TopWorx™ D-Series with AS-interface
Installation, Operation & Maintenance Manual
Table of Contents
2Switchbox Orientation
3 Mounting
3Storage
4DXP Dimensional Drawing
3 DXP - IIC Dimensional Drawing
6 DXS Dimensional Drawing
7 DXR Dimensional Drawing
8 Shaft Detail
9 Enclosure/Indicator Assembly
10 SCM Calibration
11 Spool Valves & Pilots
12 Spool Valves & Pilots
13 Safe Use
14 Certifications & Approvals
15 Warranty

D-Series with AS-I Installation, Operation & Maintenance 502.969.8000
2
Installation on Actuator
Orientations, Normal and Reverse Acting
Normal acting is full CW when the process valve is closed and CCW when the process valve is open. Reverse acting
is full CW when the process valve is open and CCW when the process valve is closed.
90° indicator dome assemblies are design to accommodate any mounting arrangement and can be adjusted up to
9° off axis if needed. 45° indicator dome assemblies can only accommodate normal acting applications that are
mounted parallel ±9°. Consult your local distributor or factory representative for 45° reverse acting or mounted
perpendicular applications.
Illustration #1
The image to the left shows a TopWorx™ unit mounted
parallel to the process valve in the closed position.
The green arrow at the top shows the “normal acting”
direction of travel to open the valve. This is the standard
orientation and your unit unless otherwise specified will
be factory set to operate in this fashion.
Illustration #2
The image to the right shows a TopWorx™ mounted
perpendicular to the process valve in the closed
position. The green arrow at the top shows the
“normal acting” direction of travel to open the valve.
Notice that the indicator dome has been rotated 90°
compared to the unit above.

www.topworx.com
3
TM
Installation on Actuator (continued)
Mounting
TopWorx™ has numerous mounting bracket kits available to meet your specific application, whether rotary or linear.
Consult your local distributor or factory representative for ordering information. The illustration shows a direct Namur
mount on a quarter turn valve. Refer to your mounting kit documentation for specific mounting instructions.
Storage
Until conduit, conduit plugs, and any applicable spool valve port connections are properly installed, the TopWorx™
unit will not support its IP/NEMA rating as the unit ships with temporary covers. Ensure that it is stored in a dry
environment with a relative humidity range between 10%-95% and a temperature ranging from -40ºF (-40ºC) to
160ºF (71ºC). Once properly installed, the temperature range listed on the nameplate will supersede this storage
temperature range.
Illustration #3: Mounting Assembly
Installation Notes
1. Use caution not to allow undue axial (thrust) load on the shaft.
2. Cycle the valve a couple of times prior to final tightening of the
mounting kit hardware. This allows the shaft to self-center in the
pinion slot, or coupler. Refer to the dimensions and materials
section of this document for appropriate tightening torque.
3. Always use sound mechanical practices when torqueing down any
hardware or making pneumatic connections. Refer to the Integrated
Pneumatic Control Valves section for detailed information on
pneumatic connections.
4. This product comes shipped with plastic plugs in the conduit entries
in an effort to protect the internal components from debris during
shipment and handling. It is the responsibility of the
receiving and/or installing personnel to provide
appropriate permanent sealing devices to prevent
he intrusion of debris, or moisture, when stored
outdoors or when installed.
5. It is the responsibility of the installer, or end user, to
install this product in accordance with the National
Electrical Code (NFPA 70) or any other national or
regional code defining proper practices.

D-Series with AS-I Installation, Operation & Maintenance 502.969.8000
4
Dimensions and Materials: TopWorx™ DXP
MOUNTING SURFACE
.85 2.10
4.52
6.21
MINIMUM 2.5" REQUIRED CLEARANCE
IN ORDER TO DISINGAGE THE SHAFT FROM THE ID BUSHING
AND REMOVE LID WHERE OPTIMUM CONDITIONS APPLY
SHAFT TYPE OPTIONAL
SEE SHAFT DETAIL
SECTION
2.13
6.65
6.76
3.85
2.25
2.25 5/16-18 UNC - 2B
.44 DEEP
VALVE TYPE OPTIONAL
SEE INTEGRATED PNEUMATIC
CONTROL VALVES SECTION
2.19
OPTIONAL CONDUIT ENTRIES
USED ONLY WHEN 4 ENTRIES
ARE SPECIFIED
OPTIONAL CONDUIT ENTRIES
MATERIALS OF CONSTRUCTION
Enclosure
Cast A360 aluminum with dichro-
mate conversion coating inside &
out, epoxy coated exterior rated for
250 hrs salt spray per ASTM B117
Fasteners 304 Stainless Steel standard
316 Stainless Steel optional
Shaft 304 Stainless Steel standard
316 Stainless Steel optional
Shaft
Bushing Oilite Bronze
Indicator
Dome Polycarbonate, UV F1 rated
Seals O-ring seals available in: Buna &
Silicone,
Maximum Fastener Torque Specifications
Enclosure Housing Bolts 8 ft-lbs [10.8 N·m]
Indicator Dome Screws 20 in-oz [141 mN·m]
Bottom Mounting Holes 10 ft-lbs [13.6 N·m]
Illustration #4

