Elumen8 GB-1 User manual

Order code: ELUM076
GB-1 Reectabeam
User Manual

www.prolight.co.uk GB-1 Reectabeam User Manual 2
Safety advice
WARNING
FOR YOUR OWN SAFETY, PLEASE READ THIS USER MANUAL
CAREFULLY BEFORE YOUR INITIAL START-UP!
• Before your initial start-up, please make sure that there is no damage caused during transportation.
• Should there be any damage, consult your dealer and do not use the equipment.
• To maintain the equipment in good working condition and to ensure safe operation, it is necessary
for the user to follow the safety instructions and warning notes written in this manual.
• Please note that damages caused by user modications to this equipment are not subject to warranty.
IMPORTANT:
The manufacturer will not accept liability for any resulting damages caused by the non-observance
of this manual or any unauthorised modication to the equipment.
OPERATING DETERMINATIONS
If this equipment is operated in any other way, than those described in this manual, the product may suffer damage and
the warranty becomes void. Incorrect operation may lead to danger e.g: short-circuit, burns and electric shocks etc.
Do not endanger your own safety and the safety of others!
Incorrect installation or use can cause serious damage to people and/or property.
CAUTION!
KEEP THIS EQUIPMENT
AWAY FROM RAIN,
MOISTURE AND LIQUIDS
CAUTION!
TAKE CARE USING
THIS EQUIPMENT!
HIGH VOLTAGE-RISK
OF ELECTRIC SHOCK!!
• Never let the power cable come into contact with other
cables. Handle the power cable and all mains voltage
connections with particular caution!
• Never remove warning or informative labels from the unit.
• Do not open the equipment and do not modify the unit.
• Do not connect this equipment to a dimmer pack.
• Do not switch the equipment on and off in short intervals,
as this will reduce the system’s life.
• Only use the equipment indoors.
• Do not expose to ammable sources, liquids or gases.
• Always disconnect the power from the mains when
equipment is not in use or before cleaning! Only handle
the power-cable by the plug. Never pull out the plug by
pulling the power-cable.
• Make sure that the available mains supply voltage is
between 100~240V AC, 50/60Hz.
• Make sure that the power cable is never crimped or
damaged. Check the equipment and the power cable
periodically.
• If the equipment is dropped or damaged, disconnect the
mains power supply immediately and have a qualied
engineer inspect the equipment before operating again.
• If the equipment has been exposed to drastic
temperature uctuation (e.g. after transportation),
do not connect power or switch it on immediately.
The arising condensation might damage the equipment.
Leave the equipment switched off until it has reached
room temperature.
• If your product fails to function correctly, stop use
immediately. Pack the unit securely (preferably in the
original packing material), and return it to your Pro Light
dealer for service.
• Only use fuses of same type and rating.
• Repairs, servicing and power connection must only be
carried out by a qualied technician. THIS UNIT CONTAINS
NO USER SERVICEABLE PARTS.
• This xture is for professional use only - it is not designed
for or suitable for household use. The product must be
installed by a qualied technician in accordance with local
territory regulations. The safety of the installation is the
responsibility of the installer. The xture presents risks of
severe injury or death due to re hazards, electric shock
and falls.
• Caution! This item is not designed to be used for extended
periods of time. Risk assessment should be carried
out based on the output power of the xtures used for
illumination, the distance from the GB-1 to xtures and
illumination time.
• WARRANTY: Two years from date of purchase.

www.prolight.co.uk GB-1 Reectabeam User Manual 3
Product overview & technical specications
Transform your beam effects with this innovative effect from eLumen8. Inside the robust, metal and fan cooled
housing are 6 individually controllable multi-faceted dishes which can be rotated continuously in any direction at
variable speeds. When strategically placed, the Reectabeam can have beam effects aimed at them, producing a
multitude of bright pin sharp shards of light that are reected across walls and oors, adding an extra dimension
to venues and danceoors.
• 6 mirror dishes
• Individually controllable mirrors
• Auto, sound active and master/slave modes
• DMX channels: 2 or 8 selectable
• 4 push button menu with LED display
• PowerCON input/ouput
• 5-Pin XLR input/output
• Fan cooled housing
GB-1 Reectabeam
Specications GB-1 Reectabeam
Power consumption 20W
Power supply 100~240V, 50/60Hz
Fuse T2.5A 250V
Dimensions 250 x 250 x 120mm
Weight 3.72kg
Order code ELUM076
250mm
250mm 120mm

