-SPTS-I-0809
800-638-3326 • edcoinc.com • [email protected]
EQUIPMENT DEVELOPMENT CO., INC.
Operator’s Instruction Manual
TG-10 TURBO GRINDERS
Table of Contents
HOW TO ORDER REPAIR PARTS
To insure product safety and reliability, always use genu-
ine EDCO replacement parts when making repairs to the
equipment.
When ordering parts, please specify the MODEL and SERI-
AL NUMBER of the machine as given on the NAMEPLATE.
In addition, give part number, description and quantity as
listed on the parts list.
Please note: Due to improvements and changes in the
equipment the illustrations shown may be different from
the actual machine.
Toll Free: Voice 1-800-638-3326 • Fax [phone]
Figure 1
Safety Information .................................................................................................................................................. 2
Table of Contents and Specifications ..................................................................................................................... 3
Safety Guidelines ................................................................................................................................................... 4
Operating Instructions .........................................................................................................................................5-8
Quick Change Multi-Accessory Disc Accessories .................................................................................................. 9
Maintenance.................................................................................................................................................... 10-11
Maintenance Schedule......................................................................................................................................... 12
SMI Dust and Silica Warning................................................................................................................................ 13
Notes .................................................................................................................................................................... 14
Limited Equipment Warranty ........................................................................................................ Inside Back Page
NOTE: Due to improvements your machine may not appear the same as the pictures in this manual.
W
H
Specifications & Dimensions are for reference
only and subject to change.
Model TG10-5B TG10-11H TG10-13P
Length (L) 41”/104cm 41”/104cm 41”/104cm
Width (W) 24”/61cm 24”/61cm 24”/61cm
Height (H) 38”/97cm 38”/97cm 38”/97cm
Total Weight 175 lbs. 180 lbs. 220 lbs.
Weights include 10” Diamond Disc (20 Segments)
L

Page 4
TG10-I-0915
800-638-3326 • edcoinc.com • [email protected]
EQUIPMENT DEVELOPMENT CO., INC.
Read and understand all operating instructions
before operating this equipment.
Death or serious injury can result if this machine is used improperly.
Eye and ear protection must be worn at all times while the grinder is in use. During normal operation,
sound pressure levels may exceed 85dBA. Use only ANSI approved safety glasses to help prevent
eye injury. Everyday eyeglasses have only impact resistant lenses; they are NOT safety glasses.
Operator must wear appropriate clothing and footwear. Do not wear loose clothing or jewelry that
can get tangled in moving parts. Footwear should provide sure footing and protection.
Materials being removed can be toxic or hazardous. A breathing respirator is required to help protect the oper-
ator from inhaling the airborne material when operating this machine.
• Inspect the work surface for cracks, uneven joints and foreign objects such as nails, screws and pipes. Damage
to the disc and/or equipment may result which can also cause serious injury to the operator. Hazardous areas
should be properly identified and clearly marked.
• The TG-10 is designed to be controlled by a single operator .
• Inspect the discs carefully before installing. Do not use any questionable disc since serious personal injury and/
or damage to property can result.
• Never operate this grinder while under the influence of drugs, alcohol or when taking medications that impair the
senses or reactions, or when excessively tired or under stress.
• Be sure decals on the machine can be clearly read and understood. Replace worn or missing decals immediately,
Safety Guidelines
Safety warnings and guidelines do not by themselves eliminate danger.
They are not given as substitutes for proper accident prevention procedures and good judgement.

