ElectrIQ ECFIRPH7W User manual

USER MANUAL
Light Panel Far Infrared Carbon Heater
with Smart App
ECFIRPH7W
Thank you for choosing electriQ
Please read the manual before using this heater
and keep it safe for future reference.
Visit our page www.electriQ.co.uk for our entire product range

2
CONTENTS
SAFETY INSTRUCTIONS
3
PRODUCT OVERVIEW
6
INSTALLATION
5
OPERATION
7
SETTING UP THE APP
8
USING THE APP
13
CLEANING AND MAINTENANCE
19
TROUBLESHOOTING
19
TECHNICAL SPECIFICATIONS
20
SUPPORT
20
PRODUCT FICHE
21

3
SAFETY INSTRUCTIONS
IMPORTANT
•Carefully read the instructions before operating the unit
•This appliance is for indoor use only.
•Rating: This unit must be only connected to a 220-240 V / 50 Hz earthed outlet.
•Installation must be in accordance with the regulations of the country where the
unit is used.
•If you are in any doubt about the suitability of your electrical supply have it
checked and, if necessary, modified by a qualified electrician.
•This heater has been tested and is safe to use. However, as with any electrical
appliance - use it with care.
•Disconnect the power from the unit before dismantling, assembling or cleaning.
•Avoid touching any moving parts within the appliance.
•Never insert fingers, pencils or any other objects through the guard.
•This appliance can be used by Children aged from 8 years and above and
persons with reduced physical, sensory or mental capabilities or lack of
experience and knowledge if they have been given supervision or instruction
concerning use of the appliance in a safe way and understand the hazards
involved. Children shall not play with the appliance. Cleaning and user
maintenance shall not be carried out by children.
•Children aged from 3 years and less than 8 years shall only switch on/off the
appliance provided that it has been placed or installed in its intended normal
operating position and they have been given supervision or instruction
concerning use of the appliance in a safe way and understand the hazards
involved. Children aged from 3 years and less than 8 years shall not plug in,
regulate, or clean the appliance or perform user maintenance.
•Children under 3 years should be kept away unless continuously supervised.
•Some parts of this product can become very hot and cause burns. Particular
attention has to be given where children and vulnerable people are present.
•Do not clean the unit by spraying it or immersing it in water.
•Never connect the unit to an electrical outlet using an extension cord. If an outlet
is not available, one should be installed by a qualified electrician.
•Never operate this appliance if the unit, cord or plug is damaged. Ensure the
power cord is not stretched, exposed to sharp object/edges, or routed under the
unit.
•Any service other than regular cleaning should be performed by an authorised
service representative. Failure to comply could result in a voided warranty.
•Never use the plug as a switch to start and turn off the heater. Use the provided
power switch on the rear of the unit.
•Do not use an external timer.
•Do not cover the air inlet or outlet, or place items close to the unit which may

4
restrict airflow, as this may present a fire risk.
•The heater must not be located immediately below a socket outlet.
•Always ensure the unit is secure before operation. Do not use on unstable or
uneven surfaces and if wall-mounted, it must be securely attached to a suitable
wall.
•Do not move or tilt the unit.
•Avoid keeping the unit in direct sunlight for a long period of time.
•The heater is designed to be used at temperatures above -20°C. If it is exposed
to temperatures below this, it must be allowed to warm above this level before
operation.
•Do not attempt to repair, disassemble or modify the appliance. This unit contains
no user-serviceable parts.
•Always unplug or disconnect the appliance from the mains power supply when
not in use, or when moving or cleaning it. Do not pull the cord to unplug the
heater.
•Keep the heater clean. Do not allow any object to enter the ventilation or exhaust
opening as this may cause electric shock, fire, or damage to the heater.
•Do not use the appliance for anything other than its intended use. It is designed
for domestic indoor use only.
•There may be a trace of odour during the first few minutes of initial use, or after
a period of storage. This is normal and will quickly disappear.
•This appliance has hot and arcing or sparking parts inside. Do not use it in areas
where gasoline, paint, or any flammable liquids are used or stored.
•This appliance is not intended for use in bathrooms, laundry areas and similar
humid locations. Never locate this appliance where it may fall into a bathtub or
otherwise become exposed to water.
•If the unit is wall-mounted, it must be installed in accordance with current
regulations for the area of installation. If unsure, professional advice should be
sought.
•WARNING: To reduce the risk of fire or electrical shock, DO NOT use this
appliance with any solid-state Speed Control Device or any variable speed
controllers.
ENERGY SAVING AND UNIT SAFETY PROTECTION TIP
•Do not cover or restrict the airflow. Do not use in a dusty environment.
•For safety and maximum performance, when used as a portable unit the minimum
distance from a wall or objects should be 50cm.

