Emerson Keystone EPI2 User manual

Installation, Operation and Maintenance Manual
VCIOM-02377-EN Rev. 0
May 2022
Keystone OM11 - EPI2
DeviceNet Interface

Notes
May 2022
Installation, Operation and Maintenance Manual
VCIOM-02377-EN Rev. 0
This page is intentionally left blank

Installation, Operation and Maintenance Manual
VCIOM-02377-EN Rev. 0
Table of Contents
May 2022
Table of Contents i
Table of Contents
Section 1: Introduction
Introduction ........................................................................................................... 1
Section 2: Operation and Storage
Operation and Storage............................................................................................ 2
Section 3: Distinguish Old/New Models
Distinguish Old/New Models................................................................................... 3
Section 4: Installation
4.1 Assembling Procedure for Models 63-125 Nm
Old Version (US or Non-US Market) ............................................................... 6
4.2 Assembling Procedure for Models 250-500-1000-2000 Nm
Old Version (US or Non-US Market) ............................................................... 9
Section 5: Communication Features
Communication Features ..................................................................................... 11
Section 6: DeviceNet Interface Module
6.1 On Board Indication Module........................................................................ 12
6.2 Wiring Diagram........................................................................................... 14
6.3 Bus/Hardwired Mode Selection ................................................................... 14
Section 7: Brief DeviceNet Description
7.1 Network Cable ............................................................................................ 16
7.2 Terminator ................................................................................................. 16
Section 8: Communication Interface
8.1 Actuator Commands................................................................................... 17
8. 2 Actuator Status and Indication ................................................................... 18
8.2.1 Positioning Algorithm ...................................................................... 19
8.3 Fail-Safe Data .............................................................................................. 20
8.4 DeadBandConguration ........................................................................... 20
8.5 UserDenedData ...................................................................................... 21
8.6 CongurationData..................................................................................... 21
8.7 DeviceNetCongurableParameters........................................................... 23
8.8 EDS File ....................................................................................................... 23

Table of Contents
May 2022
Installation, Operation and Maintenance Manual
VCIOM-02377-EN Rev. 0
Table of Contentsii
Section 9: Local Settings
9.1 On-Board Interface...................................................................................... 25
9.2 DeviceNetMACIDConguration ................................................................. 26
9.3 DeviceNetCommunicationSpeedConguration ........................................ 27
Section 10: Bluetooth Communication Module
Bluetooth Communication Module....................................................................... 28
Section 11: DeviceNet Certicate
DeviceNetCerticate............................................................................................ 29
Section 12: Optional Kits
Optional Kits ......................................................................................................... 30

Installation, Operation and Maintenance Manual
VCIOM-02377-EN Rev. 0 May 2022
1
Section 1: Introduction
Introduction
NOTE:
Before installation, these instructions must be fully read and understood.
Section 1: Introduction
The OM11 DeviceNet interface is an electronic module that allows you to connect the
Keystone EPI2 electrical actuator to a DeviceNet network. The module has its own
microprocessor and acts as a pure bus interface without affecting the actuator control
integrity. It is installed inside the actuator housing and takes the electrical power from the
actuator power supply module. The DeviceNet network is fully isolated from the
actuator electronics.
For details about EPI2 actuator, please refer to Installation, Operation and Maintenance
Manual for Keystone EPI2, Electric Actuator.
!WARNING
EPI2 actuators must be electrically isolated before any disassembling or reassembling
operations. Before any disassembling or reassembling operations, please follow in detail
the relevant section of the basic installation and operating manual (latest revision available).
!WARNING
The electronic parts of the EPI2 actuators and all option modules can be damaged by
a discharge of static electricity. Before you start, touch a grounded metal surface to
discharge any static electricity.
! WARNING
Itisassumedthattheinstallation,conguration,commissioning,maintenanceandrepair
worksarecarriedoutbyqualiedpersonnelandcheckedbyresponsiblespecialists.
! WARNING
Repairwork,otherthanoperationsoutlinedinthismanual,isstrictlyreservedtoqualied
Emerson personnel or to personnel authorized by the company itself.

