Introduction
Congratulations with the purchase of your Mistral / The Wizard of Oz with “IntraXion”
Technology.
We advise you to read this manual completely so you learn the possibilities and the use of
this system.
Different aspects can be set (see further in the manual). By means of the IntraXion
Programmer with an LCD-screen and several push buttons, information about the
functionality of the system can be displayed. Also settings can be adjusted and test
procedures can be activated via a user friendly menu.
The operator must know that he can’t take any options or functions in use, which are
against the local security or legal prescription.
The course of the game
A player inserts money and receives a number of tokens (on the central display).
By means of the joystick he can move the arm over the playfield. When he presses the
pushbutton, a token will be launched. If the player keeps the pushbutton pressed in, the
tokens will continually be launched.
The intention of the game is that a player tries to get as much points with the available
tokens.
The chips and cards are won if they are in the prize bin on the bottom of his playfield.

4
Principal of operating
We presume that the machine is set up to your wish.
If this is the case then please read first the chapter “Set Up” further in this manual
Determine the number of tokens
As the Mistral/The Wizard of Oz don‟t is a closed loop system and don‟t returns the tokens
that fell over the edge, we start to give more tokens than a regular pusher. These way
players have enough fun.
Cashbox
By emptying the machine menu „CASHBOXES‟ indicates separately the contents of the
different compartments. These meters are used to check the emptying of the cashboxes.
Besides the coin-meter there is the bill-meter that can be used for bills, tokens or credit
cards. The unit of the meter is not always the same as the monetary unit. Although every
coin-entry has a money value, some coin-entries can be set with a different unit (e.g. pieces).
After emptying the cashbox, the meters can be copied and/or cleared.
Accounts
To evaluate a long-term result, an accounting is kept the accounts are used to check the
earnings on a long term. You can clear the cashboxes daily, but let the accounts counting
Mechanical counters
Can‟t be cleared.
Each time when the controller can‟t add the mechanical an error message will appear, this to
prevent fraud. The number of error messages will be reported in the diagnostics, they only
can be cleared together with the accounts.
Also changes in settings that have influence on the result of the mechanical counters will
report an error message.

5
Working with the Intraxion Programmer
The arrows and (1) are used to navigate through the different menus and
settings.
The “Select” button (2) is used to open or close the different menus or to instigate
commands such as clear counters, restart regulator etc.
With the “Help” –button (3) can you get more information about each setting
Under specific circumstances are there possibility‟s to test the set values by pressing
“Test” –button (4). E.g. If you press T when the cursor is in front of the line “T
mechanical cycle” then the gantry will make a test cycle.
The buttons“-“and “+” (5) are for changing values.
This “i” indicates that the opposite line shows only information.
This value is unchangeable.
This “T” indicates a test function. Press to activate.
This “S” indicates a function. Press to activate.
If this is the opposite of a title or a menu, then you go back to the main menu
2
1
3
4
5

6
The Mistral / The Wizard of Oz are controlled electronically, but that doesn‟t means that it
adjusts automatically. The most imported link is, and stays, the manager.
The programmer (see picture on last page) makes it easy to adjust.
You walk through the different menus that are mutually linked, and adjust them by a simple
push on a button. The settings appear immediately on the display.
Take your time to go completely trough the settings with this manual.
Check if all tokens are played. Clear the remaining credits with the function “restart game” in
the menu “payout settings”.
Go to the menu “DEFAULT SETTINGS” (on the bottom of the main menu).
Choose your country or continent or one that joins closest to your currency or legal
regulation. Load this setting by pressing “S”.
Change your language if required, before quitting the menu.
After setting up 1 section, copy all settings to the other section by using the function “Copy all
settings”. Please note that you have to “restart game” on each section to make sure that the
payout will be correct.
Overview menu
There could be some small differences in relation to your program depending on your local
legislation.
Mistral Pusher Identification of the program. Here you find the machine
type, version, revision number and date. This information is
the most important for the technical department.
program enable*: ON = updating via the Intelli Link
connection possible. More info in program update.
firmware*: firmware version of your controller. This
firmware is important for the compatibility for soft ware
updates.
Info management This menu allows the user to simplify the menu to hide or
lock advanced settings. Hidden items (advanced
parameters OFF) are marked with a *
advanced param.*: ON= access to all settings
lock adv param.*: locks all advanced settings.
lock all param.*: locks all settings.
hide money info*: On= accounts are no longer available via the programmer
Only access via the Intelli Link
This option can only be disabled via the Intelli link.
MISTRAL PUSHER
MACHINE TYPE 61C1
VERSION 02 REV 05.5
(C)ELAUTnv 16/11/10
program enable OFF
firmware 2C
INFO MANAGEMENT
advanced param. ON
lock adv.param. OFF
lock all param. OFF
hide money info OFF

