Edco Tg-10 Assembly instructions

Printed in USA

EQUIPMENT DEVELOPMENT COMPANY, INC.

100 Thomas Johnson Drive, Frederick, MD 21702-4600 USA

Phone: 800-638-3326 or 301-663-1600 • Fax: 800-447-3326 or 301-663-1607

Website: www.edcoinc.com • E-mail: [email protected]

Operator’s Instruction Manual

TG-10

TURBO GRINDERS

Available in Gasoline, Propane and Electric

E-TG10-I-0119

E-SPTS-I-0809

EQUIPMENT DEVELOPMENT CO., INC.

READ AND UNDERSTAND THE OPERATOR’S SAFETY MANUAL THOROUGHLY

BEFORE ATTEMPTING TO OPERATE THIS EQUIPMENT.

Death or serious injury could occur if this machine is used improperly.

Machine specic Operator’s Instruction Manuals are o󰀨ered at edcoinc.com/customer-resources/manuals-parts-lists/

READ AND UNDERSTAND THE ENGINE MANUFACTURERS INSTRUCTIONS AND OPERATORS MANUAL BEFORE OPERATION.

Page 2

E-TG10-I-0119

800-638-3326 • edcoinc.com • [email protected]

EQUIPMENT DEVELOPMENT CO., INC.

•Engine exhaust from this product contains chemicals

known to the State of California to cause cancer, birth

defects or other reproductive harm.

• Tilting a gasoline powered machine tted with an

EPA approved vented charcoal lter gas cap, beyond

20° can cause fuel leakage. If a leak occurs, do not

start or run the engine until the leak is xed. Eliminate all other ignition

sources in the immediate area (no smoking, ares, sparks or ames).

Use approved gasoline absorbing material to contain the fuel leakage.

Then use clean, non-sparking tools to collect absorbed materials then

dispose of these contaminants properly.

• Gasoline is extremely ammable and poisonous. It should

only be dispensed in well ventilated areas, and with a cool

engine.

• Small gasoline engines produce high concentrations of

carbon monoxide (CO) example: a 5 HP 4 cycle engine operation in

an enclosed 100,000 cu. ft. area with only one change of air per hour

is capable of providing deadly concentrations of CO in less than fteen

minutes. Five changes of air in the same area will produce noxious

fumes in less than 30 minutes. Gasoline powered equipment should

not be used in enclosed or partially enclosed areas. Symptoms of CO

poisoning include, head-ache, nausea, weakness, dizziness, visual

problems and loss of consciousness. If symptoms occur - get into

fresh air and seek medical attention immediately.

• Never refuel a hot engine or an engine while it is running.

• Engines are shipped from factory without fuel/oil.

SAFETY MESSAGES

Indicates an imminent hazard which, if not avoided,

will result in death or serious injury.

Indicates an imminent hazard which, if not avoided,

can result in death or serious injury.

Indicates hazards which, if not avoided, could result in

serious injury and or damage to the equipment.

• Safety Instructions are proceeded by a graphic alert symbol of DANGER,

WARNING, or CAUTION.

GASOLINE / PROPANE POWERED EQUIPMENT

• Do not disconnect power by pulling cord. To disconnect, grasp the

plug, not the cord.

• Unplug power cord at the machine when not in use and before servic-

ing.

• Switch motor OFF before disconnecting power.

• Never use frayed, damaged, taped or under rated extension cords.

Electrical shock could result in death or serious injury to the operator

and damage to the equipment.

• Assure you are using the proper extension cord length.

• Equipment should only be operated by trained personnel in good

physical condition and mental health (not fatigued). The operator and

maintenance personnel must be physically able to handle the bulk

weight and power of this equipment.

• This is a one person tool. Maintain a safe operating distance to other

personnel. It is the operators’ responsibility to keep other people (work-

ers, pedestrians, bystanders, etc.) away during operation. Block o󰀨

the work area in all directions with roping, safety netting, etc.

Failure to do so may result in others being injured by ying debris or

exposing them to harmful dust and noise.

• This equipment is intended for commercial use only.

• For the operator’s safety and the safety of others, always keep all

guards in place during operation.

• Never let equipment run unattended.

• Personal Protection Equipment and proper safety attire must be worn

when operating this machinery. The operator must wear approved

safety equipment appropriate for the job such as hard hat and safety

shoes when conditions require. Hearing protection MUST be used

when operational noise levels of this equipment may exceed 85db.

Eye protection MUST be worn at all times.

GENERAL INSTRUCTIONS

Keep body parts, loose clothing and accessories away from

moving parts. Failure to do so could result in dismemberment

or death.

• Do not modify the machine.

• Stop motor/engine when adjusting or servicing this equipment. Maintain

a safe operating distance from ammable materials. Sparks

from the cutting-action of this machine can ignite ammable

materials or vapors.

