emaux SC Series User manual

EMAUX WATER TECHNOLOGY CO., LTD
STRIVE FOR CLEAR WATER
www.emauxgroup.com
USER MANUAL
SC &SCUS SERIES
CENTRIFUGAL PUMP
Installation and Operation Manual
geprüfte
Sicherheit SAA
EMPU21070141

SC & SCUS SERIES
TABLE OF
CONTENT
PAGE
2
....
4
4
....
....
....
1.SC & SCUS SERIES CENTRIFUGAL PUMP OVERVIEW
WARNINGS AND SAFETY INSTRUCTIONS
2.PRODUCT INFORMATION
3.IMPORTANT SAFETY INSTRUCTIONS
5.START UP
....
6. ROUTINE MAINTENANCE
10
....
7. WINTERIZING
11
....
8. TROUBLE SHOOTING
12
....
.... 4.INSTALLATION
CENTRIFUGAL PUMP
P1 CONTENT
WARNINGS AND SAFETY INSTRUCTIONS
GENERAL WARNING
This instruction contain general caution information for use in Pool and SPA pump installation
application. Specified Pump model function should be refer to particular manual. Components such
as the filtration system, pumps and heater must be positioned so as to prevent their being used as
means of access to the pool by young children.
This appliance should be installed by qualified electrical personnel
in accordance with National Electrical Code and all applicable
local codes and ordinances.Hazardous voltage can shock, burn,
and cause death or serious property damage. DO NOT use an
extension cord to connect unit to electric supply to reduce the risk
of electric shock.
1.The pump should be permanently connected to an individual circuit breaker.
2.Pump must be connected to a residual current device (RCD) having a rated residual operating
current notexceeding 30 mA or receptacle with ground fault circuit interrupt (GCFI).
3. Electrical grounding must be connected before connecting to electrical power. Failure to ground all
electrical equipment can cause serious or fatal electrical shock hazard.
4.Bonding: Use at least #8 AWG (#6 AWG for Canada) a solid copper conductor, run a continuous wire
from external bonding lug (if available) to the pressure wire connector provided on the electrical
equipment and to all metal parts of swimming pool, spa, or hot tub, and metal piping (except gas
piping), and conduit within 1.5 m (5 ft) of inside walls of swimming pool, spa, or hot tub.
5.Never open the inside of the drive motor enclosure. There is a capacitor bank that holds a mains
supply voltage charge even when there is no power to the unit. The voltage should be referred to
the individual pump operation voltage.
6.The pump is capable of high flow rates; use caution when installing and programming to limit
pumps performance only.
7.Switch OFF pump power before servicing and disconnecting the main circuit to the pump.
8.Never change the filter control valve position while the pump is running.
RISK OF ELECTRICAL SHOCK
COMPRESS AIR HAZARDOUS
This system enclosed pre-filter / filter and become pressurized.
Pressurized air can cause the Lid to separate which can result in
serious injury or death.
Pool and spa circulation systems operate under high pressure. When any part of the circulating
system (i.e. lock ring, pump, filter, valves, etc.) is serviced, air can enter the system and become
pressurized. Filter tank Lid and pre-filter cover must be properly secured to prevent violent
separation. Place pre-filter / filter air relief valve in the open position and wait for all pressure in the
system to be relieved before remove the lib to access the basket for cleaning.
HYPERTHERMIA
SPA water temperature excess 38°C (104°F) may be injurious to
health. Measure water temperature before entering SPA.
Hyperthermia occurs when the internal temperature of the body
reaches a level several degrees above the normal body
temperature of 98.6 °F (37 °C). The symptoms of hyperthermia
include drowsiness, lethargy, and an increase in the internal temperature of the body.
WARNINGS AND SAFETY INSTRUCTIONS P2
STAND CLEAR OF PUMP DURING START-UP
6
6
9
9. REPLACEMENT PARTS
13
....
10. TERMS OF THE WARRANTY
16
....

