   User station
 WB-2P-LR2
   User manual
    Firmware version2.4.0

WB-2P-LR2. User manual
 2
Contents
1 Introduction .................................................................................................................................................. 4
1.1 Annotation.................................................................................................................................................4
1.2 Symbols.....................................................................................................................................................4
2 Device description ....................................................................................................................................... 5
2.1 Purpose .....................................................................................................................................................5
2.2 Device specification..................................................................................................................................5
2.3 Technical features ....................................................................................................................................7
2.4 Design........................................................................................................................................................9
2.5 Light indication........................................................................................................................................10
2.6 Reset to the default settings ..................................................................................................................11
2.7 Delivery package.....................................................................................................................................11
3 Installation order........................................................................................................................................ 12
3.1 Safety rules..............................................................................................................................................12
3.2 Installation recommendations ...............................................................................................................12
3.3 WB-2P-LR2 mounting..............................................................................................................................12
3.3.1 Pre-tuning ............................................................................................................................................ 12
3.3.2 Mounting order.................................................................................................................................... 12
3.4 Switching on............................................................................................................................................14
4 Managing the device through web configurator...................................................................................... 15
4.1 Getting started ........................................................................................................................................15
4.2 Changing user .........................................................................................................................................16
4.3 Applying configuration and discarding changes ..................................................................................17
4.4 Test changes mode ................................................................................................................................18
5 Main elements of the web interface ......................................................................................................... 19
5.1 The 'Monitoring' menu ............................................................................................................................20
5.1.1 The 'Internet' submenu ....................................................................................................................... 20
5.1.2 The 'WDS' submenu ............................................................................................................................ 21
5.1.3 The 'Ethernet ports' submenu ............................................................................................................ 22
5.1.4 The 'DHCP' submenu .......................................................................................................................... 23
5.1.5 The 'ARP' submenu............................................................................................................................. 23
5.1.6 The 'PPPoE Relay' submenu............................................................................................................... 24
5.1.7 The 'PPPoE Client' submenu .............................................................................................................. 24
5.1.8 The 'Device info' submenu.................................................................................................................. 25

WB-2P-LR2. User manual
 3
5.1.9 The 'Conntrack' submenu................................................................................................................... 26
5.1.10 The 'Routes' submenu ........................................................................................................................ 27
5.2 The 'Network' menu ................................................................................................................................28
5.2.1 The 'Internet' submenu ....................................................................................................................... 28
5.2.2 The 'Radio' submenu........................................................................................................................... 37
5.2.3 The 'LAN' submenu............................................................................................................................. 39
5.2.4 The 'MAC Management' submenu..................................................................................................... 40
5.2.5 The 'Local DNS' submenu................................................................................................................... 40
5.2.6 The 'NAT and Port Forwarding' submenu.......................................................................................... 42
5.2.7 The 'Firewall' submenu ....................................................................................................................... 43
5.2.8 The 'Routes' submenu ........................................................................................................................ 45
5.2.9 The 'Dynamic DNS' submenu ............................................................................................................. 46
5.2.10 The 'SNMP' submenu.......................................................................................................................... 47
5.3 The 'IPTV' menu ......................................................................................................................................48
5.3.1 The 'IPTV' submenu ............................................................................................................................ 48
5.4 The 'System' menu..................................................................................................................................50
5.4.1 The 'Time' submenu............................................................................................................................ 50
5.4.2 The 'Access' submenu........................................................................................................................ 51
5.4.3 The 'Log' submenu.............................................................................................................................. 52
5.4.4 The 'Passwords' submenu ................................................................................................................. 54
5.4.5 The 'Configuration management' submenu...................................................................................... 55
5.4.6 The 'Firmware Upgrade' submenu ..................................................................................................... 56
5.4.7 The 'Reboot' submenu ........................................................................................................................ 57
5.4.8 The 'Autoprovisioning' submenu........................................................................................................ 57
5.4.9 The 'Advanced' submenu ................................................................................................................... 60
6 Configuration example .............................................................................................................................. 61
7 Spectrum Analyzer..................................................................................................................................... 63
8 Automatic DHCP-based update algorithm............................................................................................... 64
9 System recovering after firmware update failure .................................................................................... 67
10 Appendix А. Launch user script when starting the system..................................................................... 68
11 Application B. Antenna patterns ............................................................................................................... 69
12 The list of changes .................................................................................................................................... 70

