DMX OPERATOR PRO
2
Table of Contents
Sections:
1 : General Introduction………………..…………………………………………………………...………3
2 : Safety Information & Maintenance……….………………………..……………………………….... 4
3 : Information Notice…………………..……………..………………………………….………………... 5
4 : Features and Specifications………………………..……………………………………………….... 5
5: Technical Specifications ……………………………………………………………………….…….....6
6: Basic Control Parts……………………………………………………………………………....….…6-8
7: Set Up & Operation……………………..…… ………………………………………………….……….9
7.1 Connections……………….…………………………………………………………………………..9
7.1.1 Setting DMX Address Channels for Moving Lights….……….……………………………9
7.1.2 Setting DMX Address Channels for Dimmer Packs (Par Cans)………………………...10
7.2 Assign Joystick to Pan & Tilt..……………………………….…………..………………….…10-12
7.3 Recording Moving Lights …………………….….…………………………………..…………….12
7.3.1 Record a Moving Light Scene..………………………………………..……..……..…12-13
7.3.2 Record a Moving Light Chase..… ………………………………….……..………..…14-15
7.4 Playback Moving Light Scenes & Chases.………………………………………….….…….…16
7.4.1 Playback Moving Light Scenes. ………………………………..………………………….16
7.4.2 Playback Moving Light Chases.…..………..……………………………………………...17
7.5 Edit Moving Light Chases……………………..…….…………….…………………….……..…18
7.5.1 Add Moving Light Chase Steps………….………..…………………..………..………18-19
7.5.2 Delete Moving Light Chase Steps.……….…………………………………………………19
7.5.3 Delete Moving Light Chases…………………..….………………….………………..…...20
7.6 Recording Par Cans Scenes & Chases…….……..……………………………….……….…...21
7.6.1 Record a Par Can Scene…….…………………………….…………..………..……..21-22
7.6.2 Record a Par Can Chase..………...………………….…………………………..……22-23
7.7 Playback Par Can Scenes & Chases……………..…….……………………..…………………24
7.7.1 Playback Par Can Scenes….……….……………………………………………..…...… 24
7.7.2 Playback Par Can Chases..……….………………………………..….……………….… 25
7.8 Edit a Par Can Chase…………..………………………………………………….……………….26
7.8.1 Add Par Can Chase Steps……………..…..…………………….……………..………26-27
7.8.2 Delete Par Can Chase Steps……….……..………………….………………….……..….27
7.8.3 Delete a Par Can Chase………..………..….…………………………………..….…….. 28
8: Menu Options Set Up…………………………………………………………………….….………... 29
8.1 Access Menu Options……………...…………………………….……………………….…….… 29
8.2 Save to CF Card……………………………………………………………………….....………29-30
8.3 Read CF Card…………………………………………………………………………………….30-31
8.4 Channel Patch…………………..……………………………………..………….…..………... 32-33
8.5 Pan/Tilt Fade Set Up…………………..…………………………………….…………….…… 33-34
8.6 Display Mode Set Up…………………………..……………………………………………..…34-35
8.7 MIDI Channel Set Up…………………………………………………………………….………35-36

DMX OPERATOR PRO
3
Table of Contents (Cont.)
9: MIDI Trigger Chart…………….………………………………………………………….……….….. 37
10: CF Card Important Notice……….….………….………………….……………..…………..…..…. 37
11: Erase All Memory.......................................................................................................................38
Section 1: General introduction
Thank you for choosing the Elation DMX Operator Pro. The DMX Operator Pro is a 136 channel hybrid
lighting control device designed for DJ’s, clubs and small touring applications. This controller allows
operators to easily manipulate conventional and moving lights via simple to use buttons and faders. The
DMX Operator Pro puts programming, playback and live manipulation of Scenes and Chases at your
fingertips.
The DMX Operator Pro can control up to 8 moving lights, each consisting up to 16 channels- max 128
channels. Up to 96 programmable Scenes and 8 programmable Chases can be recorded for the moving
light section. Up to 96 programmable Scenes and 6 programmable Chases can be recorded for the
conventional par can section. There is also a compact flash slot on the rear for an optional 32MB card so
programs and setting can be saved. The compact flash card is NOT universal- it is a proprietary card that
you must buy from the dealer where you purchased your console. The model number for the optional card
is “32MB CARD”.
Also incorporated are 14 quick access scene buttons, 8 for moving lights and 6 for par cans, 8 quick
access Chase buttons for moving lights and 6 Chase buttons for par cans. The DMX Operator Pro also
incorporates an assignable joystick- ideal for pan/tilt control of scanners and moving heads. A master
fader shall be used to control the overall intensity for all 8 par can channels. A separate section of 8
independent faders are included so the lighting operator can easily control par cans on the fly. Other
features include a Tap Sync button for manual Chase override, Step/Mix/Sequence button for Chase
playback, Audio button for music trigger (via internal microphone or line level input), Group button to
control more than 1 fixture at a time and four speed and fade faders for manual override of Chases.
Every unit has been thoroughly tested and carefully packed before shipment. Unpack the shipping carton
and inspect thoroughly saving the carton and all packing materials for possible use later. Check carefully
and make sure your product is not damaged and that no included accessory is missing. If your product
appears to be damaged or missing something, please do not use it- contact our customer support staff at
[phone] ext-401 for instructions on what to do.