5
WALL MOUNTING INSTRUCTIONS
NOTE: This heater is designed to be mounted vertically on a solid wall. If the unit
does not feel secure when fixed, you will need appropriate fixings for the wall (not
supplied). Please make sure the wall is safe to mount. We highly recommend to
have the panel installed by a qualified electrician or installer. The distance from the
heater to the floor must be at least 20 cm.
Step 1. Use the supplied template to mark the position
of the holes on the wall.
Step 2. Drill holes using an 8mm drill bit.
Step 3. Insert the wall plugs into the holes.
Step 4. Screw in the supplied screws to the wall.
Step 5. Mount the panel on the screws.
Step 6. Move the panel to the left and then down until it’s secured.

6
OPERATION
DISPLAY
Power
Turns the unit
On or Off
WIFI
Use to change
the WIFI mode
Temperature
Up
Used to
increase the
desired
temperature
Temperature
Down
Used to
decrease the
desired
temperature
Timer Button
Used to set a
countdown
timer and to
disable WIFI
Heating
Status
Indicates
whether the
heater is
currently
operating
1
Weekday
2
Open Window Indicator
3
Timer Indicator
4
WIFI Indicator
5
Time
6
Temperature
7
Modes
Power Button
WIFI Button
Temperature
Up
Temperature
Down
Timer Button
Heating Status
Indicator
1 2 3 4
5
6
7

7
OPERATION
MANUAL CONTROL
Adjust your desired temperature room temperature using the “-” and “+” buttons,
after 2 seconds the updated desired temperature will be set.
TEMPERATURE CALIBRATION
If you find that the temperature display is not showing an accurate reflection of the
room temperature, it can be adjusted. Press and hold the “-” button for 5 seconds to
enter temperature calibration. The amount the temperature is changed by can be
adjusted using the “-” or “+” buttons (Range: -5 to 5⁰C)
TIMER
The inbuilt timer will allow you to set the unit to turn off after a set period of time.
Please note this timer is a one-use timer, and starts operation when programmed.
1. While the unit is operating, press the TIMER button to activate the timer.
2. Use the Temperature + and – buttons to adjust its duration.
3. Once the set time has elapsed, the unit will turn off automatically.
Press the POWER button before the time has elapsed, the timer will be cancelled
and the unit will turn off.
OPEN WINDOW DETECTION
This heater is equipped with an open window detection function. If the room
temperature decreases dramatically in a short period of time it will recognize that a
window is open. The window sign on the screen will start to flash and the heater will
enter standby for 30 minutes. You can deactivate and activate this function holding
the Timer button for 5 seconds, and the open window sign on the screen will
disappear.

8
CONNECTING THE APPLIANCE TO WIFI
DOWNLOAD THE APP TO YOUR PHONE
Download the” TUYA SMART” app, from your chosen app store, using the QR codes
below, or by searching for the app in your chosen store.
Android IOS
MODES AVAILABLE FOR SETUP
The heater has two different setup modes, Quick Connection and AP (Access Point).
The quick connection is a quick and simple way to set the unit up. The AP connection
uses a direct local WiFi connection between your phone and the heater to upload the
network details.
By default, WIFI is enabled when you switch the heater on. The WIFI symbol will flash
until a connection is established. To turn the WiFi off, press and hold the WiFi button
for 10 seconds until the heater bleeps. The WiFi symbol will flash quickly to indicate
the unit is in quick connection mode
Please ensure your device is in the correct WiFi connection mode for the connection
type you are attempting, the flashing WiFi indicator on your heater will indicate this.
Connection Type
Frequency of Flashes
Quick Connection
Flashes twice per second
AP (Access Point)
Flashes once per second
CHANGING BETWEEN CONNECTION TYPES
To change between the Wifi connection modes press the WiFi button.