www.prolight.co.uk GB-1 Reectabeam User Manual 4
Technical specications
01 - Earth point
02 - LED display
03 - Function buttons
04 - Microphone
05 - 5-Pin DMX input
06 - 5-Pin DMX output
07 - PowerCON input
08 - PowerCON output
09 - Fuse T2.5A 250V
10 - Cooling fan vents
11 - Omega clamp mounts
In the box: 1 x xture,
1 x power cable,
1 x user manual,
1 x omega clamp
& 1 x safety eye
GB-1
DUTY CYCLE: PLEASE SEE MANUAL BEFORE USE
MENU ENTERUPDOWN
DMX INPUT
DMX OUTPUT
MIC
www.prolight.co.uk
POWER INPUT:
100-240V~50/60Hz
FUSE:
T2.5A 250V
POWER OUTPUT
0608
1111
10
02
05
01
04
09
03
07
Dish 5
Dish 1
Dish 2
Dish 6
Dish 4 Dish 3

www.prolight.co.uk GB-1 Reectabeam User Manual 5
Operating instructions
S P 1
S P 9
A d d r
A 0 0 1
A 5 1 2
DMX address setting
S h N d S h o U
Show mode
d I S p d S I P
Display inversion
S o U n
o n
oFF
Sound active mode
S e n S
0
100
Sound sensitivity
uEr
Software version
t e S t
Auto test
Channel mode
C h N d
2Ch
8Ch
Slave 1
S L N d S L 1
S L 2
N a S t
Master mode
Slave 2
Led
o n
oFF
LED display on
LED display off
A u t o
A u t
0
A u t 8
Auto mode

www.prolight.co.uk GB-1 Reectabeam User Manual 6
Operating instructions
DMX mode:
Operating in a DMX control mode environment gives the user the greatest exibility when it comes to
customising or creating a show. In this mode you will be able to control each individual trait of the xture
and each xture independently.
To access the DMX address mode, press the “MENU” button on the front of the unit to show Addr
on the LED display. Now press the “ENTER” button and use the “UP” and “DOWN” buttons to set the
required DMX address. Press the “ENTER” button to conrm the setting.
To exit out of any of the above options, press the “MENU” button.
To access the DMX channel mode, press the “MENU” button on the front of the unit to show ChNd on
the LED display. Now press the “ENTER” button and use the “UP” and “DOWN” buttons to choose one of
the 2 or 8 DMX channel modes. Press the “ENTER” button to conrm the setting.
To exit out of any of the above options, press the “MENU” button.
Channel Value Function
1 000-007 No function
008-037 Macro 1
038-067 Macro 2
068-097 Macro 3
098-127 Macro 4
128-157 Macro 5
158-187 Macro 6
188-217 Macro 7
218-247 Macro 8
248-255 Sound active
2 000-255 Macro speed
(when CH1 is 008-247),
Sound sensitivity
(when CH1 is 248-255)
2 channel mode:

www.prolight.co.uk GB-1 Reectabeam User Manual 7
Channel Value Function
1 000-005 Dish 1 no rotation
006-126 Dish 1 rotation (fast-slow anticlockwise)
127-128 Dish 1 no rotation
129-249 Dish 1 rotation (slow-fast clockwise)
250-255 Dish 1 no rotation
2 000-005 Dish 2 no rotation
006-126 Dish 2 rotation (fast-slow anticlockwise)
127-128 Dish 2 no rotation
129-249 Dish 2 rotation (slow-fast clockwise)
250-255 Dish 2 no rotation
3 000-005 Dish 3 no rotation
006-126 Dish 3 rotation (fast-slow anticlockwise)
127-128 Dish 3 no rotation
129-249 Dish 3 rotation (slow-fast clockwise)
250-255 Dish 3 no rotation
4 000-005 Dish 4 no rotation
006-126 Dish 4 rotation (fast-slow anticlockwise)
127-128 Dish 4 no rotation
129-249 Dish 4 rotation (slow-fast clockwise)
250-255 Dish 4 no rotation
5 000-005 Dish 5 no rotation
006-126 Dish 5 rotation (fast-slow anticlockwise)
127-128 Dish 5 no rotation
129-249 Dish 5 rotation (slow-fast clockwise)
250-255 Dish 5 no rotation
6 000-005 Dish 6 no rotation
006-126 Dish 6 rotation (fast-slow anticlockwise)
127-128 Dish 6 no rotation
129-249 Dish 6 rotation (slow-fast clockwise)
250-255 Dish 6 no rotation
7 000-007 No rotation
008-037 Macro 1
038-067 Macro 2
068-097 Macro 3
098-127 Macro 4
128-157 Macro 5
158-187 Macro 6
188-217 Macro 7
218-247 Macro 8
248-255 Sound active
8 000-255 Macro speed (when CH7is 008-247), Sound sensitivity (when CH1 is 248-255)
8 channel mode:
Operating instructions

www.prolight.co.uk GB-1 Reectabeam User Manual 8
Master/slave mode:
To set the master unit, press the “MENU” button on the front of the master unit to show SLNd on the
LED display. Now press the “ENTER” button and use the “UP” and “DOWN” buttons to choose Nast.
Press the “ENTER” button to conrm the setting. Then select your desired program (sound active, DMX
or one of the built-in programs).
To set the other units in slave mode, press the “MENU” button on the front of the unit to show SLNd
on the LED display. Now press the “ENTER” button and use the “UP” and “DOWN” buttons to choose
either SL1 (Slave 1) or SL2 (Slave 2). Press the “ENTER” button to conrm the setting. The unit will
now run in sequence with the master unit.
To exit out of any of the above options, press the “MENU” button.
Please ensure that all slave units are set to the same DMX channel mode as the master unit.
Show mode:
To access the show mode, press the “MENU” button on the front of the unit to show ShNd
on the LED display. Press the “ENTER” button to conrm the setting and the display will show ShoU.
To exit out of any of the above options, press the “MENU” button.
Auto mode (built-in programs):
To access the auto modes, press the “MENU” button on the front of the unit to show Auto
on the LED display. Now press the “ENTER” button and use the “UP” and “DOWN” buttons select
which auto mode you require Aut0 or Aut8. Press the “ENTER” button and use the “UP” and
“DOWN” buttons to set the speed 1~ 9. Press the “ENTER” button to conrm the setting.
Value: 1 - 9 (1 = slow, 9 = fast)
To exit out of any of the above options, press the “MENU” button.
Sound active mode:
To access the sound active mode, press the “MENU” button on the front of the unit to show SoUn
on the LED display. Now press the “ENTER” button and use the “UP” and “DOWN” buttons to set the
sound mode on or ofF. Press the “ENTER” button to conrm the setting.
To adjust the sound sensitivity, press the “MENU” button on the front of the unit to show Sens
on the LED display. Now press the “ENTER” button and use the “UP” and “DOWN” buttons to set the
sound sensitivity 0~ 100. Press the “ENTER” button to conrm the setting.
Value: 0 - 100 (0 = low sensitivity, 100 = high sensitivity)
To exit out of any of the above options, press the “MENU” button.