DMX OPERATOR PRO
4
Section: 2 Safety Information & Maintenance
Please read all instructions prior to assembling, mounting, and operating your DMX OPERATOR PRO. To
protect against fire, electric shock and injury to persons, please follow the safety precautions listed below
and observe all warnings in this manual and warnings printed on the console. The following rules give
important information regarding safety during operation and maintenance for long term use. If you have
any questions regarding operation of this console, please contact our customer support staff at (800)
322-6337 ext-401.
•Use only a source of AC power that complies with local building and electrical codes
and has both overload and ground-fault protection.
•To reduce the risk of fire or electrical shock, do not expose this unit to rain or high
levels of moisture. Do not use this unit near water.
•Refer any service operation not described in this manual to a qualified technician.
•Do not dismantle or modify this unit as there are no user serviceable parts inside. Refer
all service related issues to a qualified technician.
•Use this unit only as described.
•Handle this unit carefully. Any strong shock or vibration may result in malfunction.
•Do not operate this unit when front face panel is removed.
•Any damaged or crimped AC cable should be replaced immediately. Protect the power
supply cable from being walked on or pinched.
•Do not allow children to play with this unit.
•Keep these instructions for future use.
•Heed all warnings.
•Follow all instructions.
•Clean only with dry cloth.
•Do not install near any heat sources such as heaters, stoves, amplifiers or any other
heat generating apparatus.
•Only use attachments and accessories specified by Elation Professional.
•Unplug this unit during lighting storms or when unused for long periods of time.

DMX OPERATOR PRO
5
Section: 3 Information Notice
Please read through this manual carefully and thoroughly, as it gives important information regarding
safety, use and maintenance. Keep this manual with the unit for possible future reference.
Product Modification Warning:
Elation Professional products are designed and manufactured to meet the requirements of United States
and International safety regulations. Modifications to the product could affect safety and render the
product non-compliant to relevant safety standards.
Updates & Changes:
Information and specifications in this manual are subject to change without notice. Elation Professional
assumes no responsibility or liability for any errors or inaccuracies that may appear in this manual.
Copyright:
© 2004 Elation Professional
All rights reserved. No part of this manual may be reproduced, in any form or by any means, without
permission in writing from Elation Professional.
Section: 4 Features and Specifications
•Hybrid console for 16 lights (8 moving lights and 8 conventional par cans).
•136 total DMX channels (128 channels for Moving Lights and 8 for Par Cans ).
•6 programmable Par Can Chases.
•8 programmable Moving Light Chases.
•96 programmable Scenes for Moving Lights.
•96 programmable Scenes for Par Cans.
•Speed & Fade Time faders.
•Joystick for Pan / Tilt control of Moving Lights.
•32Mb slot for exchanging data and memory files.
•Fog Machine trigger button.
•Power failure memory back up.
•MIDI Input.
•Audio input and built-in microphone for music synchronization.