 WB-2P-LR2. User manual
4
1 Introduction
1.1 Annotation
Modern tendencies of telecommunication development necessitate operators to search for the most optimal
technologies, allowing you to satisfy drastically growing needs of subscribers, maintaining at the same time
consistency of business processes, development flexibility and reduction of costs of various services provision.
Wireless technologies are spinning up more and more and have paced a huge way for a short time from unstable
low-speed communication networks of low radius to broadband networks equitable to speed of wired networks
with high criteria for the quality of provided services.
WB-2P-LR2 is a user station designed for connection to Wi-Fi access network which might be constructed using
base stations within long distances. The case of WB-2P-LR2 is sealed, that is allows to install the device outdoor
with different climate conditions.
This manual specifies intended purpose, main technical parameters, design, installation procedure, safe operation
rules and installation recommendations forWB-2P-LR2.
1.2 Symbols
Notes and warnings
Notes contain important information, tips or recommendations on device operation and setup.

Warnings are used to inform the user about harmful situations for the device and the user alike, which
could cause malfunction or data loss.


 WB-2P-LR2. User manual
5
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
2 Device description
2.1 Purpose
User station WB-2P-LR2 (herein after 'the device') is designed for access provision to secure wireless network.
WB-2P-LR2connects to a base station via Wi-Fi technology and operates at 2.4 GHz (the frequency range – 2402–
2482 MHz). The device is supposed to operate with WOP-2ac-LR2. WB-2P-LR2might be also used for wireless
bridge organization.
WB-2P-LR2 supports up-to-date requirements to service quality and allows transmitting more important traffic in
higher priorities queues. Prioritization is based on QoS technologies: CoS (special tags in VLAN packet field) and
ToS (tags in IP packet field).
The device is capable to operate in wide temperature range and in high-humidity conditions (parks, factories,
stadiums, etc.).
Power to the device is supplied via Passive PoE technology 24V.
2.2 Device specification
Interfaces:
1 port of Ethernet 10/100/1000BASE-T (RJ-45);
Wi-Fi 2.4 GHz IEEE 802.11b/g/n.
The power is suuplied via PoE injector 24V connected to 220V network.
Network functions:
operating in bridge and router modes;
operating in 'Wi-Fi Station'and 'Wireless bridge' modes;
support for VLAN Trunk;
support for Management VLAN;
support for General VLAN;
support for Transparent Mode;
static routing;
support for Transparent wireless bridge function;
support for PPPoE client;
time synchronization via NTP;
support for static address and DHCP (DHCP client on WAN side, DHCP server on LAN side);
support for DNS;
support for D-DNS;
support for NAT;
support for UPnP;
firewall;
support for cloning of MAC address on WAN interface;
support for quality of service mechanisms (QoS through DSCP and 802.1P).
support for IPTV functions (IGMP-proxy, UDP-to-HTTP proxy);
firmware update via web interface;
support for DHCP-based autoprovisioning;
support for TR-069;
remote monitoring, configuration and setup: SNMP, web interface, Telnet, SSH.
The figures below illustrate applications schemes of WB-2P-LR2.
Do not use an injector with voltage different from 24V so as not to break down the device!


 WB-2P-LR2. User manual
6

Functional scheme of using WB-2P-LR2 without router

Functional scheme of using WB-2P-LR2 with router
Functional scheme of using WB-2P-LR2 for wireless bridge organization