• Propane is extremely ammable and is heavier than air

and tends to settle in low areas where a spark or ame could

ignite gas. DO NOT start or operate this propane engine in

a poorly ventilated area where leaking propane gas could accumulate

and endanger safety of persons in area. If headache develops, shut o󰀨

machine. Have it checked for carbon monoxide emissions by a qualied

technician before using it again. To ensure personal safety, installation

and repair of propane fuel supply systems must be performed only by

qualied technicians. Carbon monoxide emissions from this machine are

greatly increased due to a dirty combustion air cleaner.

Extreme care must be taken when operating electric models

with water present: Ensure power cord is properly grounded,

is attached to a Ground-Fault-Interrupter (GFI) outlet, and is

undamaged.

• Check all electrical cables - be sure connections are tight and cable

is continuous and in good condition. Be sure cable is correctly rated

for both the operating current and voltage of this equipment.

• Improper connection of the equipment grounding conductor can

result in a risk of electric shock. Check with qualied electrician or

service person if there is any doubt as to whether the outlet is properly

grounded. Adhere to all local codes and ordinances.

• NOTE: In the event of a malfunction or breakdown, grounding provides

a path of least resistance for the electric current to dissipate. The motor

is equipped with a grounded plug and must be connected to an outlet

that is properly installed and properly grounded. DO NOT modify the

plug provided on the motor. If the plug does not t the outlet have a

qualied electrician install the proper receptacle.

ELECTRICAL POWERED EQUIPMENT

DUST WARNING

Some dust created by power sanding, sawing, grinding,

drilling, and other construction activities contains chemi-

cals known to cause cancer, birth defects, or other

reproductive harm. Materials being removed can be toxic or hazardous.

A breathing respirator is required to help protect the operator.

Some examples of these chemicals are:

• Lead from lead-based paints.

• Crystalline silica from bricks, concrete and other

masonry products.Your risk of exposure to these chemi cals varies de-

pending on how often you do this type of work. To reduce your risk: work

in a well ventilated area, use a dust control system, such as an industrial-

style vacuum, and wear approved personal safety equipment, such as a

dust/particle respirator designed to lter out microscopic particles.

• See more on the importance of dust prevention and silica warnings at:

osha.gov/silica

• More concrete and silica dust supression training and educational ma-

terials available at edcoinc.com/silica-standards or scan the QR code on

page 5.

• Written exposure plans are provided at http://www.edcoinc.com/written-

exposure-control-plans/

ELECTRICAL POWERED EQUIPMENT CONTINUED

SAFETY INFORMATION

E-TG10-I-0119

E-SPTS-I-0809

800-638-3326 • edcoinc.com • [email protected]

Page 3

EQUIPMENT DEVELOPMENT CO., INC.

Operator’s Instruction Manual

TG-10 TURBO GRINDERS

Table of Contents

HOW TO ORDER REPAIR PARTS

To insure product safety and reliability, always use genu-

ine EDCO replacement parts when making repairs to the

equipment.

When ordering parts, please specify the MODEL and SERI-

AL NUMBER of the machine as given on the NAMEPLATE.

In addition, give part number, description and quantity as

listed on the parts list.

Please note: Due to improvements and changes in the

equipment the illustrations shown may be di󰀨erent from

the actual machine.

Toll Free: Voice 1-800-638-3326 • Fax 1-800-447-3326

Figure 1

Safety Information .................................................................................................................................................. 2

Table of Contents and Specications ..................................................................................................................... 3

Safety Guidelines ................................................................................................................................................... 4

Operating Instructions .........................................................................................................................................5-8

Quick Change Multi-Accessory Disc Accessories .................................................................................................. 9

Maintenance......................................................................................................................................................10,11

Safety Symbols ................................................................................................................................................12,13

Maintenance Schedule..........................................................................................................................................14

Dust and Crystalline Silica Warning ..................................................................................................................... 15

Notes ...............................................................................................................................................................16-18

Limited Equipment Warranty ................................................................................................................................ 19

NOTE: Due to improvements your machine may not appear the same as the pictures in this manual.

W

H

Specications & Dimensions are for reference

only and subject to change.

Model TG10-5B TG10-11H TG10-13P

Length (L) 41”/104cm 41”/104cm 41”/104cm

Width (W) 24”/61cm 24”/61cm 24”/61cm

Height (H) 38”/97cm 38”/97cm 38”/97cm

Total Weight 175 lbs. 180 lbs. 220 lbs.

Weights include 10” Diamond Disc (20 Segments)

L

Page 4

E-TG10-I-0119

800-638-3326 • edcoinc.com • [email protected]

EQUIPMENT DEVELOPMENT CO., INC.

Read and understand all operating instructions

before operating this equipment.

Death or serious injury can result if this machine is used improperly.

Eye and ear protection must be worn at all times while the grinder is in use. During normal operation,

sound pressure levels may exceed 85dBA. Use only ANSI approved safety glasses to help prevent

eye injury. Everyday eyeglasses have only impact resistant lenses; they are NOT safety glasses.

Operator must wear appropriate clothing and footwear. Do not wear loose clothing or jewelry that

can get tangled in moving parts. Footwear should provide sure footing and protection.

