emaux UPH Series User manual

USER MANUAL
HIGH PREFORMANCE & HEAVY DUTY
For residential and semi-commercial pools
Model: UPH Series
ULTRA-POWER
COMMERCIAL PUMP
EMPU22041902

HIGH PREFORMANCE & HEAVY DUTY
TABLE OF
CONTENT
PAGE
2
.... WARNINGS AND SAFETY INSTRUCTIONS
4
5
7
10
9
10
....
....
....
....
....
1. UPH SERIES PUMP OVERVIEW
2. PRODUCT INFORMATION
3. IMPORTANT SAFETY INSTRUCTIONS
4. INSTALLATION
4.1 PIPING
4.2 ELECTRICAL WIRING– 3 PHASE
5. START UP
6. ROUTINE MAINTENANCE
7. WINTERIZING
8. REPLACEMENT PARTS
9. TROUBLE SHOOTING
10. TERMS OF THE WARRANTY
6
....
P1 CONTENT
ULTRA-POWER COMMERCIAL PUMP
....
8
3
.... SUCTION ENTRAPMENT HAZARD

WARNINGS AND SAFETY INSTRUCTIONS
GENERAL WARNING
These instructions contain general safety information for the use of pumps in Pool and SPA installations. For
specific pump models, refer to the respective manual. Components such as the filtration system, pumps and
heaters should not be located in an area used by young children for access to the pool.
This appliance should be installed by qualified electrical personnel in
accordance with National Electrical Code and all applicable local codes
and ordinances. Hazardous voltage can shock, burn, and cause death or
serious property damage. In order to reduce the risk of electric shock,
“DO NOT” use an extension cord to connect the unit to an electricity
supply.
1. The pump should be permanently connected to an individual circuit breaker.
2. Pump must be connected to a residual current device (RCD) having a rated residual operating current not
exceeding 30 mA or receptacle with ground fault circuit interrupt (GCFI).
3. Electrical grounding must be connected before connecting to electrical power. Failure to ground all electrical
equipment can cause serious or fatal electrical shock hazard.
4. Bonding: Use at least #8 AWG (#6 AWG for Canada) a solid copper conductor, run a continuous wire from
external bonding lug (if available) to the pressure wire connector provided on the electrical equipment and to
all metal parts of swimming pool, spa, or hot tub, and metal piping (except gas piping), and conduit within
1.5m (5 ft) of inside walls of swimming pool, spa, or hot tub.
5. Never open the inside of the drive motor enclosure. There is a capacitor bank that holds a mains supply
voltage charge even when there is no power to the unit. The voltage should be referred to the individual
pump operation voltage.
6. The pump is capable of high flow rates; use caution when installing and programming to limit pumps
performance only.
7. Switch OFF pump power before servicing and disconnecting the main circuit to the pump.
8. Never change the filter control valve position while the pump is running.
RISK OF ELECTRICAL SHOCK
COMPRESS AIR HAZARDOUS
Enclosed pre-filter / filter system will become pressurized. Compressed
air can cause the lid to separate which can result in serious injury or
death.
Pool and spa circulation systems operate under high pressure. When any
part of the circulating system (i.e. lock ring,
pump, filter, valves, etc.) is serviced, air can enter the system and become pressurized. Filter tank lid and pre-
filter cover must be properly secured to prevent violent separation. Set the pre-filter / filter air relief valve in the
open position and wait for all pressure in the system to be relieved before remove the lib to access the basket
for cleaning.
HYPERTHERMIA
SPA water temperature excess 38°C (104°F) may be hazardous to health.
Test water temperature before entering spa water.
Hyperthermia occurs when the internal temperature of the body reaches
a level several degrees above the normal body temperature of
98.6 °F (37 °C). The symptoms of hyperthermia include drowsiness,
lethargy, and an increase in the internal temperature of the body.
WARNINGS AND SAFETY INSTRUCTIONS P2

