USER MANUAL
ULTRASLIM 800 WATT OIL FILLED RADIATOR
EORW800LED
Thank you for choosing electriQ
Please read the manual before using this heater
and keep it safe for future reference.
Visit our page www.electriQ.co.uk for our entire product range
THIS PRODUCT IS ONLY SUITABLE FOR WELL INSULATED SPACES OR
OCCASIONAL USE.

2
CONTENTS
SAFETY
3
PRODUCT OVERVIEW
5
OPERATION
5
TECHNICAL SPECIFICATIONS
7
CLEANING AND MAINTENANCE
8
TROUBLESHOOTING
8
PRODUCT FICHE
9

3
SAFETY INSTRUCTIONS
IMPORTANT
•Carefully read the instructions before operating the unit
•This appliance is for indoor use only.
•Rating: This unit must be only connected to a 220-240 V / 50 Hz earthed
outlet.
•Installation must be in accordance with regulations of the country where the
unit is used.
•If you are in any doubt about the suitability of your electrical supply have it
checked and, if necessary, modified by a qualified electrician.
•This heater has been tested and is safe to use. However, as with any electrical
appliance use it with care.
•Disconnect the power from the unit before dismantling, assembling or
cleaning.
•Avoid touching any moving parts within the appliance.
•Never insert fingers, pencils or any other objects though the guard.
•This appliance can be used by Children aged from 8 years and above and
persons with reduced physical, sensory or mental capabilities or lack of
experience and knowledge if they have been given supervision or instruction
concerning use of the appliance in a safe way and understand the hazards
involved.
•Children shall not play with the appliance.
•Cleaning and user maintenance shall not be carried out by children.
•Children aged from 3 years and less than 8 years shall only switch on/off the
appliance provided that it has been placed or installed in its intended normal
operating position and they have been given supervision or instruction
concerning use of the appliance in a safe way and understand the hazards
involved.
•Children aged from 3 years and less than 8 years shall not plug in, regulate,
or clean the appliance or perform user maintenance.
•Children under 3 years should be kept away unless continuously supervised.
•Some parts of this product can become very hot and cause burns. Particular
attention has to be given where children and vulnerable people are present.
•Do not clean the unit by spraying it or immersing it in water.
•Never connect the unit to an electrical outlet using an extension cord. If an
outlet is not available, one should be installed by a qualified electrician.
•Never operate this appliance if the unit, cord or plug is damaged. Ensure the
power cord is not stretched, exposed to sharp object/edges, or routed under
the unit.
•Any service other than regular cleaning should be performed by an authorised
service representative. Failure to comply could result in a voided warranty.

4
•Never use the plug as a switch to start and turn off the heater. Use the
provided power button located on the control panel.
•Do not use an external timer.
•Do not cover the appliance, or place items close to the unit which may restrict
airflow, as this may present a fire risk.
•The heater must not be located immediately below a socket outlet.
•Always place the unit on a dry and stable surface. Do not move or tilt the unit.
•Avoid keeping the unit in direct sunlight for a long period of time.
•The heater is designed to be used at temperatures above -20°C. If it is
exposed to temperatures below this, it must be allowed to warm above this
level before operation.
•Do not attempt to repair, disassemble or modify the appliance. This unit
contains no user-serviceable parts.
•Always unplug or disconnect the appliance from the mains power supply
when not in use, or when moving or cleaning it. Do not pull the cord to unplug
the heater.
•Keep the heater clean. Do not allow any object to enter the ventilation or
exhaust opening as this may cause electric shock, fire, or damage to the
heater.
•Do not use the appliance for anything other than its intended use. It is
designed for domestic indoor use only.
•There may be a trace of odour during the first few minutes of initial use, or
after a period of storage. This is normal and will quickly disappear.
•This appliance has hot and arching or sparking parts inside. Do not use it in
areas where gasoline, paint, or any flammable liquids are used or stored.
•This appliance is not intended for use in bathrooms, laundry areas and similar
humid locations. Never locate this appliance where it may fall into a bathtub
or otherwise become exposed to water.
•WARNING: To reduce the risk of fire or electrical shock, DO NOT use this
appliance with any solid-state Speed Control Device or any variable speed
controllers.
ENERGY SAVING AND UNIT SAFETY PROTECTION TIPS
•Do not cover or restrict the airflow. Do not use in dusty environment.
•For safety and maximum performance, the minimum distance from a wall or
objects should be 50cm.

5
PRODUCT OVERVIEW
OPERATION
Press the ON/OFF button to start the heater. To adjust the desired temperature,
press the SET button and then adjust using the + and –buttons.
SETTING THE DAY AND TIME
•Press the SET button 3 times so that the day is flashing and use the + and –
buttons to adjust
•Press the SET button 4 times so that the hour is flashing and use the + and –
buttons to adjust
•Press the SET button 5 times to so that the minute is flashing and use the + and –
buttons to adjust
NOTE: The clock will be reset to default when the unit is powered off.
F
+
-
Set
Mode
WE P3
25⁰C
ST
W
: - -
OFF
ON/OFF
Display
Temperature Up
Temperature
Down
Mode Selection
Temperature
Set