www.topworx.com
5
TM
Dimensions and Materials: TopWorx™ DXP - IIC
MATERIALS OF CONSTRUCTION
Enclosure
Cast A360 aluminum with dichro-
mate conversion coating inside &
out, epoxy coated exterior rated for
250 hrs salt spray per ASTM B117
Fasteners 304 Stainless Steel standard
316 Stainless Steel optional
Shaft 304 Stainless Steel standard
316 Stainless Steel optional
Shaft Bushing Oilite Bronze
Indicator Dome Polycarbonate, UV F1 rated
Seals O-ring seals available in: Buna &
Silicone,
Maximum Fastener Torque Specifications
Enclosure Housing Bolts 8 ft-lbs [10.8 N·m]
Indicator Dome Screws 20 in-oz [141 mN·m]
Bottom Mounting Holes 10 ft-lbs [13.6 N·m]
Illustration #5

D-Series with AS-I Installation, Operation & Maintenance 502.969.8000
6
Dimensions and Materials: TopWorx™ DXS
MOUNTING SURFACE
.85 2.10
4.52
6.21
MINIMUM 2.5" REQUIRED CLEARANCE
IN ORDER TO DISINGAGE THE SHAFT FROM THE ID BUSHING
AND REMOVE LID WHERE OPTIMUM CONDITIONS APPLY
SHAFT TYPE OPTIONAL
SEE SHAFT DETAIL
SECTION
2.13
6.65
6.76
3.85
2.25
2.25 5/16-18 UNC - 2B
.44 DEEP
VALVE TYPE OPTIONAL
SEE INTEGRATED PNEUMATIC
CONTROL VALVES SECTION
2.19
OPTIONAL CONDUIT ENTRIES
USED ONLY WHEN 4 ENTRIES
ARE SPECIFIED
OPTIONAL CONDUIT ENTRIES
MATERIALS OF CONSTRUCTION
Enclosure Cast 316 Stainless Steel
Fasteners 304 Stainless Steel standard
316 Stainless Steel optional
Shaft 304 Stainless Steel standard
316 Stainless Steel optional
Shaft Bushing N/A
Indicator Dome Polycarbonate, UV F1 rated
Seals O-ring seals available in: Buna &
Silicone,
Maximum Fastener Torque Specifications
Enclosure Housing Bolts 8 ft-lbs [10.8 N·m]
Indicator Dome Screws 20 in-oz [141 mN·m]
Bottom Mounting Holes 10 ft-lbs [13.6 N·m]
Illustration #6

www.topworx.com
7
TM
SHAFT TYPE OPTIONAL
SEE SHAFT DETAIL
SECTION
2.00
1.10
2.10
4.51
6.21
MINIMUM 2.5" REQUIRED CLEARANCE
IN ORDER TO DISINGAGE THE SHAFT FROM THE ID BUSHING
AND REMOVE LID WHERE OPTIMUM CONDITIONS APPLY
2.25
2.25
5.03
3.66
6.10
2.14
VALVE TYPE OPTIONAL
SEE INTEGRATED PNEUMATIC
CONTROL VALVES SECTION
5/16-18 UNC - 2B
.44DP
MOUNTING SURFACE
OPTIONAL CONDUIT ENTRIES
USED ONLY WHEN 4 ENTRIES
ARE SPECIFIED
OPTIONAL CONDUIT ENTRIES
Dimensions and Materials: TopWorx™ DXR
MATERIALS OF CONSTRUCTION
Enclosure Valox®364
Polybutylene
Terephthalate (PBT)
Fasteners 304 Stainless Steel standard
316 Stainless Steel optional
Shaft 304 Stainless Steel standard
316 Stainless Steel optional
Shaft Bushing Delrin®500P white
Indicator Dome Polycarbonate, UV F1 rated
Seals O-ring seals available in: Silicone
Maximum Fastener Torque Specifications
Enclosure Housing Bolts 10 in-lbs [903 mN·m]
Indicator Dome Screws 20 in-oz [141 mN·m]
Bottom Mounting Holes 8 ft-lbs [13.6 N·m]
Illustration #7