DMX OPERATOR PRO
6
Section: 5 Technical Specifications
•Model………………………………….DMX OPERATOR PRO
•Power Input…………………………..DC 9~15V, 600 mA min.
•LCD……………………………………2×16 characters
•Audio Trigger…………………………Built-in microphone or line in
•DMX Output…………………….…….3 PIN female DMX connector
•Dimensions…………………………...7” (L) × 3.15” (H) × 19” (W)
•Weight…………………………………14 lbs.
Section: 6 Basic Control Parts
6.1 Front panel
•SCENE buttons:
The Scene buttons are used to playback or store Scenes for Moving Lights and Par Cans.
•CHASE button (Moving Light Section):
This Chase button is used to playback or store Chases for Moving Lights.
•CHASE button (Par Can Section):
This Chase button is used to playback or store Chases for Par Cans.
•FIXTURE buttons:
The Fixture buttons are used to select moving lights when recording Scenes and Chases or for
manual control.
•DIMMER faders:
The Dimmer faders (channels 129 thru 136) are used to adjust relevant dimming level for each
channel.
•PAGE button:
The Page button is used when selecting between pages for relevant Scenes and Chases.
•STEP / MIX / SEQ button:
Used to manually trigger Chase steps or switch between the Mix and Sequence mode Chase
playback for moving lights.
•TAP SYNC button:
There are two (2) of these buttons that temporarily override the Chase speed rate. Tap on the
button two times to enable and override originally set speeds.
•AUDIO button:
The Audio button will activate the internal microphone or a line level input for music
synchronization when Chases or Chases are played back.

DMX OPERATOR PRO
7
Section: 6 Basic Control Parts (Cont.)
•GROUP button:
The Group button is used to control more than one moving light at a time.
•BLACKOUT button:
The Blackout button takes all DMX values to zero.
•SETUP button:
The Setup button allows access to the DMX Operator Pro’s menu options.
•FOG MACHINE button:
This button will trigger a compatible fog machine when connected to the rear fog input.
•DEL button:
This button is used to delete relevant Scenes, Chase steps and entire Chases.
•RECORD button:
The Record button is used to record Scenes and Chases. It also functions as an Enter button for
various menu options.
•ESC button:
This button is used to cancel or escape relevant operation or modes.
•UP/DOWN buttons:
The Up / Down buttons are used to scroll or adjust desired levels during operation.
•CH.PAGE button:
Press this button to switch between Moving Light Channels 1-8 and Channels 9-16. When the LED
above the button is “OFF”, it means channels 1-8 are active, when the LED is “ON “, it means
channels 9-16 are active.
•FINE button:
When the Fine button is pressed, it allows for fine adjustment of PAN / TILT position (16 bit).
•“Arrow” buttons on all sides of joystick:
These buttons are used to manually adjust the PAN / TILT position for the selected moving lights.
•Joystick:
The joystick is used to control the PAN / TILT movement for selected moving lights.
•STANDBY button:
This button is used to blackout the par can channel's (129-136).
•Fade & Speed button:
This button enables and disables fade time for par can channels.
•Full On button:
Pressing this button will temporarily activate par can channels 129-136 to 100% full intensity.
•Auto button:
The Auto button is used to activate Auto trigger mode for selected par can scene page.

DMX OPERATOR PRO
8
Section: 6 Basic Control Parts (Cont.)
•ONE/MIX/SEQ button:
This button is used to select between the three modes.
•Speed Fader:
This fader is used to adjust desired Chase rate during playback.
•Fade Fader:
This fader is used to adjust desired fade time during playback.
•Audio Fader:
The Audio fader is used to adjust the internal microphones sensitivity for par can Chase playback.
•Master Fader:
The Master fader is used to proportionally control the output for par can channels 129-136..
6.2 Rear panel
•POWER ON / OFF :
The Power switch is used to turn the console ON and OFF.
•DC INPUT :
DC 9 ~15V, 500mA min. Power Supply (Included)
•AUDIO LINE INPUT :
0.1V~1Vp-p. RCA line level input.
•DMX polarity select
Use this switch to select desired DMX polarity (2-,3+ / 2+,3-).
•DMX OUT :
3 pin XLR output to send DMX data to fixtures.
•MIDI IN :
This input receives MIDI information from a MIDI device.
•FOG MACHINE INPUT :
Connect a compatible fog machine for on board monitoring and triggering.
•CF CARD socket:
The CF card socket is for our optional compact flash card used to store and exchange information.
The model number for the optional CF card is “32MB/CARD”. (It is only available through Elation
Professional).
•EXT STEP CONTROL INPUT :
This input is for an optional external foot controller.