Page 5
TG10-I-0915
E-SPTS-I-0809
800-638-3326 • edcoinc.com • [email protected]
EQUIPMENT DEVELOPMENT CO., INC.
Operating Instructions
ExhaustfromthisenginecontainsCarbonMonoxide,aninvisible,odorlessgasthatcankill.
Inaddition,itcontainschemicalsknown,incertainquantities,tocausecancer,birthdefects
or other reproductive harm.
Before Operating:
• Visually inspect machine:
- Verify all guards are in place and fasteners are tight.
- Check engine oil level (gasoline/propane models).
- Inspect power cord for damage and check for proper grounding (electric models).
• Inspect disc assembly:
- Check discs for damage or wear.
- Check mounting hardware.
- Check belt tension after first 4 hours of use with factory new equipment or after installing new belts.
• Inspect the work area:
Inspect work area carefully before starting to grind. EDCO will not be held responsible for damage to the
discs caused by striking protruding slab inserts, nails, screws, pipe extensions, machinery bases, or other
objects that transmit sudden shocks.
• If dry grinding:
- Hook up heavy-duty vacuum.
- NOTE:
Donotusedryvacuumwhenwetgrinding.
• If wet grinding:
- Attach hose to water supply.
Important Reminder!
A water mist system or an industrial vacuum must be used while operating this equipment and the operator
must wear a respirator. Failure to comply could lead to serious illness and possible death.
Safety warnings and guidelines do not by themselves eliminate danger.
They are not given as substitutes for proper accident prevention and good judgement.
Figure 2

Page 6
TG10-I-0915
800-638-3326 • edcoinc.com • [email protected]
EQUIPMENT DEVELOPMENT CO., INC.
Gasoline Models: (11 HP Honda Engine)
To Start the Engine:
• Tilt the machine back slightly to allow the disc to clear the slab surface.
• Start the engine according to the directions in the engine manufacturer’s Owner’s Manual.
NOTE:If during operation refueling becomes necessary, allow the engine to cool down. NEVER refuel a hot engine.
To Stop the Gasoline Model:
• Tilt the machine back slightly to allow the disc to clear the slab surface.
• Turn the engine off.
To STOP engine - Press Emergency Stop Switch to OFF position
Press to ON position when re-starting Engine (Figure 3)
Propane Models: (13 HP Honda Engine with 110V Key Start)
Propane is extremely flammable. VAPOR ONLY
To Start the Engine:
• Ensure that tank is positioned properly (arrow up).
• Turn on main valve on tank & Emergency Stop switch on handle.
• If you detect a gas odor immediately shut off engine and consult your operator’s manual.
• Turn key to START
• Open throttle completely until engine runs smooth.
• Adjust throttle back to idle and sit machine back on surface.
• Increase speed to operating position & begin grinding.
To Stop the Propane Model:
NOTE: If engine stops abruptly (uncontrolled stop) or using E-STOP wait several minutes for propane
gas to clear the fuel system and carburator before trying to re-start.
• Tilt machine back slightly to allow the disc to clear the slab surface.
• If stopping for the day close valve and allow machine to purge propane from system.
• Turn key and emergency switch off.
• Otherwise just turn key off.
Electric Models: (5 HP Baldor. Available in 1 Phase or 3 Phase)
Electric units must be connected to a properly grounded electrical system using an approved electrical cable.
To Start the Motor:
• Tilt the machine back slightly, just enough for the disc to clear the slab surface.
• On 5 HP, single phase turn to the ON position. On the 5 HP, three phase, press the ON button.
• Be sure to check motor for correct rotation.
• Gently set the machine back down until the disc touches the slab surface and begin moving the machine.
NOTE: If the machine stops suddenly return the rotary can switch or starter box to the off position
before pressing the manual reset on the motor.
Figure 3
S
tart
)