Materials being removed can be toxic or hazardous. A breathing respirator is required to help protect the oper-

ator from inhaling the airborne material when operating this machine.

• Inspect the work surface for cracks, uneven joints and foreign objects such as nails, screws and pipes. Damage

to the disc and/or equipment may result which can also cause serious injury to the operator. Hazardous areas

should be properly identied and clearly marked.

• The TG-10 is designed to be controlled by a single operator .

• Inspect the discs carefully before installing. Do not use any questionable disc since serious personal injury and/

or damage to property can result.

• Never operate this grinder while under the inuence of drugs, alcohol or when taking medications that impair the

senses or reactions, or when excessively tired or under stress.

• Be sure decals on the machine can be clearly read and understood. Replace worn or missing decals immediately,

Safety Guidelines

Safety warnings and guidelines do not by themselves eliminate danger.

They are not given as substitutes for proper accident prevention procedures and good judgement.

E-TG10-I-0119

E-SPTS-I-0809

800-638-3326 • edcoinc.com • [email protected]

Page 5

EQUIPMENT DEVELOPMENT CO., INC.

Operating Instructions

Exhaust from this engine contains Carbon Monoxide, an invisible, odorless gas that can kill.

In addition, it contains chemicals known, in certain quantities, to cause cancer, birth defects

or other reproductive harm.

Before Operating:

• Visually inspect machine:

- Verify all guards are in place and fasteners are tight.

- Check engine oil level (gasoline/propane models).

- Inspect power cord for damage and check for proper grounding (electric models).

• Inspect disc assembly:

- Check discs for damage or wear.

- Check mounting hardware.

- Check belt tension after rst 4 hours of use with factory new equipment or after installing new belts.

• Inspect the work area:

Inspect work area carefully before starting to grind. EDCO will not be held responsible for damage to the

discs caused by striking protruding slab inserts, nails, screws, pipe extensions, machinery bases, or other

objects that transmit sudden shocks.

• If dry grinding:

- Hook up heavy-duty vacuum.

- NOTE:

Do not use dry vacuum when wet grinding.

• If wet grinding:

- Attach hose to water supply.

Important Reminder!

A water mist system or an industrial vacuum must be used while operating this equipment and the operator

must wear a respirator. Failure to comply could lead to serious illness and possible death.

Safety warnings and guidelines do not by themselves eliminate danger.

They are not given as substitutes for proper accident prevention and good judgement.

Figure 2

Page 6

E-TG10-I-0119

800-638-3326 • edcoinc.com • [email protected]

EQUIPMENT DEVELOPMENT CO., INC.

Gasoline Models: (11 HP Honda Engine)

To Start the Engine:

• Tilt the machine back slightly to allow the disc to clear the slab surface.

• Start the engine according to the directions in the engine manufacturer’s Owner’s Manual.

NOTE: If during operation refueling becomes necessary, allow the engine to cool down. NEVER refuel a hot engine.

To Stop the Gasoline Model:

• Tilt the machine back slightly to allow the disc to clear the slab surface.

• Turn the engine o󰀨.

To STOP engine - Press Emergency Stop Switch to OFF position

Press to ON position when re-starting Engine (Figure 3)

Propane Models: (13 HP Honda Engine with 110V Key Start)

Propane is extremely ammable. VAPOR ONLY

To Start the Engine:

• Ensure that tank is positioned properly (arrow up).

• Turn on main valve on tank & Emergency Stop switch on handle.

• If you detect a gas odor immediately shut o󰀨 engine and consult your operator’s manual.

• Turn key to START

• Open throttle completely until engine runs smooth.

• Adjust throttle back to idle and sit machine back on surface.

• Increase speed to operating position(MAXIMUM 3400RPM’s) & begin grinding.

Refer to tachometer(Figure 3.1) for operating speed.

To Stop the Propane Model:

NOTE: If engine stops abruptly (uncontrolled stop) or using E-STOP

wait several minutes for propane gas to clear the fuel system and carburator

before trying to re-start.

• Tilt machine back slightly to allow the disc to clear the slab surface.

• If stopping for the day close valve and allow machine to purge propane from system.

• Turn key and emergency switch o󰀨.

• Otherwise just turn key o󰀨.

Electric Models: (5 HP Baldor. Available in 1 Phase or 3 Phase)

Electric units must be connected to a properly grounded electrical system using an approved electrical cable.

To Start the Motor:

• Tilt the machine back slightly, just enough for the disc to clear the slab surface.

• On 5 HP, single phase turn to the ON position. On the 5 HP, three phase, press the ON button.

• Be sure to check motor for correct rotation.

• Gently set the machine back down until the disc touches the slab surface and begin moving the machine.

NOTE: If the machine stops suddenly return the rotary can switch or starter box to the o󰀨 position

before pressing the manual reset on the motor.

Figure 3

Figure 3.1

E-TG10-I-0119

E-SPTS-I-0809

800-638-3326 • edcoinc.com • [email protected]

Page 7

EQUIPMENT DEVELOPMENT CO., INC.

To Stop the Electric Model:

• Tilt the machine to allow the disc to clear the slab surface.

