ENCLO EC18006 User manual

www.encloscreens.com
Florence
Screen Kit
W/ Planter Box
45 min
Assembly
Approximate time
Assembly Video
Scan the QR Code below
ASSEMBLY
INSTRUCTIONS
EC18006 CEDAR COLOR
EC18007 ASH COLOR
VER. 080123

2
jCheck the inside of the larger pieces in your box for other
materials packed inside.
jWhen assembling components, place on a non-abrasive surface
(i.e. shipping box) to avoid scratching.
jWe recommend an area approximately 5’x 8’for unobstructed
assembling.
jYou should not need to use excessive force when assembling
components.
VISIT OUR WEBSITE FIRST,
SO WE CAN HELP YOU RIGHT AWAY!
Although great care has been taken to ensure proper packaging and
handling of this product, occasionally problems occur. If you discover
any missing, damaged, or defective parts, please visit our website to
order replacement parts. If you experience any further trouble with
your product, please contact our customer service department.
parts.nychbrands.com (Connental US and Canada only)
suppor[email protected]om
704-892-5222 /877-234-6196
Customer service agents are available to take calls weekdays from 9am-5pm EST.
If you call outside of business hours, please leave a voicemail.
To help you quickly and accurately, please have reference item number
EC18006/EC18007 and the specic part name which can be found on
page 4. It is helpful if you can provide the batch lot which is a stamped
number on the end of the box.
If you are having problems with the assembly or installation of this
product, we are happy to assist you with the process, so please give
us a call at 704-892-5222 / 877-234-6169
If for some reason you need to return this product, please allow
us to help resolve your issues rst. If you still decide to return the
product, you will need to initiate the return from the company you
originally purchased from.
GENERAL
INFORMATION
MISSING OR
DAMAGED PARTS?
NEED ASSEMBLY
HELP?
NEED TO RETURN?
IMPORTANT
DETAILED PRODUCT DIMENSIONS &SPECIFICATIONS
(Only availible in the
continental US and
Canada)

3
42 3/4 in
42 1/2 in
46 in
3/4 in
44 in
11 in
46 in
44 in
7 1/4 in
3/4 in
9 1/2 in
Note: Planter Box Depth is 8 ⁄" when oor is installed
DETAILED PRODUCT DIMENSIONS &SPECIFICATIONS
Planter Box Volume: qts (1.6 cubic ft)

4
RECCOMENDED TOOLS
Power Drill with Phillips Bit
SURFACE MOUNTED INSTALLATION OPTIONAL
PRODUCT ASSEMBLY
DIRT
¾" Rebar (2)
Hammer
DECK
¼" Lag Screws
3" Length (4)
Matching Driver Bit
Wood Drill Bit
Power Drill
PATIO
¼" Concrete Screws
2¼" Length (4)
Matching Driver Bit
Concrete Drill Bit
Hammer Drill
Reccomended if installing into
high wind environment
Surface mounting screws
not included
RECCOMENDED TOOLS
Ruler or Measuring Tape
1 2 3 4 5 6 7 8 9 10 11 12
OR

5
SMALL PARTS
LARGE PARTS
Galvinized Steel L
Bracket (2) ⁄" Drill Bit (1)
LAY OUT MATERIALS
A B
H
O
C
G
Top view Top view
P
K
Short Post (2)
1 ¾" x 1 ¾" x 11"
JI
Short Floor Support (3)
⁄" x 1 ½" x 7 ¼"
Spacer (24)
1½" Self-Drilling Stainless
Steel Screw (8)
L
¾" Self-Drilling Stainless
Steel Screw (22)
MN
Corner Post Cap (4)
Left Post (1)
1 ¾" x 1 ¾" x 44"
Long Board (2)
⁄" x 11" x 44"
Right Post (1)
1 ¾" x 1 ¾" x 44"
Short Board (2)
⁄" x 11" x 7 ¼"
Floor Board (1)
⁄" x 7 ¼" x 44"
D FE
Wide Horizontal Slat (4)
⁄" x 3" x 44"
Long Floor Support (2)
⁄" x 1 ½" x 29 ½"
Thin Horizontal Slat (8)
⁄" x 1 ½" x 44"

6
x1
A
ASSEMBLING THE PLANTER SCREEN
Assemble on box or other
smooth surface to prevent
scratching
1
2
x1
D
D
Place board with
channel facing up
A

7
3
4
x4
L
Lx4
8 7 6 5 4 3 2 1
8 7 6 5 4 3 2 1
7 ¼ in
7 ¼ in
Shift part (D) until
spacing is equal on
either side.
D
(18 ½cm)
(18 ½cm)
Ensure that the side
of part (A) and part
(D) are ush

8
x1
D
x1
Ax4
L
Repeat steps 1-4 to create
one additional panel
5

9
x2
K
x4
M
6
7
M
K
Note: Ensure tabs on
posts and notches on
boards align.
x4
Ensure capped end of post
faces down as shown.
Flip Panel

10
x4
M
x2
B
8
9
B
Lift Panel
Ensure that boards are ush
Mx4

11
x1 x1
G H
Top View
10
11
G
H
x4
M
Open channels should
be facing each other
Mx4
Ensure posts are ush

12
12
13
x1
A
A
x4
M
Ensure board is ush
Mx4

13
x4
J
x1
C
14
15
C
J
Align
Note: For best plant growth,
it is recommended to drill (2)
3/4" diameter drainage holes
in part (C) roughly 12" apart.

14
x2
I
x1
E
16
17
E
Alighn tab with
notch on spacer
I

15
18
E
F
Repeat steps 16 and 17, following
the pattern shown below
x7 x4
E F x22 I
x4
x7

16
19
x4
N
20
x2
M
N
x4
M

17
21
DIRT
STEP 22
¾" Rebar (2)
Hammer
DECK
STEP 23
¼" Lag Screws
3" Length (4)
Matching Driver Bit
Wood Drill Bit
Power Drill
PATIO
STEP 23
¼" Concrete Screws
2¼" Length (4)
Matching Driver Bit
Concrete Drill Bit
Hammer Drill
SURFACE MOUNTED INSTALLATION OPTIONAL
Surface mounting screws
not included
Recommended if installing into
high wind environment

18
DIRT INSTALLATION
(Optional)
Recommended if installing into
high wind environment
1722
22.1
22.2

19
PATIO / DECK INSTALLATION
(Optional)
Recommended if installing into
high wind environment
1723
P
O
Re-install
removed screw
23.1
23.2
23.3

20
Repeat steps
for left post
Mx2
Drill and install
mounting screws
according to instructions
on screw packaging
(mounting screws
not included)
23.4
23.5
23.6