 WB-2P-LR2. User manual
7
2.3 Technical features
Table 1 shows main specifications of the device.
Table 1 –Main specifications
LAN Ethernet interface parameters
Number of ports 1
Electrical connector RJ-45
Data rate, Mbps 10/100/1000,auto-negotiation
Standards BASE-T
Wireless interface parameters
Standards 802.11b/g/n
Frequency range 2402–2482 MHz
Modulation DSSS, CCK, BPSK, QPSK, 16QAM, 64QAM
Speed of data transmission 802.11b: up to 11 Mbps
802.11g: up to 54 Mbps
802.11n: up to 300 Mbps
Maximum output power of the transmitter 2.4 GHz:26 dBm
Receiver sensitivity 2.4 GHz:-98 dBm
Security 64/128/152- bit WEP encryption, WPA/WPA2,
centralized authorization via RADIUS server (WPA/WPA2
Enterprise)
Antenna's parameters
Gain 2x10.5 dBi
Polarization dualpolarized antenna
Beam angle (horizontal polarization) 60°
Beam angle (horizontal polarization) 40°

 WB-2P-LR2. User manual
8
SWR 2.0 max.
Impedance 50 Ohm
Front to back ratio > 20 dB
Control
Remote control web interface, Telnet, SSH, SNMP (monitoring), TR-069
Access restriction by password
General parameters
Processor Realtek RTL8197FS 1 GHz
RAM 128 MB
Flash 32 MB
Power supply PoE 24 V
Power consumption 9 W max.
Operating temperatures form -45 to +65°С
Operating humidity 95% max.
Ingress Protection Marking IP54
Dimensions 80x66x282 mm
Weight 0,35 kg

 WB-2P-LR2. User manual
9
2.4 Design
WB-2P-LR2 housed in a plastic case, industrial version. The size of the device: 80x66x282 mm.
The layout of WB-2P-LR2 is shown in the figure below.
    
WB-2P-LR2 layout
LAN port 10/100/1000Base-T (RJ-45 connector) for local network connection and power supply via PoE,
grounding connector and the button for resetting to factory settings ('Reset') are located on the bottom panel of
the device.
WB-2P-LR2 bottom panel's elements

 WB-2P-LR2. User manual
10
2.5 Light indication
The light indication panel of WB-2P-LR2 is shown below.
WB-2P-LR2 light indication panel
The current state of the device is shown with the help of light indicators located on the back panel of WB-2P-LR2.
The list of indicators and their description is shown in the table below.
Table 2 – Description of rear panel LED indicators
LED LED status Description
Power – Device power and
operation status LED
solid green the device power supply is enabled, normal operation
solid orange the device is loaded but IP address is not received via
DHCP
solid red the device is loading
LAN – LAN interface
indicator
solid green (10, 100
Mbps)/solid orange
(1000 Mbps)
the channel between LAN interface of WB-2P-LR2 and
connected device is active
flashes packet data transmission between LAN interface of
WB-2P-LR2 and connected device

 WB-2P-LR2. User manual
11
1.
2.
•
•
•
•
•
•
•
•
LED LED status Description
WLAN – received signal
strength indicator (RSSI)
solid red the device is connected to a base station. The base
station signal level is more than -98 dBm
solid yellow the device is connected to a base station. The base
station signal level is more than -80 dBm
solid green the device is connected to a base station. The base
station signal level is more than -70 dBm
solid green the device is connected to a base station. The base
station signal level is more than -60 dBm
none of the indicators is
on
the device is not connected to the base station
2.6 Reset to the default settings
There are two ways to reset the device to factory settings:
Using 'Reset' button on the device. When the device is loaded, press and hold'Reset' button located on the
bottom panel (approximately 10–15 seconds) until 'Power' indicator is flashing orange.
Using PoE injector supplied with the device. When the device is loaded, press and hold'RST' button of the
injector (approximately 10–15 seconds) until'Power' indicator of WB-2P-LR2 is flashing orange.
Device will be rebooted automatically. DHCP client will be launched by default. If the address is not received
via DHCP the device will have IP address — 192.168.1.1,subnet mask —255.255.255.0; User Name/
Password to access via Web interface: admin/password.
2.7 Delivery package
The basic supply package of WB-2P-LR2 includes:
User station WB-2P-LR2;
Mounting kit: 2 clamps for attaching;
PoE injector 24 V;
Patch cord RJ-45, 5e cat. 1.5 m;
Cord for europlug - C13-F-1.8 m;
Sheet with light indication description;
Conformity certificate;
Technical passport.
A bracket with horizontal and vertical adjustment might be included to the supply package upon a request.

