ENDA EPV141 User manual

OUTPUTS
Alarm output Relay: 250V AC, 8A (for resistive load), NO+NC
Mechanical 30.000.000 ; Electrical 100.000 operation.
Life expectancy for relay
0 ... +50°C/-25 ... 70°C
HOUSING
Housing type Suitable for flush-panel mounting. (According to DIN 43 700)
Dimensions W72xH72xD97mm
Weight
Enclosure material Self extinguishing plastics.
ENDA EPV141 AC/DC VOLTMETER
While cleaning the device, solvents (thinner, benzine, acid etc.) or corrosive materials must not be used.
EPV141 Approx. 350g (after packing)
EPV141-24 Approx. 350g (after packing)
Supply Voltage Order Code
230V AC +%10 -%20
24V AC %10±
Output
Relay
Relay
-
-
EPV141-R
EPV141
EPV141-24-R
EPV141-24
SÝSEL MÜHENDÝSLÝK ELEKTRONÝK SAN. VE TÝC. A.Þ.
Yukarý Dudullu 34775 - ÜMRANÝYE/ÝSTANBUL/TÜRKÝYE
Tel : [phone] Pbx. Fax : [phone]
url : www.enda.com.tr
Barbaros Cad. Kutup Sok. No:20
* 77 x 34mm sized.
* 3 digits display.
*
* Easy to use by front panel keypad.
* Multifunctional alarm output (NO+NC) for upper and lower
limits.
* Having CE mark according to Europan Norms.
Values between -100V and 100 V can be indicated with one
decimal number.
ýSupply 230V AC +%10 -%20, 50/60Hz or 24V AC %10 , 50/60Hz
Power consumption
2.5mm² screw-terminal connections
Wiring
Scale
Sensitivity
ELECTRICAL CHARACTERISTICS
0V...500V
0,1V (for input values between -100V and 100V)
Max. 5VA
AC and RMS
DC -500V...500V
V
SET
ENDA
ACDC
DC
ACOUT
EPV 141
EPV141-E-01
1/3
±
Accuracy
EMC
Safety requirements
EN 61326-1: 1997, A1: 1998, A2: 2001 (Performance criterion B for the EMC standard.)
EN 61010-1: 2001 (Pollution degree 2, overvoltage category II)
%1
AC
RMS
DC ±
%1
%1
(Full scale) (For square wave form %2)±
(Full scale)
Input Impedance 870kÙ
Frequency Range
Input Range -500V...500V , max. 800Vpeak , (Device damages 1250V peak and more voltage.)
± (Full scale) (For square wave form %2)
±
DC , 10Hz - 200Hz (For square wave form 10Hz-70Hz)
Thank you for choosing ENDA EPV141 AC/DC voltmeter.
Read this document carefully before using this device. The guarantee will be expired by
damaging of the device if you don't attend to the directions in the user manual. Also we don't
accept any compensations for personal injury, material damage or capital disadvantages.
Technical Specifications
.Do not use the device in locations subject to corrosive and flammable gases
ENVIRONMENTAL CONDITIONS
Ambient/stroge temperature
Max. Relative humidity
Rated pollution degree
Height
%80 up to 31°C decreasing linearly %50 at 40°C.
According to EN 60529 Front panel : IP60 , Rare panel : Ip20
Max. 2000m
1V (for input values that lower than -100V and higher than 100V )

UP.l1
UP.l1 HYS.U+
UP.l1 HYS.U-
LO.l1
LO.l1 HYS.U+
LO.l1 HYS.U-
Out
Out
dly.U
A.out n.c.=
A.out n.o.=
dly.U dly.ldly.l
Input
t
t
t
Dimensions
Note :
34mm
70mm 8mm
85mm
71mm
29mm
Depth
Rubber
Panel
2
1
2/3 EPV141-E-01
V
SET
ENDA
ACDC
DC
ACOUT
EPV 141
SN: XXXXXXXXX
1 2 3 4 5 6 78910 11 12
EPV141-R VOLTMETERAC/DC
OUTPUT
250V AC 8A
RESISTIVE LOAD
ENDA INDUSTRIAL ELECTRONICS
230V AC +10% -20%
50/60Hz 5VA
CAT II
+
max.
800V peak
AC / DC
SN: XXXXXXXXX
12345678910 11 12
EPV141-24-R VOLTMETERAC/DC
OUTPUT
250V AC 8A
RESISTIVE LOAD
ENDA INDUSTRIAL ELECTRONICS
+
CAT II
max.
800V peak
AC / DC
SN: XXXXXXXXX
1234567 8 9 10 11 12
EPV141 VOLTMETERAC/DC
ENDA INDUSTRIAL ELECTRONICS
230V AC +10% -20%
50/60Hz 5VA +
max.
800V peak
AC / DC
CAT II
SN: XXXXXXXXX
1 2 3 4 5 6 7 8 9 10 11 12
EPV141-24 VOLTMETERAC/DC
ENDA INDUSTRIAL ELECTRONICS
+
max.
800V peak
AC / DC
CAT II
SN: XXXXXXXXX
12345678910 11 12
EPV141-R VOLTMETERAC/DC
OUTPUT
250V AC 8A
RESISTIVE LOAD
ENDA INDUSTRIAL ELECTRONICS
230V AC +10% -20%
50/60Hz 5VA
CAT II
+
max.
800V peak
AC / DC
24V AC 10%
50/60Hz 5VA
24V AC 10%
50/60Hz 5VA
A
-A
0
A
0
A
0
A
-A
A
0
A
0
A
-A
0
T3T/2
T/2 2T
T3T/2
T/2 2T
T3T/2
T/2 2T
T3T/2
T/2
0
T
3T/2
T/2
2T
T3T/2
T/2 2T
dd
T2T
0.308 A
0.386 A
0.000
A
0.000
A
d
T
d
T
A
A
d
T
Ad
T2
2
0.000
1
2
A1
2
A
2
A1
2
Ap
1
2
A
1
Ap
2
A1
2
A1
2
A1
3
A1
3
A1
ac Ac.dc
dc (rms)
Packing
Flush mounting
clamp
For removing mounting clamps:
Pull out the clamp in direction 2
- Push out the flush-mounting clamp
In direction 1 shown in figure below.
-
1) Panel thickness should be maximum
7mm.
2) If there is no 60mm free space at the back
side of the device, it would be difficult to
remove it from the panel.
Panel cut-out
Connection Diagram
4
5
SUPPLY:
NOTE :
184-253V AC
50/60Hz 3VA
Line
Neutral
Not:
Cable Size: 1,5mm²;
230V AC
Supply
Switch
Fuse
F 100mA
250V AC
Fuse should be connected.
1) Mains supply cords shall meet the requirements of
IEC 60227 or IEC 60245.
2) In accordance with the safety regulations, the power
supply switch shall bring the identification of the relevant
instrument and it should be easily accessible by the operator.
10
12
Faz
Nötr
Equipment is protected throughout by
DOUBLE INSULATION
Holding screw 0.4-0.5Nm.
ENDA EPV141
is intended for installation in control panels.Make sure
that the device is used only for intended purpose.The electrical
connections must be carried on by a qualified staff
and must be according to the relevant locally applicable regulations.
During an installation, all of the cables that are connected to the device
must be free of energy. The device must be protected against
inadmissible humidity, vibrations, severe soiling and make sure that the
operation temperature is not exceeded. The cables should not be close
to the power cables or components.