Page 7
TG10-I-0915
E-SPTS-I-0809
800-638-3326 • edcoinc.com • [email protected]
EQUIPMENT DEVELOPMENT CO., INC.
To Stop the Electric Model:
• Tilt the machine to allow the disc to clear the slab surface.
• Turn rotary switch to the OFF position or press OFF button on the starter box.
Wet Grinding:
• In the wet grinding stage - water is fed from a standard garden hose into a
ball valve cut off, then into a nozzle that sprays over the disc assembly. (Figure 4)
Use the ball valve to regulate the flow of water to the disc.
Only use enough water flow to reduce dust. Excess water flow will
create clean up problems and could cause a hazardous walking area.
Always use dust control when using this product, vacuum or water mist.
Dry Grinding:
Dry Grinding creates a large volume of airborne dust. For health reasons, the operator should
wear an applicable respirator. The dust may contain chemicals known to cause serious
illnesses, including Silicosis - a fatal disease of the lungs. Check the chemical properties of the
material to be removed and follow all EPA/OSHA regulations.
Controlling the Grind:
• Grinding discs are extremely aggressive. It is important to KEEP THE GRINDER MOVING IN A SIDE-TO-SIDE
MOTION, do not let the grinder stay in one spot, even for a few seconds, or the surface will be damaged. When
grinding is completed, tilt the machine back and shut off the power.
• To achieve a smooth “polished” surface, complete the grinding operation with an EDCO dual disc unit using
grinding stones or dyma-serts.
• To remove a light coating, move the grinder quickly. For heavier removal, move the grinder more slowly.
• Keep the grinding disc flat - do not attempt to grind against vertical surfaces. Be sure the machine is in the correct
operating position. (See Figure 5)
Figure 4
Figure 5 Figure 6

Page 8
TG10-I-0915
800-638-3326 • edcoinc.com • [email protected]
EQUIPMENT DEVELOPMENT CO., INC.
Comments in paragraph below are in reference to this level adjustment control (Figure 6).
NOTE: Ensure when leveling the machine as explained below that it (the machine) is sitting on a FLAT LEVEL
surface otherwise adjustments may not be correct for the surface being worked on.
If rear of grinding disc is higher (not touching the work surface) than the front of the disc (touching the work
surface) turn this control (Figure 7) counter clockwise until disc sits level (flat) on the work surface.
If front of grinding disc is higher (not touching the work surface) than the rear of the disc (touching the work
surface) turn this control (Figure 7) clockwise until disc sits level (flat) on the work surface.
Do a light touch pass after each adjustment looking for a complete circle from the disc.
Discs:
• Inspect the disc (Figure 7) periodically to determine it’s wear characteristics, if signs of uneven wear appear the
cause should be determined and corrected. If repairs are needed contact EDCO or your EDCO representative.
• Rigid Head can be used on uneven expansion joints, high spots, joint curls and bridge decks, removing coatings
and grinding rough concrete surfaces. Use with a vacuum or water for dust control but not the same time. (Figure 8)
• Flex Head can be used preparing a smooth, flat floor to receive a new coating, removing coatings, grind rough
concrete surfaces. Can be used with a vacuum or water for dust control but not the same time. (Figure 9)
• This unit comes standard with a 10” Diamond Disc. Optional 6 pocket Mulit-Accessory disc can be supplied. This
allows for the use of low profile grinding tools.
NOTE: The low profile tooling can be used in either a 6 tool set up or a 3 tool set up. If only using 3 tools
make sure they are evenly spaced on the disc.
• Each new machine is shipped with a RIGID HEAD (FLEX HEAD OPTIONAL) 10”/255 mm factory balanced disk.
Itisimportanttomaintainthecouplingtowhichthediskisattached.Aworncoupling,damagedbearingsora
bentshaftwillcausethegrindingdiscstowearunevenly.(Figure 8 rigid head assembly & 9 flex head assembly.)
ItisimportanttonoteFLEXHEADforsmoothflat surfaces, RIGID HEAD for buckled, bumpy or rough surfaces.
Figure 7 Figure 8 Figure 9
Disc shown is for reference only. Standard RIGID HEAD Optional FLEX HEAD