DMX OPERATOR PRO
9
Section: 7 Set Up
7.1 Connections
(1) With an XLR male to female cable, connect the XLR male end into the DMX Operator
Pro.
(2) Connect the female XLR end into the input of your first moving light fixture or dimmer
pack.
(3) With another XLR cable, connect the male XLR end into the output of your first moving
light or dimmer pack and the female XLR end into the input of your second moving light or
dimmer pack in line.
(4) In a daisy chain manner, continue to connect the remainder of your moving lights and
dimmer packs.
7.1.1 Setting DMX Address Channels for Moving Lights
There is no fixture library incorporated into this console. Each fixture is automatically assigned
sixteen DMX channels. Therefore, you will need to set the starting DMX address channels to your
moving lights as follows:
(1) Set the starting DMX address channel on your first moving light fixture to one (1).
(2) Set the DMX channel on your second moving light fixture to seventeen (17).
(3) Set the DMX channel on your third fixture to thirty three (33).
(4) Set the DMX channel on your fourth fixture to forty nine (49).
(5) Continue to address the remainder of your fixtures according to the chart below.
Fixture # 1 2 3 4 5 6 7 8
DMX
Channel 1 17 33 49 65 81 97 113

DMX OPERATOR PRO
10
7.1.2 Setting DMX Address Channels for Dimmer Packs (Par Cans)
There is no fixture library incorporated into this console. There are eight DMX channels reserved
for par cans which will be independently controlled via eight faders. These eight DMX channels
were designed to be assigned to two four channel dimmer packs. However, you may assign them
as you like as long as they fall within the reserved DMX channels of 129 to 136. To set two four
channel dimmer packs, follow these steps:
(1) Set the starting DMX address channel on your first dimmer pack to (129)- dip switches 1
& 8 ON.
(2) Set the DMX channel on your second dimmer pack to (133)- dip switches 1,3 & 8 ON. .
7.2 Assign Joystick to Pan & Tilt
(1) Press and hold down the "SETUP" button for three (3) seconds or until the green
LED above the SETUP button comes on. The LCD will display the following with a
cursor box flashing over the # 1 option.
1. CF CARD ↓
2.ASSIGNCH.
(2) Press the "DOWN" button one (1) time so that the cursor is now flashing over the # 2
"ASSIGN CH." option. The LCD will display the following with the cursor box now
flashing over the # 2 option.
1. CFCARD ↓
2. ASSIGN CH.
(3) Press the "Record" button to enter the assign channel option. The LCD will display
the following:
CHANNEL01>OUT01
OK ESC SEL ADJ

DMX OPERATOR PRO
11
7.2 Assign Joystick to Pan & Tilt (Cont.)
(4) Press the "UP" button sixteen (16) times or until your LCD display reads "PAN
>NONE" on the top line as displayed below.
PAN >NONE
OK ESC SEL ADJ
(5) Next, press the "DOWN" button until the LCD display's the Pan channel # for your
fixture. You will have to refer to the DMX chart that came with your light to input this
information. For example, if the Pan channel of your light is channel # 1, then you
would set your controller up as displayed below.
PAN >CH01
OK ESC SEL ADJ
(6) Press the "UP" button one (1) time so that your LCD display’s "TILT >NONE" on the
top line as displayed below.
TILT >NONE
OK ESC SEL ADJ
(7) Next, press the "DOWN" button until the LCD display's the tilt channel # for your
fixture. Once again, please refer to the DMX chart that came with your light for this
information. For example, if the Tilt channel of your light is channel # 2, then you
would set your controller up as displayed below.
TILT >CH02
OK ESC SEL ADJ
(8) If your lights incorporate Pan Fine and Tilt Fine channels, repeat steps 4 thru 7.
(9) Next, press and hold down the "GROUP" button and simultaneously select
the "FIXTURE" number buttons to select the lights you wish to assign the
joystick to. All selected fixtures will have the LED above the buttons flashing.

