elsner elektronik KNX R4 16 A Guide

EN
Installation and Adjustment
KNX R4 16 A and
KNX R8 16 A
Switching Actuators
Item numbers 70571 (KNX R4 16 A) and 70570 (KNX R8 16 A)

1 Contents
Elsner Elektronik GmbH • Sohlengrund 16 • 75395 Ostelsheim • Germany
Actuators KNX R4 16 A and KNX R8 16 A • from application 1.0
Status: 28.05.2020 • Subject to technical changes. Errors excepted.
1. Description ........................................................................................... 3
1.0.1. Scope of delivery .......................................................................................... 3
1.1. Technical specification ............................................................................................. 3
2. Installation and start-up ....................................................................... 4
2.1. Installation notes ...................................................................................................... 4
2.2. Safety notice for automatic functions .................................................................... 5
2.3. Connection ................................................................................................................ 6
2.3.1. Insulation properties of the clamp groups ................................................. 8
2.3.2. Connection examples ................................................................................. 10
2.4. Instructions for assembly and operational start-up. ........................................... 11
3. Addressing of the device at the bus .................................................. 11
4. Disposal ............................................................................................. 12
5. Transfer protocol ............................................................................... 13
5.1. List of all communication objects ......................................................................... 13
6. Setting parameters ............................................................................ 16
6.1. Behaviour on power failure/ restoration of power .............................................. 17
6.2. General settings ..................................................................................................... 17
6.3. Switch function ....................................................................................................... 17
6.3.1. Relationship between logic operation – timer switch – Block ................. 18
6.3.2. Linking ......................................................................................................... 19
6.3.3. Switch on and off delay .............................................................................. 19
6.3.4. Staircase time switch .................................................................................. 20
6.3.5. Block function .............................................................................................. 21
6.3.6. Scenes ......................................................................................................... 21

2 Clarification of signs
This manual is amended periodically and will be brought into line with new software
releases. The change status (software version and date) can be found in the contents footer.
If you have a device with a later software version, please check
www.elsner-elektronik.de in the menu area "Service" to find out whether a more up-to-
date version of the manual is available.
Clarification of signs used in this manual
Installation, inspection, commissioning and troubleshooting of the device
must only be carried out by a competent electrician.
Safety advice.
Safety advice for working on electrical connections, components,
etc.
DANGER! ... indicates an immediately hazardous situation which will lead to
death or severe injuries if it is not avoided.
WARNING! ... indicates a potentially hazardous situation which may lead to
death or severe injuries if it is not avoided.
CAUTION! ... indicates a potentially hazardous situation which may lead to
trivial or minor injuries if it is not avoided.
ATTENTION! ... indicates a situation which may lead to damage to property if it is
not avoided.
ETS In the ETS tables, the parameter default settings are marked by
underlining.

3 Description
Actuators KNX R4 16 A and KNX R8 16 A • Version: 28.05.2020 • Technical changes and errors excepted.
1. Description
The potential-free outputs of the Actuators KNX R4 16 A and KNX R8 16 A switch
consumer loads up to 16 Ampere.
Time functions such as an on/off delay or a staircase lighting function can be config-
ured in the devices applications. Linking with AND or OR is also possible.
Functions:
•Free of potential relay output for consumer loads with up to 16 A.
KNX R4 16 A: 4 individually controllable outputs.
KNX R8 16 A: 8 individually controllable outputs.
•Timer functions: on and/or off delay, staircase lighting timer switch with
adjustable pre-warning (light blinks prior to switch-off)
Configuration is made using the KNX software ETS 5. The product file can be down-
loaded from the ETS online catalogue and the Elsner Elektronik website on www.els-
ner-elektronik.de in the “Service” menu.
1.0.1. Scope of delivery
•Actuator
1.1. Technical specification
Housing Plastic
Colour White
Assembly Series installation on mounting rail
Protection category IP 20
Ambient temperature Operation -20…+45°C, storage -55…+90°C
Ambient humidity max. 95% RH, avoid condensation
Operating voltage KNX bus voltage
Current at the bus operation without relay activity: 15 mA.
For permanent relay switching operations up to 30 mA
Output load capacity • 16 A with alternating voltage, maximum 250 V AC
• 5 A with direct current 30 V DC
• UL approval up to 10 A
• Cable cross section 1.5 mm² to 2.5 mm²
Maximum load Each terminal contact may be loaded with a maximum
of 16 A.
Data output KNX +/- bus connector terminal
BCU type Integrated microcontroller
PEI type 0
Group addresses max. 254
Assignments max. 254