 WB-2P-LR2. User manual
12
1.
2.
3.
4.
5.
6.
7.
8.
1.
2.
3.
4.
5.
1.
3 Installation order
This section defines safety rules, installation recommendations, setup procedure and the device starting
procedure.
3.1 Safety rules
Do not open the device case. There are no user serviceable parts inside.
Do not install the device during a thunderstorm. There is a risk of lightning stroke.
You must follow requirements for voltage, current and frequency specified in the user manual.
Measuring devices and computer must be grounded before connecting to the device. The electric potential
differnce between devices' cases should not exceed 1 V.
Make sure that all the cables are intact and they are reliably attached to connectors.
You should satisfy established standards and requirements for working at height during the device
installation on the high-rise constructions.
The device exploitation should be performed by speciallyprepared engineering and technical personnel.
Connect only to operational service equipment.
3.2 Installation recommendations
Recommended location for device installation: communications mast/pole.
Before you install and enable device, check the device for visible mechanical defects. If defects are
observed, you should stop the device installation, draw up corresponding act and contact the supplier.
Install the device vertically on communications mast or pole in the way that the LAN port is pointed down.
In order to provide better receiving signal level, the sectoral antenna of a base station should be in line of
sight of WB-2P-LR2. You may achive the highest signal level by antenna alignment with the help of RSSI
indicators.
The transmitting part of the device is located on the other side from brackets. This area should be directed
to base station sectoral antenna.
After adjusting, make sure that level of the received signal from the base station should be no more than -65 ÷ -70
dBm.
3.3 WB-2P-LR2 mounting
3.3.1 Pre-tuning
Before installing, proceed pre-tuning of the device (see sectionConfiguration example). For this, power on the
device (paragraph 2-7, sectionMounting algorithm) and follow the instructions given in the sectionConfiguration
example. Make sure that the user station connects required wireless network: RSSI indicators should be on.
3.3.2 Mounting order
Install the device on communications mast/pole pointing LAN port down as it is shown on the figure below.
Attach the device using clamps supplied in the device package. Comply the safety rules and
recommendations given in Safety rulesandInstallation recommendations.
Install the device on communications mast/pole so that the device is directed to base station sectoral
antenna as much as possible. There should also be direct visibility to the base station.


 WB-2P-LR2. User manual
13
2.
3.
4.
5.
Remove the bottom cover which close LAN-port.Ground the device through a grounding connector.
Connect Ethernet cable to LAN port.
Close the bottom cover.
Connect Ethernet cable connected to WB-2P-LR2to PoE port of injector.

 WB-2P-LR2. User manual
14
6.
7.
8.
9.
1.
2.
3.
Connect Ethernet cable of your LAN network or PC to LAN port of PoE injector.

Connect PoE injector to 220V socket with the help of power line cord.

Align the position of the device for best signal level receiving. The level of received signal is shown by the
indication located on the back panel of the device.
Fasten the clamps.
3.4 Switching on
Plug the injector into 220 V outlet. Connect a PC to LAN port of the injector.
WB-2P-LR2 loads in a minute after switching on. Connect to the web configurator of WB-2P-LR2 through a
browser.
Network configuration is described in section 5.1 The 'Network' menu.
IP address by default: 192.168.1.1.
Login: admin, password: password.


 WB-2P-LR2. User manual
15
1.
2.
3.
4 Managing the device through web configurator
4.1 Getting started
To start, you need to connect the device through a browser:
Open a web browser(web-page explorer), for example, Firefox, Opera, Chrome.
Enter IP-address of the device to the browser address line.
If connection is successful, request form with user name and password will be displayed on a browser
window.
Enter your username into ‘Login’ and password into ‘Password’ field. Click the ‘Log in’ button. Device Web
configurator home page will be opened in the browser window.
IP address by default: 192.168.1.1, subnet mask: 255.255.255.0. The device is capable to obtain
an IP address via DHCP.

Factory settings: login: admin, password: password.