• Turn rotary switch to the OFF position or press OFF button on the starter box.

Wet Grinding:

• In the wet grinding stage - water is fed from a standard garden hose into a

ball valve cut o󰀨, then into a nozzle that sprays over the disc assembly. (Figure 4)

Use the ball valve to regulate the ow of water to the disc.

Only use enough water ow to reduce dust. Excess water ow will

create clean up problems and could cause a hazardous walking area.

Always use dust control when using this product, vacuum or water mist.

Dry Grinding:

Dry Grinding creates a large volume of airborne dust. For health reasons, the operator should

wear an applicable respirator. The dust may contain chemicals known to cause serious

illnesses, including Silicosis - a fatal disease of the lungs. Check the chemical properties of the

material to be removed and follow all EPA/OSHA regulations.

Controlling the Grind:

• Grinding discs are extremely aggressive. It is important to KEEP THE GRINDER MOVING IN A SIDE-TO-SIDE

MOTION, do not let the grinder stay in one spot, even for a few seconds, or the surface will be damaged. When

grinding is completed, tilt the machine back and shut o󰀨 the power.

• To achieve a smooth “polished” surface, complete the grinding operation with an EDCO dual disc unit using

grinding stones or dyma-serts.

• To remove a light coating, move the grinder quickly. For heavier removal, move the grinder more slowly.

• Keep the grinding disc at - do not attempt to grind against vertical surfaces. Be sure the machine is in the correct

operating position. (See Figure 5)

Figure 4

Figure 5 Figure 6

Figure 3Figure 3

Page 8

E-TG10-I-0119

800-638-3326 • edcoinc.com • [email protected]

EQUIPMENT DEVELOPMENT CO., INC.

Comments in paragraph below are in reference to this level adjustment control (Figure 6).

NOTE: Ensure when leveling the machine as explained below that it (the machine) is sitting on a

FLAT LEVEL

surface otherwise adjustments may not be correct for the surface being worked on.

If rear of grinding disc is higher (not touching the work surface) than the front of the disc (touching the work

surface) turn this control (Figure 7) counter clockwise until disc sits level (at) on the work surface.

If front of grinding disc is higher (not touching the work surface) than the rear of the disc (touching the work

surface) turn this control (Figure 7) clockwise until disc sits level (at) on the work surface.

Do a light touch pass after each adjustment looking for a complete circle from the disc.

Discs:

• Inspect the disc (Figure 7) periodically to determine it’s wear characteristics, if signs of uneven wear appear the

cause should be determined and corrected. If repairs are needed contact EDCO or your EDCO representative.

• Rigid Head can be used on uneven expansion joints, high spots, joint curls and bridge decks, removing coatings

and grinding rough concrete surfaces. Use with a vacuum or water for dust control but not the same time. (Figure 8)

• Flex Head can be used preparing a smooth, at oor to receive a new coating, removing coatings, grind rough

concrete surfaces. Can be used with a vacuum or water for dust control but not the same time. (Figure 9)

• This unit comes standard with a 10” Diamond Disc. Optional 6 pocket Mulit-Accessory disc can be supplied. This

allows for the use of low prole grinding tools.

NOTE: The low prole tooling can be used in either a 6 tool set up or a 3 tool set up. If only using 3 tools

make sure they are evenly spaced on the disc.

• Each new machine is shipped with a RIGID HEAD (FLEX HEAD OPTIONAL) 10”/255 mm factory balanced disk.

It is important to maintain the coupling to which the disk is attached. A worn coupling, damaged bearings or a

bent shaft will cause the grinding discs to wear unevenly. (Figure 8 rigid head assembly & 9 ex head assembly.)

It is important to note FLEX HEAD for smooth at surfaces, RIGID HEAD for buckled, bumpy or rough surfaces.

Figure 7 Figure 8 Figure 9

Disc shown is for reference only. Standard RIGID HEAD Optional FLEX HEAD

E-TG10-I-0119

E-SPTS-I-0809

800-638-3326 • edcoinc.com • [email protected]

Page 9

E-SECNG-I-0714

15

301-638-3326 • edcoinc.com • [email protected]

EQUIPMENT DEVELOPMENT COMPANY

FOR USE WITH QUICK-CHANGE MULTI-ACCESSORY DISC

DOUBLE DIAMOND DOTS: General Purpose Grind -

Removes general purpose epoxy, mastics, thinsets,

water-proofing coatings and more.

SINGLE DIAMOND DOTS: Aggressive Grind -

Grinds and removes thick epoxies, weather-proofing

membrane and other coatings.

PCD ACCESSORY: Extremely Aggressive

Removal - Digs through industrial strength

coverings, water-proofing membranes,

thick epoxies and much more -

Leaves a textured concrete surface.

EDCO ARROW: Hard glue

removal, fast coating removal,

create smooth surfaces and more

PEAKS: General Purpose Grind -

Smoothes surfaces with fewer scratchs - Ideal for

concrete preparation and polishing. Removes thinsets,

concrete coatings and more

MAGNA-BLADE: Magna-Blades use carbide tipped

blocks to strip away coatings and clean oors without

grinding into the concrete. The replaceable multi-

sided tungsten carbide can be rotated for maximum

use.