4 Installation and start-up
Actuators KNX R4 16 A and KNX R8 16 A • Version: 28.05.2020 • Technical changes and errors excepted.
KNX R4 16 A (70571):
KNX R8 16 A (70570):
The product is compliant with the provisions of EU guidelines.
2. Installation and start-up
2.1. Installation notes
Installation, testing, operational start-up and troubleshooting should
only be performed by an electrician.
DANGER!
Risk to life from live voltage (mains voltage)!
There are unprotected live components within the device.
• VDE regulations and national regulations are to be followed.
• Ensure that all lines to be assembled are free of voltage and take
precautions against accidental switching on.
• Do not use the device if it is damaged.
• Take the device or system out of service and secure it against
unintentional use, if it can be assumed, that risk-free operation is no
longer guaranteed.
The device is only to be used for the intended purpose described in this manual. Any
improper modification or failure to follow the operating instructions voids any and all
warranty and guarantee claims.
After unpacking the device, check it immediately for possible mechanical damage. If it
has been damaged in transport, inform the supplier immediately.
The device may only be used as a fixed-site installation; that means only when assem-
bled and after conclusion of all installation and operational start-up tasks and only in
the surroundings designated for it.
Dimensions approx. 53 x 88 x 60 (W x H x D, mm), 3 modules
Weight approx. 150 g
Outputs 4 × output, free of potential,
each power supply U | OUT
Communication objects 37
Dimensions approx. 107 x 88 x 60 (W x H x D, mm), 6 modules
Weight approx. 270 g
Outputs 8 × output, free of potential,
each power supply U | OUT
Communication objects 73

5 Installation and start-up
Actuators KNX R4 16 A and KNX R8 16 A • Version: 28.05.2020 • Technical changes and errors excepted.
Elsner Elektronik is not liable for any changes in norms and standards which may occur
after publication of these operating instructions.
2.2. Safety notice for automatic functions
WARNING!
Risk of injury from automatically moving components!
Parts of the system can be started by the automatic controls
and be a danger to persons.
• No persons may remain in the travelling range of parts
driven by an electric motor.
• Adhere to the relevant building regulations.
• Ensure that the return path/access to the building is not blocked
if spending time outside the building (danger of being locked out).
• Correctly decommission the system for maintenance and
cleaning work.
If there is a power outage, the system does not work. Therefore, shadings should be
moved to a save position if there are anticipated weather conditions, for example, if
this has not already been done by the automatic function (product protection).
If the power supply is removed, the connected drive switches off. When the power is
restored, the consumer remains switched off until a new movement command is re-
ceived by the actuator.

6 Installation and start-up
Actuators KNX R4 16 A and KNX R8 16 A • Version: 28.05.2020 • Technical changes and errors excepted.
2.3. Connection
Fig. 1 KNX R4 16 A
1 Labeling field
2 Programming LED (BUS) and programming
button (PRG)
3 Slot Bus connector (KNX +/-)
4 LED output A1 (A2, B1, B2 accordingly)
5 Button on/off output A1 (A2, B1, B2 accor-
dingly)
6 Power LED
7 Output A1:
UA1 (voltage) / A1 (out)
8 Output A2:
UA2 (voltage) / A2 (out)
9 Output B1:
UB1 (voltage) / B1 (out)
10 Output B2:
UB2 (voltage) / B2 (out)
2
3
5
6
987
1
4
10