Page 9
TG10-I-0915
E-SPTS-I-0809
800-638-3326 • edcoinc.com • [email protected]
EQUIPMENT DEVELOPMENT CO., INC.
FOR USE WITH QUICK-CHANGE MULTI-ACCESSORY DISC
DOUBLE DIAMOND DOTS: General Purpose Grind -
Removes general purpose epoxy, mastics, thinsets,
water-proofing coatings and more.
SINGLE DIAMOND DOTS: Aggressive Grind -
Grinds and removes thick epoxies, weather-proofing
membrane and other coatings.
PCD ACCESSORY: Extremely Aggressive
Removal - Digs through industrial strength
coverings, water-proofing membranes,
thick epoxies and much more -
Leaves a textured concrete surface.
EDCO ARROW: Hard glue
removal, fast coating removal,
create smooth surfaces and more
PEAKS: General Purpose Grind -
Smoothes surfaces with fewer scratchs - Ideal for
concrete preparation and polishing. Removes thinsets,
concrete coatings and more

Page 10
TG10-I-0915
800-638-3326 • edcoinc.com • [email protected]
EQUIPMENT DEVELOPMENT CO., INC.
Maintenance
Follow the engine manufacturer’s guidelines for regular maintenance.
Disconnect spark plug lead (Figure 10) before performing any maintenance on this machine! Or
on the electric model, unplug the electric cord at the machine (instead of at the wall) to assure
the machine will remain un-plugged while you are working on it.
Inspect Every 8 Hours:
• Inspect the disc mounting screws. (Figure 11) The constant vibration and heat generated, especially when
grinding dry, could cause the screws to loosen and the disc to become off balance.
After every use:
• Inspect for lash in head (Does head move up/down) ? (Figure 12). Verify that jam nuts, items 8 on page 10 in
PartsBreakdownaretightandthereisn’tanyplay.Allowingthesenutstoremainloosecandamagetheheadassembly.
• If movement is noticed, STOP. Damage to head assembly may occur. In order to tighten these nuts the sheave under
thehoodmustberemoved.Bottomnutshouldbetightenedandthenbackedoffuntilheadturnsfreely.Thentopnut
shouldbetighteneddownandjammedusingtwowrenchesturninginoppositedirections.Aftertighteningmakesure
headstillturnsfreely.
Lubricate Weekly:
• Bearings (Figure 13) must be lubricated weekly with Lubriplate 930-AA High Temp Grease or equivalent.
• Access fitting through opening on hood.
Figure 10
Figure 12
Figure 11
Figure 13
Disc Mounting
Screws

Page 11
TG10-I-0915
E-SPTS-I-0809
800-638-3326 • edcoinc.com • [email protected]
EQUIPMENT DEVELOPMENT CO., INC.
Maintenance
Belts:
To remove/replace belts:
• Remove belt cover to expose belts. (Figure 14)
• Loosen engine/motor mounting bolts (Figure 15) on both sides of the TG-10 and slide engine forward to allow
belts to slide off.
• Replace worn belts with a complete set of new belts - even if only one belt is showing wear.
• Slide engine back in place until belts are tight and retighten engine mounting bolts.
• Reinstall belt cover and tighten hardware.
• After four hours of use, retighten belts.
Engine Air Filter:
Inspect the air filters (Figure 16) for excess dust, dirt or damage before the engine is operated. More often if operating
in a dusty environment.
Operating the engine with a damaged or dirty air filter, or without an air filter, will allow dirt to enter the engine causing
rapid engine wear which would not be covered under the engine manufacturer’s warranty.
Follow the engine manufacturer’s procedures for keeping the filters in good condition.
Figure 14
Figure 16Figure 15

Page 12
TG10-I-0915
800-638-3326 • edcoinc.com • [email protected]
EQUIPMENT DEVELOPMENT CO., INC.
Maintenance Schedule
Read and follow the
engine manufacturer’s
maintenance schedule.
Repairs are to be done by
authorized EDCO Dealers only.
* When applicable.
Before Operation
After First 4 Hours
Every 8 Hours
Weekly
As Necessary
Adjust Wheel
Height
X
X
X
X
X
X
X
Inspect Entire
Machine
* Check Oil & Fuel
Levels
* Inspect Propane
Connections
Inspect Disc
Inspect Belt Tension
Lubricate Shaft Bear-
ings
Inspect/Tighten
Disc Mounting Screws
* Inspect Vacuum
(empty bins, etc.)
XX
X
X
* Check Air Filter
(Clean if Necessary) X
Inspect/tighten Jam
nuts on head assy. X