SUCTION ENTRAPMENT HAZARD
This pump produces high levels of suction and creates a strong vacuum
at the main drain at the bottom of your pool and spa. This suction is so
strong that it can trap adults or children under water if they come in
close proximity to a pool or spa drain or a loose or broken drain cover or
grate.
The Virginia Graeme Baker (VGB) Pool and Spa Safety Act creates new
requirements for owners and operators of commercial swimming Pools
and spas.
Commercial pools or spas constructed on or after December 19, 2008, shall utilize:
1. A multiple main drain system without isolation capability with suction outlet covers that meet ASME/ANSI
A112.19.8a Suction Fittings for Use in Swimming Pools, Wading Pools, Spas, and Hot Tubs and either:
1.1 A safety vacuum release system (SVRS) meeting ASME/ANSI A112.19.17 Manufactured Safety Vacuum
Release systems (SVRS)
For Residential and Commercial Swimming Pool, Spa, Hot Tub, and Wading Pool Suction Systems and/or
ASTM F2387 Standard
Specification for Manufactured Safety Vacuum Release Systems (SVRS) for Swimming pools, Spas and Hot
Tubs or
1.2 A properly designed and tested suction-limiting vent system or
1.3 An automatic pump shut-off system.
Commercial pools and spas constructed prior to December 19, 2008, with a single submerged suction outlet shall
use a suction outlet cover that meets ASME/ANSI A112.19.8a and either:
1. A SVRS meeting ASME / ANSI A112.19.17 and/or ASTM F2387, or
2. A properly designed and tested suction-limiting vent system, or
3. An automatic pump shut-off system, or
4. Disabled submerged outlets, or
5. Suction outlets shall be reconfigured into return inlets.
There are five types of suction entrapment according to The Virginia Graeme Baker (VGB) Pool and Spa Safety Act
1. Body Entrapment a section of the torso becomes entrapped
2. Limb Entrapment an arm or leg is caught by or pulled into an open drainpipe
3. Hair Entrapment or entanglement hair is pulled into and/or wrapped around the grate of the drain cover
4. Mechanical Entrapment the bather's jewelry or clothing gets caught in the drain or the grate
5. Evisceration the victim's buttocks come into contact with the pool suction outlet and he or she is disemboweled
TO REDUCE ENTRAPMENT HAZARD RISK
To prevent entrapment, two functioning suction outlets per pump must be installed. The
minimum separation of suction on the same floor or wall must be at least 1 meter (3ft). This
will avoid “dual blockage” by bather.
If the drain or its cover is damaged, broken, cracked, missing or not securely attached, shut
down the pool and replace it immediately.
A vacuum safety release or vent system is recommended to be installed for suction entrapment release.
P3 SUCTION ENTRAPMENT HAZARD

1. UPH SERIES ULTRS POWER PUMP OVERVIEW
Ultra-Power is a series of high-performance pumps designed to achieve the highest flows among similar pumps
on the market. By utilizing state-of-the-art engineering, the one-piece molded pump body with a large capacity
8-liter strainer basket makes it unique among all comparable pumps. Built with corrosion and chemical resistant
glass-reinforced thermoplastic and superior seawater graded mechanical seal guarantee a long working life.
Ultra-Power is Emaux’s first commercial pump with a 3” union to achieve the hydraulic performance of more
than 45m3/h at 18m of head (7hp model). With a wide selection of power options (4, 5.5 and 7hp) available in 3-
phase motors, it becomes one of the most efficient and energy-saving solutions for various ranges of the
commercial pool and seawater facilities.
2. PRODUCT INFORMATION
DIMENSIONS
UPH SERIES ULTRS POWER PUMP OVERVIEW P4
Code
380V/50Hz Model Connection
Size
9024401 UPH400 3”/90mm 4
9024402
9024403
UPH550
UPH700
5.5
7
3”/90mm
3”/90mm
Horsepower
(hp) Strainer
Vol(L)
8
8
8
RPM
2850
2850
2850
Input
Power
(kw)
3
4
5
Noise
(dB)
70
72
72
Current
(AMP)
5.5
7
9
Head(m)
8 10 12 14 16 18
FlowRate(m³/h)
64
82
96
62
75
90 82 72 60 45
66 58 43 28
53 42 30 -