7
Accounts total out: total of won merchandise, expressed in terms of
money.
total in: total receipts, expressed in terms of money
result: amount of payout merchandise expressed in
percentage
total wins: number of won points
The accounts are used as “long term counters”. You can
check the results of a certain period. They can be used as
a base for the payment between manager and owner.
Clear the accounts by placing the cursor next to the line
“clear accounts” and press “S”.
#total wins1: number of paid points (pieces) of dispenser 1
#total wins2: number of paid points (pieces) of dispenser 2.
#total wins3: number of paid points (pieces) of dispenser 3.
Cashboxes coin in: amount of received coins.
bill/tk in: amount of received bills/tokens.
wins: total of won chips.
The “cashboxes” are used as “short term counter”.
You can use them to check the earnings by emptying the
cashbox. Clear this also by pressing “S”.
wins 1: number of paid points (pieces) of dispenser 1
wins 2: number of paid points (pieces) of dispenser 2
wins 3: number of paid points (pieces) of dispenser 3
Payout settings purchase value= the price of the purchased merchandise.
vending point= the vending price in points value
payout percentage: the percentage that you want to pay
this is the relation between purchase value and vending
points.
disp 1: points value of the chips in dispenser 1
disp 2: points value of the chips in dispenser 2.
disp 3: points value of the chips in dispenser 3.
i xx pieces/playfield: the number of chips on the palyfield,
this is not the points value on the playfield.
Restart game*:clearing the payout regulator: no money in, no chips out. If you make some
changes in the settings, than you have to restart the game. This has no influence on the
counters. This function clears also the remaining tokens.
ACCOUNTS
total out: 0.00
total in: 0.00
result: ERR%
#total wins: 0
S clear accounts
#total wins1: 0
#total wins2: 0
#total wins3: 0
CASH BOXES
coin in: 0.00
bill/tk in: 0.00
#wins: 0
S clear cashboxes
#wins1: 0
#wins2: 0
#wins3: 0
PAYOUT SETTINGS
0.20 purchase val.
= 200 vending point
payout percent. 33%
disp.1 50 points
disp.2 200 points
disp.3 100 points
i 98pieces/field
S restart game

8
Token settings start budget: mimimum budget to start
The following lines determines the bonus tokens.
All inserts will be add to each other as long the game is
not started.
Eg 4 inserts of €0.50 or 2 inserts of €1 give the same
number of tokens as 1 insert of €2.
The next lines allows you to give bonus tokens. You can
give more tokens for a larger amount.
Attention: the pay out percentage will raise with extra
tokens.
The value of the reference channel (tot.of (ref)) is used as
base for the calculation.
token limit*:coin and bill acceptor will be disabled when
you reach this limit. Once the tokens fall below this limit,
the coin and bill acceptor are again enabled.
money limit*:coin and bill acceptors will be disabled
when you reach this limit. You have to play all tokens
before it will be enabled again.
Bonus Prizes This menu allows you to give extra chips for a specific
amount e.g. 2 extra chips for a total of € 5. On each insert
of 5 euro 2 extra chips of dispenser 1 will be dispensed on
the playfield.
Game settings volume game: volume during the game
volume attr: volume during the attract mode.
attract time: the interval time between the attraction when
there is not being played.
free game mode: if this function is on, you can play
without inserting any money. This has no influence on the
counters or pay out regulator. The bonus wheel is disabled
with this function.
standby: ON= standby, not possible to insert money, on the display 1 bar will light up.
Dispenser 1 settings refill lock: by using the function “get dispenser x” the “refill
lock” will turn automatticaly to ON.
The carrousel wil stop dispensing chips. At the end of the
service, press S in front of this line to tunr it back OFF
get dispenser 1: gets dispenser 1 to the middle of this
playfield
refill disp 1: Press S to insert the amount of chips of the
bulk fill. Changable with + and –.
disp1 alarm: when this amount is reached an error wil be displayed
tot refill1: amount of total filled chips when the refill function is used.This amount will be
cleared with the accounts
TOKEN SETTINGS
start budget 2.00
* 1 tokens for
(minimum val)0.10
* 12 tokens for
a total of 1.00
* 70 tokens for a
total of (ref) 5.00
* 150 tokens for
a total of 10.00
* 350 tokens for
a total of 20.00
*1000 tokens for
a total of 50.00
tokens limit 2000
money limit 50.00
GAME SETTINGS
volume game 12/30
volume attr. 20/30
attract time 10 min
free game mode OFF
standby OFF
DISPENSER1 SETTINGS
S refill lock OFF
S get dispenser 1
S refill disp1 20
S disp1 alarm 0
i total refill1 0
BONUS PRIZES
* 0 exta prizes for
a total of 20.00
0 exta prizes for
a total of 50.00