Page 13
TG10-I-0915
E-SPTS-I-0809
800-638-3326 • edcoinc.com • [email protected]
EQUIPMENT DEVELOPMENT CO., INC.
Grinding/cutting/drillingofmasonry,concrete,metalandothermaterialscangeneratedust,mistsandfumescontainingchem-
icals known to cause serious or fatal injury or illness, such as respiratory disease, cancer, birth defects or other reproductive
harm. If you are unfamiliar with the risks associated with the particular process and/or material being cut or the composition
of the tool being used, review the material safety data sheets and/or consult your employer, the manufacturers/suppliers,
governmental agencies such as OSHA and NIOSH and other sources on hazardous materials. California and some other
authorities, for instance, have published lists of substances known to cause cancer, reproductive toxicity, or other harmful
effects.
Control dust, mist and fumes at the source where possible. In this regard use good work practices and follow the recom-
mendations of the manufacturers/suppliers, OSHA/NIOSH, and occupational and trade associations. Water should be used
for dust suppression when wet grinding/cutting/drilling is feasible. When the hazards from inhalation of dust, mists and
fumes cannot be eliminated, the operator and any bystanders should always wear a respirator approved by NIOSH/MSHA
for the material being used.
Grinding/cutting/drilling of masonry, concrete and other materials with silica in their composition may give off dust or mists
containing crystalline silica. Silica is a basic component of sand, quartz, brick clay, granite and numerous other minerals and
rocks. Repeated and/or substantial inhalation of airborne crystalline silica can cause serious or fatal respiratory diseases,
including silicosis. In addition, California and some other authorities have listed respirable crystalline silica as a substance
known to cause cancer. When grinding/cutting/drilling such materials, always follow the respiratory precautions mentioned
above.
SMI Dust and Silica Warning

Page 14
TG10-I-0915
800-638-3326 • edcoinc.com • [email protected]
EQUIPMENT DEVELOPMENT CO., INC.
NOTES
_________________________________________________________________________________________________________________
_________________________________________________________________________________________________________________
_________________________________________________________________________________________________________________
_________________________________________________________________________________________________________________
_________________________________________________________________________________________________________________
_________________________________________________________________________________________________________________
_________________________________________________________________________________________________________________
_________________________________________________________________________________________________________________
_________________________________________________________________________________________________________________
_________________________________________________________________________________________________________________
_________________________________________________________________________________________________________________
_________________________________________________________________________________________________________________
_________________________________________________________________________________________________________________
_________________________________________________________________________________________________________________
_________________________________________________________________________________________________________________
_________________________________________________________________________________________________________________
_________________________________________________________________________________________________________________
_________________________________________________________________________________________________________________
_________________________________________________________________________________________________________________
_________________________________________________________________________________________________________________
_________________________________________________________________________________________________________________
_________________________________________________________________________________________________________________
_________________________________________________________________________________________________________________
_________________________________________________________________________________________________________________
_________________________________________________________________________________________________________________
_________________________________________________________________________________________________________________
_________________________________________________________________________________________________________________
This page intentionally left blank.