IMPORTANT: The instruction manual you are holding includes essential information on the
safety measures for installation and start-up of this equipment. Therefore, the installer as
well as the user must read the instructions before beginning installation and start-up. Keep
this manual for future reference.
1. A protective device is to be installed in the fixed wiring.
2. This appliance cannot be used by children (8 years or below). Children shall not play with the appliance.
Cleaning and user maintenance shall not be made by children without supervision.
3. This appliance cannot be used by persons with reduced physical, sensory or mental capabilities, or lack of
experience and knowledge, unless they have been given supervision or instruction concerning the use of the
appliance by a person responsible for their safety.
4. The appliance shall be installed in accordance with national wiring regulations and a means of disconnection
must be incorporated in the fixed wiring in accordance with the wiring rules. A disconnected system must be
incorporated in the fixed.
5. The pump is to be supplied through a residual current device (RCD) or Ground Fault Circuit Interrupt (GFCI)
having a rated residual operation current not exceeding 30mA.
PERFORMANCE DATA
P5 IMPORTANT SAFETY INSTRUCTIONS
3. IMPORTANT SAFETY INSTRUCTIONS
Correct disposal of this product
This symbol on the product, or in its packaging, indicates that this
product may not be treated as household waste. Instead, it should be
taken to the appropriate waste collection point for the recycling of
electrical and electronic equipment. By ensuring this product is
disposed of correctly, you will help prevent potential negative
consequences for the environment and human health, which could
otherwise be caused by the inappropriate waste handling of this
product. For more detailed information about the recycling of this
product, please contact your local council, your household waste
disposal service, or the shop where you purchased the product.

4. INSTALLATION
4.1 PIPING
1. Install the pump as close to the pool as possible, preferably in a dry, well ventilated area away from direct
sunlight. Protect the pump from excessive moisture.
2. Place the pump as close to the water source as possible, so that the suction pipe is short, straight and direct
to reduce the friction loss. Don't install the pump at more than 10ft (3 meters) of geometrical height from
water level. Pump priming time for 3m (10ft) should be at least 7 minutes at 2900 RPM.
3. Before installing the pump, make sure that the surface is solid, elevated, rigid and vibration free.
4. Secure the pump to the base with screws or bolts to limit the vibration and the stress on the pipe or the joints.
5. Leave enough space for gate valves in suction and discharge piping, if required.
6. Connect the suction and discharge pipe to theoutlet and inlet of the swimming pool.
7. Make sure that floor drainage is adequate to prevent flooding.
8. Make sure that the pump and piping are accessible for servicing.
INSTALLATION P6
Note: The pump suction and discharge connections have thread stops, DO NOT try to screw the pipe beyond
these stops.
The two sets of 3” union adaptors with 3” nut are universally designed for bot metric and imperial PVC pipe
connection.
4.2 ELECTRICAL WIRING
WARNING: This power pump requires a certified electrician or qualified
poor installer to ensure there is adequate protection between the pump
motor and mains power supply according to individual country’s safely
code.
1. The pump has to connect to circuit breaker to isolate the motor from the mains power for overload
protection. The circuit breaker rating should comply with the electrical specification of the pump’s working
voltage and power.
2. 3-phase motor require external three-phase motor starter or magnetic motor starter to control the motor on/
off.
3. To ensure the rotation of the pump, power up the motor for a second then off to check the rotation of the
motor fan or shaft. The fan or shaft will match the rotation arrow noted on the pump if wired correctly. Swap
either two connection (wired to U1, V1 or W1) if direction is revised.
4. The power supply must be equipment with a Residual Current Device (RCD) or Ground Fault Circuit Interrupt

V2 U2 W2
U1 V1 W1
L1 L2 L3
U1 V1 W1
L1 L2 L3
V2 U2 W2
P7 INSTALLATION
If the RCD/GFCI device trips, it means there is fault on the power line or motor. Do not use
this pump. Disconnect the pump and have the problem corrected by a qualified service
representative before using. Press the reset button to reset the RDC/GFCI devices after
fixing. If the power line problem is not fixed it will keep the circuit shut off and will not
reset.
It is recommended to test the RCD/GFCI at least once a month.
P7 INSTALLATION
RCD NEMA GFCI Receptacle NEMA GFCI Breaker
This is a 380Vac (+10% - 6%) 50/60Hz three-phase pump.
Unscrew the terminal box at the top of the pump. There are four terminals labelled as U1, V1, W1 and T (EARTH).
Connect the power wires to these terminals according to the electrical code.
UPH550/UPH700
Delta Connection
UPH400
WYE/STAR Connection
5. START UP
1. Verify the pump shaft turn freely.
2. Check that the mains voltage, current and frequency correspond with the name plate.
3. Never let the pump run dry! Running a pump dry may cause damage the mechanical seal
causing leakage and flooding.
4. Fill the pre-filter with water before starting the motor.
5. Before removing the pre-filter lid, STOP PUMP, CLOSE GATE VALVES in suction and discharge pipes.
6. Always STOP THE PUMP before when RELEASING ALL PRESSURE from the pump and the piping system.
7. Never tighten or loosen screw while the pump is in operation.
8. The suction pipe and the suction inlet in the pool must be free from obstruction.
Tighten/untighten the pump Lid by hand only.
Earth
Earth