9
Dispenser 2 setting Idem as dispenser 1 settings
Dispenser 3 settings Idem as dispenser 1 settings
Money settings To adjust the value on each channel. Coin 1*is equal to
the first channel of the coin acceptor.
bill value *:the value of the first bill on the bill acceptor.
money value*:minimum unit of account (value factor)
decimals*:the visual numbers after the comma. If there is
indicated 1 than the money values will be displayed up to 1
number after the comma ex. 20,5
meter divider*:the value of a pulse to the mechanical
counters. E.g. if „1‟ is marked, then 1 pulse will be given to
the counters by each Euro. A 2 Euro coin will count 2 units
on the counter. The amount you see will be the amount in
Euros...
System settings link address: every playfield in an Intelli Link network has
a unique number that can be set in this menu. 1 is the
standard number and if this is 0 than it will not be
recognized as present in the link.
initial filling*: this function is used when you bring the
machine into use, to fill the playfield with the set number of
chips.
copy all settings *: this function allows you to copy the
settings to the other sections.
load EUR / load USA / load UK*:load the default money and credit, specific for your
country or continent and depending on your local legislation. These settings can be individual
changed when necessary.
Diagnostics last coin: the value of the last insert.
payout rate: the frequency by which the chips will be
dropped on teh playfield.
SYSTEM SETTINGS
link address 1
S initial filling
S copy all settings
S load defaults EUR
S load defaults USA
S load defaults UK
DIAGNOSTICS
i last coin 0.00
i payout rate 1/10
MONEY SETTINGS
coin 1 0.20
coin 2 0.50
coin 3 1.00
coin 4 2.00
coin 5 0.10
bill value 5.00
money value 0.05
decimals 2
meter divider 1.00
MONEY SETTINGS
coin 1 0.20
coin 2 0.50
coin 3 1.00
coin 4 2.00
coin 5 0.10
bill value 5.00
money value 0.05
decimals 2
meter divider 1.00
DISPENSER2 SETTINGS
S refill lock OFF
S get dispenser 2
S refill disp2 20
S disp1 alarm 0
i total refill2 0
DISPENSER3 SETTINGS
S refill lock OFF
S get dispenser 3
S refill disp1 20
S disp1 alarm 0
i total refill1 0

