ENDA EPA942 User manual

SET
AC DC ACDC
ALR
LOCK
ENDA EPA942
PROGRAMMABLE AMMETER
0.000
OUT
1/5 EPA942-E-01-190130
SİSEL MÜHENDİSLİK ELEKTRONİK SAN. VE TİC. A.Ş.
Şerifali Mah. Y.Dudullu 34775
ÜMRANİYE/İSTANBUL-TURKEY
Tel : [phone] Pbx. Fax : [phone]
url : www.enda.com.tr
Barbaros Cad. No:18
Read this document carefully before using this device. The guarantee will be expired by
damaging of the device if you don't attend to the directions in the user manual. Also we don't
accept any compensations for personal injury, material damage or capital disadvantages.
ENDA EPA942 PROGRAMMABLE AC/DC AMMETER
Thank you for choosing ENDA EPA942 Programmable AC/DC Ammeter.
96 x 96mm sized.
4 digits display.
Easy to use with front panel keypad.
Can be used with current transformer or shunt.
Programmable scale between 5A and 9999A.
Multi-functional alarm output for Lower and Upper limits (NO).
Multi-functional alarm setpoints with Alarm Output (NO).
Multifunctional alarm output (NO+NC) for upper and lower limits.
Communication feature over isolated RS485, using ModBus RTU protocol.(Optional).
Measuring type can be selected as AC, DC or true RMS.
Key lock feature.
CE marked according to European Norms.
Order Code : EPA942 - - -
1 2 3
1 -
R...........(Out) Relay
2R.........(Out + ALR) Relay
Blank.....No Relay
Output 3 - Isolated ModBus
(Specify at Order).
RSI......Isolated ModBus
2 -
230VAC...230V AC
110VAC...110V AC
24VAC.....24V AC
SM...........9-30V DC / 7-24V AC
Supply Voltage
TECHNICAL SPECIFICATIONS
ENVIRONMENTAL CONDITIONS
Height Max. 2000m
80 Relative humidity for temperatures up to 31% °C, decreasing linearly to 50% at 40°C.
Ambient/stroge temperature
Max. Relative humidity
0 ... +50°C/-25 ... 70°C
Rated pollution degree According to EN 60529 Front panel : IP65 , Rear
panel : IP20
Do not use the device in locations subject to corrosive and flammable gases.
Supply 230V AC +10% -20%, 50/60Hz or 24V AC 10% , 50/60Hz or optional 9-30V DC / 7-24V AC 10% SMPS± ±
Power consumption
2.5mm² screw-terminal connections
Wiring
Scale
Sensitivity
Accuracy
EMC
Safety requirements
EN 61326-1: 2013
EN 61010-1: 2010 (Pollution degree 2, overvoltage category II)
ELECTRICAL CHARACTERISTICS
0A...9999A (Specified by )c.tr.r c.tr.r parameter. For example:scale is 0A...5A for =5.00
0.001A x ( /5 ) ( For example , 0.001A for =5.00 )c.tr.r c.tr.r
Max. 5VA
AC
RMS
DC ± 1%
1%
(full scale) (± 2% For square wave form)
(full scale)
(full scale) (± 2% For square wave form)
Input Impedance 12mΩ
Frequency Range DC , 10Hz - 200Hz (10Hz - 70Hz For square wave form)
Input Range -5A...5A ( Device may be damaged at 10A and above currents )
-60mV...60mV ( Device may be damaged at 50V and above voltages )
AC and RMS
DC -999A...9999A (Specified by parameter. For example:scale is -5A...5A for =5.00) c.tr.r c.tr.r
±
± 1%
40kΩ
&
&
15
12
14
13
&
&
15
12
14
13
OUTPUTS
Alarm output 2 Relays: 250V AC, 10A (for resistive load), NO.
Mechanical 30.000.000 ; Electrical 100.000 operation.
Life expectancy for relay
HOUSING
Housing type Suitable for flush-panel mounting.
Dimensions W96xH96xD50mm
Weight
Enclosure material Self extinguishing plastics.
Approx. 410g (after packing)
While cleaning the device, solvents (thinner, gasoline, acid etc.) or corrosive materials must not be used.