May 2022
Installation, Operation and Maintenance Manual
VCIOM-02377-EN Rev. 0
2
Section 2: Operation and Storage
Operation and Storage
Section 2: Operation and Storage
The module is designed to work and to be stored in the same environment as the actuator.

Installation, Operation and Maintenance Manual
VCIOM-02377-EN Rev. 0 May 2022
3
Section 3: Distinguish Old/New Models
Distinguish Old/New Models
Figure 1 Label for non-US market - digits X7X8 on product coding chart
Section 3: Distinguish Old/New Models
It is important to distinguish between EPI2 old models and the new ones. To install the
board on base actuator, in fact, it is necessary to choose the correct mechanical parts from
the kit.
Furthermore, the meaning of some data exchanged on the DeviceNet interface depends
on model (old or new); differences will be explained in the following sections.
Figures 1 and 2 allow to distinguish old version of EPI2 from the new version (on the labels,
the digits of Product Number are boxed); furthermore, the logic boards with heatsink
identiesoldversionmodels,whilelogicboardswithoutheatsinkidentiesnew
version models.
Figure 2 Label for US market – digit 6 on product coding chart

May 2022
Installation, Operation and Maintenance Manual
VCIOM-02377-EN Rev. 0
4Distinguish Old/New Models
Section 3: Distinguish Old/New Models
Figure 3 Example of EPI2 old version (heatsink present)
Figure 4 Example of EPI2 new version (heatsink not present)

Installation, Operation and Maintenance Manual
VCIOM-02377-EN Rev. 0 May 2022
5
Installation
Section 4: Installation
Section 4: Installation
To assemble the OM11 into the EPI2 actuator, proceed as follows:
• Ensure that all the parts received with the OM11 are available, as described in
Section 12, Optional Kits.
• Using Section 12, Optional Kits, select only mechanical parts (screws and spacers)
depending on actuator models.
• Gather the right tools for the assembly and for setting the actuator controls.
• With an Allen wrench of 5 mm, unscrew the cover screws, see Figure 5.
Figure 5
• Remove the actuator cover, see Figure 6.
Figure 6
Follow one of the following assembling procedures depending on actuator model.

May 2022
Installation, Operation and Maintenance Manual
VCIOM-02377-EN Rev. 0
6Installation
Section 4: Installation
4.1 Assembling Procedure for Models 63-125 Nm
Old Version (US or Non-US Market)
• Detect the black cable required for the OM11 which is already included in the basic
actuator, see Figure 7.
Figure 8
• ConnecttheatcablefurnishedintothekittoconnectorJ3onOM11,see
Figure 8.
Figure 7

Installation, Operation and Maintenance Manual
VCIOM-02377-EN Rev. 0 May 2022
7
Installation
Section 4: Installation
• Tighten the 3 metal spacers, see Figure 10.
Figure 10
Figure 11
• ConnecttheOM11atcabletoconnectorJ8onthelogicboard,seeFigure11.
• Unscrew the 3 screws, see Figure 9: 3 pcs M3x10.
Figure 9
metal spacer
screw

May 2022
Installation, Operation and Maintenance Manual
VCIOM-02377-EN Rev. 0
8Installation
Section 4: Installation
• Place the OM11 card onto the spacer and tighten the 4 screws, see Figure 12.
Figure 12
• Connectthe8-pinconnectortoconnectorJ3onOM11,seeFigure13.
Figure 13
screw

Installation, Operation and Maintenance Manual
VCIOM-02377-EN Rev. 0 May 2022
9
Installation
Section 4: Installation
4.2 Assembling Procedure for Models
250-500-1000-2000 Nm Old Version
(US or Non-US Market)
• Detect the black cable required for the OM11 which is already included in the basic
actuator; disassemble local mechanical indicator, see Figure 14.
Figure 14
• ConnecttheatcablefurnishedintothekittoconnectorJ3onOM11,see
Figure 15.
Figure 15

May 2022
Installation, Operation and Maintenance Manual
VCIOM-02377-EN Rev. 0
10 Installation
Section 4: Installation
• Connect the 8-pin connector to connector on OM11, see Figure 18.
• ConnecttheOM11atcabletotheconnectoronthelogicboard,seeFigure16.
Figure 16
• Place the OM11 card onto the heatsink spacers and tighten the 4 screws; assemble
local mechanical indicator, see Figure 17.
Figure 17
Figure 18
screw