240
221
370
A
SUCTION ENTRAPMENT HAZARD
This pump produces high levels of suction and creates a strong
vacuum at the main drain at the bottom of your pool and spa. This
suction is so strong that it can trap adults or children under water if
they come in close proximity to a pool or spa drain or a loose or
broken drain cover or grate.
The Virginia Graeme Baker (VGB) Pool and Spa Safety Act creates
new requirements for owners and operators of commercial
swimming Pools and spas.
Commercial pools or spas constructed on or after December 19, 2008, shall utilize:
1. A multiple main drain system without isolation capability with suction outlet covers that meet
ASME/ANSI A112.19.8a Suction Fittings for Use in Swimming Pools, Wading Pools, Spas, and Hot
Tubs and either:
1.1 A safety vacuum release system (SVRS) meeting ASME/ANSI A112.19.17 Manufactured Safety
Vacuum Release systems (SVRS)
For Residential and Commercial Swimming Pool, Spa, Hot Tub, and Wading Pool Suction
Systems and/or ASTM F2387 Standard
Specification for Manufactured Safety Vacuum Release Systems (SVRS) for Swimming pools,
Spas and Hot Tubs or
1.2 A properly designed and tested suction-limiting vent system or
1.3 An automatic pump shut-off system.
Commercial pools and spas constructed prior to December 19, 2008, with a single submerged suction
outlet shall use a suction outlet cover that meets ASME/ANSI A112.19.8a and either:
1. A SVRS meeting ASME/ANSI A112.19.17 and/or ASTM F2387, or
2. A properly designed and tested suction-limiting vent system, or
3. An automatic pump shut-off system, or
4. Disabled submerged outlets, or
5. Suction outlets shall be reconfigured into return inlets.
There are five types of suction entrapment according to The Virginia Graeme Baker (VGB) Pool and Spa
Safety Act
1.Body Entrapment a section of the torso becomes entrapped
2.Limb Entrapment an arm or leg is caught by or pulled into an open drainpipe
3.Hair Entrapment or entanglement hair is pulled into and/or wrapped around the grate of the drain
cover
4.Mechanical Entrapment the bather's jewelry or clothing gets caught in the drain or the grate
5.Evisceration the victim's buttocks come into contact with the pool suction outlet and he or she is
disemboweled
TO REDUCE ENTRAPMENT HAZARD RISK
Two function suctions outlets per pump must be installed to prevent entrapment.
The minimum separate of suction on the same plate must be at least point to point
measurement 1 meter (3ft) apart. It is used to avoid “dual blockage” by bather.
If suction is found damage, broken, cracked, missing or not securely attached during
regular checking, shunt down the pool and replace it immediately.
A vacuum release or vent system is recommended to install for suction entrapment release.
P3 SUCTION ENTRAPMENT HAZARD SC & SCUS SERIES CENTRIFUGAL PUMP OVERVIEW P4
1. SC & SCUS SERIES CENTRIFUGAL PUMP OVERVIEW
It is a low power, low noise and easy to maintenance self-priming pump for small
residential in ground pool installation. SC and SCUS series Pre-filter with transparent Lid
cover easy to observe the basket need to be clean or not.
IPX5 aluminum motor enclosure design is good for outdoor deployment and heat
dissipation.
There is built in thermal protection to protect the motor when fault operation cause
motor over heat.
SCUS is a 115V/230V 60Hz dual voltage pump which need a 3 phase electric power
supply for 230Vac operation.