ENDA
TM

SN: XXXXXXXXX
18
212
7910 611 313 414 515
ENDA
INDUSTRIAL ELECTRONICS
EPA942-R-230VAC-RSI2
PROGRAMMABLE AC/DC AMMETER
230V AC
±10% -%20
50/60Hz 7VA
ALR
AC 250V 10A
RESISTIVE LOAD
COM
B A
8 680 40 7 706 1 43
Made in Turkey
+
Max. 5A
AC / DC
Max. 60mV
AC / DC
+
Rs485
ModBus
}
CAT II
SN: XXXXXXXXX
18
212
7910 611 313 414 515
ENDA
INDUSTRIAL ELECTRONICS
EPA942-230VAC-RSI
PROGRAMMABLE AC/DC AMMETER
230V AC
±10% -%20
50/60Hz 7VA
COM
B A
8 680 40 7 706 1 43
Made in Turkey
+
Max. 5A
AC / DC
Max. 60mV
AC / DC
+
Rs485
ModBus
}
CAT II
OUT AC 250V 10A
RESISTIVE LOAD
UP.l1
UP.l1 HYS.U +
UP.l1 HYS.U -
LO.l1
LO.l1 HYS.L +
LO.l1 HYS.L -
Out1
Out1
dly.U
A.out n.c. =
A.out n.o. =
dly.U dly.ldly.l
Input
t
t
t
2/5
A
-A
0
A
0
A
0
A
-A
A
0
A
0
A
-A
0
ac ac.dc
dc
T3T/2
T/2 2T
T3T/2
T/2 2T
T3T/2
T/2 2T
T3T/2
T/2
0
T
3T/2
T/2
2T
T3T/2
T/2 2T
dd
T2T
0.308 A
0.386 A
0.000
A
0.000
A
d
Td
T
A
A
d
T
Ad
T2
2
0.000
1
2
A1
2
A
2
A1
2
Ap
1
2
A
1
Ap
2
A1
2
A12
A1
3
A1
3
A1
7
8
184-253V AC
50/60Hz 7VA
Anahtar
ac Ac.dc
dc (rms)
7
8
104mm
99mm
90.5mm
90.5mm
57mm
Panel
2
50mm
96mm
96mm
SET
AC DC ACDC
ALR
LOCK
ENDA EPA942
PROGRAMMABLE AMMETER
0.000
OUT
USET
USET HSET +
Out2
Out2
ASET n.c.=
ASET n.o. =
Input
t
t
t
1
1
DIMENSIONS
Depth
Panel Cut-out OUTPUT CHARTALARM OUTPUT CHART
1)
2)
Panel thickness should be maximum 10mm.
There must be at least 60mm free space
behind the device, otherwise it would be difficult
to remove it from the panel.
- Push the flush-mounting
clamp in direction 1 as
shown in the figure left.
- Then, pull out the clamp in
direction 2.
For removing mounting clamps :
Flush mounting
clamp
Gasket
NOTE :
SUPPLY:
Fuse
F 100mA
250V AC
Line
Neutral
230V AC
Supply
Fuse should be connected.
Cable size: 1,5mm²
1) Mains supply cords shall meet the requirements of IEC 60227 or IEC 60245.
2) In accordance with the safety regulations, the power supply switch shall bring the identification of
the relevant instrument and it should be easily accessible by the operator.
Equipment is protected throughout by DOUBLE
INSULATION
Holding screw 0.4-0.5Nm.
Line
Neutral
ENDA EPA942 is intended for installation in control panels. Make sure that the device is used
only for intended purpose.The electrical connections must be carried on by a qualified staff and
must be according to the relevant locally applicable regulations. During an installation, all of the
cables that are connected to the device must be free of electrical power. The device must be
protected against inadmissible humidity, vibrations and severe soiling. Make sure that the
operation temperature is not exceeded. The cables should not be close to the power cables or
CONNECTION DIAGRAM
CAUTION :
If 5A and 60mV inputs are connected at the same time, the measurement will be incorrect.
EPA942-E-01-190130

SET
AC DC ACDC
ALR
LOCK
ENDA EPA942
PROGRAMMABLE AMMETER
0.000
OUT
&
ConF Out1 Out2
SET
*
* tYpE
d.pnt
Opnt
Adr5
bAUd
U5ET
H5ET
UPLL
HYSU
dLYU
LOLL
HYSL
Current Conversion Ratio
It can be adjusted between 5.00(/5) and 9999(/5). If this
parameter changes, upper limit value is set to maximum scale
,minimum limit value is set to minimum scale and hysteresis
Measuring Method
It can be adjusted to ac , dc or acdc. LEDs on the top of the
display indicates the adjusted measurement method.
Decimal Indicator
If measured value is lower than 10, it can be shown as (0.000),
(0.00), (0.0) or (0), (For DC measurements (0.00) ).