While holding key , by using and keys delay time for upper limit alarm can be adjusted between 0 and
90 0 seconds.
SET
Used for adjusting the value of the setpoint in the run mode and for adjusting the selected
parameter in the programming mode.
Programming
key
SET
Used for increasing the setpoint value, as well as the parameter when in programming.
When held down for a few seconds, the change rate accelerates.
Used for decreasing the setpoint value, as well as the parameter when in programming.
When held down for a few seconds, the change rate accelerates.
Increment
key
Decrement
key
EPV141 PROGRAMMING DIAGRAM
V
SET
ENDA
ACDC
DC
ACOUT
EPV 141
EPV141-E-01
3/3
If both & keys are pressed and held for 5 seconds,programming mode is entered or to running mode is returned.
Üst limit
histerisiz deðeri
Üst limit alarmý için
gecikme süresi
Üst limit
deðeri
Alarm
çýkýþ konumu
Alt limit
deðeri
Alt limit
histerisiz deðeri
Alt limit alarmý için
gecikme süresi
PROGRAMMING MODE
Ölçüm
metodu
If this key is pressed
hysteresis value
appears for
upper limit
If this key is pressed
delay time appears
for upper limit.
If this key is pressed
upper limit value
appears.
SET
SET
SET
SET
SET
SET
If this key is pressed
alarm output position
appears.
SET
If this key is pressed
lower limit value
appears.
If this key is pressed
hysteresis value
appears for
lower limit
If this key is pressed
alarm output position
appears.
If this key is pressed
measuring type
position appears.
SET
If both keys are
pressed upper limit
value can be adjusted.
Measuring Value
SET
SET
&
&
If this key is pressed
upper limit value
appears.
SET
SET
If this key is pressed
upper limit value
appears.
If both keys are
pressed lower limit
value can be adjusted.
ADJUSTING ALARM VALUE
Or
While holding key , by using and keys upper limit value
can be adjusted between -500V and 500V. This parameter can’t be lower than
( ) value.lo.l1 + HYS.l + HYS.U
SET
While holding key , by using and keys lower limit value
can be adjusted between -500V and 500V. This parameter can’t be upper than
( ) value.Up.l1 - HYS.l - HYS.U
(*) There is only EPV141 , EPV141-24 ) that have no relay.
.
type parameter at the models(
If you wait 25 seconds before holding down the keys or power off and power up again, you skip to operation mode
Means, measured voltage value is higher than up scale. Means, measured voltage value is lower than down scale.
ERROR MESSAGES
*
SET
While holding key , by using and keys upper limit value can be adjusted between -500V and 500V.
This parameter can’t be lower than ( ) value.lo.l1 + HYS.l + HYS.U
While holding key , by using and keys hysteresis value for upper limit can be adjusted between 0.0V and
This parameter can’t be higher than20.0V. ( - - ) value.Up.l1 Lo.l1 Hys.l
SET
While holding key , by using and keys lower limit value can be adjusted between -500V and 500V.
This parameter can’t be upper than ( ) value.UP.l1 - HYS.U - HYS.L
SET
While holding key , by using and keys hysteresis value for lower limit can be adjusted between 0.0V and
This parameter can’t be higher than20.0V. ( - - ) value.Up.l1 Lo.l1 Hys.U
SET
While holding key , by using and keys delay time for lower limit alarm can be adjusted between 0 and
90 0 seconds.
SET
While holding key , by using and keys alarm output position can be adjusted
at alarm condition.
n.o. N.c.. n.o. is adjusted ,
output relay is powered
or If
SET
While holding key , by using and keys measuring type can be adjusted ac dc acdc..Three leds
shows measuring type at the top of the display.
, or
SET