2. PRODUCT INFORMATION
Model Input
Voltage Current
(AMP) Noise (dB)
Head(m)
4
FlowRate(m³/h)
SC050
SC075
SC100
SC150
SC200
SCUS100
SCUS150
SCUS200
0.51
0.75
0.97
1.30
1.71
0.97
1.40
1.80
Input
(kW)
220V
50/60Hz
115/230V
60Hz
2.5
3.5
4.7
5.9
8.2
8.4/4.2
12.4/6.2
16.0/8.0
60
68
70
70
73
70
70
73
6 8 10 12 14
12
16.4
19
22
26
17
6.8
13.8
17
20
23.2
15
20
22
9
14
17.2
21
12
18
20.8
10
14
18
7
15
18.6
11.8
16
5
13
SC
DIMENSIONS

P5 PRODUCT INFORMATION INSTALLATION P6
SCUS A
240
221
370
Horsepower
Capacitance
220V
Weight
(kg) Capacitance
110V
0.5hp
0.75hp
1.0hp
1.5hp
2.0hp
1.0hp
1.5hp
2.0hp
10.4
12.1
13.4
14.9
15.4
15
16
17.5
14µF
20µF
25µF
25µF
30µF
/
/
/
40µF
60µF
90µF
90µF
90µF
/
/
/
Model
Connection
Size
Code
230V/115V
60Hz
88020605
88020607
88020608
Sc050
SC075
SC100
SC150
SC200
SCUS100
SCUS150
SCUS200
1.5”/50mm
1.5”/50mm
1.5”/50mm
1.5”/50mm
1.5”/50mm
1.5”/50mm
1.5”/50mm
1.5”/50mm
88021703
88021704
88021705
88021707
88021708
/
/
/
Code
220V
50Hz
Code
220V
60Hz
/
/
/
/
/
88021803
88021804
88021805
88021807
88021808
/
/
/
PERFORMANCE CURVE
Remark: The performance curve above is for 50Hz models
80 100 120
0
10
20
30
40
50
60
14 16 18 20 22 24 26 Q(m³/h)
Q(LPM)
250 300 350 400 450
SC020SC075
SC200
SCUS200
SCUS150
SC150
SC100
SCUS100
20 40 60
4 6 8 10 12
50 100 150 200
20
18
16
14
12
10
8
6
4
2
0
H(m)
U.S.g.p.m
0
2
0
3. IMPORTANT SAFETY INSTRUCTIONS
The user guide you are holding includes essential information on
the safety measures to be implemented for installation and start-
up. Therefore, the installer as well as the user must read the
instructions before beginning installation and start-up. Keep this
manual for future reference.
The pump should be installed according to your local electrical installation ordinances
and regulations. Only qualified, licensed personnel should install the pump and the
wiring.
This appliance cannot be used by persons (including children) with reduced physical,
sensory or mental capabilities or lack of experience and knowledge unless they have
been given supervision or instruction concerning use of the appliance in a safe way and
understand the hazards involved. Children must not play with the appliance.
This appliance can be used by children aged from 8 years and above and persons with
reduced physical, sensory or mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction concerning use of the appliance in a safe
way and understand the hazards involved. Children shall not play with the appliance.
Cleaning and user maintenance shall not be made by children without supervision.
4. INSTALLATION
4.1 PIPING
1. Install the pump as close to the pool as possible, preferably in a dry, well ventilated
area away from direct sunlight. Protect the pump from excessive moisture.
2. Place the pump as close to the water source as possible, so that the suction pipe is
short, straight and direct to reduce the friction loss. Don't install the pump at more
than 10 ft (3 meters) of geometrical height from water level.
3. Before installing the pump, make sure that the surface is solid, elevated, rigid and
vibration free.
4. Secure the pump to the base with screws or bolts to limit the vibration and the stress
on the pipe or the joints.
5. Leave enough space for gate valves in suction and discharge piping, if required.
6. Ensure there is enough clearance for pre-filter basket & Lid open and motor
ventilation.
7. Connect the suction and discharge pipe to the outlet and inlet of the swimming pool.
8. Make sure that floor drainage is adequate to prevent flooding.
9. Make sure that the pump and piping are accessible for servicing.

P7 INSTALLATION
MIN 5 X SUCTION PIPE DIAMETER
ELBOW
Veritcal lift
no more than 2m(6ft)
Recommended Piping
Note: The pump suction and discharge connections are
mounded in thread stops, DO NOT try to screw the
pipe beyond these stops.