DMX OPERATOR PRO
12
7.2 Assign Joystick to Pan & Tilt (Cont.)
(10) Now that you’ve assigned your Pan and Tilt channels to the joystick, you need to
confirm and save these settings to memory. To do this, press the "RECORD" button
one (1) time. The LCD display will momentarily read "GOOD". You can now exit menu
mode by pressing the "ESC" button two (2) times. You now should have control of
the pan and tilt using the joystick for all assigned lights.
7.3 Recording Moving Lights
7.3.1 Record a Moving Light Scene
This next section will take you through the necessary steps to record moving light Scenes. You will
be using the section for moving lights which is located on the left side of your console or all
buttons to the left of the LCD display- including buttons in the LCD display section. The Scene
buttons you will be recording to- are located on the upper top left section of your console
numbered 1 through 8. Scenes can be played back one of two ways. The first way is to manually
trigger each desired scene and the second is to include the desired group of scenes into a Chase
for automatic sequential playback.
(1) Press and hold down the "RECORD" button for three (3) seconds or until the green
LED next to the RECORD button comes on. The LCD will display the following:
SELECTASCENE
OR CHASE! PAGE01
(2) If this is your first time recording Scenes, you should start saving them on Page #01-
please go to step #3 now. If you want to select a different page number from what is
displayed, press the “PAGE” button so that the red LED above the Page button
comes ON and then use the “UP” and “DOWN” buttons to scroll through to the other
pages. To select the new page, simply stop on the desired page and go to step #3.
There are a total of 12 pages.

DMX OPERATOR PRO
13
7.3.1 Record a Moving Light Scene (Cont.)
(3) Select the “SCENE” button where you wish to record to. The selected Scene LED
will flash repeatedly. For example, if you are on Page #01 and you select Scene #1,
the LED above the #1 Scene button will flash repeatedly and your LCD will display the
following:
EDIT SCENE1/PG01
SAVE ESC PAGE01
(4) Select the “FIXTURE” or fixtures that you wish to include into the selected scene.
The selected fixture will have its LED flashing above the button. To select more than
one fixture at a time, simultaneously press and hold down the “GROUP” button and
select the fixture #’s that you want grouped. In this case, all selected fixtures will have
their LED’s flashing in tandem.
(5) Next, use the faders to set your moving lights to the look you desire. To control
channels 1-8 of your moving lights, make sure the “CH.PAGE” L E D i s O F F. To
control channels 9-16, make sure the “CH.PAGE” LED is ON.
(6) Once your look is set, press the “RECORD” button to SAVE. All LED’s will flash once
confirming that your scene has been saved. Your LCD will once again display the
following:
SELECTASCENE
OR CHASE! PAGE01
(7) To record additional Scenes, repeat steps 3 thru 6.
(8) To exit record mode, press the “ESC” button one time.

DMX OPERATOR PRO
14
7.3.2 Record a Moving Light Chase
These next steps will guide you on how to record Chases for your moving lights. Chases are a
sequence of Scenes that incorporate separate hold and fade times- the hold times work in
conjunction with the SPEED fader, the fade time’s work in conjunction with the FADE fader. It is
suggested that you record several Scenes before attempting to record a Chase. As previously
explained in the Record Scenes section, you will once again be using the moving light and LCD
display sections to record Chases. There are eight Chases that you can record up to 99 steps
each into.
(1) Press and hold down the "RECORD" button for three (3) seconds or until the green
LED next to the RECORD button comes on. The LCD will display the following:
SELECTASCENE
OR CHASE! PAGE01
(2) Select the “CHASE” button 1-8, where you wish to record to. The selected CHASE
LED will flash repeatedly. For example, if you select CHASE #1, the LED above the
#1 CHASE button will flash repeatedly and your LCD will display the following:
EDIT CHASE1/TL00
ADD ESC STEP00
(3) If you previously programmed Scenes into page #01, the LED’s above each button
containing a scene, will be on. At this point, you may select one of those Scenes or
press the “PAGE” button so that the red LED above the Page button comes on and
then use the “UP” and “DOWN” buttons to scroll through the other pages. Select the
“SCENE” # that you wish to have as your first Chase step. The LED above the
selected Scene # will then be flashing. (NOTE: YOU CAN ALSO SELECT FIXTURES,
SET THEIR PARAMETERS AND RECORD THEM INTO CHASES ON THE FLY.
HOWEVER, IF YOU ARE NEW TO DMX OR PROGRAMMING THIS CONSOLE, IT
IS STRONGLY RECOMMENDED THAT YOU SELECT PRE PROGRAMMED
SCENES TO RECORD CHASES).

