EDELBROCK CAT-BACK EXHAUST SYSTEM (SPLIT EXIT)
for 1987-1996 Ford Pick-Up Trucks 2 & 4WD With 5.0L, 5.8L V8 Engines
Catalog #5682
INSTALLATION INSTRUCTIONS
Application: Designed for 1987-1996 Ford F-150/F-250 pick-up trucks, up to 155” w.b., and flareside, 2 & 4WD with 5.2L, 5.8L V8
engine. NOTE: Split exhaust systems on four-wheel drive vehicles may require removal or relocation of spare tire.
Suggested Tools for Installation:
❑3/8” rachet set with SAE and metric sockets ❑9/16” and 15mm wrenches
❑Jackstands and jack ❑Liquid penetrant
❑Long pry bars (for removing rubber-mounted hangers) ❑Hacksaw (to cut intermediate pipe to required length)
❑Tape measure ❑3/8” Drill motor and drill bit
Disassembly
1. Raise vehicle and support with the proper jackstands,
leaving the rear suspension hanging.
2. Use caution around hot exhaust systems to avoid burns.
3. Use penetrating oil on all nuts and bolts, and rubber lube on
the rubber hangers.
4. Remove all nuts, bolts, and hangers from the rear of the
catalytic converter to the tailpipes.
5. Remove the old exhaust system.
Assembly
1. Assemble the overaxle pipe to the muffler using two gaskets
and four of the 1-1/4" bolts, nuts, and lockwashers.
2. Install the hanger supplied into the two rubber hangers with
the long side to the left so it will lean forward when attached
to the muffler flange.
3. Slip the muffler assembly over the axle from the front and
attach the hanger to the back side of the muffler flange
using the center hole with the 1-1/2" bolt, nut and
lockwasher supplied.
4. Now tie or block assembly in place and you can check the
length of the intermediate pipe needed for your truck. The
following are the measurements that we developed. Using
the following chart, cut the Intermediate pipe to the
following lengths, measuring from the front 2-1/4" swage
back.
Cut to
A. Standard Cab - Short Bed 117" Wheelbase.....13-1/2"
B. Standard Cab - Long Bed 133" Wheelbase......29-1/2"
C. Supercab - Short Bed 138" Wheelbase...........34-5/8"
D. Supercab - Long Bed 155" Wheelbase............50-3/4"
Please study these instructions carefully before installing your new Cat-Back Exhaust System. If you have any questions, please
contact our Technical Hotline at: 1-800-416-8628, 7:00 am to 5:00 pm, Monday through Friday, Pacific Standard Time or e-mail
us at [email protected]. Please fill out and mail your warranty card.
WARNING: Exhaust gas contains carbon monoxide, a
deadly invisible gas. Correct any leaks before
driving!
5. Deburr the cut, install one 3” band clamp and slip the 3" end
of the tube into the muffler. Install one 2-1/4” band clamp
on the front and slip the 2-1/4" end over the catalytic
converter outlet.
6. Level the muffler and snug the clamps up.
7. You may have to loosen your spare and adjust its position to
clear the tailpipes. NOTE: An oversized spare tire will
not work with the split system.
8. Install band clamps on the tailpipes and slip them onto the
overaxle pipe. Align the pipes where you want them and
either tie them or block them in position. Locate a hole in
the frame or drill one for the universal hangers supplied that
will hang the pipes where you like them. The hangers are
extra long so that you can trim the length when done. Use
U-clamps to secure tailpipes to universal hangers.
9. Start from the front, check for clearance, align, and tighten
the system to the rear.
10. Start your truck, check for leaks, and correct if any is found.
NOTE:: For those trucks thathave Roll Pans installed, you can
modify the hangers to fit your situation on the rear exit models.
This will not be necessary on the side exit models.

WARNING: Support your vehicle with proper jack
stands or ramps rated for the total vehicle weight.
Place stands so that the rear axle is allowed to hang
free for easy system removal.
WARNING: These Cat-back Systems are
engineered to fit stock catalytic converters or
equivalent replacements.If your original system has
been modified, Edelbrock will not warranty fit or
performance.
KIT CONTENTS - CAT-BACK EXHAUST SYSTEM
Qty.part # Description
125-3068 Overaxle assembly
125-3069 Left Tailpipe assembly
125-3070 Right Tailpipe assembly
125-3071 Intermediate pipe
125-5564 SDT Muffler
225-5582 Tailpipe Tips (304 SS)
223-1773 2-1/2" U-clamp (Zinc)
123-4010 Rear muffler hanger
233-5400 Two-bolt gaskets
233-8001 Hangers
146-6612 3” Band clamp
246-6610 2” Band clamp
146-6614 2-1/4" Band clamp
63/8"-16 x 1-1/4" bolts
13/8"-16 x 1-1/2" bolt
73/8"-16 nuts 73/8" lockwashers
®
22--11//44""BBaannddccllaammpp
33””BBaannddccllaammpp
UU--ccllaammpp
TTwwoo--bboollttffllaannggeeggaasskkeettss
RReeaarrMMuufffflleerrHHaannggeerr
OOvveerrAAxxlleePPiippeeAAsssseemmbbllyyIInntteerrmmeeddiiaatteePPiippee
AAsssseemmbbllyy
TTaaiillppiippeess
SSDDTTMMuufffflleerr##5555776644
22--11//22""UU--ccllaammpp aannddhhaannggeerr
22--11//22""UU--ccllaammpp aannddhhaannggeerr
TTaaiillppiippeeTTiippss
((330044SSSS))