The two sets of 1.5” or 2” (refer to individual product
connection) union adaptor are universal design for
metric and imperial for PVC pipe connection.
4.2 ELECTRICAL WIRING
This power pump demand licensed or certified
electrician or qualified pool installer to ensure
there is adequate protection between the pump
motor and mains power supply according to
individual countries safety code.
The pump has power cord with plug attached on
the plug, plug it to a power socket with circuit
breaker to isolate the motor from the mains power for over load protection. The circuit
breaker rating should refer to the electrical specification of individual pump working
voltage and power.
The power has to be with a Residual Current Device (RCD) or Ground Fault Circuit
Interrupt (GFCI) having a rated residual operating current not exceeding 30mA.
If the RCD / GFCI device trips, it means there is fault on the power
line or motor. Do not use this pump. Disconnect the pump and have
the problem corrected by a qualified service representative before
using. Press the reset button to reset the RDC / GFCI devices after
fixed. It will keeps the circuit shut off and will not reset if the power
line problem is not fixed.
It is recommend to test the RCD / GFCI at least once a month.
Pumps should be shipped with Power cord with plug for corresponding countries. If
there is not power cord attached to the pump, it is necessary to follow the local
electricity power line color code to connect the power according to the wiring for
individual pump diagram.
4.3 WIRING BOX DIAGRAM
SCUS100, SDUS150 and SCUS200 is 115/230V dual voltage operation pump for United
State market. 3 phase electricity power source is needed when 230V is connected. 115V
or 230Vac have to connect L1 line to terminal L1 and L2 line to L2 terminal according to
the wiring diagram.
Ground on motor metal case
1
2
3
Protector
Red
Black
115V~60Hz
Black
Red
Yellow
L1 L2 A B
Blue
White M
SCUS100, SCUS150 and SCUS200 (230Vac)
INSTALLATION P8

P9 START UP ROUTINE MAINTENANCE P10
SCUS100, SCUS150 and SCUS200 (230Vac)
1
2
3
Protector
Red
Black
230V~60Hz
Black
Red
Yellow
L1 L2 A B
Blue
White M
Bonding Terminal
Bonding Instructions – Permanently wired units will need to
include instructions for connecting the solid copper, equipotential
bonding conductor. For SCUS200, SCUS100, and SCUS150 with ETL
Mark for the United States, the size of the bonding conductor
should be No.8 AWG. For Canada the size of the bonding conductor
should be No. 6 AWG. Bonding Nut location is as photo.
5. START UP
1.Verify the pump shaft turn freely.
2.Check the mains voltage, current and frequency are accordingly
to the name plate.
3.Never run pump dry! Running pump dry may cause damage to
the mechanical seal causing leakage and flooding. Fill the pre-
filter with water before starting motor.
4.Before removing the pre-filter Lid, STOP PUMP, CLOSE GATE VALVES in suction and
discharge pipes.
5.Always STOP THE PUMP before when RELEASE ALL PRESSURE from the pump and the
piping system before proceeding.
6.Never tighten or loosen screw while the pump is in operation.
7.The suction pipe and the suction inlet in the pool must be free from obstruction.
Tighten/untighten the pump Lid by hand only.
Before start-up, the alignment of the pump should be checked.
The tubing should be inspected to ensure that they are properly
fitted and tightened and that they do not exert pressure or tension
on the pump's suction or discharge connection. The pump should
never be operated.
1. Clear all piping of construction debris and verify that the piping has passed a proper
pressure test.
2. Check the filter and other equipment for proper installation, verifying all clamps and
connections are properly installed as per the manufacturer's instructions.
3. Open any shut off valves on the suction and discharge lines.
4. Open the filter pressure relief valve and release all pressure from the system.
5. If the pump is located below the water level of the pool, opening the pressure relief
valve will fill the pump with water.
6. If the pump is located above the pool water level, remove the Lid from the pre-filter
and fill with water before starting the pump.
