Ekinex EK-GD1-DL-4-HV User manual

1
DALI 2 90-230 Vac 4-channels phase cut
dimmers
Code: EK-GD1-DL-4-HV
Main functional characteristics
• Memory function settable via DALI bus: it saves the last
brightness level in the event of a power failure
• Fade time, minimum and maximum brightness level
settable via DALI bus
• Soft on and o󰀨
• Min level brightness: 0.1%
• Logarithmic adjustment curve settable via DALI bus
• On and o󰀨 times settable via DALI
• Optimized output curve
• Channel buttons 1-2-3-4 for local on / o󰀨 test in case of
DALI bus absence (for EK-GD1-DL-4-HV model only):
by holding down the button relating to a channel, the
connected load ashes at 1 s intervals
• Signaling in case of short circuit, lack of voltage and
overload
DALI 2 standard bus dimmer with 90-230 Vac power sup-
ply and 4 channels, for controlling the brightness of LED
and halogen sources with 90-230V AC 50/60Hz voltage
for a maximum of 200W on 4 channels each.
Datasheet STEKGD1DL4HV_EN
Note: values for output current and nominal power
have to be intended as maximum values, depen-
ding on the ventilation conditions. The reported va-
lues are measured with a room temperature of 40
°C. For electronic loads and/or LEDs whose PFC or
harmonic distortion is not known, consider the maxi-
mum power halved compared to the nominal value.
i
Description
The ekinex DALI 2 phase-cut dimmer powered at 90-230
Vac with 4 channels EK-GD1-DL-4-HV allows the bright-
ness control of luminous loads with voltage 90 - 230 Vac
at 50/60 Hz. The device has a max. of 200 W for each
channel. The loads that can be used with the EK-GD1-
DL-4-HV dimmer can be incandescent lamps, mains vol-
tage halogen lamps, dimmable mains voltage LED lamps,
dimmable mains voltage LED strips, switching power sup-
plies for Phase cutting dimmable LEDs.
The dimmer cuts the phase in Trailing Edge mode (on the
falling edge).
The dimmer is DALI2 certied (GTIN:8050054980065)
with reference to parts 101, 102, 205.
Technical data
Inputs
• Power supply: 90 - 230 Vac 50/60 Hz
• Maximum input current: 4 A
• Inputs according to DALI 2 protocol certied to IEC
62386, parts 101, 102, 205.
Outputs
• Power supply: 90 - 230 Vac 50/60 Hz
• Output power per channel 110 W @ 110 Vac, 220 W @
220 Vac, 230 W @ 230 Vac
• Minimum load power: 1 W per channel
• Maximum output current: 1 A
Dimming
• Trailing edge dimming mode with open load control
(OPEN CIRCUIT) and short circuit on the load (SHORT
CIRCUIT)
• Dimming range: 1-100%
Environmental conditions and other characteristics
• Operating temperature: - 20 ° C ... + 40 ° C
• Storage temperature: - 40 ° C ... + 60 ° C
• Transport temperature: - 40 ° C ... + 60 ° C
• Maximum case temperature (tc): 80 °C
• Relative humidity: 91% non-condensing
• Protection degree: IP00 (IP20 inside a wall-mounting
box or electrical panel)
• Loads and supply wiring: 1.5 mm2solid – 2.5 mm2
stranded (16 - 13 AWG)
• Stripping: 5.0 - 6.0 mm
• Housing in plastic material
• Device suitable for installation in panels/cabinets 4 UM
• Weight 200 g
• Dimensions (LxHxP): 71 x 91 x 62 mm

2
To remove the device, be sure that inputs, outputs, and
the input power supply have been disconnected. Then
use a screwdriver to slide down the locking device and
remove the device from the rail.