D-Series with AS-I Installation, Operation & Maintenance 502.969.8000
8
Dimensions and Materials: Shafts
Illustration #8: Shaft Detail

www.topworx.com
9
TM
Indicator / Dome Replacement Kits
AV-GB002 90º, Green/Open, Red/Closed, Buna O-Ring
AV-YB002 90º, Yellow/Open, Black/Closed, Buna O-Ring
AV-TB002 90º, Green/Thru, Red/Divert, Buna O-Ring
AV-4B002 90º, Green/Open, Red/Closed, Buna O-Ring
Pilot Device Options:
See Illustration
#5
Sensor
Options:
See
Illustration
#6
Indicator Assembly
See Illustration #2
Shaft Assembly
See Illustration #7
Valve Options:
See Illustration #4
External Ground Lug
Internal Ground
Lug
O-ring Seal
Conduit Entry
Screws are
captive
Illustration #9: Enclosure Assembly
Color-coded Indicator is
available in several
coordinating rotations and
forms for various valve
types, such as 90 , 180
and Thru-divert applications.
00
O-ring
Available in Buna-N,
Silicone, EPDM, Viton
10-32 Captive screws,
Stainless (x4)
Indicator Dome,
5 adjustable
Polycarbonate
with keyed mask.
Several rotation and
form options.
+
O
Illustration #10: Indicator Assembly
#10
#11
#12 pg. 10

D-Series with AS-I Installation, Operation & Maintenance 502.969.8000
10
Calibrating Limit Switches inside the SCM-ASi Module
- D2 + - D3 +
+ASI-
CLOSE ASI OPEN
LEDs
AS-i
Terminals
TopWorx
SCM-ASi 2.1
Calibration
Switch
Solenoid
Terminals AUX Input
Terminals
Close
Open
Inputs
Outputs
Illustration #11: SCM-ASI
Sensor Communication Module
Solenoid Note: Internal mount pilot in the DXP/DXS is 0.6W. For any externally mounted, or customer supplied, solenoid valve 4 watt maximum
power consumption is allowed. A 170 mA max surge current limitation is required to prevent activation of the short circuit protection.
D-Series with ASi Wiring
Step 1
For internally-mounted or external pilot device(s), wire the ‘+’
and ‘-’ leads to the terminals marked D0 (open) and D1
(closed). The internally-mounted pilot has an LED indicator
for power verification. Note: For an externally mounted
solenoid valve, 4 watt maximum power consumption
is allowed. A 160 mA surge current limit is required to
prevent activation of the short circuit protection circuit.
Step 2
Connect the AS-i communication wires to the terminals
marked AS-i ‘+’ and AS-i ‘-’ . (See Illustration 12 for wiring
diagram) Note: For calibration of the switches, a 24 VDC
power supply may be used instead of an ASI Controller.
If an ASI Controller is not available, wire +24 VDC to
ASI+, and GND to ASI-. The calibration switch will still be
able to actuate the valve.
Additional Instruction for wiring an external switch input.
For externally mounted auxiliary input limit switches, wire
switches to the terminals marked -D2+ for the open switch
and -D3+ for the closed limit switch.
Never perform the switch calibration procedure where area is
known to be hazardous.
Step 1
Once pneumatic hookup and wiring has been completed
close the valve using the SCM-ASI on-board calibration
switch, as seen in Illustration 11. If no AS-i network connec-
tion is available, you may connect a 24VDC power supply to
the + ASI - terminals as previously described.
Step 2
With the valve in the CLOSED position, disengage the
BOTTOM Cam from the splined Hub and rotate Clockwise
until the Red LED lights. Release the Cam to re-engage the
splined Hub.
Step 3
Open the valve by sliding the calibration switch to the OPEN
position.
Step 4
Once the valve is in the OPEN position, disengage the TOP
cam from the splined hub and rotate Counter-clockwise until
the Green LED lights. Release the Cam to re-engage the
splined Hub.
Step 5
Cycle the valve CLOSED and OPEN several times using the
calibration switch to verify both limit switches are
maintaining their set points.
Step 6
Finally, slide the calibration switch to the ASI position. The AS-i
network will now have full control of the valve once the SCM-
ASI has been addressed.
AS-i Specifications
Device ID
Device I/O A Free Profile
B 2 Inputs / 2 Outputs
Inputs
D2 Open Limit Switch
D3 Closed Limit Switch
0 Switch Open
1 Switch Closed
Outputs
D1 Solenoid #1 (Close)
D0 Solenoid #2 (Open)
0 De-energize Solenoid
1 Energize Solenoid
Current 40mA + open solenoid current and
closed solenoid current
Max solenoid current = 160mA
per outputMax power = 4 watts per output)
Voltage 20 to 30VDC
Profile S-B.A.0
NOTE: When upgrading a TopWorx AS-i module with a
new TopWorx AS-i 2.1 module, make sure the input and
output data bit positions are updated as indicated above.
Illustration #12: SCM-ASI
Wiring Diagram