7. Check to see that the Lid O-ring and seat areas are clean and lubricated. Debris in the
sealing area can cause air to leak into the system and make it difficult to prime the
pump.
8. Close/tighten the Lid to make an airtight seal.
9. Turn on the pump.
10. If the pump does not prime within 15 minutes. Ensure all instructions to this point
have been followed. Stop the pump! Check for suction leaks and repeat steps (1)
through (8).
6. ROUTINE MAINTENANCE
The only routine maintenance needed is the inspection and cleaning of the pre-filter
basket. Debris or trash collected in the basket will choke off the water flow through the
pump. Follow the instructions below in order to clean the pre-filter basket:
1. Turn off the pump, close the gate valve in suction and discharge, and release all
pressure from the system before proceeding.
2. For SC pump series, turn the transparent Lid cover follow the arrow on the Lid cover by
opening key provided to release and lock the Lid ring. For SCUS pump series, place the
key for Lid around the transparent Lid cover, hold the two handles and turn anti
clockwise to release the Lid.
3. Remove the pre-filter basket and cleaning. Make sure all the holes in the basket are
clear, flush the basket with water and replace it in the trap with large opening at the
pipe connection port(between ribs provided). If the basket is replaced back wards, the
cover will not fit on the trap body.

P11 WINTERIZING
8. TROUBLE SHOOTING
Pump delivers no water
Leakage of water at the shaft
Low pump capacity
1. Valve in the suction or discharge line partly closed
2. Suction or discharge line partly plugged
3. Suction or discharge line too small
4. Plugged basket in skimmer or hair and lint pre-filter
5. Dirty sand filter
6. Impeller clogged
1.Shaft seal requires replacement
1.Pump is not primed
2.Closed valve in suction or discharge line
3.Leakage or air into suction system
4.Impeller clogged
High pump pressure 1. Discharge vale or inlet fittings closed too much
2. Return lines too small
3. Dirty filters
Noisy pump and motor
1.Plugged basket in skinner or hair in lint pre-filter
2.Worn motor bearings
3.Valve in suction line partly closed
4.Suction line partly plugged
5.Vacuum hose plugged or too small
6.Pump not supported properly
1.Leakage of air into the suction line in connections or valve stem
2.Cover gasket of hair and lint pre-filter needs cleaning
3.Low water level in the pool
Air bubbles at inlet fittings
Problem description Possible causes
Motor does not start
1.Disconnect switch or circuit breaker in off position
2.Fuses blown or thermal overload open
3.Locked motor shaft
4.Motor windings burned out
5.Defective starting switch inside single phase motor
6. Disconnected or defective wiring
7.Low voltage
Pump does not reach full speed 1. Low voltage
2. Pump connected to the wrong voltage
Motor overheats
(protector trips)
1. Low voltage
2. Motor windings connected to the wrongvoltage on dual voltage model
3. Inadequate ventilation
Note: If the above recommendations of this manual do not solve your particular problem(s),
please contact your local service agent for further assistance.
TROUBLE SHOOTING P12
4. Clean and inspect the Lid's O-ring ring; reinstall on the Lid cover.
5. Clean the ring groove on the pre-filter body and replace the Lid. To help keep the Lid
from sticking, tighten it by hand only.
6. Fill up the filter body with water and Prime the pump.
SC Series SCUS Series Basket opening face to suction inlet
7. WINTERIZING
If the air temperature drops below 0°C (35°F), the water in the system can freeze and
cause damage. Freezing damage is not warrantable.
To prevent freezing damage follow the procedures listed below:
1.Shut off electrical power for the pump at the house circuit breaker.
2.Drain the water out of the pump case by removing the two drain plugs from the case.
3.Store the plugs in the pump basket.
4.Cover the motor to protect it from severe rain, snow and ice.
5.If it is possible, store the pump in a dry location during this time.
6.Do not wrap the motor in plastic. It will cause condensation and rust on the inside of
the motor.