DMX OPERATOR PRO
15
7.3.2 Record a Moving Light Chase (Cont.)
(4) Next, set your desired hold and fade time for your first Chase step by using the
“SPEED” fader for your HOLD time and the “FADE” fader for your FADE time. The
hold and fade time range is five tenths of a second to ten minutes. Therefore, the
maximum times that can be set to hold or fade a selected scene step is 10 minutes
and the minimum time is .5 second. Note: When adjusting the speed fader, “S”
represents “Speed” followed by the set hold time- .05 to 59.00S (Seconds), after 59
seconds, the LCD will display “1M00S”, “M” represents minutes and can be adjusted
up to 10M00S (10 minutes and 0 seconds). “F” represents Fade time.
(5) Once your scene is selected and your speed and fade times have been set, press the
“RECORD” button, all of the LED’s will flash one (1) time and your Chase step will
advance one (1) time as well. The LCD will display the following:
EDIT CHASE1/TL01
ADD ESC STEP01
•“TL” represents total Chase steps and “STEP” represents current Chase step.
This becomes important when wanting to edit your Chase later (See Editing
Moving Light Chases in section 7.5 on page 18).
(6) Repeat steps 3-5 to continue recording additional steps into your Chase. Each time
you record a new scene into your Chase, the Chase step will advance by one (1). You
can store up to 99 steps maximum per Chase.
(7) Once you’ve completed recording your Chase, press the “ESC” button two (2) times
to exit record mode.

DMX OPERATOR PRO
16
7.4 Playback Moving Light Scenes and Chases
7.4.1 Playback Moving Light Scenes
(1) Press the “PAGE” button so the red LED above the Page button comes on.
(2) Locate the page which contains the scene that you wish to playback by using the “UP
& DOWN” buttons. You will notice the Page numbers changing on the top left corner
of the LCD display as you press either the UP or DOWN buttons. (Note: As you are
scrolling through pages, the green Scene LED’s may come on and off. When an LED
is ON, this means that there is a Scene stored there- when the LED is OFF, it means
that the location is empty or has no scene stored there).
(3) Once you’ve located the page containing the scene that you want to playback, press
the desired “SCENE” # 1-8 button. The selected scene LED will begin to flash and
the scene will come ON. The green FIXTURE LED’s for fixtures which are included
into the selected scene will also come ON. You can manually select any fixture and
control it on the fly while the other fixtures continue to run the selected scene.
(4) To turn the selected scene OFF, press the same scene button or press
“BLACKOUT”. You may also select another scene in which case the originally
selected scene will turn OFF and the newly selected scene will come ON and its LED
will flash.

DMX OPERATOR PRO
17
7.4.2 Playback Moving Light Chases
Chases can be played back in MIXED or SEQUENCE modes. On the console MIXED is
abbreviated by “MIX” and SEQUENCE by “SEQ”. In MIXED mode, selected Chase LED’s will
flash simultaneously and all selected Chases will run at the same time. If a fixture or fixtures are
included into more than one (1) Chase, the last selected Chase will be the one to take precedence.
In SEQUENCE mode, selected Chases will playback one at a time in the order they were selected.
The relevant Chase LED’s will flash when running while the other Chase’s LED’s remain steadily
ON.
(1) Select the desired playback mode by pressing the “MIX/SEQ” button. When the LED
above the MIX/SEQ button is steadily ON, playback will take place in MIXED mode.
When the LED above the MIX/SEQ button is flashing, playback will take place in
SEQUENCE mode.
(2) Select the “CHASE” button that you wish to playback. The selected Chase or
Chases will begin to run immediately including the originally set speed and fade times.
However, the selected Chase speed and fade times can manually be adjusted on the
fly by simultaneously pressing the “CHASE” # button followed by the
“STEP/MIX/SEQ” button. A rapidly flashing Chase LED indicates that you can
manually override the preset speed and fade times by adjusting the “SPEED” and
“FADE” faders- the “TAP SYNC” function will also be enabled (see Tap Sync on
Pg-6) . A slow flashing Chase LED indicates that the Chase is running at its
preprogrammed speed and fade times. Adjusting the Speed and Fade fader at this
time, will have no effect. You can also manually trigger Chase steps by tapping on the
“STEP/MIX/SEQ” when desired.
(To synchronize your Chase to sound, simply press the “AUDIO” button so the red
LED above the Audio button comes ON. Any set FADE TIMES will not work in
Audio mode. The “TAP SYNC” LED will flash when ever sound is detected via an
internal microphone.)