7 Installation and start-up
Actuators KNX R4 16 A and KNX R8 16 A • Version: 28.05.2020 • Technical changes and errors excepted.
The Actuators KNX R4 16 A and KNX R8 16 A are installed on a mounting rail
(series installation). The connection is made using a KNX connector on the KNX data
bus. In addition, a power supply for the connected drive or consumer is necessary (out-
put free of potential).
Fig. 2 KNX R8 16 A
1 Labeling field
2 Programming LED (BUS) and programming button (PRG)
3 Slot Bus connector (KNX +/-)
4 LED output A1 (A2, B1, B2, C1, C2, D1, D2 accordingly)
5 Button on/off output A1 (A2, B1, B2, C1, C2, D1, D2 accordingly)
6 Power LED
7OutputA1:U
A1 (voltage) / A1 (out)
8OutputA2:U
A2 (voltage) / A2 (out)
9OutputB1:U
B1 (voltage) / B2 (out)
11 Output C1: UC1 (voltage) / C1 (out)
12 Output C2: UC2 (voltage) / C2 (out)
13 Output D1: UD1 (voltage) / D1 (out)
14 Output D2: UD2 (voltage) / D2 (out)
12
3
4
5
6
7 8 9 1110 12 13 14

8 Installation and start-up
Actuators KNX R4 16 A and KNX R8 16 A • Version: 28.05.2020 • Technical changes and errors excepted.
Follow the guidelines and standards for SELV electric circuits
while installing and cable laying of the KNX connection and
inputs!
The physical address is assigned by the KNX software. There is a button with a control
LED for this on the actuator.
2.3.1. Insulation properties of the clamp groups
The Actuators KNX R4 16 A and KNX R8 16 A are assigned to Overvoltage cate-
gory III and Pollution degree 2 or 3 according to EN60664-1. According to this classifi-
cation,
between 250 V power cables and FELV 4 kV surge voltage resistance and
between 250 V power cables and SELV 6 kV surge voltage resistance
must be provided. This provision must be observed during the installation.
With single insulation,
at pollution degree 2 a voltage of 400 V AC and
at pollution degree 3 a voltage of 250 V AC
is allowed between two channels.
KNX R4 16 A:
Neighbouring clamp groups may not be used with mixed
voltages, as there is only single insulation between them.
Non-labelled clamps (X) may not be used, to avoid influencing the insulation proper-
ties!
Fig. 3 KNX R4 16 A Insulation properties of the clamp groups
Insulation 4 kV (single insulation)

9 Installation and start-up
Actuators KNX R4 16 A and KNX R8 16 A • Version: 28.05.2020 • Technical changes and errors excepted.
KNX R8 16 A:
The clamp groups [A1, A2, B1, B2] and [C1, C2, D1, D2] can be used with mixed voltag-
es, as there is increased insulation between them. Non-labelled clamps (X) may not be
used, to avoid influencing the insulation properties!
Fig. 4 Insulation properties of the clamp groups
Insulation 6 kV (increased insulation)
Insulation 4 kV (single insulation)

10 Installation and start-up
Actuators KNX R4 16 A and KNX R8 16 A • Version: 28.05.2020 • Technical changes and errors excepted.
2.3.2. Connection examples
Mains
(230 V AC)
KNX R4 16 A:
A1 A2 B1 B2
Each terminal contact may be
loaded with a maximum of 16 A.

11 Addressing of the device at the bus
Actuators KNX R4 16 A and KNX R8 16 A • Version: 28.05.2020 • Technical changes and errors excepted.
KNX R8 16 A:
2.4. Instructions for assembly and operational
start-up.
Never expose actuators to water (e.g. rain) or dust. This can damage the electronics.
You must not exceed a relative air humidity of 95%. Avoid condensation.
After the auxiliary voltage has been applied, the device will enter an initialisation phase
lasting a few seconds. During this phase no information can be received or sent via the
bus.
3. Addressing of the device at the bus
The device is supplied with the bus address 15.15.255. You can program another ad-
dress into the ETS by overwriting the 15.15.255 address or by teaching via the pro-
gramming button.
Mains
(230 V AC)
A1
A2
B1
B2 C2 D2
C1 D1
Each terminal
contact may be
loaded with a
maximum of
16 A.