P13 REPLACEMENT PARTS
9. REPLACEMENT PARTS
Key No. Part No. Description QTY
1
2
3
4*
5
6
7
8
9
10
10
10
10
10
10
10
11
12
13
01041043
01311010
01311011
01311012
01311013
E020001
02011089
01111008
02021088
01111076
89280105
89021307
01111006
02011105
01111009
89021704
01311007
01311008
01311009
TransparentLid
O-RingforLid
Basket(Big)
1.5"Union(Black/WhiteColour)
DrainPlugWithO'Ring
SCPumpBody
O-ringforDiffuser
Diffuser
ImpellerScrewwith O-ring
ImpellerSC050(110V/60HZ) &(220V/60HZ)
ImpellerSC075(110V/60HZ) &(220V/60HZ)
ImpellerSC050(220V/50HZ) &(380V/50HZ)/SC100(110V/60HZ)&(220V/60)
ImpellerSC075(220V/50HZ) &(380V/50HZ)/SC150(110V/60HZ)&(220V/60HZ)
mpellerSC100(220V/50HZ)& (380V/50HZ)/SC200(110V/60HZ)&(220V/60HZ
ImpellerSC150(220V/50HZ) &(380V/50HZ)
ImpellerSC150(220V/50HZ) &(380V/50HZ)
3/4"MechanicalSeal
O-RingforFlange
SCPumpFlange
1
1
1
2
2
1
1
1
1
1
1
1
1
1
1
1
4
1
1
15
16
16
16
16
16
16
16
16
16
16
16
16
16
16
16
16
16
16
16
16
17
18
19
20
21
21
21
21
21
21
21
21
22
23
24
25
14 01021014
02011096
89021705
89021706
89021707
89021708
89021709
89021801
89021802
89021803
89021804
89021805
89022001
89022002
89022003
89022004
89022005
89021901
89021902
89021903
89021904
89021905
01021022
01111007
89021311
89021505
04016019
04016021
04016022
04016023
04016010
04016012
04016014
04016015
01031007
01031009
01031002
02011104
Ring Lock Nut
Motor SC050(220V/50HZ)
Motor SC075(220V/50HZ)
Motor SC100(220V/50HZ)
Motor SC150(220V/50HZ)
Motor SC200(220V/50HZ)
Motor SC050(220V/60HZ)
Motor SC075(220V/60HZ)
Motor SC100(220V/60HZ)
Motor SC150(220V/60HZ)
Motor SC200(220V/60HZ)
Motor SC050(380V/50HZ)
Motor SC075(380V/50HZ)
Motor SC100(380V/50HZ)
Motor SC150(380V/50HZ)
Motor SC200(380V/50HZ)
Motor SC050(110V/60HZ)
Motor SC075(110V/60HZ)
Motor SC100(110V/60HZ)
Motor SC150(110V/60HZ)
Motor SC200(110V/60HZ)
Opening Key
Base
Cable Box for SC Pump (220V/50Hz))
Cable Box for SC Pump (110V/60Hz))
Capacitor for SC050 & SS/SD/SQ/ST075 Pump (110V)
Capacitor for SC075 & SS/SD/SQ/ST100-124 Pump (110V)
Capacitor for SR/SB10-15 & SC100-150 Pump (110V)
Capacitor for SR/SB20-30 & SC200 Pump (110V)
Capacitor for SS/SD/SQ/SP/ST075 & SC050 Pump
Capacitor for SS/SD/SQ/SP/ST100-120/ SC075
Capacitor for SB/SR10,SB15/ SC100/ SC150
Capacitor for SB/SR20 & SC/EPH200 & SPH200 Pump
Cooling Fan for SC SB/SR10,SB/SR15
Fan Cover for SB/SR10,SB/SR15 Pump (220V/50Hz)
Fan Cover for SB/SR10,SB/SR15 Pump (110V/60Hz)
O-Ring for 1.5" Union
Motor Slinger
Key No. Part No. Description QTY
REPLACEMENT PARTS P14
9.1 SC SERIES
1
2
3
4
5
6
78
9
10
11
12 13
14 15 16
17
18
16
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
2

8
791012 13 14 15
18
1
2
3
24
4
5617
11
16
20
21
23
22
19
Note: 4* 89280105B is 1.5" Union is in Black Color
4* 89280105W is 1.5" Union is in White Color
P15 REPLACEMENT PARTS TERMS OF THE WARRANTY P16