If measured value between 10 and 100, it can be shown as
(0.00) ,(0.0) or (0), (For DC measurements (0.0) or (0) ).
If measured value between 100 and 1000, it can be shown as
(0.0) or (0), (For DC measurements only (0).
If measured value is higher than 1000, it can be shown as (0) (For
DC measurements only (0) ).
If device includes relay, dPnt type may change according to
relay parameters value.
Samping Time
If 1 ( 1 ) is selected ; sampling time of the measurement is 250ms,
If 2 ( 2 ) is selected, it is 500ms.
If 3 ( 3 ) is selected, it is 750ms.
If 4 ( 4 ) is selected, it is 1 second.
Device Address
It can be adjusted between 1 - 247 .
Baud Rate
It can be adjusted as OFF, 1200, 2400, 4800, 9600,
19200, 38400, 57600 and 115200
OtYp
dLyL
ASET Alarm Output Relay Contact Position
Can be adjusted as n.o or n.c .
If n.o is selected, in case of alarm, Alr relay is activated.
Alarm Upper Limit Value
It can be adjusted between minimum and maximum scale
that is specified with c.tr.r parameter. This parameter
can’t be lower than H5Et value.
PROGRAMMING MODE
Measured Value Measured Value
LOCK LOCK
L0C UL0C
0.00 0.00
LOCKING & UNLOCKING KEYPAD
SET
UPLL LOLL U5ET
0.00
0.00
Measured
Value
+
By pressing to SET key for 3 seconds, quick menu is entered.
QUICK MENU
&&01.01 2015
Year
Day.Month
If these keys are pressed and held together, revision date appears as day,
month and year.
While revision information displayed and if one of the pressed key is
released, measured value is displayed again.
Measured Value
SET
0.00
REVISION NUMBER
(*) c.t.r.r. , tYPE , d.Pnt and 0ptn parameters are available
for only that devices have no relays.
(**) Adr5 and bAUd parameters are available for only that
devices have ModBus.
*
*
*
*
*
*
iIncludes in R extension devices. i
EPA942 PROGRAMMING DIAGRAM
LOCK
Lock / Unlock
Keypad Locks / Unlocks keypad.
3/5
& & &
SET SET
Used for displaying and configuring the selected parameter value.
Programming
Key
Used for increasing the setpoint value and changing parameters.
When held down for a few seconds, configured numeric value increases faster.
When held down for a few seconds, configured numeric value increases faster.
Used for decreasing the setpoint value and changing parameters.
Increment
Key
Decrement
Key
SET
If these keys are pressed and held for 3 seconds, “Programming Mode” is entered or it returns to “Running Mode”.
If and keys are pressed while parameter names are displayed, than it returns to measured value.
Out1
It can be adjusted as n.o. or If is selected, incase
of alarm, out relay is activated.
Output Relay Contact Position
N.c.n.o
Upper Limit Value
It can be adjusted between minimum and maximum scale
that is specified with c.tr.r parameter. This parameter can’t
be lower than ( ) value.l0ll - HY5U - HY5U
Hysteresis Value for Upper Limit
It can be adjusted between 0 and ctrr /5 parameter.
This parameter can’t be higher than ( - -
HY5L). When ctrr changed, HY5U gets the value of
0.1 .
Upll l0ll
Delay Time for Upper Limit Alarm
It can be adjusted between 0 and 900 .
Lower Limit Value
It can be adjusted between lower scale and upper scale that
is specified with c.tr.r parameter. This parameter can’t be
higher than value.UPLL - HY5U - HY5L
Hysteresis Value for Lower Limit
It can be adjusted between 0 and Ctrr /5 . This
parameter can’t be higher than - -
value. When ctrr is changed, HY5U gets the value of
0.1 .
UPLL L0LL HY5U
Delay Time for Lower Limit Alarm
It can be adjusted between 0 and 900 seconds.
Includes in 2R extension devices.
Hysteresis Alarm Value for Upper Limit
Can be adjusted between 0 and 20. This parameter can’t
be higher than U5Et or 20 value. When ctrr changed,
H5Et gets the value of 0.1 .
SET
SETTING UP THE PARAMETERS
tYPE dC ACdC
If key is pressed, the current value of the parameter appears by flashing on the display.
SET
After the setting up the parameters, if set key is pressed again, adjusted parameter name appears on display.
By using “UP” or “DOWN” navigation keys, selected parameter can be adjusted to the desired value.
SET
SET
Powered on device by pressing key dPAr message appears
on display and device reset to default settings.
Measured current value is higher than maximum scale.