12 Disposal
Actuators KNX R4 16 A and KNX R8 16 A • Version: 28.05.2020 • Technical changes and errors excepted.
4. Disposal
After use, the device must be disposed of or recycled in accordance with the legal reg-
ulations. Do not dispose of it with the household waste!

13 Transfer protocol
Actuators KNX R4 16 A and KNX R8 16 A • Version: 28.05.2020 • Technical changes and errors excepted.
5. Transfer protocol
5.1. List of all communication objects
Abbreviations:
R Read
WWrite
C Communication
T Transfer
No Text Function Flags DPT type Size
0 Software version Readable R-C- [217.1]
DPT_Version
2 Bytes
1 Channel A1 - Switching Input -WC- [1.1]
DPT_Switch
1 Bit
2 Channel A1 - Feedback Output R-CT [1.1]
DPT_Switch
1 Bit
3 Channel A1 - Status Readable R-C- [1.1]
DPT_Switch
1 Bit
4 Channel A1 - Blocking object Input -WC- [1.1]
DPT_Switch
1 Bit
5 Channel A1 - Start staircase
light function
Input -WC- [1.10]
DPT_Start
1 Bit
6 Channel A1 - Start/stop
staircase light function
Input -WC- [1.10]
DPT_Start
1 Bit
7 Channel A1 - Linking Input -WC- [1.2]
DPT_Bool
1 Bit
8 Channel A1 - Call up / saving
scenes
Input -WC- [18.1]
DPT_SceneCo
ntrol
1 Byte
9 Channel A1 - Local operation
blocking object
Input -WC- [1.1]
DPT_Switch
1 Bit
10 Channel A2 - Switching Input -WC- [1.1]
DPT_Switch
1 Bit
11 Channel A2 - Feedback Output R-CT [1.1]
DPT_Switch
1 Bit
12 Channel A2 - Status Readable R-C- [1.1]
DPT_Switch
1 Bit
13 Channel A2 - Blocking object Input -WC- [1.1]
DPT_Switch
1 Bit
14 Channel A2 - Start staircase
light function
Input -WC- [1.10]
DPT_Start
1 Bit
15 Channel A2 - Start/stop
staircase light function
Input -WC- [1.10]
DPT_Start
1 Bit

14 Transfer protocol
Actuators KNX R4 16 A and KNX R8 16 A • Version: 28.05.2020 • Technical changes and errors excepted.
16 Channel A2 - Linking Input -WC- [1.2]
DPT_Bool
1 Bit
17 Channel A2 - Call up / saving
scenes
Input -WC- [18.1]
DPT_SceneCo
ntrol
1 Byte
18 Channel A2 - Local operation
blocking object
Input -WC- [1.1]
DPT_Switch
1 Bit
19 Channel B1 - Switching Input -WC- [1.1]
DPT_Switch
1 Bit
20 Channel B1 - Feedback Output R-CT [1.1]
DPT_Switch
1 Bit
21 Channel B1 - Status Readable R-C- [1.1]
DPT_Switch
1 Bit
22 Channel B1 - Blocking object Input -WC- [1.1]
DPT_Switch
1 Bit
23 Channel B1 - Start staircase
light function
Input -WC- [1.10]
DPT_Start
1 Bit
24 Channel B1 - Start/stop
staircase light function
Input -WC- [1.10]
DPT_Start
1 Bit
25 Channel B1 - Linking Input -WC- [1.2]
DPT_Bool
1 Bit
26 Channel B1 - Call up / saving
scenes
Input -WC- [18.1]
DPT_SceneCo
ntrol
1 Byte
27 Channel B1 - Local operation
blocking object
Input -WC- [1.1]
DPT_Switch
1 Bit
28 Channel B2 - Switching Input -WC- [1.1]
DPT_Switch
1 Bit
29 Channel B2 - Feedback Output R-CT [1.1]
DPT_Switch
1 Bit
30 Channel B2 - Status Readable R-C- [1.1]
DPT_Switch
1 Bit
31 Channel B2 - Blocking object Input -WC- [1.1]
DPT_Switch
1 Bit
32 Channel B2 - Start staircase
light function
Input -WC- [1.10]
DPT_Start
1 Bit
33 Channel B2 - Start/stop
staircase light function
Input -WC- [1.10]
DPT_Start
1 Bit
34 Channel B2 - Linking Input -WC- [1.2]
DPT_Bool
1 Bit
35 Channel B2 - Call up / saving
scenes
Input -WC- [18.1]
DPT_SceneCo
ntrol
1 Byte
36 Channel B2 - Local operation
blocking object
Input -WC- [1.1]
DPT_Switch
1 Bit
No Text Function Flags DPT type Size