START UP P8
Before start-up, check the alignment of the pump. The pipes should be inspected to ensure
that they are properly fitted and tightened and that they do not exert pressure or tension
on the pump's suction or discharge connection.
1. Clear all piping of construction debris and verify that the piping has passed a proper pressure test.
2. Check the filter and other equipment for proper installation, verifying all clamps and connections are properly
installed as per the manufacturer's instructions.
3. Open any shut off valves on the suction and discharge lines.
4. Open the filter pressure relief valve and release all pressure from the system.
5. If the pump is located below the water level of the pool, opening the pressure relief valve will fill the pump
with water.
6. If the pump is located above the pool water level, remove the Lid from the pre-filter and fill with water before
starting the pump.
7. Check to see that the Lid O-ring and seat areas are clean and lubricated. Debris in the sealing area can cause
air to leak into the system and make it difficult to prime the pump.
8. Close/tighten the Lid to make an airtight seal.
9. Turn on power wait for pump to prime. Pump priming time for 3m (10ft) should be at least 7 minutes. Priming
will depend on vertical length of suction lift and horizontal length of suction pipe. If the pump does not
prime within priming time, stop the motor and determine cause.
10. If the pump does not prime within 10 minutes. Ensure all instructions to this point have been followed. Stop
the pump! Check for suction leaks and repeat steps (I) through (VIII).
6. ROUTINE MAINTENANCE
The pump mechanical seal requires no lubrication and service.
The only routine maintenance needed is the inspection and cleaning of the pre-filter basket. Debris or trash
collected in the basket will choke off the water flow through the pump. Follow the instructions below in order to
clean the pre-filter basket:
1. Turn off the pump, close the gate valve in suction and discharge, and release all pressure from the system
before proceeding.
2. Lose the suction inlet hose or piping.
3. Turn the ring-lock by hand to open it and release the transparent Lid.
4. Remove the pre-filter basket and clean. Make sure all the holes in the basket are clear, flush the basket with
water. Put back the basket with the guideline on the edge of the basket. If the basket is not placed correctly,
the transparent lid and its ring-lock will not fit well and will cause air leakage.
5. Clean and inspect the lid O-ring ring and replace it if it is damaged. Reinstall it on the transparent lid.
6. Clean the ring groove on the pre-filter body and replace the Lid. To help keep the Lid from sticking, tighten it
by hand only.
7. Connect back the suction hose or pipe. Water should flood the pump body and restart the pump.
8. Restart the pump and check that it is priming correctly.
7. WINTERIZING
If the air temperature drops below 0°C (35°F), the water in the system can freeze and cause damage. Damage
due to freezing is not covered by warranty.
Prevention of damage from freezing:
1. Shut off electrical power for the pump at the house circuit breaker.
2. Drain the water out of the pump case by removing the two drain plugs from the case.
3. Store the plugs in the pump basket.
4. Cover the motor to protect it from severe rain, snow and ice.
5. If it is possible, store the pump in a dry location during this time.
6. Do not wrap the motor in plastic. It will cause condensation and rust on the inside of the motor.

