ENCLO EC18024 User manual

www.encloscreens.com
60 min
Assembly
Approximate time
Assembly Video
Scan the QR Code below
ASSEMBLY
INSTRUCTIONS
EC18024 CEDAR COLOR
EC18025 ASH COLOR
VER. 101322
6' Florence
Screen Kit
w/ Planter Box

2
jCheck the inside of the larger pieces in your box for other
materials packed inside.
jWhen assembling components, place on a non-abrasive surface
(i.e. shipping box) to avoid scratching.
jWe recommend an area approximately 5’x 8’for unobstructed
assembling.
jYou should not need to use excessive force when assembling
components.
VISIT OUR WEBSITE FIRST,
SO WE CAN HELP YOU RIGHT AWAY!
Although great care has been taken to ensure proper packaging and
handling of this product, occasionally problems occur. If you discover
any missing, damaged, or defective parts, please visit our website to
order replacement parts. If you experience any further trouble with
your product, please contact our customer service department.
parts.nychbrands.com
[e-mail]
704-892-5222 /877-234-6196
Customer service agents are available to take calls weekdays from 9am-5pm EST.
If you call outside of business hours, please leave a voicemail.
To help you quickly and accurately, please have reference item number
EC18024/ EC18025 and the specic part name which can be found on
page 5. It is helpful if you can provide the batch lot which is a stamped
number on the end of the box.
If you are having problems with the assembly or installation of this
product, we are happy to assist you with the process, so please give
us a call at 704-892-5222 / 877-304-3263
If for some reason you need to return this product, please allow
us to help resolve your issues rst. If you still decide to return the
product, you will need to initiate the return from the company you
originally purchased from.
GENERAL
INFORMATION
MISSING OR
DAMAGED PARTS?
NEED ASSEMBLY
HELP?
NEED TO RETURN?
IMPORTANT
DETAILED PRODUCT DIMENSIONS &SPECIFICATIONS

3
DETAILED PRODUCT DIMENSIONS &SPECIFICATIONS
45.94
72.24
45.95
12.95
0.69 in
45.95 in
12.95 in
72.24 in
61.14 in
12.94 in
45.94 in
6 
Planter Box Depth: 8.3"
Planter Box Volume: 2.33 cubic ft (70 qts)
Note: For best plant growth, it is recommended to drill (2) ¾" diameter drainage
holes in the oor board roughly 12" apart.

4
*- Tools required for a smoother installaon experience.
LAY OUT TOOLS
Drill Phillips Screwdriver Bit

5
SCREEN
PLANTER BOX
HARDWARE
L
Top Post Cap (2)
N
Spacer (44)
M
Corner Post Cap (2)
O
¾" Self-Drilling Stainless
Steel Screw (28)
B
Planter Short Board (2)
⁄" x 11" x 11"
C
Floor Supports (3)
⁄" x 1 ½" x 12 ¾"
D
Front Post (2)
1⁄" x 1 ⁄" x 11"
I JH
Wide Board (8)
⁄" x 3" x 44"
Right Post - Long (1)
1" x 1⁄" x 61"
Left Post - Long (1)
1" x 1⁄" x 61"
K
Narrow Board (14)
⁄" x 1 ½" x 44"
A
Planter Long Board (2)
⁄" x 11" x 44"
E F
Back Left Post (1)
1 ⁄" x 1 ⁄" x 11"
Back Right Post (1)
1 ⁄" x 1 ⁄" x 11"
G
Floor (1)
⁄" x 11" x 44"
LAY OUT MATERIALS

6
1
2E x1 F x1
Assemble on box or other
smooth surface to prevent
scratching
Place board with
channel facing up
A x1 A
E
F

7
3
4
C x3
A x1 D x2
Carefully set this portion aside until Step 5.
Dx2
A
C

8
5
6

9
O x16
7
8
B x2
B

10
9
10
I x1H x1
O x4
H
I

11
11
11
J x1 N x2
J
N

12
12 x14
Kx42 N
Repeat step 11,
following the pattern
shown below
x7
J

13
1313
14
O x4

14
15
L x2 M x2
L
M

15
1716
Note: For best plant growth,
it is recommended to drill (2)
3/4" diameter drainage holes
in part (G) roughly 12" apart.
G x1
G

16
17

17
(Optional) In high wind environments
1718
Note: Depending on your
surface, use an L-bracket with
concrete or wood screws
for extra security. If you are
installing on soft ground,
we recommend using 3/4"
diameter rebar through the
front posts to reinforce the unit.

www.encloscreens.com
[e-mail]
704-892-5222
877-234-6196
6935 Reames Rd. Ste. K.
Charlotte, NC 28216