DMX OPERATOR PRO
18
7.5 Edit Moving Light Chases
7.5.1 Add Moving Light Chase steps
(1) Press and hold down the "RECORD" button for three (3) seconds or until the green
LED next to the RECORD button comes ON. The LCD will display the following:
SELECTASCENE
OR CHASE! PAGE01
(2) Select the “CHASE” button 1-8, that you wish to edit. The selected CHASE LED will
flash repeatedly. For example, if you select CHASE #1, the LED above the #1 CHASE
button will flash repeatedly and your LCD will display the following:
EDIT CHASE1/TLXX
ADD ESC STEP00
•TLXX = Total Chase steps.
(3) Press the “PAGE” button so that the LED above its button goes OFF. Use the “UP”
and “DOWN” buttons to scroll through your Chase steps. Stop where you wish to
add a step. For example, Chase #1 contains 15 total steps and I wish to add a step
after step #7. The LCD should display the following:
EDIT CHASE1/TL15
ADD ESC STEP07
(4) Press “RECORD” button one (1) time. Your Chase step will advance by one-
“STEP08”. A temporary step will be created which is a copy of your previous step.
(5) Press the “PAGE” button so that the LED above its button comes ON. Use the “UP”
and “DOWN” buttons to scroll through the scene pages. Stop when you locate the
page # that contains the scene you wish to add and select it by pressing the
corresponding Scene # button.
(6) Press the “RECORD” button one (1) time to store the new scene.
(7) Press the “PAGE” button one (1) time then press the “DOWN” button one (1) time.

DMX OPERATOR PRO
19
7.5.1 Add Moving Light Chase steps (Cont.)
(8) Press the “DEL” button one (1) time to erase the temporary step.
(9) To delete additional steps, repeat steps 3 thru 8. Press “ESC” two (2) times to exit.
7.5.2 Delete Moving Light Chase steps
(1) Press and hold down the "RECORD" button for three (3) seconds or until the green
LED next to the RECORD button comes ON. The LCD will display the following:
SELECTASCENE
OR CHASE! PAGE01
(2) Select the “CHASE” button 1-8, that you wish to delete steps out of. The selected
CHASE LED will flash repeatedly. For example, if you select CHASE #1, the LED
above the #1 CHASE button will flash repeatedly and your LCD will display the
following:
EDIT CHASE1/TLXX
ADD ESC STEP00
•TLXX = Total Chase steps.
(3) Press the “PAGE” button so that the LED above its button goes OFF. Use the “UP”
and “DOWN” buttons to scroll through your Chase steps. Stop at the step that you
wish to delete.
(4) Press the “DEL” button one (1) time. All LED’s on you the Moving Light section of the
console will flash and your Chase step will decline by one. The step has been deleted.
To delete additional steps, repeat steps 3 & 4.
(5) Press “ESC” two (2) times to exit.

DMX OPERATOR PRO
20
7.5.3 Delete Moving Light Chases
(1) Press and hold down the "RECORD" button for three (3) seconds or until the green
LED next to the RECORD button comes on. The LCD will display the following:
SELECTASCENE
OR CHASE! PAGE01
(2) Select the “CHASE” button 1-8, that you wish to delete. The selected CHASE LED
will flash repeatedly. For example, if you select CHASE #1, the LED above the #1
CHASE button will flash repeatedly and your LCD will display the following:
EDIT CHASE1/TLXX
ADD ESC STEPXX
•TLXX = Total Chase steps.
(3) Press and hold down the same “CHASE” button then press the “DEL” button one (1)
time. The LCD will momentarily display “DEL ONE PROGRAM PLEASE WAIT….”
Once the Chase has been deleted from memory, the LCD will display the following:
EDIT CHASE1/TL00
ADD ESC STEP00
•TL00 = Indicates that there are zero (0) steps in this Chase.
(4) At this point you can record a new Chase on the same Chase button or press “ESC”
one (1) time and repeat steps 2 & 3 to delete additional Chases.
(5) To exit Chase delete mode, press “ESC” two (2) times.