Protections
The device is equipped with the following protections:
• OVP Input voltage peak protection
• RVP Overcurrent protection with 3 A non-resettable
fuse
• OCP Output open circuit protection
Mounting
The device has degree of protection IP00 (IP20 inside a
wall-mounting box or electrical panel), and are therefore
suitable for use in dry interior rooms. The mounting must
be performed on a proled rail according to EN 60715
inside electrical distribution panels and cabinets.
To disassemble the device, to have rst to disconnect the
inputs, outputs and power supply.
When assembling, make sure to leave only the front pa-
nel accessible; all other sides must not be accessible.
Proceed as follows:
• with the aid of a tool bring the locking device in the fully
lowered position (a);
• place the upper edge of the rear inner prole on the
upper edge of the rail (b);
• rotate the device towards the rail (c);
• push the locking device upward until it stops (d).
Control, signaling and connection elements
The device is equipped with a spring clamp for connecting
the output loads on 4 channels and the 90 - 230 Vac input
power supply (4). There is also a signaling LED for the
presence of the power supply (2), a button and LED for
each channel (3), for local on / o󰀨 test also in case of DALI
bus absence and nally a spring terminal for connection
of the DALI line (1).
The terminals for power supply and loads follow the dia-
gram in the table:
a b
dc
Note. When mounting the device in boards and ca-
binets it shall be provided the necessary ventilation
so that the temperature can be kept within the ope-
rating range of the device.
i
Setup and installation
The steps to setup the device are as follows:
1. Connect the loads to the -x and COM terminals
of the device
2. Connect the DALI bus to the corresponding terminals
of the device
3. Connect the 90 - 230 Vac power supply to the L, N
input terminals of the device
EK-GD1-DL-4-HV
Power
1 2 34
EK-GD1-DL-4-HV
Dimmer Dali 90-230V~ 4 canali
Out: 4x 200W
3
1
4
2
Nr. Label Connection
1 - DALI bus - pole 1 and 2 spring clamp
2 Power Signalling LED
3 x LED and channel x (x = 1,2,3,4) button
4 - Power supply and loads clamps
1 2 3 45678 9 10 11 12
NL NL
CO
M
1
CO
M
2
CO
M
3
CO
M
4
Label Connection
Channel x (x=1,2,3,4) AC output - Live
COM Channel x (x=1,2,3,4) AC output - Neutral
N AC input - Neutral
L AC input - Live
x

3
INSTALLATION TECHNICAL NOTES
• Installation and maintenance must be
performed only if the power supply has
been turned o󰀨.
• Installation and maintenance must only
be performed by qualied personnel in
compliance with current regulations.
• The product must be installed inside a
wall mounting box or an electrical panel,
where it is recommended to install a sur-
ge protector.
• The product must be protected by a sui-
tably sized fuse.
• The product must be protected by a su-
itably sized magnetothermic switch on
the main input line.
• The product must be installed in a verti-
cal position with the front / label facing
the front or in a horizontal position with
the front / label facing upwards. Other
product installation positions are not al-
lowed.
• Do not connect inductive loads.
Do not connect to UPS (uninter-
ruptible power supply) with ou-
tput other than Pure Sine Wave.
The device is not grounded. Protection
from accidental contacts is guaranteed
by the casing.
• Use in thermally harsh environments
could limit the output power.
• In the system, keep the 90-230Vac circu-
its and the non-SELV circuits separate
from the SELV circuits at very low safety
voltage and from the DALI bus
• It is absolutely forbidden to connect, for
any reason whatsoever, directly or indi-
rectly, the 90-230Vac mains voltage to
the DALI bus or to the loads.
• Use double insulated cables.
!
DALI bus line connections
The connection to the DALI bus network is done via the
spring clamp terminal, located on the front of the device
in the upper part.
The length and type of the connection cables to the DALI
bus must be compliant with the protocol specication and
the present regulations and they should be isolated from
every wiring or parts at voltage not SELV. Use double in-
sulated shielded and twisted cables.
All the devices connected to the DALI bus must be SELV
(the devices connected must be SELV or supply a SELV
signal).