9
REGISTER THE APP
2. Read the Privacy policy and
press the Agree Button.
3. Enter your email address or
phone number and press
continue to register.
4. A verification code will be
sent by the method selected
in step 3. Enter the code into
the app.
2. The app is now registered.
It will automatically log you
in following registration.
5. Type in the password you
would like to create. This
needs to be 6-20 characters,
with letters and numbers.
1. Press on the register button
at the bottom of the screen.

10
SETTING UP YOUR HOME WITHIN THE APP
TUYA is designed so it can work with a large number of compatible smart devices
within your home. It can also be set up to work with multiple devices within different
houses as such during the setup process, the app requires that different areas are
created and named to allow easy management of all your devices. When new devices
are added, they are assigned to one of the rooms you have created.
CREATING ROOMS
1. Press on the ADD HOME
button.
3. Type in a name for your
home,
4. Press on the location button
to select the location of your
home. (See SETTING
YOUR LOCATION below)
5. New rooms can be added
by pressing the ADD
ANOTHER ROOM option at
the bottom. (See ADD
ANOTHER ROOM below)
6. Untick any rooms that are
not required on the app.
7. Press DONE in the top right
corner.
SETTING YOUR LOCATION
Use your finger to
move the orange
HOME symbol.
When the symbol is
in the approximate
location of your
home, press the
confirm button in
the top right corner.
Location details
allows the app to
be set up later to
respond to weather
conditions in your
area.
ADD ANOTHER ROOM
Type in the
name of the
room, and
press Done in
the top right
corner

11
CONNECTING USING THE QUICK CONNECTION METHOD
Before initiating the connection, make sure the WiFi indicator is flashing twice per
second. If not follow the instructions for changing the connection mode. Also ensure
your phone is connected to the WiFi network. (We advise turning mobile data off during
setup)
2. Select the type of device
as “Heater” within the Home
Appliance tab.
3. Press on the orange button at
the bottom of the screen.
4. Enter your Wi-Fi password
and press confirm.
5. This will then transfer the
settings to the heater. Wait for
this to complete. If this fails,
retry.
1. Open app and press “+” to
add device, or use the add
device button

12
CONNECTING USING AP MODE (ALTERNATIVE METHOD)
Before initiating the connection, make sure the unit is in standby mode, with the WiFi
Indicator flashing once per second. If not follow the instructions for changing the
WiFi connection mode. Also ensure your phone is connected to the WiFi network.
(We advise turning mobile data off during setup)
1. Open app and press “+” to
add device, or use the add
device button
2. Select the type of device
as “Heater” within the Home
Appliance tab.
3. Press on the AP mode
button in the top right of the
screen.
4. Ensure the WiFi indicator on
the heater is slowly flashing
(once per second), then
press on the orange button
at the bottom of the screen
to confirm
5. Enter your WiFi password
and press confirm.
6. Go to network settings in your
phone and connect to the
“SmartLife xxx” connection.
There is no password to
enter. Then return back to the
app to complete setup.
This will then transfer the settings to the heater.
Once the connection process has completed, go back to the network settings on your phone to ensure
your phone has reconnected to your WiFi router.

13
CONTROLLING YOUR APPLIANCE THROUGH THE APP
THE HOME SCREEN
NOTE: Due to continuous development of the app, the layout and available features may be subject to change.
Each device has its own entry on the home screen to allow the user to either quickly turn the unit on or
off, or to enter the device screen to make other changes.
Smart Scene: Allows you
to program intelligent
behaviour based on the
internal and external
environment
Add Device: Add a device
to the app, and go through
the setup process.
Profile: Provides the
option for changing
settings,
Name of Heater: Press to
enter the Device Screen
Home: Return to home
screen from the Smart
Scene and Profile screens
Voice Control: Press to
give verbal instructions for
operation.