EQUIPMENT DEVELOPMENT CO., INC.

Page 10

E-TG10-I-0119

800-638-3326 • edcoinc.com • [email protected]

EQUIPMENT DEVELOPMENT CO., INC.

Maintenance

Follow the engine manufacturer’s guidelines for regular maintenance.

Disconnect spark plug lead (Figure 10) before performing any maintenance on this machine! Or

on the electric model, unplug the electric cord at the machine (instead of at the wall) to assure

the machine will remain un-plugged while you are working on it.

Inspect Every 8 Hours:

• Inspect the disc mounting screws. (Figure 11) The constant vibration and heat generated, especially when

grinding dry, could cause the screws to loosen and the disc to become o󰀨 balance.

After every use:

• Inspect for lash in head (Does head move up/down) ? (Figure 12). Verify that jam nuts, items 8 on page 10 in

Parts Breakdown are tight and there isn’t any play. Allowing these nuts to remain loose can damage the head assembly.

• If movement is noticed, STOP. Damage to head assembly may occur. In order to tighten these nuts the sheave under

the hood must be removed. Bottom nut should be tightened and then backed o󰀨 until head turns freely. Then top nut

should be tightened down and jammed using two wrenches turning in opposite directions. After tightening make sure

head still turns freely.

Lubricate Daily:

• Bearings (Figure 13) must be lubricated daily with Lubriplate 930-AA High Temp Grease or equivalent.

• Access tting through opening on hood.

Figure 10

Figure 12

Figure 11

Figure 13

Disc Mounting

Screws

E-TG10-I-0119

E-SPTS-I-0809

800-638-3326 • edcoinc.com • [email protected]

Page 11

EQUIPMENT DEVELOPMENT CO., INC.

Maintenance

Belts:

To remove/replace belts:

• Remove belt cover to expose belts. (Figure 14)

• Loosen engine/motor mounting bolts (Figure 15) on both sides of the TG-10 and slide engine forward to allow

belts to slide o󰀨.

• Replace worn belts with a complete set of new belts - even if only one belt is showing wear.

• Slide engine back in place until belts are tight and retighten engine mounting bolts.

• Reinstall belt cover and tighten hardware.

• After four hours of use, retighten belts.

Engine Air Filter:

Inspect the air lters (Figure 16) for excess dust, dirt or damage before the engine is operated. More often if operating

in a dusty environment.

Operating the engine with a damaged or dirty air lter, or without an air lter, will allow dirt to enter the engine causing

rapid engine wear which would not be covered under the engine manufacturer’s warranty.

Follow the engine manufacturer’s procedures for keeping the lters in good condition.

Figure 14

Figure 16Figure 15

Page 12

E-TG10-I-0119

800-638-3326 • edcoinc.com • [email protected]

This symbol means that the Operator’s, owners, instruction and/or manufacturer(s) manuals must be

read and understood before operating or attempting to operate this electrical, gasoline, diesel or

propane powered equipment, failure to do so can result in personal injury and possible death.

(Blue background with white pictogram.)

This symbol means that proper eye protection must be worn/used during the operation of this equipment. There is

a potential risk of operator eye damage, injury or loss of sight. This also applies to any personnel standing

nearby observing the operation of this equipment.

(Blue background with white pictogram.)

This symbol means that proper ear protection should be worn/used during the operation of this equipment.

There is a potential risk of operator hearing damage, injury or loss of hearing which will increase based on the

length of exposure. This also applies to any personnel standing nearby observing the operation of this equipment.

(Blue background with white pictogram.)

This symbol means that proper head protection should be worn/used during the operation of this equipment there

is a potential risk of operator head injury from foreign or loose objects the equipment might come in

contact with during operation. This also applies to any personnel standing nearby or observing the

operation of this equipment.

(Blue background with white pictogram.)

This symbol means that proper breathing protection or engineering controls must be worn/used during the

operation of this equipment there is a potential risk of operator lung damage. Repeated and/or substantial

inhalation of airborne crystalline silica can cause serious or fatal respiratory diseases, including silicosis. In

addition, to California and some other authorities have listed respirable crystalline silica as a substance known

to cause cancer. When grinding/cutting/drilling such materials, always follow local respiratory precautions.

This also applies to any personnel standing nearby or observing the operation of this equipment.

(Blue background with white pictogram.)

This symbol means do not insert ngers/digits under any edge of the belt cover while the engine/

motor on the machine is running because personal injury and loss of ngers/digits may result.

(Black pictogram with red “No” symbol outline)

This symbol denotes the lifting point and means that if lifting of this equipment is necessary use a lifting

device that is designed to accomodate or exceed the weight of this machine. Check the Operator’s

manual for specications. Using a device that is not designed to accomodate or exceed the weight of this

machine could result in damage to the machine and personal injury. Do not lift equipment over people

because death or serious injury could result.