Page 15
TG10-I-0915
E-SPTS-I-0809
800-638-3326 • edcoinc.com • [email protected]
EQUIPMENT DEVELOPMENT CO., INC.
LIMITED EQUIPMENT WARRANTY OF SALE – TERMS & CONDITIONS
Equipment Development Company, Inc. herein referred to as EDCO (Seller) warrants that
each new unit manufactured by EDCO to be free from defects in material and workmanship
in normal use and service for a period of (1) one year (except for the cutter drum assembly
on all model concrete/asphalt planes, in which case the warranty period shall be 90 days)
from date of shipment to the original retail or equipment rental center owner.
Accessories or equipment furnished and installed on the product by EDCO but manufactured by
others, including, but not limited to engines, motors,electrical components, transmissions etc., shall
carry the accessory manufacturers own warranty.
EDCO will, at its option, repair or replace, at the EDCO factory or at a point designated by
EDCO, any part which shall appear to the satisfaction of EDCO inspection to have been
defective in material or workmanship.
EDCO reserves the right to modify, alter and improve any part or parts
without incurring any obligation to replace any part or parts previously sold without such
modified, altered or improved part or parts.
This warranty is in lieu of and excludes all other warranties, expressed, implied, statutory,
or otherwise created under applicable law including, but not limited to the warranty of mer-
chantability and the warranty of fitness for a particular purpose in no event shall seller or
the manufacturer of the product be liable for special, incidental, or consequential damages,
including loss of profits, whether or not caused by or resulting from the negligence of seller
and/or the manufacturer of the product unless specifically provided herein. In addition, this
warranty shall not apply to any products or portions there of which have been subjected to
abuse, misuse, improper installation, maintenance, or operation, electrical failure or abnormal
conditions and to products which have been tampered with, altered, modified, repaired,
reworked by anyone not approved by seller or used in any manner inconsistent with the
provisions of the above or any instructions or specifications provided with or for the product
FORCE MAJEURE
Seller’s obligation hereunder are subject to, and Seller shall not be held responsible for, any
delay or failure to make delivery of all or any part of the Product due to labor difficulties,
fires, casualties, accidents, acts of the elements, acts of God, transportation difficulties,
delays by a common carrier, inability to obtain Product, materials or components or qualified
labor sufficient to timely perform part of or all of the obligations contained in these terms
and conditions, governmental regulations or actions, strikes, damage to or destruction in
whole or part of manufacturing plant, riots, terrorist attacks or incidents, civil commotions,
warlike conditions, flood , tidal waves, typhoon, hurricane, earthquake, lightning, explosion
or any other causes, contingencies or circumstances within or without the United States not
subject to the Seller’s control which prevent or hinder the manufacture or delivery of the
Products or make the fulfillment of these terms and conditions impracticable. In the event
of the occurrence of any of the foregoing, at the option of Seller, Seller shall be excused
from the performance under these Terms and Conditions, or the performance of the Seller
shall be correspondingly extended.
This document sets forth the terms and conditions pursuant to which the purchaser (“Pur-
chaser”) will purchase and Equipment Development Co.Inc. (“Seller”)will sell the products,
accessories, attachments (collectively the Products “) ordered by the Purchaser. These terms
and conditions shall govern and apply to the sale of Seller’s Products to Purchaser, regardless
of any terms and conditions appearing on any purchase order or other forms submitted by
Purchaser to Seller, or the inconsistency of any terms therein and herein.
1. PRICE
All prices set forth on any purchase order or other document are F.O.B. Sellers facility or distribution
point, as may be determined by Seller (F.O.B.Point). All prices are exclusive of any and all taxes,
including, but not limited to, excise, sales, use, property or transportation taxes related to the sale or
use of the Products, now or hereafter imposed, together with all penalties and expenses. Purchaser
shall be responsible for collecting and/or paying any and all such taxes, whether or not they are
stated in any invoice for the Products. Unless otherwise specified herein, all prices are exclusive