9.2 SCUS SERIES
2
3
4
5
6
7
8
9
10
10
10
11
12
13
14
15
101041046
02021088
01111076
89280105B
89021307
01111006
02011105
01111009
89021704
01311009
01311010
01311011
E020001
02011089
01111008
01021014
02011096
Transparent Lid
O-Ring for lid
Basket (Big)
1.5"union(Black)
Drain Plug With O-ring
SCUS Pump Body
O-ring for Diffuser
Diffuser
Impeller Screw with O-ring
Impeller SCUS100(115/230V 60HZ)
Impeller SCUS150(115/230V 60HZ)
Impeller SCUS200(115/230V 60HZ)
3/4"Mechanical seal
O-ring for Flange
SC Pump Flange
Ring Lock Nut
Motor Slinger
Key No. Part No. Description QTY
1
1
1
2
1
1
1
1
1
1
1
1
1
1
1
1
1
16
16
17
18
19
20
21
21
22
23
24
16 04020096
04020097
04020098
01021022
01111007
01020014
89021505
04016041
04016042
01031007
01031002
02011104
Motor SCUS100(115/230V 60HZ)
Motor SCUS150(115/230V 60HZ)
Motor SCUS200(115/230V 60HZ)
Opening Key
Base
Key for transparent Lid
Cable Box for SCUS Pump
Capacitor for SCUS100-SCUS150 Pump
Capacitor for SCUS200 Pump
Cooling fan for SC SB/SR10,SB/SR15/SCUS
Fan Cover for SB/SR10,SB/SR15 Pump/SCUS
O-Ring for 1.5" Union
Key No. Part No. Description QTY
1
1
1
1
1
2
1
1
1
1
1
2
10. TERMS OF THE WARRANTY
As original purchaser of this equipment have purchased from Emaux Water Technology
Co Ltd, through Authorized International Distributor or Dealer, warrants its products free
from defects in materials and workmanship under normal use during warranty period.
The warranty period begins on the day of purchase and extends only to the original
purchaser. It is not transferable to anyone who subsequently purchases the product from
you. It excludes all expendable parts.
During the warranty period, Emaux authorized reseller will repair or replace defective
parts with new parts or, at the option of Emaux, serviceable used parts that are
equivalent or superior to new parts in performance.

P17 TERMS OF THE WARRANTY
This Limited Warranty extends only to products purchased from Emaux authorized
reseller. This Limited Warranty does not extend to any product that has been damaged or
rendered defective
(a) as a result of accident, misuse or abuse;
(b) as a result of an act of God;
(c) by operation outside the usage parameters stated herein;
(d) by the use of parts not manufactured or sold by Emaux;
(e) by modification of the product;
(f) as a result of war or terrorist attack; or
(g) as a result of service by anyone other than Emaux authorized reseller or authorized
agent.
EXCEPT AS EXPRESSLY SET FORTH IN THIS WARRANTY, EMAUX MAKES NO OTHER
WARRANTIES EXPRESSED OR IMPLIED, INCLUDING ANY IMPLIED WARRANTIES OR
MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. EMAUX EXPRESSLY
DISCLAIMS ALL WARRANTIES NOT STATED IN THIS LIMITED WARRANTY. ANY IMPLIED
WARRANTIES THAT MAY BE IMPOSED BY LAW ARE LIMITED TO THE TERMS OF THIS
EXPRESS LIMITED WARRANTY.