14
DEVICE SCREEN
The device screen is the main control screen for the heater, providing access to the controls to amend
the functions and settings.
Edit Name: Use to
change the name of the
heater
Back: Returns to the
Home Screen
Power: Use to turn
the unit on or off.
Device Name
Desired
Temperature:
Displays what has
been set as the
target room
temperature.
Decrease Desired
Temperature
Temperature range
15-35C
Increase Desired
Temperature
Temperature range
15-35C
Current
Temperature:
Displays what the
current temperature
is.
Countdown
Timer:
Use to set a
timer to turn the
unit on or off.
Schedule:
Use to program the
heater to change
the operation and
desired
temperature
throughout the
week.

15
SCHEDULE
Select the time you want the action to
occur, how often you want it to occur,
and whether the unit is to turn on or
off, and the desired temperature.
Press on save in the top right corner,
and the schedule is activated, and will
be visible on the main schedule
screen. Schedules can also be
amended and deleted as required.
The app provides a timer that can be
easily programmed using your phone.
This can be accessed through the
schedule option at the bottom of the
device screen.
A number of separate schedule
entries can be created to automate
operation of the heater throughout the
week. All currently created schedules
will be visible on this screen, with the
option to add a new schedule.

16
SMART SCENES
Smart Scenes is a powerful tool providing the option to customize the operation of the air heater
based both on conditions within the room and outside influences. This gives the user the option of
specifying much more intelligent actions. These are split into two categories Scene and
Automation.
SCENE
Scene allows for a one touch button to be added to the Home Screen. The button can be used to
change a number of settings in one go, and can change all the settings within the unit. A number
of scenes can easily be setup, allowing the user to easily change between a number of preset
configurations.
Below is an example of how to set up a scene:
3. Press the Pen next to
“Please Enter Scene Name” to
input the name for your Scene
Show on Dashboard: Leave
this on if you require the scene
to be displayed as a button on
the Home Screen
Press the Red Plus to add the
action required. Then select
the heater from the list of
devices.
4. Chose the function, set the
value for the function, and
then press the back button in
the top right corner, to return
to the previous screen.
6. Once all the functions required have been added, press the Save button in the top right corner to
finalize and save your new Scene. It will then be saved to the home screen
1. Press on the
Smart tab at the
bottom of the
Home screen
2. Press on the Plus in the top right corner or
on Add Scenario to add a smart scene.

17
AUTOMATION
Automation allows an automatic action to be set up for the device. This can be triggered by the
Time, and a range of other influences, depending what other TUYA enabled devices you have on
the network.
1. Press on the Scene tab at
the bottom of the Home
screen
2. Press on the Automation
tab at the top of the screen.
3. Press on the + at the top of
the screen or press on Add
Automatic Action
4. Setup is very similar to the scene
setup on the previous page, and
includes an extra section for
specifying a trigger for the scene to
start.
Press the Pen next to “Please Enter
Scene Name” to input the name for
your Scene
Press the Red Plus next to “When
any condition is satisfied” to add the
trigger
Press the Red Plus next to “Execute
following actions” to add the action
required. Then select the heater
from the list of devices.
6. Chose the function,
set the value for the
function, and then press
the back button in the
top right corner, to
return to the previous
screen.
5. Select the condition when the
automation should start. A
number of triggers can be
combined.
7. Once all the functions required have been
added, press the Save button in the top right
corner to finalize and save your new scene.
The automation is now set up, it can be turned on
and off using the toggle on the home page.