(Blue background with white pictogram.)

This GHS pictogram identies that the chemicals contained present serious health hazards.

(Black pictogram with red diamond symbol outline)

SAFETY SYMBOLS

EQUIPMENT DEVELOPMENT CO., INC.

E-TG10-I-0119

E-SPTS-I-0809

800-638-3326 • edcoinc.com • [email protected]

Page 13

800-638-3326 • edcoinc.com • [email protected]

EQUIPMENT DEVELOPMENT CO., INC.

SAFETY SYMBOLS

This symbol means that the machine is heavy if the machine needs to be lifted onto or o󰀨 of a truck,

loading dock etc. that proper technique or heavy duty lifting device should be used, personal injury could result.

(Yellow background with black pictogram and black outline)

This symbol means that there are sharp components and if feet/ngers/digits come in contact personal

injury or death could result.

(Yellow background with black pictogram and black outline)

This symbol means that potential hazardous voltages are present and the equipment must be properly

grounded and extreme caution should be taken. If for any reason maintenance or repair is needed,

insure that voltage(s) are disconnected at the machine and the source unless (be cautious) voltage needs

to be present to troubleshoot the problem, then only qualied personal should work on “live” systems.

(Yellow background with black pictogram and black outline)

This symbol means hazardous pressures are present. Caution should be exercised to prevent personal

injury or damage to equipment. Face, eye and head protection should be used.

(Yellow background with black pictogram and black outline)

This symbol means explosive and hazardous vapors are present. Caution should be exercised to

prevent personal injury to face and eyes. Breathing and personal protection should be used when

servicing.

(Yellow background with black pictogram and black outline)

This symbol means that the guards must remain in place while the engine/motor on the machine is

running because death or personal injury may result.

(Yellow background with black pictogram and black outline)

This symbol means that there are moving parts and if feet/ngers/digits are inserted under any edge of

the cutter/grinder/saw cover while the engine/motor on the machine is running that personal injury and loss

of foot/ngers/digits may result.

(Yellow background with black pictogram and black outline)

This symbol means the surface is HOT and that if ngers/digits/hands or any bare or unprotected skin comes

in contact with this surface or hot accessory, possible serious burns and personal injury may result.

(Yellow background with black pictogram and black outline)

This symbol means that this machine or product exposes the operator to chemicals, gases or dust

particles that are listed by the state of California as potentially causing cancer or reproductive harm.

For more information go to: www. P65Warnings.ca.gov.

(Yellow background with black pictogram and black outline)

Page 14

E-TG10-I-0119

800-638-3326 • edcoinc.com • [email protected]

EQUIPMENT DEVELOPMENT CO., INC.

Maintenance Schedule

Read and follow the

engine manufacturer’s

maintenance schedule.

Repairs are to be done by

authorized EDCO Dealers only.

* When applicable.

Before Operation

After First 4 Hours

Every 8 Hours

Weekly

As Necessary

Adjust Wheel

Height

X

Inspect Entire

Machine

* Check Oil & Fuel

Levels

* Inspect Propane

Connections

Inspect Disc

Inspect Belt Tension

Lubricate Shaft Bear-

ings

Inspect/Tighten

Disc Mounting Screws

* Inspect Vacuum

(empty bins, etc.)

X X

X

* Check Air Filter

(Clean if Necessary) X

Inspect/tighten Jam

nuts on head assy. X

E-TG10-I-0119

E-SPTS-I-0809

800-638-3326 • edcoinc.com • [email protected]

Page 15

EQUIPMENT DEVELOPMENT CO., INC.

DUST AND CRYSTALLINE SILICA WARNING

Grinding/cutting/drilling of masonry, concrete, metal and other materials can generate dust,

mists and fumes containing chemicals known to cause serious or fatal injury or illness, such as

respiratory disease, cancer, birth defects or other reproductive harm. If you are unfamiliar with

the risks associated with the particular process and/or material being cut or the composition of

the tool being used, review the material safety data sheets and/or consult your employer, the

manufacturers/suppliers, governmental agencies such as OSHA and NIOSH and other sources

on hazardous materials. California and some other authorities, for instance, have published lists

of substances known to cause cancer, reproductive toxicity, or other harmful e󰀨ects.

Control dust, mist and fumes at the source where possible. In this regard use good work practices

and follow the recommendations of the manufacturers/suppliers, OSHA/NIOSH, and occupa-

tional and trade associations. Water should be used for dust suppression when wet grinding/

cutting/drilling is feasible. When the hazards from inhalation of dust, mists and fumes cannot

be eliminated, the operator and any bystanders should always wear a respirator approved by

NIOSH/MSHA for the material being used.

Grinding/cutting/drilling of masonry, concrete and other materials with silica in their composition

may give o󰀨 dust or mists containing crystalline silica. Silica is a basic component of sand,

quartz, brick clay, granite and numerous other minerals and rocks. Repeated and/or substantial

inhalation of airborne crystalline silica can cause serious or fatal respiratory diseases, including

silicosis. In addition, California and some other authorities have listed respirable crystalline silica

as a substance known to cause cancer. When grinding/cutting/drilling such materials, always

follow the respiratory precautions mentioned above.