P9 REPLACEMENT PARTS
8. REPLACEMENT PARTS
Key No. Part No. Description QTY
1
2
3
4
5
6
7
8
9
10
10
11
12
13
14
14
14
15
16
17
18
19
20
20
20
21
22
420408561
420386559
111010040
420236559
420058561
01111017
02020014
420228563
111002561
430301835
430301845
111010055
112010164
420218561
420369026
420369027
420368562
111010053
112010163
420208561
112000069
42059099028
42059099029
42059099030
112192716
420128561
113005935
1
1
1
1
1
2
2
2
2
2
2
1
3
1
1
1
1
1
1
1
1
10
1
1
1
4
1
Nut For Lid
Transparent Lid
O-Ring For Lid
Basket
Pre-Filter Body
Drain Plug
O-Ring
Union Nut
O-Ring for Union
3" Union Adaptor
GB90mm Union Adaptor
O-Ring for Diffuser
M4.2X42 Screw
Diffuser
Impeller For 4HP(380V 50Hz)
Impeller For 5.5HP(380V 50Hz)
Impeller For 7HP(380V 50Hz)
O-Ring for Flange
3/4" Mechanical Seal
Screw for Impeller
Flange
M8X35 Screw
Motor for UPH400
Motor for UPH550
Motor for UPH700
M10X30 Screw
Base
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
8
9
10
16
17
18
19 20
21
22

TROUBLE SHOOTING P10
9. TROUBLE SHOOTING
Problem description Possible causes
Motor does not start
1. Disconnect switch or circuit breaker in off position
2. Fuses blow nor thermal over load open
3. Locked motor shaft
4. Motor windings burned out
Pump does not reach full speed 1. Low voltage
2. Pump connected to the wrong voltage
Motor over heats
(protect or trips)
1. Low voltage
2. Motor windings connected to the wrong voltage on dual voltage model
Pump delivers no water 1. Pump is not primed
2. Closed valve in suction or discharge line
Leakage of water at the shaft Shaft seal requires replacement
Low pump capacity
1. Valve in the suction or discharge line partly closed
2. Suction or discharge line partly plugged
3. Suction or discharge line too small
High pump pressure
1. Discharge vale or inlet fittings closed too much
2. Return lines too small
3. Dirty filters
Noisy pump and motor
1. Plugged basket in skinner or hair in lint strainer
2. Worn motor bearings
3. Valve in suction line partly closed
Air bubbles at inlet fittings
1. Leakage of air into the suction line in connections or valve stem
2. Cover gasket of hair and lint strainer needs cleaning
3. Low water level in the pool
Note: If the above recommendations of this manual do not solve your particular problem(s), please contact your
local service agent for further assistance.
5. Defective starting switch inside
single phase motor
6. Disconnected or defective wiring
7. Low voltage
3. Leakage or air into suction system
4. Impeller clogged
4. Plugged basket in skimmer or hair
and lint strainer
5. Dirty filter
6. Impeller clogged
4. Suction line partly plugged
5. Vacuum hose plugged or too small
6. Pump not supported properly
10. TERMS OF THE WARRANTY
As original purchaser of this equipment have purchased from Emaux Water Technology Co Ltd, through
Authorized International Distributor or Dealer, warrants its products free from defects in materials and
workmanship under normal use during warranty period. The warranty period begins on the day of purchase and
extends only to the original purchaser. It is not transferable to anyone who subsequently purchases the product
from you. It excludes all expendable parts.
During the warranty period, Emaux authorized reseller will repair or replace defective parts with new parts or, at
the option of Emaux, serviceable used parts that are equivalent or superior to new parts in performance.
This Limited Warranty extends only to products purchased from Emaux authorized reseller. This Limited
Warranty does not extend to any product that has been damaged or rendered defective
(a) as a result of accident, misuse or abuse;
(b) as a result of an act of God;
(c) by operation outside the usage parameters stated herein;
(d) by the use of parts not manufactured or sold by Emaux;
(e) by modification of the product;
(f) as a result of war or terrorist attack; or
(g) as a result of service by anyone other than Emaux authorized reseller or authorized agent.
EXCEPT AS EXPRESSLY SET FORTH IN THIS WARRANTY, EMAUX MAKES NO OTHER WARRANTIES EXPRESSED OR
IMPLIED, INCLUDING ANY IMPLIED WARRANTIES OR MERCHANTABILITY AND FITNESS FOR A PARTICULAR
PURPOSE. EMAUX EXPRESSLY DISCLAIMS ALL WARRANTIES NOT STATED IN THIS LIMITED WARRANTY. ANY
IMPLIED WARRANTIES THAT MAY BE IMPOSED BY LAW ARE LIMITED TO THE TERMS OF THIS EXPRESS LIMITED
WARRANTY.

YOUR PREMIER SUPPLIER
www.emauxgroup.com
EMAUX WATER TECHNOLOGY CO., LTD