18
PROFILE TAB
The profile tab gives you the option to edit both
your detail, and use the added features of the
unit.
HOME MANAGEMENT
Home Management proves options for managing
your TUYA account, giving options such as
adding a home, adding and removing rooms, and
sharing devices with family.
MESSAGE CENTRE
View notifications from devices, if alarms are set
up (dependent on device)
HELP CENTRE
Provides assistance using the features provided
within the app
MORE SERVICES
This allows the unit to be integrated with your
favorite home automation hardware such as
Google Home and the Amazon Echo.
CONNECTION TROUBLESHOOTING
1. Check whether the device is powered on and is in the correct WiFi connection
mode, if not please refer to the CHANGING BETWEEN CONNECTION MODES
section.
2. Ensure the WiFi password has been entered into the app correctly (Case
sensitive)
3. Check that the phone is connected to the WiFi you are connecting the device to.
4. Ensure the network you are connecting it to is 2.4Ghz (5Ghz WiFi networks are
not supported), and that there is a strong WiFi signal to the item.
5. If your router is dual band, ensure that the 2.4ghz network has a different network
name (SSID). Further advice on changing router settings will be available from
your Internet service provider / Router manufacturer.
6. Check the settings on the router. Encryption should be WPA2-PSK and
authorisation type should be set to AES
7. Try using the alternative connection method. i.e. If connection is failing when
attempting to connect through CF mode, try AP mode.

19
CLEANING AND MAINTENANCE
ATTENTION: Please shut off the unit and unplug from the mains before cleaning or
performing any maintenance.
CLEANING THE SURFACE
•Clean the heater with a duster or a soft wet cloth.
Do not use chemical solvents (such as benzene, alcohol or gasoline) as they may
cause irreversible damage. Make sure no water enters the control panel or gaps in the
casing.
•Do not run the unit until completely dry.
•Place the heater in its original box or cover to protect it from dust when not in use.
•Store it in a cool dry place.
TROUBLESHOOTING
Do not repair or disassemble the unit by yourself, unauthorized repair attempts will
invalidate the warranty and may cause bodily harm.
Issue
Possible Reason
Solution
No power
1. Power cord is unconnected
2. There is no power from socket
3. The power switch on the rear of the unit
is turned off.
1. Connect the power cord
2. Check socket is turned on
3. Ensure the power switch on
the rear of the unit is in the on
position
Odour
emission
from unit
1. New unit. When the unit is used for the
first time the fan motor may produce and
odour which will dissipate within a week of
use
1. No action required
Strong
vibrations
and noise
1. Unit is not placed on a flat surface
2. Unit may be damaged
1. Place on a flat surface. May
put an anti-vibration mat
underneath
2. If the heater is damaged
discontinue use and contact the
service centre.
If the above solutions do not resolve the problem please contact the service centre.
TECHNICAL DATA
Model no.
ECFIRPH7W
Voltage
220V-240V 700W
Frequency
50 / 60 Hz
Max power
700W
IP Rating
IP20
Product Dimensions
60x115 mm

20
electriQ UK SUPPORT
www.electriQ.co.uk/support
Please, for your own convenience, make these simple checks before calling
the service line.
If the unit still fails to operate call: 0330 390 3061 or complete the online
form
1. Is the unit plugged into the mains?
2. Is the fuse OK?
3. Switch the unit off and wait three minutes to see if the issue is resolved.
Restart the unit.
Office hours: 9AM - 5PM Monday to Friday
www.electriQ.co.uk
Unit J6, Lowfields Business Park
Lowfields Way, Elland
West Yorkshire, HX5 9DA
DECLARATION OF CONFORMITY
Hereby, electriQ declares that this heater follows Directive 2014/53/EU. The full text
of the EU declaration of conformity is available at the following internet address:
https://www.electriQ.co.uk/content/declaration-of-conformity
Disposal: Do not dispose this product as unsorted municipal waste. Collection of such
waste must be handled separately as special treatment is necessary.
Recycling facilities are now available for all customers at which you can
deposit your old electrical products. Customers will be able to take any
old electrical equipment to participating civic amenity sites run by their
local councils. Please remember that this equipment will be further
handled during the recycling process, so please be considerate when
depositing your equipment. Please contact the local council for details of
your local household waste recycling centres.