Measured current value is lower than minimum scale.
DEFAULT SETTINGS
ERROR MESSAGES
EPA942-E-01-190130

0001d
0002d
0003d
0004d
0005d
0006d
0007d
0009d
0010d
0011d
0012d
0x0001
0x0002
0x0003
0x0004
0x0005
0x0006
0x0007
0x0009
0x000A
0x000B
0x000C
word
word
word
word
word
word
word
word
word
word
The upper limit of the hysteresis value
Delay time for the upper limit alarm
The lower limit of the setpoint
The lower limit of the hysteresis value
Delay time for the lower limit alarm
Measurement method (0=AC, 1=DC, 2=ACDC)
Decimal point. (0=X, 1=X.X, 2=X.XX, 3=X.XXX)
Baudrate (0=Off;1=1200;2=2400; 3=4800; 4=9600; 5=19200
6= 38400; 7= 57600; 8= 115200)
dlyU
L0Ll
HY5L
dLyl
HY5U
ctrr
typE
dpnt
OPTN
aDr5
BAUD
0.100
5.000
0
0.100
0
no
aCdC
0.000
4
1
oFF
Readable/Writable
Readable/Writable
Readable/Writable
Readable/Writable
Readable/Writable
Readable/Writable
Readable/Writable
Readable/Writable
Readable/Writable
Readable/Writable
Readable/Writable
0000d
0001d
0002d
0003d
0004d
0005d
0x0000
0x0001
0x0002
0x0003
0x0004
0x0005
word
word
word
word
word
word
Current change ratio.
Measurement method (0=AC, 1=DC, 2=ACDC)
Decimal point. (0=X.XX,1=X.X,2=X)
Baudrate (0=Off;1=1200;2=2400; 3=4800; 4=9600; 5=19200
6= 38400; 7= 57600; 8= 115200)
ctrr
typE
dpnt
OPTN
aDr5
BAUD
5
aCdC
0.00
4
1
0ff
Readable/Writable
Readable/Writable
Readable/Writable
Readable/Writable
Readable/Writable
Readable/Writable
*HOLDING REGISTER PARAMETER TABLE (NO RELAY MODELS)
Device address for RS485 network connection.
Adjustable between 1-247.
Sampling time of the measurement value. If 1 is selected, it is
250ms. If 2 is selected, it is 500ms. If 3 is selected, it is 750ms.
If 4 is selected, it is 1 second.
Sampling time of the measurement value
Device address for RS485 network connection.
Adjustable between 1-247.
Holding Register
Addresses
Decimal Hex
Data
Type
Data Content Parameter
Name
Read/Write
Permission Status
Value
0000d 0x0000 word
The upper limit of the setpoint UPLL
Readable/Writable
5
HOLDING REGISTERS FOR R EXTENSION DEVICES
ENDA EPA942 DIGITAL AMPERMETER MODBUS PROTOCOL ADDRESS MAP
word
0tyP
0.000
0008d 0x0008 word Readable/Writable
Input Register
Addresses
Decimal Hex
Data
Type Data Content Parameter
Name Read/Write Permission
0000d 0x0000 word Measured current value -- Only Readable
INPUT REGISTERS FOR R EXTENSION DEVICES
Discrete Input
Addresses
Decimal Hex
Data
Type Data Content Parameter
Name
0000d 0x0000 Bit Relay output state (0=OFF; 1=ON)--
DISCRETE INPUTS FOR R EXTENSION DEVICES
Coil Addresses
Decimal Hex
Data
Type Data Content Parameter
Name Read/Write
Permission
0000d 0x0000 Bit Out1 Output Relay Contact Position (0=no; 1=nc)0TYP
COILS FOR R EXTENSION DEVICES
Status
Value
Only Readable
Read/Write Permission
Readable/Writable
Note 1 : 0TyP and A5ET menu parameters can be used as “Holding Register” or “Coil”.
Note 2 : Received "ModBus input register value" is multiplying by 1000 (based on d.pnt) and mA value reached.
For example ;
if modbus value is 2842, (for d.pnt = 2 (0.00)) 28.42x1000 = 28420 mA, ie 28.42A
if modbus value is 2842, (for d.pnt = 3 (0.000)) 2.842x1000 = 2842 mA, ie 2.842A
0001d 0x0001 Bit Alarm Output Relay Contact Position (0=no; 1=nc)A5ET Readable/Writable
no
no
* Coil and Discrete input parameters are not available that devices have no relays.
Current change ratio.
