emerio HV-111712 User manual

HV-111712
Hand vacuum cleaner (EN)
Handstaubsauger (DE)
Aspirateur à main (FR)
Handdammsugare (SE)
Handstofzuiger (NL)
Odkurzacz ręczny (PL)

- 1 -
Content –Inhalt –Teneur –Innehåll –Inhoud –Treść
Instruction manual –English........................................................................................- 2 -
Bedienungsanleitung –German...................................................................................- 9 -
Mode d'emploi –French............................................................................................- 16 -
Bruksanvisning –Swedish ..........................................................................................- 23 -
Gebruiksaanwijzing –Dutch.......................................................................................- 30 -
Istukja osługi – Polish..........................................................................................- 37 -

- 2 -
Instruction manual –English
SAFETY INSTRUCTIONS
Before use make sure to read all of the below instructions in
order to avoid injury or damage, and to get the best results
from the appliance. Make sure to keep this manual in a safe
place. If you give or transfer this appliance to someone else
make sure to also include this manual.
In case of damage caused by user failing to follow the
instructions in this manual the warranty will be void. The
manufacturer/importer accepts no liability for damages
caused by failure to follow the manual, a negligent use or use
not in accordance with the requirements of this manual.
1. This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction concerning
use of the appliance in a safe way and understand the
hazards involved.
2. Children shall not play with the appliance.
3. Cleaning and user maintenance shall not be made by
children without supervision.
4. If the supply cord is damaged, it must be replaced by the
manufacturer, its service agent or similarly qualified
persons in order to avoid a hazard.
5. Before inserting the plug into the mains socket, please
check that the voltage and frequency comply with the
specifications on the rating label.
6. Disconnect the mains plug from the socket when the
appliance is not in use and before cleaning.
7. Ensure that the mains cable is not hung over sharp edges
and keep it away from hot objects and open flames.
8. Do not immerse the appliance or the mains plug in water
or other liquids. There is danger to life due to electric
shock!

- 3 -
9. To remove the plug from the plug socket, pull the plug. Do
not pull the power cord.
10. Do not touch the appliance if it falls into water. Remove
the plug from its socket, turn off the appliance and send it
to an authorized service center for repair.
11. Do not plug or unplug the appliance from the electrical
outlet with a wet hand.
12. Never attempt to open the housing of the appliance, or to
repair the appliance yourself. This could cause electric
shock.
13. Never leave the appliance unattended during use.
14. This appliance is not designed for commercial use. For
household use only.
15. Do not use the appliance for other than intended use.
16. Do not wind the cord around the appliance and do not
bend it.
17. Close supervision is necessary for any appliance being used
by or near children. Do not leave the system unattended
while connected. Keep hair, loose clothing, fingers and all
parts of body away from opening and moving parts.
18. Do not use to pick up flammable or combustible liquids
such as gasoline or use in areas where they may be
present.
19. Do not pick up anything that is burning or smoking such as
cigarettes, matches or hot ashes.
20. Use extra care when cleaning on stairs.
21. Do not use the appliance without the dust cup filter in
place.
22. The use of accessory attachment not recommended by the
appliance manufacturer may cause injuries.
23. Do not put any objects into openings. Do not use with any
opening blocked. Keep free of dust, lint, hair and anything
else that may reduce air flow.
24. To reduce the risk of electric shock, do not use outdoors or
on wet surfaces. Use only on dry surfaces.

- 4 -
25. To reduce the risk of injury from moving parts or electric
shock, unplug before servicing and cleaning.
26. Important: If the suction opening in the unit is blocked,
switch off the appliance and remove the blocking
substance before you start the unit again.
27. Do not operate the appliance too close to heaters,
radiators or cigarette butts.
28. Before inserting the power plug into the wall outlet, make
sure that your hands are dry.
29. Before you start vacuuming, make sure to remove large or
sharp objects that might damage the dust cup filter.

- 5 -
HV-111712 EN
PARTS DESCRIPTION
1. Main unit
2. Dust cup
3. Extension tube
4. Floor brush
5. Textile nozzle
6. Crevice nozzle
7. Round brush
8. On/off button
9. Handle
10. Dust cup release button
11. Connection tube release button
12. Connection tube
13. Suction hole opening
14. Locking clip
USE
NOTE: Always remove the power plug from the wall outlet before assembling or removing accessories.
1. Insert the connection tube into the suction hole opening; make sure it fits firmly. You can also press and
hold the connection tube release button to remove it from the suction hole opening.
2. Connect different nozzle tools / brushes onto the connection tube for different cleaning purposes.
When connect the floor brush, please connect the extension tube first.
Assemble the floor brush before use: Insert the adapter (A) into the brush hole (B) and fix with the clip (C).
The floor brush has two positions, one for hard and one for soft/textile surfaces –Choose the right one.

- 6 -
3. Plug in the appliance.
4. Press the on/off button to turn on the appliance. Press it again, the unit will be turned off.
NOTE: During use, please pay attention to the dust capacity and do not exceed the MAX level indicated on
the dust cup. This appliance is for dry suction only.
Caution: The suction hole opening must be open and free of any obstructions at all times. Otherwise, the
motor will overheat and could become damaged.
CLEANING AND MAINTENANCE
1. Except for the main unit, other parts can be cleaned in warm soapy water (<40℃). Rinse and dry them
completely before reassembly. Do not immerse the main unit in water or any other liquids.
2. Use only a soft moist cloth to clean the outside of the unit. Do not allow any kind of liquid to enter the unit.
3. Do not use aggressive chemicals or abrasives.
4. Do not use the device if the filter is broken or worn out.
5. The unit does not contain parts serviceable by you, do not disassemble it and do not try to repair it
yourself.
In order to achieve the best performance, empty the dust cup and clean the dust cup filter after each use.
1. Press the dust cup release button to remove the container from the main unit.
2. Press down the locking clip on low end of the dust cup to empty dust from the container.
3. Detach the upper part from the dust cup. Gently pull the dust cup filter (A) and cyclonic frame (B) out of the
dust cup. Rinse them in warm water, and then air dry completely for 24 hours before placing them back in
the dust cup.
Important Note: DO NOT use a washing machine to clean the dust cup filter. Do not use a hair dryer to dry it.
AIR DRY ONLY.