Connection of power supply and loads
The connection to the 90-230 Vac 50-60Hz power supply
is done via the spring terminals, located in the lower part
of the device.
Characteristics of the supply and loads terminal block
• Spring tightening of the conductors
• Power and loads wiring: 1.5 mm2solid – 2.5 mm2stran-
ded – 16 - 13 AWG
• Stripping recommended approx.: 5.0 - 6.0 mm
Output
The cables connected to the outputs must be correctly
sized and must be isolated from any wiring or parts with
di󰀨erent voltages. The length and type of connection ca-
bles must comply with the regulations in force.
Characteristics of the DALI terminal block
• Spring tightening of the conductors
• Command and bus wiring: 0.05 mm2solid – 1.5 mm2
stranded – 30 - 16 AWG
• Conductor stripping recommended: 5.0 - 6.0 mm
• Length of connection cables < 25 m
Conguration and commissioning
Conguration and commissioning activities of the device
must be carried out according to the design of the building
automation system done by qualied planners.
For commissioning the device the following activities are
required:
• make the electrical connections as indicated above;
• power up the supply and the DALI bus;
• carry out the device programming via a DALI interface.
By holding down the button relating to a channel, a test
is carried out on the connected load, which lights up and
ashes for 1s.
Installation diagrams
The device can be installed by wiring the outputs with ei-
ther a separate COM pole or a common COM pole. The
following schemes can be implemented:
1. Outputs with separate COM pole connection
Installation diagram with outputs with
separate COM pole connection
DALI
90-230 Vac
50-60 Hz
L
N

4
Note. The programming of the parameters men-
tioned above must be carried out only during the
programming phase. If the customer has a DALI
programmer / master, he can reprogram them as
he wishes.
i
Dimensions [mm]
2. Outputs with common COM pole connection
The terminals indicated by the COM label can be used as
a common terminal for the loads
Installation diagram with outputs with
common COM pole connection
DALI
90-230 Vac
50-60 Hz
L
N
Warning! For the EK-GD1-DL-4-HV model, the N
terminals for input must not be connected to the
COM outputs
!
Conguration change
Subsequently, it is possible to change the device con-
guration and addressing by using a DALI application for
parameterization, which allows you to:
• congure the DALI system and dene its parameters;
• set the DALI devices (groups, scenarios, IDs, etc.);
• test the communication on the DALI bus;
• update the device.
Power
1 2 34
EK-GD1-DL-4-HV
Dimmer Dali 90-230V~ 4 canali
Out: 4x 200W
EK-GD1-DL-4-LV
Dimmer Dali 12/48Vdc 4 canali
DC In: 12-48V
Out: 4x max 5A
Power
1 2 34

5
Summary table of load types depending on the input power supply
TE = Trailing Edge
@220 V 50/60 Hz
SYMBOL LOAD TYPE
MAX POWER
MODE CURVE
SINGLE
CHANNEL
SUM OF
CHANNELS
Halogen or incandescent bulbs (230V ~ 50/60Hz) 230 W 460 W TE Linear
Ferromagnetic transformers (Halogen bulbs at 12/24V
~ 50/60Hz) Incompatible
Electronic transformers (Halogen bulbs 12/24V ~
50/60Hz) 115 W 330 W TE Logarithmic
Dimmable LED lamps (230V ~ 50/60Hz) 115 W 330 W TE Logarithmic
Lamp power supplies LED (230V ~ 50/60Hz) 115 W 330 W TE Logarithmic
LED strip (230V ~ 50/60Hz) 230 W 460 W TE Linear /
logarithmic
Energy saving lamps (ESL/CFL) Incompatible
Warning! Never connect the transformer wi-
thout rst having connected the load on the se-
condary, to avoid overvoltages that are destruc-
tive to the appliance.
!