www.prolight.co.uk GB-1 Reectabeam User Manual 9
Setting the DMX address:
The DMX mode enables the use of a universal DMX controller. Each xture requires a “start address”
from 1- 511. A xture requiring one or more channels for control begins to read the data on the channel
indicated by the start address. For example, a xture that occupies or uses 7 channels of DMX and was
addressed to start on DMX channel 100, would read data from channels: 100,101,102,103,104,105
and 106. Choose a start address so that the channels used do not overlap. E.g. the next unit in the
chain starts at 107.
DMX 512:
DMX (Digital Multiplex) is a universal protocol used as a form of communication between intelligent
xtures and controllers. A DMX controller sends DMX data instructions form the controller to the xture.
DMX data is sent as serial data that travels from xture to xture via the DATA “IN” and DATA “OUT”
XLR terminals located on all DMX xtures (most controllers only have a data “out” terminal).
DMX linking:
DMX is a language allowing all makes and models of different manufactures to be linked together
and operate from a single controller, as long as all xtures and the controller are DMX compliant.
To ensure proper DMX data transmission, when using several DMX xtures try to use the shortest
cable path possible. The order in which xtures are connected in a DMX line does not inuence the
DMX addressing. For example; a xture assigned to a DMX address of 1 may be placed anywhere in
a DMX line, at the beginning, at the end, or anywhere in the middle. When a xture is assigned a
DMX address of 1, the DMX controller knows to send DATA assigned to address 1 to that unit,
no matter where it is located in the DMX chain.
DATA cable (DMX cable) requirements (for DMX operation):
This xture can be controlled via DMX-512 protocol. The DMX address is set on the back of the unit.
Your unit and your DMX controller require a standard 3-pin XLR connector for data input/output,
see image below.
Note: DMX cable must be daisy chained and cannot be split.
DMX setup
Further DMX cables can be
purchased from all good sound
and lighting suppliers or
Pro Light Concepts dealers.
Please quote:
CABL10 – 2m
CABL11 – 5m
CABL12 – 10m

www.prolight.co.uk GB-1 Reectabeam User Manual 10
Notice:
Be sure to follow the diagrams below when making your own cables. Do not connect the cables
shield conductor to the ground lug or allow the shield conductor to come in contact with the XLRs
outer casing. Grounding the shield could cause a short circuit and erratic behaviour.
Special note:
Line termination:
When longer runs of cable are used,
you may need to use a terminator on
the last unit to avoid erratic behaviour.
Using a cable terminator will decrease
the possibilities of erratic behaviour.
(3-pin - Order ref: CABL90, 5-pin - Order ref: CABL89)
5-pin XLR DMX connectors:
Some manufactures use 5-pin XLR connectors for data transmission in place of 3-pin. 5-pin XLR xtures
may be implemented in a 3-pin XLR DMX line. When inserting standard 5-pin XLR connectors in to a
3-pin line a cable adaptor must be used. The diagram below details the correct cable conversion.
Termination reduces signal transmission
problems and interference. It is always
advisable to connect a DMX terminal,
(resistance 120 Ohm 1/4 W) between pin 2
(DMX-) and pin 3 (DMX+) of the last xture.
5-pin XLR (female)
Pin 1: GND (screen)
Pin 2: Signal (-)
Pin 3: Signal (+)
Pin 4: N/C
Pin 5: N/C
3-pin XLR (female)
Pin 1: GND (screen)
Pin 2: Signal (-)
Pin 3: Signal (+)
3-pin XLR (male)
Pin 1: GND (screen)
Pin 2: Signal (-)
Pin 3: Signal (+)
5-pin XLR (male)
Pin 1: GND (screen)
Pin 2: Signal (-)
Pin 3: Signal (+)
Pin 4: N/C
Pin 5: N/C
DMX setup

www.prolight.co.uk GB-1 Reectabeam User Manual 11
WEEE notice
Correct Disposal of this Product
(Waste Electrical & Electronic Equipment)
(Applicable in the European Union and other European countries
with separate collection systems)
This marking shown on the product or its literature, indicates that it should not be disposed
with other household wastes at the end of its working life. To prevent possible harm to the
environment or human health from uncontrolled waste disposal, please separate this from other
types of wastes and recycle it responsibly to promote the sustainable reuse of material resources.
Household users should contact either the retailer where they purchased this product, or their
local government ofce, for details of where and how they can take this item for environmentally
safe recycling.
Business users should contact their supplier and check the terms and conditions of the
purchase contract. This product should not be mixed with other commercial wastes for disposal.

www.prolight.co.uk GB-1 Reectabeam User Manual 12