Installation, Operation and Maintenance Manual
VCIOM-02377-EN Rev. 0 May 2022
11
Communication Features
Section 5: Communication Features
Section 5: Communication Features
Communication protocol CAN bus standard, 5 wires DeviceNet application
Network topology Line/Trunk-drop topology
Transmissionmedium   SpeciccableforDeviceNetnetwork:1twisted 
pair for power, 1 twisted pair for data and shield
Data rate 125 250 500 Kbps
Cable length 500 250 100 m
(length may also vary with cable thickness)
Device number 64 devices per segment
Bus access Producer-consumer network
Bus termination External bus terminators required
Keystone Implementation
Device type Generic (00 hex)
Group Group 2 only slave
Physical layer Isolated node with transceiver powered by
the network
Current consumption Current drawn from the network to power the
transceiver: 29 mA at 24 V; 27 mA at 17 V;
25 mA at 11 V
Communication   Predenedmaster/slaveconnection:explicit 
message and polled I/O
Baud rate 125 Kbps, 250 Kbps, 500 Kbps (default 125 Kbps).
     Networkcongurableormanualcongurablevia 
on-board rotary BCD switch
Addressing(MACID)   0-63(default63).Networkcongurableormanual
     congurableviaon-boardrotaryBCDswitches
Temperature -40 °C, +85 °C
EMC protections EN 50081-2 and EN 50082-2

May 2022
Installation, Operation and Maintenance Manual
VCIOM-02377-EN Rev. 0
12 DeviceNet Interface Module
Section 6: DeviceNet Interface Module
Section 6: DeviceNet Interface Module
The module consists in a single PCB that is installed inside the actuator housing. It is
connectedtotheEPI2basecardviaatcable.TheinternalwiringconnectstheDeviceNet
data lines to the actuator terminal board.
6.1 On-Board Indication Module
The DeviceNet interface is equipped with 5 LEDs, pushbuttons and BCD rotary switches to
offeracongurationanddiagnosticinterfaceon-board.
Figure 19
Localconguration
interface Network status LED:
NET_STAT
RESET pushbutton
Condition LED Description
No power Off There is no power applied to the device.
Operational Green The device is operating in a normal condition.
Standby Flashing green Thefactorycommissioningisnotnished;
serial number not yet assigned.
Minor fault Flashing red Recoverable fault due to a non-critical
diagnostic indication
Unrecoverable fault Red
Device has an unrecoverable fault:
• HW alarm
• Power failure alarm
• Position sensor alarm
• High temperature alarm
Mod_Stat
• ModuleStatusLEDasdenedinspec.Vol.3,“DeviceNetAdaptationforCIP”,
Section 7
Table 1.

Installation, Operation and Maintenance Manual
VCIOM-02377-EN Rev. 0 May 2022
13
Section 6: DeviceNet Interface Module
DeviceNet Interface Module
Net_Stat
• NetworkStatusLEDasdenedinspec.Vol.3,“DeviceNetAdaptationforCIP”,
Section 7
Table 2.
Reset
• Reset pushbutton
Local Conguration
• On-boardinterfaceforlocalcongurationofMACIDandBaudRate.Bydefault,
the board is set to accept MACID and Baud Rate from the network, but it is also
possible to set these parameters by hardware setting. Detailed procedures are
given in Section 9, Local Settings.
Condition LED Description
Not powered/not on-line Off Device is not on-line
On-line, not connected Flashing green Device is on-line, but is not allocated to
a Master
Link OK on-line connected Green Device is on-line and is not allocated to
a Master
Connection time-out Flashing red One or more I/O connection are in
timed-out state
Critical link failure Red Failed communication device. The device
has detected an error that has rendered it
incapable of communicating on the network
(Duplicate MACID or Bus-Off).
Communication faulted
and received an identify
comm fault
request-long protocol
Flashing red and green Aspeciccommunicationfaulteddevice.
The device has detected a Network Access
error and is in the Communication Faulted
state. The device has subsequently received
and accepted an Identify Communication
Faulted Request-Long Protocol message.