6
CHILD LOCK
Press ”+” and ”–” at the same time to enable child lock. In child lock mode the control
panel is deactivated. To exit child lock mode, press ”+” and ”–” again at the same
time.
OPEN WINDOW FUNCTION
Press “MODE” for 3 seconds, a buzzer will sound and the open window symbol
will be displayed .
Press “MODE” for 3 seconds to deactivate the feature.
When this function is activated , the heater will stop working when the room
temperature drops by 3℃in 1 minute.
24 HOUR TIMER
The inbuilt timer will allow you to set the unit to turn off after a set period of time.
Please note this timer is a one-use timer, and starts operation when programmed.
1. While the unit is operating, press the SET button twice to activate the
timer. The timer symbol will display on the screen.
2. Use the Temperature + and – buttons to adjust its duration.
3. Once the set time has elapsed, the unit will turn off automatically.
Press the POWER button before the time has elapsed, the timer will be cancelled
and the unit will turn off.
7 DAY TIMER
Press “MODE” button to enter the 7-day timer mode then choose between the pre-
sets: P1, P2, P3, P4 using the “+”and “-”buttons.
：Comfort mode is 22℃
：ECO mode is 18 ℃
P1 TIMER (Monday - Sunday) is a Pre-set program and no adjustment is possible

7
P2 TIMER:
Is preset and cannot be adjusted. The heater will has different settings for weekdays
and weekends.
(Monday - Friday) Pre set program
(Saturday - Sunday) Pre set program
P3：Monday-Sunday Can be customised. 18-22℃
•Press the MODE button 3 times and set the day using the + and –buttons.
•Press the MODE button 4 times and set the hour using the + and –buttons.
•Press the MODE button 5 times and set the minute using the + and –buttons.
Set all days up to Sunday, then set the temperature for each day
P4：ANTI-FROST
“P4 Fr” will be displayed on screen and the heater will aiom to keep the temperature
between 4°C and 7°C.
TECHNICAL SPECIFICATIONS
Model no.
EORW800LED
Voltage
220-240V
Frequency
50hz
Max power
800W
IP Rating
IP22
Product
Dimensions
950x65x550mm

8
MAINTENANCE
CLEANING AND STORAGE
ATTENTION: Please shut off the unit and unplug from the mains before
cleaning or performing any maintenance.
CLEANING THE SURFACE
•Clean the heater with a duster or a soft wet cloth.
Do not use chemical solvents (such as benzene, alcohol or gasoline) as they
may cause irreversible damage. Make sure no water enters the control panel
or gaps in the casing.
•Do not run the unit until completely dry.
•Place the heater in its original box or cover to protect it from dust when not
in use.
•Store it in a cool dry place.
TROUBLESHOOTING
Do not repair or disassemble the unit by yourself, unauthorized repair attempts will
invalidate the warranty and may cause bodily harm.
Issue
Possible Reason
Solution
No power
1. Power cord is unconnected
2. There is no power from socket
3. The power switch on the rear of the unit
is turned off.
1. Connect the power cord
2. Check socket is turned on
3. Ensure the power switch on
the rear of the unit is in the on
position
Odour
emission
from unit
1. New unit. When the unit is used for the
first time the fan motor may produce and
odour which will dissipate within a week of
use
1. No action required
Strong
vibrations
and noise
1. Unit is not placed on a flat surface
2. Unit may be damaged
1. Place on a flat surface. May
put an anti-vibration mat
underneath
2. If the heater is damaged
discontinue use and contact the
service centre.
If the above solutions do not resolve the problem please contact the service centre.
Disposal: Do not dispose this product as unsorted municipal waste. Collection of such
waste must be handled separately as special treatment is necessary.
Recycling facilities are now available for all customers at which you can
deposit your old electrical products. Customers will be able to take any
old electrical equipment to participating civic amenity sites run by their
local councils. Please remember that this equipment will be further
handled during the recycling process, so please be considerate when
depositing your equipment. Please contact the local council for details of
your local household waste recycling centres.

9
electriQ UK SUPPORT
www.electriQ.co.uk/support
Please, for your own convenience, make these simple checks before calling
the service line.
If the unit still fails to operate call: 0871 620 1057 or complete the online
form
1. Is the unit plugged into the mains?
2. Is the fuse OK?
3. Switch the unit off and wait three minutes to see if the issue is resolved.
Restart the unit.
Office hours: 9AM - 5PM Monday to Friday
www.electriQ.co.uk
Unit J6, Lowfields Business Park
Lowfields Way, Elland
West Yorkshire, HX5 9DA

10
Model Identifier: EORW800LED
Item
Symbol
Value
Unit
Item
Unit
Heat Output
Type of heat input, for electric storage local
space heaters only (select one)
Nominal heat
output
Pnom
0.8
kW
manual heat charge control, with integrated
thermostat
No
Minimal heat
output
Pmin
0.0
kW
manual heat charge control with room
and/or outdoor temperature feedback
No
Maximum
continuous
heat output
Pmax
0.8
kW
electronic heat charge control with room
and/or outdoor temperature feedback
No
Auxiliary electricity consumption
fan assisted heat output
No
At nominal
heat output
elmax
N/A
kW
Type of heat output/room temperature control
(select one)
At minimum
heat output
elmin
N/A
kW
single stage heat output and no room
temperature control
No
In standby
mode
elSB
1
W
two or more manual stages, no room
temperature control
No
with mechanical thermostat room
temperature control
No
with electronic room temperature control
No
with electronic room temperature control
plus day timer
No
with electronic room temperature control
plus week timer
Yes
Other control options (multiple selections
possible)
room temperature control with presence
detection
No
room temperature control, with open
window detection
Yes
with distance control option
No
with adaptive start control
No
with working time limitation
No
with black bulb sensor
No
Contact
Details
electriQ, Unit J6, Lowfields Business Park, Lowfields Way, Elland,
West Yorkshire, HX5 9DA