15 Transfer protocol
Actuators KNX R4 16 A and KNX R8 16 A • Version: 28.05.2020 • Technical changes and errors excepted.
Channel C and D only for KNX R8:
37 Channel C1 - Switching Input -WC- [1.1]
DPT_Switch
1 Bit
38 Channel C1 - Feedback Output R-CT [1.1]
DPT_Switch
1 Bit
39 Channel C1 - Status Readable R-C- [1.1]
DPT_Switch
1 Bit
40 Channel C1 - Blocking object Input -WC- [1.1]
DPT_Switch
1 Bit
41 Channel C1 - Start staircase
light function
Input -WC- [1.10]
DPT_Start
1 Bit
42 Channel C1 - Start/stop
staircase light function
Input -WC- [1.10]
DPT_Start
1 Bit
43 Channel C1 - Linking Input -WC- [1.2]
DPT_Bool
1 Bit
44 Channel C1 - Call up / saving
scenes
Input -WC- [18.1]
DPT_SceneCo
ntrol
1 Byte
45 Channel C1 - Local operation
blocking object
Input -WC- [1.1]
DPT_Switch
1 Bit
46 Channel C2 - Switching Input -WC- [1.1]
DPT_Switch
1 Bit
47 Channel C2 - Feedback Output R-CT [1.1]
DPT_Switch
1 Bit
48 Channel C2 - Status Readable R-C- [1.1]
DPT_Switch
1 Bit
49 Channel C2 - Blocking object Input -WC- [1.1]
DPT_Switch
1 Bit
50 Channel C2 - Start staircase
light function
Input -WC- [1.10]
DPT_Start
1 Bit
51 Channel C2 - Start/stop
staircase light function
Input -WC- [1.10]
DPT_Start
1 Bit
52 Channel C2 - Linking Input -WC- [1.2]
DPT_Bool
1 Bit
53 Channel C2 - Call up / saving
scenes
Input -WC- [18.1]
DPT_SceneCo
ntrol
1 Byte
54 Channel C2 - Local operation
blocking object
Input -WC- [1.1]
DPT_Switch
1 Bit
55 Channel D1 - Switching Input -WC- [1.1]
DPT_Switch
1 Bit
56 Channel D1 - Feedback Output R-CT [1.1]
DPT_Switch
1 Bit
No Text Function Flags DPT type Size