See more on the importance of dust prevention and silica warnings at osha.gov/silica.

See more concrete and silica dust supression training and educational

materials at edcoinc.com/silica-standards or scan the QR code at right.

Page 16

E-TG10-I-0119

800-638-3326 • edcoinc.com • [email protected]

EQUIPMENT DEVELOPMENT CO., INC.

NOTES

_________________________________________________________________________________________________________________

This page intentionally left blank.

E-TG10-I-0119

E-SPTS-I-0809

800-638-3326 • edcoinc.com • [email protected]

Page 17

EQUIPMENT DEVELOPMENT CO., INC.

NOTES

_________________________________________________________________________________________________________________

This page intentionally left blank.

Page 18

E-TG10-I-0119

800-638-3326 • edcoinc.com • [email protected]

EQUIPMENT DEVELOPMENT CO., INC.

NOTES

_________________________________________________________________________________________________________________

This page intentionally left blank.

E-TG10-I-0119

E-SPTS-I-0809

800-638-3326 • edcoinc.com • [email protected]

Page 19

EQUIPMENT DEVELOPMENT CO., INC.

Equipment Development Company, Inc. herein referred to as EDCO (Seller) warrants that

each new unit manufactured by EDCO to be free from defects in material and workmanship

in normal use and service for a period of (1) one year (except for the cutter drum assembly

on all model concrete/asphalt planers AND the chisel head assembly on all model ALR’s &

ALR-BS in which case the warranty period shall be 90 days) from date of shipment to the

original retail or equipment rental center owner.

Accessories or equipment furnished and installed on the product by EDCO but manufactured by

others, including, but not limited to engines, motors,electrical components, transmissions etc.,

shall carry the accessory manufacturers own warranty.

EDCO will, at its option, repair or replace, at the EDCO factory or at a point designated by

EDCO, any part which shall appear to the satisfaction of EDCO inspection to have been

defective in material or workmanship.

EDCO reserves the right to modify, alter and improve any part or parts

without incurring any obligation to replace any part or parts previously sold without such

modified, altered or improved part or parts.

This warranty is in lieu of and excludes all other warranties, expressed, implied, statutory,

or otherwise created under applicable law including, but not limited to the warranty of

merchantability and the warranty of fitness for a particular purpose in no event shall seller

or the manufacturer of the product be liable for special, incidental, or consequential dam-

ages, including loss of profits, whether or not caused by or resulting from the negligence

of seller and/or the manufacturer of the product unless specifically provided herein. In ad-

dition, this warranty shall not apply to any products or portions there of which have been

subjected to abuse, misuse, improper installation, maintenance, or operation, electrical

failure or abnormal conditions and to products which have been tampered with, altered,

modified, repaired, reworked by anyone not approved by seller or used in any manner

inconsistent with the provisions of the above or any instructions or specifications provided

with or for the product.

FORCE MAJEURE

Seller’s obligation hereunder are subject to, and Seller shall not be held responsible for, any

delay or failure to make delivery of all or any part of the Product due to labor difficulties,

fires, casualties, accidents, acts of the elements, acts of God, transportation difficulties,

delays by a common carrier, inability to obtain Product, materials or components or qualified

labor sufficient to timely perform part of or all of the obligations contained in these terms

and conditions, governmental regulations or actions, strikes, damage to or destruction in

whole or part of manufacturing plant, riots, terrorist attacks or incidents, civil commotions,

warlike conditions, flood , tidal waves, typhoon, hurricane, earthquake, lightning, explosion

or any other causes, contingencies or circumstances within or without the United States not

subject to the Seller’s control which prevent or hinder the manufacture or delivery of the

Products or make the fulfillment of these terms and conditions impracticable. In the event

of the occurrence of any of the foregoing, at the option of Seller, Seller shall be excused

from the performance under these Terms and Conditions, or the performance of the Seller

shall be correspondingly extended.

This document sets forth the terms and conditions pursuant to which the purchaser (“Pur-

chaser”) will purchase and Equipment Development Co.Inc. (“Seller”)will sell the products,

accessories, attachments (collectively the Products “) ordered by the Purchaser. These

terms and conditions shall govern and apply to the sale of Seller’s Products to Purchaser,

regardless of any terms and conditions appearing on any purchase order or other forms

submitted by Purchaser to Seller, or the inconsistency of any terms therein and herein.

1. PRICE

All prices set forth on any purchase order or other document are F.O.B. Sellers facility or dis-

tribution point, as may be determined by Seller (F.O.B.Point). All prices are exclusive of any

and all taxes, including, but not limited to, excise, sales, use, property or transportation taxes

related to the sale or use of the Products, now or hereafter imposed, together with all penalties

and expenses. Purchaser shall be responsible for collecting and/or paying any and all such

taxes, whether or not they are stated in any invoice for the Products. Unless otherwise speci-

fied herein, all prices are exclusive of inland transportation, freight, insurance and other costs

and expenses relating to the shipment of the Products from the F.O.B. point to Purchaser’s

facility. Any prepayment by Seller of freight insurance and other costs shall be for the account

of Purchaser

and shall be repaid to Seller.