10
TEST INFO
i coin in 00000000
i bill in 00000000
i ctrl but. 00000000
i det&ext 00000000
i lamps 00000000
i coinm.out 00000I00
i hopper1 00000000
i XYstatus 00000I00
i Xposition 0
i lnk.stat 00000000
i data in 0
Mechanical diagnostics calibrate carr: calibration of the carousel
tot tokens: Total amount of the played tokens
clear tot tokens: to clear the total of played tokens.
Module Info playfield nb *:identification number of the playfield.
Following lines are use to verify the different ITX modules
ON= OK
OFF= not OK
ERR= does not work correct.
ID= ITLNK_A0000*: software version on this
Test info This menu shows if the input to the IntraXion controller is
activated (=I) or not (=O), a very useful tool to track
problems with the system.
The list below shows all in and outputs, and where you can
activate them.
The information lines above indicates if the input to the Intelli controller is activated
(=I) or not (=O). The inputs are counted from the right to the left.
If an input changes, it has to be visible only on 1 position!
This menu will help you to localize and possibly solve a problem.
in/output checklist via Interaxion programmer
0/1
0/1
0/1
0/1
0/1
0/1
0/1
0/1
coin inputs
x
x
x
coin 5
coin 4
coin 3
coin 2
coin 1
bill inputs
bill error
B4 inh2
B3 inh1
bill 2
bill 1
x
x
x
ctrl buttons inputs*
x
ana LGC
SEL1
fire
left
right
back
forw
set buttons*
x
x
x
x
x
x
SEL3
SEL2
both =SEL4
dispenser 1/2 inputs*
x
ana lgc
refill2
refill1
disp2b
disp2a
disp1b
disp1a
detect & ext input
x
ctr fb
ADC lgc
dpr in
tilt
ext door
ctr conn
prize det
control lamp out*
SEL4fsh
LP SEL4
SEL3fsh
LP SEL3
SEL2fsh
LP sel2
SEL1fsh
LP SEL1
coinmech outputs
ctr3
ctr2
ctr1
inh2
inh1
coin enb
err out
win out
playf inputs*
x
ana LGC
SW16
SW15
SW14
SW13
SW12
SW11
*=external source
MODULE INFO
i play field nb. 0
i soundfile
ID= ITXSND6100R00
i controls mod. ON
ID= ITBIO_D0101
i motor mod. ON
ID= ITXGX_B0102
i hopper mod. ON
ID= ITBIO_D0401
i bonus mod. ON
ID= ITBNS_B0101
i linker mod. ON
ID= ITLNK_B0002
i caroussel mod. ON
ID= ITX6200R02.5
MECHANIC DIAGN.
S calibrate carr.
i tot tokens 0
S clear tot tokens

11
Set Up
Attention: after set up 1 section, copy all settings to the other sections. For this you
can use the function “copy all settings”. Then “restart game” on each section.
Volgende instellingen zijn het belangrijkste en hebben ook invloed op de uitbetaling.
Token settings Set first the number the number of tokens you want to give
for each amount.(€1, €2, €5,€10…) Keep in mind that how
more extra tokens you give, the higher the payement will
be. The number of tokens en money value on the
reference channel (marked in yellow) determines the set
payout percentage.
Each insert of this amount will pay exactly the set
percentage.
If you give extra tokens, each insert higher than the
reference channel, will pay raise the payout percentage.
Payout settings Set first the points value:
If the purchase value is eg € 0.20, and sell this for eg 200pt
If the proportion between these is 30% then you have to
set tis like this.
Next set the value of the chips in dispenser 1,2 and 3, this
have be in proportion with the earlier set settings.
PAYOUT SETTINGS
0.20 purchase val.
= 200 vending point
payout percent. 33%
disp.1 50 points
disp.2 200 points
disp.3 100 points
i 98pieces/field
S restart game
TOKEN SETTINGS
start budget 2.00
* 1 tokens for
(minimum val)0.10
* 12 tokens for
a total of 1.00
* 70 tokens for a
total of (ref) 5.00
* 150 tokens for
a total of 10.00
* 350 tokens for
a total of 20.00
*1000 tokens for
a total of 50.00
tokens limit 2000
money limit 50.00