 WB-2P-LR2. User manual
16
•
•
4.2 Changing user
There are two user types for the device: admin and viewer:
admin(password by default: password) has the full access to the device: read/write any settings, full device
status monitoring.
viewer may only view full device configuration without editing privileges; may access full device status
monitoring.
When you click the «Logout» button, the current user session will be terminated; login window will be displayed:
To change the access, you should specify the corresponding username and password and click the Log in button.
You may select languages on the top-right of the page. Russian and English languages are available for
WB-2P-LR2.


 WB-2P-LR2. User manual
17
1.
2.
4.3 Applying configuration and discarding changes
Applying configuration
The visual indication of the settings applying is realized in the web interface.
The visual indication of the settings applying:
Image State description
After clicking 'Apply', the process of settings saving to device memory is
launched. This is indicated by the icon in the tab name and on the Apply
button.
Successful settings saving and application are indicated by the icon in the
tab name.
If any parameter value have been set incorrectly, the error notification with
description will be displayed after pressing 'Apply' button. The mark will be
displayed next to the tab name and on 'Apply' button.
The 'Apply' button in the menu appears as follows: .
Discarding changes
The button for discarding changes appears as follows: .
Press 'Apply' to save configuration to flash memory and apply new settings. All the settings come
into operation without device rebooting.

You can discard changes only before clicking the 'Apply' button. If you click the 'Apply' button, all
the changed parameters will be applyed and saved to device memory. You will not be able to
return to previous configuration after clicking 'Apply'.


 WB-2P-LR2. User manual
18
•
•
4.4 Test changes mode
The device has a test mode for a test configuration application.
To activate it, press the 'Test changes' button on the top panel of the web interface.
Test mode operating time is 300 seconds (5 minutes). During this time you can navigate through the web
configurator tabs and make any changes by applying them on each page using the 'Apply' button.
After checking the required configuration, press the 'Exit from Test Mode' button and select the desired action:
'Save and exit' – pressing this button will exit the test mode and save to the non-volatile memory all
configuration changes that were made and applied in this mode. It will be impossible to undo changes
made in the test mode.
'Cancel and exit' – pressing will exit the test mode and cancel all changes made in this mode. The
configuration in effect on the device before the test mode is activated will be restored.
If the administrator does not exit the test mode within 300 seconds, this will happen automatically along with a
rollback of all changes that have been made in this mode. After the specified time, the configuration will be
restored even if access to the device is lost as a result of the changes made.

 WB-2P-LR2. User manual
19
1.
2.
3.
4.
5.
6.
5 Main elements of the web interface
The figure below shows navigation elements of the web configurator.
The user interface is divided into seven areas:
Username, which was used to enter the system and 'logout' button to finish the user session.
Menu tabs which contain submenu tabs are divided into categories:Monitoring, Network, IPTV,System.
Submenu tabs manage the settings field below.
Settings field, which is based on the user select. The field is dedicated to view device settings and setting
configuration data.
Configuration management buttons, the detailed description is given in sectionApplying configuration and
discarding changes.
Information field. The field contain information on firmware version and web interface version.

 WB-2P-LR2. User manual
20
•
•
•
•
•
•
•
5.1 The 'Monitoring' menu
To move to monitoring mode, select 'Monitoring' on the left panel.
5.1.1 The 'Internet' submenu
In the Internet submenu, you may view main network settings of the device.
Internet Connection
Network connection –the parameter shows the type of connection to external network;
Connection Status–the parameter shows state of connection to external network;
SSID –a name of wireless network, to which the device is connected;
Access Protocol – protocol, used for network access;
IP address – device IP address in external network;
Link Capacity –parameter that reflects the effectiveness of the use of a modulation by the device on the
transmission. It is calculated based on the number of packets transmitted on each modulation, and the
reduction factors. The maximum value is 100% (means that all packets are transmitted at maximum
modulation for the maximum nss type supported by the device). The minimum value is 2% (in the case
when the packets are transmitted to the modulation nss1mcs0 for the device with MIMO 3x3 support). The
parameter value is calculated for the last 10 s;
Link Quality –parameter that displays the status of the link, calculated based on the number of sent
retransmit packets. The maximum value is 100% (all transmitted packets were sent on the first attempt), the
Some pages are not updated automatically. To obtain current information from the device, click the
button.