2. PAYMENT TERMS

Payment terms are as follows. 2% 10 days (to approved and qualified accounts). Net 30

days. This is a cash discount for invoices paid within 10 days after the invoice date, regard-

less of date of receipt of shipment. This is not a trade discount and will not be granted to

accounts that do not adhere to stated terms.

*All past due accounts are subject to a late payment fee of 1.5% per month or a maximum

allowed by law if different, along with the expenses incidental to collection including reason-

able attorney’s fees and costs.

*Seller reserves the right to hold shipments against past due accounts.

*Seller reserves the right to alter payment terms.

3. FREIGHT TERMS

All shipments will be made F.O.B. shipping point as designated in these Terms and Condi-

tions, and title shall pass at the F.O.B. point. Delivery to the initial common carrier shall

constitute delivery to the Purchaser. Any claims for loss or damage during shipment

are to be filed with carrier by the Purchaser. Seller will not assume responsibility for the

performance of the carrier.

Back orders will be shipped in the most practical fashion with charges consistent with

our freight policy established with the original order. UPS, FED EX, MAIL or shipments

by other couriers are subject to the same terms and conditions as outlined in paragraph

#3”Freight Terms”.

4. DELIVERY, DAMAGES, SHORTAGES

Seller shall use reasonable efforts to attempt to cause the Products to be delivered as provided

for in these Terms & Conditions. Delivery to the initial common carrier shall constitute the delivery

to the Purchaser. Sellers responsibility, in so far as transportation risks are concerned ceases

upon the delivery of the Products in good condition to such carrier at the F.O.B. point and all the

Products shall be shipped at the Purchaser’s risk. Seller shall not be responsible or liable for

any loss of income and/or profits, or incidental, special, consequential damages resulting from

Seller’s delayed performance in shipment and delivery.

5. RETURN OF DEFECTIVE PRODUCTS

Defective or failed material shall be held at the Purchaser’s premises until authorization has

been granted by Seller to return or dispose of Products. Products that are to be returned

for final inspection must be returned Freight Prepaid in the most economical way. Credit

will be issued for material found to be defective upon Seller’s inspection based on prices

at time of purchase.

6. PRODUCTS ORDERED IN ERROR

Products may be returned, provided that claim is made and Seller is notified within 7 days

of receipt of Products, and the Products are in original buyer’s possession not more than

30 days prior to return, subject to Seller’s approval. If Products are accepted for return,

they must be Freight Prepaid and buyer will be charged a minimum of 15% restocking

charge, plus a charge back for outbound freight charges if the original order was shipped

prepaid. Returns are not accepted for any Products that are specifically manufactured to

meet the buyer’s requirement of either specifications or quantity.

AGREEMENTS

These Terms and Conditions constitute the entire agreement between Seller and Purchaser as

it relates to terms and conditions of sale, and supersedes any and all prior oral or written agree-

ments, correspondence, quotations or understandings heretofore in force between the parties

relating to the subject matter hereof. There are no agreements between Seller and Purchaser

with respect to the Product herein except those specifically set forth in and made part of these

terms and conditions. Any additional terms, conditions and/or prices are rejected by Seller.

These terms and conditions may be modified, cancelled or rescinded only by a written

agreement of both parties executed by their duly authorized agents.

USE ONLY GENUINE EDCO PARTS & ACCESSORIES

For your own safety, the safety of others and the life of your machine.

SUBMIT ALL WARRANTY CLAIMS AT:

edcoinc.com/customer-support/warranty-claim-form/

LIMITED EQUIPMENT WARRANTY OF SALE

TERMS AND CONDITIONS

(NOT APPLICABLE TO SALES THROUGH AUTHORIZED DISTRIBUTION)

800-638-3326 • edcoinc.com • [email protected]

EQUIPMENT DEVELOPMENT CO., INC.

Scan This QRC or Visit

www.edcoinc.com/customer-support

READ

:

EDCO Owner’s Manuals and Parts Listings share basic information

and parts of each product. Download and print them whenever needed.

WATCH:

EDCO Product Training Videos show how to use products, install

tooling, and perform basic maintenance.

FIND:

Somewhere on this product is an EDCO QRC Training Decal. Scanning

this code provides owner’s information, videos, and other training content

anywhere/anytime on your mobile device.

JOIN:

EDCOed.com is a free, 24-hour training space. Each certication track

focuses on a specic EDCO product group. The information in these tracks help

businesses be successful with those products.

Example Only

EDCO is always updating online training / information so you always have the most recent content.

Also see Operator’s Safety & Limited Warranty Manual

Equipment Development Co., Inc. • 800.638.3326 • [email protected]

BEFORE USING THIS PRODUCT

Have You Used EDCO’s Online Customer Support??

Edco TG-10 Assembly instructions

Popular Grinder manuals by other brands