4/5 EPA942-E-01-190130
SİSEL MÜHENDİSLİK ELEKTRONİK SAN. VE TİC. A.Ş.
Şerifali Mah. Y.Dudullu 34775
ÜMRANİYE/İSTANBUL-TURKEY
Tel : [phone] Pbx. Fax : [phone]
url : www.enda.com.tr
Barbaros Cad. No:18 ENDA
TM
Alarm Output Relay Contact Position

0001d
0002d
0003d
0004d
0005d
0006d
0007d
0009d
0010d
0011d
0012d
0x0001
0x0002
0x0003
0x0004
0x0005
0x0006
0x0007
0x0009
0x000A
0x000B
0x000C
word
word
word
word
word
word
word
word
word
word
The upper limit of the hysteresis value
Delay time for the upper limit alarm
The lower limit of the setpoint
The lower limit of the hysteresis value
Delay time for the lower limit alarm
Measurement method (0=AC, 1=DC, 2=ACDC)
Decimal point. (0=X, 1=X.X, 2=X.XX, 3=X.XXX)
Baudrate (0=Off;1=1200;2=2400; 3=4800; 4=9600; 5=19200
6= 38400; 7= 57600; 8= 115200)
dlyU
L0Ll
HY5L
dLyl
HY5U
ctrr
typE
dpnt
OPTN
aDr5
BAUD
0.100
5.000
0
0.100
0
no
aCdC
0.000
4
1
oFF
Readable/Writable
Readable/Writable
Readable/Writable
Readable/Writable
Readable/Writable
Readable/Writable
Readable/Writable
Readable/Writable
Readable/Writable
Readable/Writable
Readable/Writable
Current change ratio.
Device address for RS485 network connection.
Adjustable between 1-247.
Measurement period. If 1 is selected, it is
250ms. If 2 is selected, it is 500ms. If 3 is selected, it is 750ms.
If 4 is selected, it is 1 second.
Holding Register
Addresses
Decimal Hex
Data
Type
Data Content Parameter
Name
Read/Write
Permission Status
Value
0000d 0x0000 word
The upper limit of the setpoint UPLL
Readable/Writable
5
HOLDING REGISTERS FOR 2R EXTENSION DEVICES
ENDA EPA942 DIGITAL AMPERMETER MODBUS PROTOCOL ADDRESS MAP
word
0tyP
0.000
0008d 0x0008 word
Readable/Writable
Input Register
Addresses
Decimal Hex
Data
Type Data Content Parameter
Name Read/Write Permission
0000d 0x0000 word Measured current value -- Only Readable
INPUT REGISTERS FOR 2R EXTENSION DEVICES
Discrete Input
Addresses
Decimal Hex
Data
Type Data Content Parameter
Name
0000d 0x0000 Bit Relay output state (0=OFF; 1=ON)--
DISCRETE INPUTS FOR 2R EXTENSION DEVICES
Coil Addresses
Decimal Hex
Data
Type Data Content Parameter
Name Read/Write
Permission
0000d 0x0000 Bit Out1 Output Relay Contact Position (0=no; 1=nc)0TYP
COILS FOR 2R EXTENSION DEVICES
Status
Value
Only Readable
Read/Write Permission
Readable/Writable
Note 1 : 0TyP and A5ET menu parameters can be used as “Holding Register” or “Coil”.
Note 2 : Received "ModBus input register value" is multiplying by 1000 (based on d.pnt) and mA value reached.
For example ;
if modbus value is 2842, (for d.pnt = 2 (0.00)) 28.42x1000 = 28420 mA, ie 28.42A
if modbus value is 2842, (for d.pnt = 3 (0.000)) 2.842x1000 = 2842 mA, ie 2.842A
0001d 0x0001 Bit Alarm Output Relay Contact Position (0=no; 1=nc)A5ET Readable/Writable
no
no
5/5 EPA942-E-01-190130
SİSEL MÜHENDİSLİK ELEKTRONİK SAN. VE TİC. A.Ş.
Şerifali Mah. Y.Dudullu 34775
ÜMRANİYE/İSTANBUL-TURKEY
Tel : [phone] Pbx. Fax : [phone]
url : www.enda.com.tr
Barbaros Cad. No:18 ENDA
TM
Alarm Output (OUT) Relay Contact Position
Alarm Output (OUT) Relay Contact Position A5ET Readable/Writable no
Alarm Upper Limit Value U5Et Readable/Writable 5.000
0.100
Hysteresis Alarm Value for Upper Limit H5Et Readable/Writable
0013d 0x000D word
0014d 0x000E word
0015d 0x000F word