of inland transportation, freight, insurance and other costs and expenses relating to the shipment
of the Products from the F.O.B. point to Purchaser’s facility. Any prepayment by Seller of freight
insurance and other costs shall be for the account of Purchaser and shall be repaid to Seller.
2. PAYMENT TERMS
Payment terms are as follows. 2% 10 days (to approved and qualified accounts). Net 30 days.
This is a cash discount for invoices paid within 10 days after the invoice date, regardless of
date of receipt of shipment. This is not a trade discount and will not be granted to accounts
that do not adhere to stated terms.
*All past due accounts are subject to a late payment fee of 1.5% per month or a maximum
allowed by law if different, along with the expenses incidental to collection including reason-
able attorney’s fees and costs.
*Seller reserves the right to hold shipments against past due accounts.
*Seller reserves the right to alter payment terms.
3. FREIGHT TERMS
All shipments will be made F.O.B. shipping point as designated in these Terms and Con-
ditions, and title shall pass at the F.O.B. point. Delivery to the initial common carrier shall
constitute delivery to the Purchaser. Any claims for loss or damage during shipment are
to be filed with carrier by the Purchaser. Seller will not assume responsibility for the per-
formance of the carrier.
Back orders will be shipped in the most practical fashion with charges consistent with our
freight policy established with the original order. UPS, FED EX, MAIL or shipments by other
couriers are subject to the same terms and conditions as outlined in paragraph #3”Freight
Terms”.
4. DELIVERY, DAMAGES, SHORTAGES
Seller shall use reasonable efforts to attempt to cause the Products to be delivered as provided
for in these Terms & Conditions. Delivery to the initial common carrier shall constitute the delivery
to the Purchaser. Sellers responsibility, in so far as transportation risks are concerned ceases
upon the delivery of the Products in good condition to such carrier at the F.O.B. point and all the
Products shall be shipped at the Purchaser’s risk. Seller shall not be responsible or liable for any
loss of income and/or profits, or incidental, special, consequential damages resulting from Seller’s
delayed performance in shipment and delivery.
5. RETURN OF DEFECTIVE PRODUCTS
Defective or failed material shall be held at the Purchaser’s premises until authorization has
been granted by Seller to return or dispose of Products. Products that are to be returned
for final inspection must be returned Freight Prepaid in the most economical way. Credit
will be issued for material found to be defective upon Seller’s inspection based on prices
at time of purchase.
6. PRODUCTS ORDERED IN ERROR
Products may be returned, provided that claim is made and Seller is notified within 7 days
of receipt of Products, and the Products are in original buyer’s possession not more than
30 days prior to return, subject to Seller’s approval. If Products are accepted for return, they
must be Freight Prepaid and buyer will be charged a minimum of 15% restocking charge,
plus a charge back for outbound freight charges if the original order was shipped prepaid.
Returns are not accepted for any Products that are specifically manufactured to meet the
buyer’s requirement of either specifications or quantity.
AGREEMENTS
These Terms and Conditions constitute the entire agreement between Seller and Purchaser as it
relates to terms and conditions of sale, and supersedes any and all prior oral or written agreements,
correspondence, quotations or understandings heretofore in force between the parties relating to
the subject matter hereof. There are no agreements between Seller and Purchaser with respect
to the Product herein except those specifically set forth in and made part of these terms and
conditions. Any additional terms, conditions and/or prices are rejected by Seller.
These terms and conditions may be modified, cancelled or rescinded only by a written
agreement of both parties executed by their duly authorized agents.
USE ONLY GENUINE EDCO PARTS & ACCESSORIES
For your own safety, the safety of others and the life of your machine.

E-SPTS-I-0809
800-638-3326 • edcoinc.com • [email protected]
EQUIPMENT DEVELOPMENT CO., INC.
SURFACE PREPARATION, RESTORATION, PROFESSIONAL
SAWING EQUIPMENT & HAND HELD TOOLS
100 THOMAS JOHNSON DRIVE, FREDERICK, MD 21702
PHONE: [phone] OR 301-663-1600
Fax: [phone] or 301-663-1607
Email: [email protected]
Website: edcoinc.com
Patents Pending & Issued
Created 5 2014
Printed in USA ©2015