16 Setting parameters
Actuators KNX R4 16 A and KNX R8 16 A • Version: 28.05.2020 • Technical changes and errors excepted.
6. Setting parameters
The parameter defaults are underlined.
57 Channel D1 - Status Readable R-C- [1.1]
DPT_Switch
1 Bit
58 Channel D1 - Blocking object Input -WC- [1.1]
DPT_Switch
1 Bit
59 Channel D1 - Start staircase
light function
Input -WC- [1.10]
DPT_Start
1 Bit
60 Channel D1 - Start/stop
staircase light function
Input -WC- [1.10]
DPT_Start
1 Bit
61 Channel D1 - Linking Input -WC- [1.2]
DPT_Bool
1 Bit
62 Channel D1 - Call up / saving
scenes
Input -WC- [18.1]
DPT_SceneCo
ntrol
1 Byte
63 Channel D1 - Local operation
blocking object
Input -WC- [1.1]
DPT_Switch
1 Bit
64 Channel D2 - Switching Input -WC- [1.1]
DPT_Switch
1 Bit
65 Channel D2 - Feedback Output R-CT [1.1]
DPT_Switch
1 Bit
66 Channel D2 - Status Readable R-C- [1.1]
DPT_Switch
1 Bit
67 Channel D2 - Blocking object Input -WC- [1.1]
DPT_Switch
1 Bit
68 Channel D2 - Start staircase
light function
Input -WC- [1.10]
DPT_Start
1 Bit
69 Channel D2 - Start/stop
staircase light function
Input -WC- [1.10]
DPT_Start
1 Bit
70 Channel D2 - Linking Input -WC- [1.2]
DPT_Bool
1 Bit
71 Channel D2 - Call up / saving
scenes
Input -WC- [18.1]
DPT_SceneCo
ntrol
1 Byte
72 Channel D2 - Local operation
blocking object
Input -WC- [1.1]
DPT_Switch
1 Bit
No Text Function Flags DPT type Size

17 Setting parameters
Actuators KNX R4 16 A and KNX R8 16 A • Version: 28.05.2020 • Technical changes and errors excepted.
6.1. Behaviour on power failure/ restoration of
power
Behaviour following a failure of the bus power supply:
The device sends nothing.
Behaviour on bus restoration of power and following programming or reset:
The device sends all outputs according to their send behaviour set in the parameters
with the delays established in the "General settings" parameter block.
6.2. General settings
First set the general parameters for the bus communication (message rate, transmis-
sion delays). In addition, you can specify whether all or only the changed settings are
transferred to the bus when programming scenes.
The label for objects is placed in front of all the objects of Actuators KNX R4 16
A and KNX R8 16 A, making their assignment more recognisable in the ETS.
Activate the switch function
The actuator KNX R4 16 A has 2 channels A and B with double switch function each.
The actuator KNX R8 16 A has 4 channels A, B, C and D with double switch function
each.
6.3. Switch function
The label for channel objects is placed in front of all the objects of this channel, mak-
ing their assignment more recognisable in the ETS.
The Scenes menu is activated here.
Select the appropriate relay operation for the connected device.
Maximum message rate 1… 20; 5 messages per second
Transmission delay of switching and status
outputs after power restoration
5s… 2 h
When using scenes:
Transfer when programming All parameters • only changed parameters
Object labelling [Free text max. 20 characters]
Channel A Do not use • Double switch function
Label for channel objects [Free text max. 20 characters]
Use scenes
(see the Scenes chapter)
No • Yes
Relay operation Closer • Opener

18 Setting parameters
Actuators KNX R4 16 A and KNX R8 16 A • Version: 28.05.2020 • Technical changes and errors excepted.
Set the behaviour for bus voltage drop and after reset/download.
If necessary, activate the status object that outputs the relay status.
If necessary, activate the link menu that enables a link with AND or OR.
Activate the required time function. Here either the switch-on and/or switch-off can
be delayed or a staircase timer switch can be set up.
If required, activate the Block function menu in which you can define a block.
6.3.1. Relationship between logic operation – timer switch –
Block
Application example: Staircase light that is only to be switched at twilight/night (link)
and that is switched on in the event of a fire alarm (block).
Behaviour following a bus voltage drop • no change
• opened
• closed
Behaviour after reset and ETS download • no change
• opened
• closed
Use status object • No
• as an active feedback object
• as a passive status object
Use linking function No • Yes
Use time function • No
• as a switch on delay
• as a switch off delay
• as a switch on and off delay
• as a staircase time switch
Use blocking object No • Yes