May 2022
Installation, Operation and Maintenance Manual
VCIOM-02377-EN Rev. 0
14 DeviceNet Interface Module
Section 6: DeviceNet Interface Module
6.2 Wiring Diagram
The DeviceNet interface is connected to the actuator terminal board by internal wiring, see
Figure 20.
Figure 20
678917 18 195
Optional module - DeviceNet interface
Connector H
HW Mode
Shield
CAN_V+
(red)
CAN_V-
(black)
CAN_H
(white)
CAN_L
(blue)
DeviceNet line
6.3 Bus/Hardwired Mode Selection
The DeviceNet interface manages the bus/hardwired mode selection by means of the
input terminal indicated with HW MODE. The physical input accepts from 24 V - 125 V DC
or AC, polarity insensitive. When the input is left unconnected or no voltage is applied,
the actuator is under bus control from which is possible to send commands and read
status. When an appropriate voltage is applied to the HW MODE input, the actuator turns
under Hardwired control. In this condition, the bus can only read actuator status while the
actuator follows the hardwired open and close controls connected to the terminal board.
For further details, please refer to Installation, Operation and Maintenance Manual for
Keystone EPI2, Electric Actuator.

Installation, Operation and Maintenance Manual
VCIOM-02377-EN Rev. 0 May 2022
15
Brief DeviceNet Description
Section 7: Brief DeviceNet Description
Section 7: Brief DeviceNet Description
DeviceNetisalow-levelnetworkthatprovidesconnectionbetweenindustrialelddevices
(sensors and actuators) and higher-level devices (controllers). DeviceNet uses CAN
(Controller Area Network) for its datalink layer, and CIP (Common Industrial Protocol)
for the upper layers of the network. The major physical and media characteristics of the
DeviceNet are:
• Trunk-line/drop-line topology of the network
• Support for up to 64 devices in a network (i.e., 1 master and 63 EPI2 actuators)
• Node removal without altering the network behavior
• Support of both network-powered and self-powered devices on the
same network
• Wiring error protection
• Selectable data rate of 125 k baud, 250 k baud and 500 k baud
Table 3.
• Adjustablepowercongurationtomeetindividualapplicationneeds
• High current capability (up to 8 A at 24 V DC)
• Operation with off-the-shelf power supplies
• Available power taps that allow the connection of several power suppliers
• Built-in overload protection
• Controller Area Network (CAN) technology for Media Access Control and
Physical Signalling
Data rate Trunk distance Drop length
Maximum Cumulative
125 k baud 500 meters 6 meters 156 meters
250 k baud 250 meters 6 meters 78 meters
500 k baud 100 meters 6 meters 39 meters

TR
TR Trunk
Drop
May 2022
Installation, Operation and Maintenance Manual
VCIOM-02377-EN Rev. 0
16
Section 7: Brief DeviceNet Description
Brief DeviceNet Description
7.1 Network Cable
To obtain the expected performances from the communication network, the suitable cable
mustbeutilized.DeviceNetrequiresaspeciccablecomposedofaPowerpair,aDataPair
andashieldwithdrainwire.DeviceNetdenesdifferentcablestobeusedinthedifferent
parts of the network.
• in the trunk line, thick cable is normally used, e.g., BELDEN 3082A
— 1 pair 15 AWG 19x28 Tinned Copper - Power pair
— 1 pair 18 AWG 19x30 Tinned Copper - Data pair
— inner shield 100% coverage
• in the drop line, thick cable is normally used, e.g., BELDEN 3084A
— 1 pair 22 AWG 19x34 Tinned Copper - Power pair
— 1 pair 24 AWG 19x36 Tinned Copper - Data pair
— inner shield 100% coverage
Figure 21
7.2 Terminator
The DeviceNet network must be terminated to each end of the main trunk line with a
120 ohm resistor across CAN_H and CAN_L data line.
Figure 22
PLC DeviceNet
scanner
Power
tap
Term. Term.
DeviceNet
Power supply
Tap
Tap
Tap
CAN V+
CAN H
Shield
CAN L
CAN V-