- 7 -
4. Put the dust cup filter and cyclonic frame carefully into the dust cup. Never operate the appliance without
the dust cup filter in place.
5. Attach the dust cup to the main body of the unit.
Note: It is recommended that the dust cup filter be replaced every three months (depending on usage) to ensure
peak performance of the unit.
TROUBLESHOOTING
PROBLEM
POSSIBLE REASON
SOLUTION
Appliance does not operate
No power in electrical outlet.
Check fuse or breaker. Replace
fuse/reset breaker.
Appliance does not pick up or
suction power is weak
1.Dust cup is full.
2.Dust cup filter needs cleaning
or replacement.
1.Empty dust cup container.
2.Remove dust cup filter and
check for object(s) in air duct and
remove. Clean or replace dust
cup filter.
Dust escaping from appliance
1.Dust cup is full.
2.Dust cup filter is not installed
correctly.
1.Empty dust cup container.
2.Check and install the dust cup
filter correctly.
TECHNICAL DATA
Operating voltage: 220-240V ~ 50-60Hz
Power consumption: 600W
GUARANTEE AND CUSTOMER SERVICE
Before delivery our devices are subjected to rigorous quality control. If, despite all care, damage has occurred
during production or transportation, please return the device to your dealer. In addition to statutory legal rights,
the purchaser has an option to claim under the terms of the following guarantee:
For the purchased device we provide 2 years guarantee, commencing from the day of sale. If you have a
defective product, you can directly go back to the point of purchase.
Defects which arise due to improper handling of the device and malfunctions due to interventions and repairs
by third parties or the fitting of non-original parts are not covered by this guarantee. Always keep your receipt,
ithout the eeipt ou a’t lai a fo of aat. Daage aused  ot folloig the istutio
manual, will lead to a void of warranty, if this results in consequential damages then we will not be liable.
Neither can we hold responsible for material damage or personal injury caused by improper use if the
instruction manual is not properly executed. Damage to accessories does not mean free replacement of the
whole appliance. In such case please contact our service department. Broken glass or breakage of plastic parts is
always subject to a charge. Defects to consumables or parts subjected to wearing, as well as cleaning,
maintenance or the replacement of said parts are not covered by the warranty and are to be paid.
ENVIRONMENT FRIENDLY DISPOSAL
Recycling –European Directive 2012/19/EU
This marking indicates that this product should not be disposed with other household wastes. To
prevent possible harm to the environment or human health from uncontrolled waste disposal, recycle
it responsibly to promote the sustainable reuse of material resources. To return your used device,
please use the return and collection systems or contact the retailer where the product was purchased. They can
take this product for environmental safe recycling.

- 8 -
Emerio Deutschland GmbH (no service address)
Höfferweg 14
51519 Odenthal
Germany
Customer service:
T: [phone]
E: [e-mail]

- 9 -
Bedienungsanleitung –German
SICHERHEITSHINWEISE
Lesen Sie vor dem Gebrauch unbedingt die nachfolgenden
Anleitungen, um Verletzungen oder Beschädigungen zu
vermeiden und das beste Ergebnis mit dem Gerät zu erzielen.
Bewahren Sie diese Bedienungsanleitung an einem sicheren
Ort auf. Wenn Sie dieses Gerät an eine andere Person
weitergeben, stellen Sie sicher, dass Sie auch diese
Bedienungsanleitung aushändigen.
Im Falle von Beschädigungen, die durch die Missachtung der
Anleitungen in dieser Bedienungsanleitung verursacht
wurden, wird die Garantie ungültig. Der Hersteller/Importeur
haftet nicht für Schäden, die durch Missachtung der
Bedienungsanleitung, fahrlässigen Gebrauch oder Benutzung,
die nicht in Übereinstimmung mit den Anforderungen dieser
Bedienungsanleitung erfolgt, verursacht wurden.
1. Dieses Gerät kann von Kindern ab 8 Jahren und Personen
mit eingeschränkten körperlichen, sensorischen oder
geistigen Fähigkeiten oder mangelnder Erfahrung und
Kenntnis benutzt werden, wenn sie beaufsichtigt werden
oder in die sichere Benutzung des Gerätes unterwiesen
werden und die damit verbundenen Gefahren verstehen.
2. Kinder dürfen nicht mit dem Gerät spielen.
3. Die Reinigung und vom Benutzer auszuführende
Wartungsarbeiten dürfen von Kindern nur unter Aufsicht
durchgeführt werden.
4. Wenn das Netzkabel beschädigt ist, muss es vom Hersteller,
seinem Kundendienst oder einer ähnlich qualifizierten
Person ausgewechselt werden, um Gefahren zu
vermeiden.
5. Bevor Sie den Stecker mit der Netzsteckdose verbinden,
prüfen Sie bitte, ob die Spannung und die Frequenz mit
den Angaben auf dem Typenschild übereinstimmen.
6. Ziehen Sie den Netzstecker aus der Steckdose, wenn das
Gerät nicht benutzt oder bevor es gereinigt wird.