@110 V 50/60 Hz
SYMBOL LOAD TYPE
MAX POWER
MODE CURVE
SINGLE
CHANNEL
SUM OF
CHANNELS
Halogen or incandescent bulbs (230V ~ 50/60Hz) 110 W 220 W TE Linear
Ferromagnetic transformers (Halogen bulbs at 12/24V
~ 50/60Hz) Incompatible
Electronic transformers (Halogen bulbs 12/24V ~
50/60Hz) 55 W 110 W TE Logarithmic
Dimmable LED lamps (230V ~ 50/60Hz) 55 W 110 W TE Logarithmic
Lamp power supplies LED (230V ~ 50/60Hz) 55 W 110 W TE Logarithmic
LED strip (230V ~ 50/60Hz) 110 W 220 W TE Linear /
logarithmic
Energy saving lamps (ESL/CFL) Incompatible

6
Disposal
At the end of its useful life the product
described in this datasheet is classied
as waste from electronic equipment in
accordance with the European Direc-
tive 2012/19/EU (WEEE recast), and
cannot be disposed together with the
municipal undi󰀨erentiated solid waste.
• ekinex®defective devices must be returned to the ma-
nufacturer at the following address: Ekinex S.p.A. Via
Novara 35, I-28010 Vaprio d’Agogna (NO) Italy
Marks
• CE: the device complies with the Electromagnetic
Compatibility Directive (2014/30/EU), the Low Volta-
ge Directive (2014/35/EU) and the RoHS III Directive
(2011/65/EU).
• Reference Standards: EN IEC 55015:2019 = CISPR
15:2018; EN 61547:2009 = IEC 61547:2009; EN IEC
61000-3-2:2019 = IEC 61000-3-2:2018; EN 61000-3-
3:2013 + A1:2019 = IEC 61000-3-3:2013 + A1:2017.
IEC 61347-2-11:2001, AMD1:2017 used in conjuction
with IEC 61347-1:2015, AMD1:2017.
References
• IEC/EN 62386-101 - Digital addressable lighting inter-
face, General requirements - System
• IEC/EN 62386-102 Digital addressable lighting interfa-
ce, General requirements - Control gear
• IEC/EN 62386-205 - Digital addressable lighting inter-
face, Particular requirements for control gear – – Sup-
ply voltage controller for incandescent lamps (device
type 4)
• IEC 60929-E.2.1 Control interface for controllable bal-
lasts - control by DC voltage - functional specication
Maintenance
The device is maintenance-free. To clean use a dry cloth.
It must be avoided the use of solvents or other aggressive
substances.
Warning! Incorrect disposal of this product may
cause serious damage to the environment and hu-
man health. Please be informed about the correct
disposal procedures for waste collecting and pro-
cessing provided by local authorities.
!
Documentation
This datasheet refers to the release A1.0 of the ekinex®
device EK-GD1-DL-4-HV, and is available for download
at www.ekinex.com as a PDF (Portable Data Format) le.
File name Device release Updating
STEKGD1DL4HV_EN.pdf A1.0 11 / 2023
Warnings
• Installation, electrical connection, conguration and
commissioning of the device can only be carried out by
qualied personnel in compliance with the applicable
technical standards and laws of the respective countri-
es
• Opening the housing of the device causes the imme-
diate end of the warranty period
• In case of tampering, the compliance with the essential
requirements of the applicable directives, for which the
device has been certied, is no longer guaranteed
Other information
• The instruction sheet must be delivered to the end cu-
stomer with the project documentation
• For further information on the product, please contact
the ekinex®technical support at the e-mail address:
[email protected] or visit the website www.ekinex.
com
• Each ekinex®device has a unique serial number on
the label. The serial number can be used by installers
or system integrators for documentation purposes and
has to be added in each communication addressed to
the EKINEX technical support in case of malfunctioning
of the device
• DALI, DALI2 and their logos are registered trademarks
of the Digital Illumination Interface Alliance (DiiA).
© EKINEX S.p.A. The company reserves the right to make changes to this
documentation without notice.