12
Warnings and Errors
Warnings and errors are visible on the Intelli Programmer.
They appear when a bad working of the crane is detected.
You can clear these by pressing “S”. You clear only the mentioning and not the problem. By
an error a code will appear on the token display.
Warning:
The coin acceptor will be disabled when the good working of the crane isn‟t guaranteed.
First you have to solve the problem and clear the error message before you can continue to
again.
Warning:
Information about a potential problem.
You can still play without solving the possible problem.
Display code: 1
Reboot the machine. Contact your local dealer if the failure
repeats.
Display code: 2
Check if all doors are closed well. Otherwise check the
door contacts and wiring for signs of damage. Only visible
via the Intelli Link
Display code: 3
This warning appears when the sensor of the launcher
doesn‟t or not in time detects a token.
Display code: 4
The proportion between money and token settings is too
low, check the token settings.
Display code: 5
Electronic account meters overflow, clear the account
meter.
Display code: 6
Electronic cashbox meters overflow, clear the cashbox
meters meter
Display code: 7
The coin- or bill acceptor has reported a problem. Check
the coin/bill acceptor on their functionality.
Display code: 8
This warning appears when dispenser 1 doesn‟t paid out,
possible the dispenser is empty or obstructed.
ERRORS AND WARNINGS
door open. Druk S
om verder te gaan
FOUTEN EN WAARSCHUW
game price n corr
Press S to resume
ERRORS AND WARNINGS
account meter ovl
Press S to resume
ERRORS AND WARNINGS
cashbox meter ovl
Press S to resume
ERRORS AND WARNINGS
coin/bill accept
Press S to resume
ERRORS AND WARNINGS
system malfuction.
Press S to resume
ERRORS AND WARNINGS
prize disp.1
emptyPress S to
resume
ERRORS AND WARNINGS
launcher timeout.
Press S to resume

13
Display code: 9
This warning appears when dispenser 2 doesn‟t paid out,
possible the dispenser is empty or obstructed.
Display code: 10
This warning appears when dispenser 3 doesn‟t paid out,
possible the dispenser is empty or obstructed.
Display code: 11
The proportion between purchase price, percentage and
points value are not correct in regard to other settings.
Display code: 12
If the payout, number of chips on the playfield, is not
between the 65 and 125 pieces.
Display code: 13
The dispenser is almost empty. Only if you fill the
dispensers with the refill function.
Display code: 14
The refill function can be used again after closing and re
open the door.
Display code: 31
No communication with the Linker module.
Display code:32
No communication with the carrousel controller.
Display code:33
Mechanical counters are not connected.
Display code:34
No communication with the hopper module
Display code:35
No communication with the motor module.
ERRORS AND WARNINGS
prize disp.2
emptyPress S to
resume
FOUTEN EN WAARSCHUW
linker mod. status
Press S to resume
ERRORS AND WARNINGS
carrousel status
Press S to resume
ERRORS AND WARNINGS
meters disconnect
Press S to resume
ERRORS AND WARNINGS
hopper mod status
Press S to resume
ERRORS AND WARNINGS
prize disp.3
emptyPress S to
resume
ERRORS AND WARNINGS
reopen window first
Press S to resume
ERRORS AND WARNINGS
motor mod status
Press S to resume
ERRORS AND WARNINGS
prizes/field n corr
Press S to resume
ERRORS AND WARNINGS
product def n corr
Press S to resume
ERRORS AND WARNINGS
prizes low al.
Press S to resume

14
Display code:36
No communication with the controls module.
Display code:37
No communication with the display module.
Display code:38
Problem with the escalator hopper, can be obstructed or
didn‟t pay in time.
Display code:39
Problem with the escalator hopper sensor. No sensor
connected or obstructed.
Display code:40
Problem with the movement of the carousel.
Display code:41
The payout of the chips is not between the 65 and 125
pieces on the playfield.
Display code:42
The payout of the chips is not between the 65 and 125
pieces on the playfield.
Display code:43
Too many or too little chips on the playfield.
Display code:44
The carrousel is locked, unlock this in the menu “dispenser
setting x “ by pressing S in front of the line “refill lock”, this
should be on OFF.
ERRORS AND WARNINGS
controls mod status
Press S to resume
ERRORS AND WARNINGS
display mod status
Press S to resume
ERRORS AND WARNINGS
escalator timeout
Press S to resume
ERRORS AND WARNINGS
carrousel motor
Press S to resume
ERRORS AND WARNINGS
escal. coin sensor
Press S to resume
ERRORS AND WARNINGS
lower point values
Press S to resume
ERRORS AND WARNINGS
higher point values
Press S to resume
ERRORS AND WARNINGS
payout calculation
Press S to resume
ERRORS AND WARNINGS
refill lock on
Press S to resume
